Volt 3602 Series User manual

VOLT®Line Voltage Landscape Lighting
VOLT®Estate Size Path & Area Lights
3602 Series
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2018, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

VOLT®Estate Size Path & Area Lights
3602 Series
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
To avoid the risk of re, explosion, or electric shock, this product should
be installed, inspected, and maintained by a qualied electrician only, in
accordance with all applicable electrical codes.
To avoid electric shock:
1. Be certain electrical power is OFF before and during installation and
maintenance.
2. Luminaire must be connected to a wiring system with an equipment-
grounding conductor.
To avoid explosion:
1. Make sure the supply voltage is the same as the rated luminaire
voltage.
2. Do not install where the marked operating temperatures exceed the
ignition temperature of the hazardous atmosphere.
3. Do not operate in ambient temperatures above those indicated on the
luminaire.
For supply connections use wire rated for at least 90°C (194°F)
Warning: these luminaire should ONLY be installed by a qualied electrician.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn o/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
!
!
www.voltlighting.com
- 2 -

Package Contents
Product Dimensions
A. (1) Fixture Body
[email protected] • 813.978.3700
- 3 -
10.25”
38.5”
6”
3”
6”
3”
10.25”
6”
3”
9”
38.5” 36”

www.voltlighting.com
INSTALLATION INSTRUCTIONS
- 4 -
VOLT®Estate Size Path & Area Lights
3602 Series
Remove Stem Top
1
Loosen the stem top and remove
it from the top end of the stem.
Stem
Stem Top
Install Bulb
2
Insert the bulb with the correct
wattage and type marked on the
xture label and push rmly into
place.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
Socket
Bulb

[email protected] • 813.978.3700
- 5 -
Thread the stem top onto the
stem and hand tighten until
snug.
Install Stem Top
3
Stem Top
Stem
Install Stake and Conduit
4
Dig a hole in the ground for the conduit runs and the stake. Install the
conduit. Slide the stabilizer grid onto the stake and secure with the
screws. Place the stake over the conduit runs then backll against the
mounting stake.
Stake
Stabilizer
Grid
Conduit
Ground Level

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 6 -
Remove the cap from the stake
by loosening the set screws.
Remove Cap from Stake
5
Set Screw
Cap
Stake
VOLT®Estate Size Path & Area Lights
3602 Series
Thread the cap onto the Junction
Box.
Install Cap to Junction Box
6
Cap
Junction Box
* Junction Box is not
provided by VOLT®

[email protected] • 813.978.3700
- 7 -
Install Fixture to Junction Box
7
Remove the cover from the junction
box by loosening the screws. Place
the xture supply wires into the
junction box.
Thread the junction box onto the
bottom of the xture and hand
tighten until snug.
Fixture
Junction Box
Supply Wires
Screw
Cover
Install Junction Box to Stake
8
Pass the main supply cable into
the junction box. Place the cap
back onto the stake and secure
with the previously removed
screws. Tighten until snug with a
screwdriver.
Main Supply Cable
Junction Box
Cap
Screw
Stake Conduit
* Junction Box is not
provided by VOLT®
* Junction Box is not
provided by VOLT®

INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 8 -
VOLT®Estate Size Path & Area Lights
3602 Series
Wire Connection
9
Strip the leads from the xture supply wire and main supply cable. Using
wire connectors (sold separately), connect the leads from the xture
supply wire to the main supply cable leads. Then, connect the ground
wires to the ground screw in the junction box.
After wiring, carefully tuck the slack wires into the junction box. Attach
the cover back onto the junction box and secure with the previously
removed screws.
Main Supply Cable
Wire Connectors
Junction Box
Screw
Cover
Fixture Supply Wires
Ground Screw
* Junction Box is not
provided by VOLT®

[email protected] • 813.978.3700
- 9 -
Install Hat
10
Place the hat onto the stem top and secure it with the nial, or thread
the hat onto the stem top directly. Hand tighten until snug.
Stem Top
Finial
Hat
Stem Top
Finial
Hat
OPTIONAL A OPTIONAL B
StemTop
Hat
OPTIONAL C
Install/Replace Bulb
Disconnect the power, before replacing the bulb. Then remove the nial,
hat and stem top to expose the bulb and replace it with the correct
wattage and type marked on the xture label. Then, reinstall the stem
top, hat and nial.
IMPORTANT: Bulbs must be protected from moisture and dust at all
times. Always reinstall the stem top and hat when removed.

www.voltlighting.com
INSTALLATION INSTRUCTIONS
- 10 -
VOLT®Estate Size Path & Area Lights
3602 Series

[email protected] • 813.978.3700
- 11 -

is-3602series-ver8.pdf
Specications and product details subject to change without notice.
© Copyright 2018, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 12 -
