Volt LPL-PLKIT User manual

Installation Instructions
WARNING
LIT FIXTURE IS HOT!
This xture is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situation.
1. Make sure that the power is turned OFF before installing or servicing this xture.
2. This xture is perfect for placing in water fountains, water falls, ponds, pools, etc.
3. This xture is intended to be used only with a power supply (transformer) rated
maximum of 300 watts (25 AMPS) at 12 volts ~ 22 volts.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in order to
connect to the main low voltage cable.
5. Wiring connections must be made with UL listed wire connectors that is suitable for
outdoor use.
6. Position the wire connector so that it is located within 6 inches (15.2 cm) from a
building structure, a luminaire, or tting.
3W 7” China Hat with Finial, 12V Outdoor Brass Path Light, Includes
Stake & LED bulb
LPL-PLKIT
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

FIGURE A
FIGURE B
Ground Stake
Stem
GU4 Bulb
Socket
Hat
REFER TO FIGURE A WITH
INSTRUCTIONS 1-3:
STEP 1: Remove the nial, waterproof
washer, hat and shield from the stem.
STEP 2: Insert the GU4 Bulb into the
socket.
STEP 3: Install the shield, hat,
waterproof washer and nial back onto
the stem.
STEP 4: Make a wire connection with the
run line by splitting the two ends of each
wire. Then connect both left side ends
of each wire and both right side ends.
These do not have polarity, so just don’t
connect both ends of the same wire
together. See Figure B for details.
STEP 5: Turn on the transformer to
ensure xture is functioning properly.
STEP 6: Enjoy your new outdoor lighting.
Installation Instructions
Right Side Right Side
Left Side Left Side Run Wire
Fixture Wire
Wire Connector
Wire Connector
Waterproof
Washer
Finial
Shield
