Volt VAL-2006-4-BBZ User manual

VOLT®Landscape Lighting
VOLT®Lucid Brass Spotlight
VAL-2006-4-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2021, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

VOLT®Lucid Brass Spotlight
VAL-2006-4-BBZ
INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 2 -
Important: Please Read Before Installation
Important Safety Instructions
!
!
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing
this luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M)
or more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL Listed wire connectors that
is suitable for outdoor use.
5. Position the low voltage wire and UL listed wire connector so that
it is located within 6 inches (15.2 cm) from a building structure, a
luminaire or tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
Lighted lamp is HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Lamp gets HOT quickly!
2. Do not touch the hot lens, guard or enclosure.
3. Keep lamp away from materials that may burn.
4. Do not touch lamp at any time. Use a soft cloth. Oil from skin may
damage lamp.
5. Do not operate the luminaire tting with a missing or damaged shield.
SAVE THESE INSTRUCTIONS

Package Contents
Parts Required (Sold Separately)
A. (1) MR16 Bulb
[email protected] • 813.978.3700
- 3 -
Product Dimensions
Remove Glare Guard
1
A. (1) Fixture
2”
2.58”
2.18”
5”
Loosen the set screw and
remove it from the glare
guard. Rotate the glare guard
counter clockwise and remove
it from the xture.
ROTATE
Fixture
Set Screw
Glare Guard

www.voltlighting.com
INSTALLATION INSTRUCTIONS
- 4 -
Install Glare Guard
3
Install MR16 Bulb
2
VOLT®Lucid Brass Spotlight
VAL-2006-4-BBZ
Use a custom or MR16 bulb (sold
separately), with the correct
wattage and type as marked on
the luminaire label. Push the
bulb onto the socket properly.
CAUTION: Do not exceed
maximum wattage marked on
luminaire label.
NOTE: DO NOT touch lamp with
bare hands. Use soft cloth to
handle lamp.
Fixture
Custom
MR16 Bulb
Standard
MR16 Bulb
(optional)
Glare Guard
Thread the glare guard
clockwise onto the xture.
Tighten the set screw back
onto the glare.
Fixture
Set Screw
ROTATE

[e-mail] • 813.978.3700
- 5 -
4
5
Install Stake
Determine the desired location
for mounting the stake mount.
Hammer the stake into the
ground until ange of stake
is ush to grade. To avoid
damage to the stake, place a
board on top of the stake while
hammering.
Note: If the ground is hard and
the stake is difcult to install,
make a crosscut in the ground
using a at shovel.
Board
Ground
Soil
Stake
Install Fixture to Stake
Pass the xture wire through
the center hole of the stake.
Thread the xture body onto
the stake and hand tighten until
snug.
Fixture
Ground
Soil
Stake
Cable

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 6 -
Wire Connection
6
7
VOLT®Lucid Brass Spotlight
VAL-2006-4-BBZ
Strip both leads from the xture pigtail. Using two UL listed wire
connectors (sold separately), connect the leads from the xture to the
main supply cable leads.
Pigtail
Supply Cable
from Fixture
Wire Connectors
Main Supply Cable
Adjust Fixture
Loosen the knuckle and adjust
the xture to the desired
orientation. Always tighten
the knuckle after adjustment.
Fixture
Knuckle
ROTATE

[email protected] • 813.978.3700
- 7 -
Install/Replace MR16 Bulb
Reverse Step 1 - Step 3 to expose the MR16 bulb and replace it with correct
wattage and type marked on luminaire label. Reinstall the glare guard.
IMPORTANT: Bulbs must be protected from moisture and dust at all times.
Always reinstall glare guard when removed.

IS-VAL-2006-4-BBZ-ver1.pdf
Specications and product details subject to change without notice.
© Copyright 2021, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
