VSYSTO S2F User manual

- 1 -
S Dash Cam
2F
User Manual

- 2 -
● This product is an auxiliary (vehicle driving recorder) product for safe driving. Any loss
caused by malfunction, information loss or using this product is irrelevant to our company.
● This product is an auxiliary device for recording external images of vehicles. Due to the
different driving environment and vehicle environment, some functions will not support. The
unscheduled firmware upgrade in order to improve the product will change the performance
of the product, and sometimes the camera will cannot record due to the environment, so the
driving images recorded in this product is for reference only. The state of TF card will also
lead to camera cannot record.
● Although this product can record and save the videos of accidents, it does not guarantee
that all the accident videos can be recorded. Slight collision accidents can't start the
collision sensor, so the video may not be recorded in the specialized folder.
● Be sure to disconnect the power supply when inserting or pulling out TF memory card.
● For the stable use of the product, it is recommended to format the TF card at least once a
week.
● Generally TF card has a service life. Long-term use of TF card may cause the data to be
unable to save. In this case, it is recommended to buy a new TF card to use. Our company will
not be liable for data destruction caused by the long-term use of TF card.
● Please do not install or operate this product while driving.
● This device may disturb the function of improperly protected medical equipment. If you
have any question or are uncertain whether the medical equipment can shield external RF
energy, please consult your doctor or medical equipment manufacturer.
● Please do not make this product subject to strong impact or vibration, so as not to damage
the product and cause malfunction or unavailable.
● Please do not use it in an environment with excessive dust density, so as to prevent
cameras and other parts from being contaminated with dust, which will affect the video
effect.
● Please stop using this product before cleaning and maintenance.
● Please do not use chemical solvents or detergents to clean this product.
● Please do not disassemble or modify this product without authorization.
● The ambient temperature range for the normal use of this device's function is -20 to 65
degrees Celsius. Exceeding this temperature range may lead to product failure, fire or
explosion.
●Please use it within the scope permitted by law.
Notes for Using the Dash Cam

- 3 -
After opening the package, please confirm whether the driving recorder is in good condition and the accessories are complete.
1)Main Unit x1 2）Camera x2
3)Power Cable x1 4）USB Test Cable x1
5)Tie x8 6）Bracket x1
7)TF Card（Optional） x1 8）GPS Module x1
9)Wire Controller x1
The Packing List
Product Appearance Diagram
Product Connection Diagram
▶ With the advancement of technology, the product structure and parameters will continue to be improved. The pictures and texts
in this book are for reference only. If there are pictures or descriptions that do not match the actual product, please refer to the
actual display of the product.
TF Card Slot
Display Screen Bracket Hole
Speaker
Camera Interface
Power Cable Interface
wire controller and
GPS module interface
MIC Hole
OK
Camera Interface

- 4 -
Images Information and Menu Description
1. Press to select the video to playback
1.Character description on the display in video mode
R/REC-211019-120514R.TS
1
1
RearCam
F/REC-211019-175340R.TS
1
1
2021/10/19 17:53:25 [00:00:26]
“F/” indicates front camera video playback “R/” indicates rear camera video playback
2021/09/20 11:22:58 00:02:56
P
Video Time
WiFi
Date & Time Information
Recording
Countdown
2021/10/19 17:53:25 [00:00:26]
Support Parking Monitoring
60 5 HPA53 M
Altitude Atmospheric Pressure
1. After selecting, r ess[OK]to enter Video
Mode.
2. The icon becomes larger to indicate that
the function is selected.
p
When the parking is detected,
the progress bar will shut down
after running the altitude, and
the time is 5 minutes.
1. After selecting, press[OK]to enter
Playback Mode.
2. The icon becomes larger to indicate that
the function is selected.
Long press for 3 seconds in
the Playback Mode to switch to
the video files list of front and
rear camera
1. Front camera video files name
identification: REC_The year,
month and time of current video
F.MOV
2. Rear camera video files name
identification: REC_The year,
month and time of current video
R.MOV
1. After selecting, press[OK]to enter
Setting Mode.
2. The icon becomes larger to indicate that
the function is selected.
1.Video clip time 1/2/3/5 minutes can be selected
2.Sound record On/Off
3.MIC sensitivity Set the sound level of MIC
4.Auto screen off Set the display screen backlight to be off,or off after 1 min/3min
5.Parking monitoring On/Off
6.Parking monitoring sensitivity Set the vibration sensitivity when parking
7.Recording Time After Flameout Set recording time after flameout(15 minutes / 30 minutes / 1 hour / 2 hours / 3 hours )
8.Date format YYYY MM DD/MM DD YYYY/DD MM YYYY
9.Clock setting Day&Time
10.Time zone selection Time zone selection around the world
11.Speed watermark Whether it is necessary to turn on the driving speed display when playing videos on the computer.
12.GPS Status Display the current number of satellites,longitude,latitude and other information
13.Unit system Set the speed unit selection displayed when driving
14.Rear camera mirror Whether mirror selection is required for the rear camera display
15.Protection Sensitivity G-Sensor adjustment
16.Button sound On/Off
17.Voice guide On/Off
18.Format SD card Delete all videos from the memory card
19.WIFI Mode WIFI On/Off
20.System reset Restore to the factory default settings
21.FW version Information about the current software version of the machine
1. After selecting, press[OK]to enter
Language Choosing Mode.
2. The icon becomes larger to indicate
that the function is selected.
1.
language
2. The number of language choices depends on the actual model!
Language identification — Corresponding to the selected

- 5 -
Up Button：
①In the video recording interface,short press the up button once toswitch tothe full screen mode
of the rear camera,which can beused asa backup camera.Then short press the upbutton once to
return.
②In the video recording interface, long press the up button to turn off the recorder. After the
motorcycle is powered off, the recorder will usually turn off after 5 minutes without vibration. If
you don't want to wait 5 minutes, you can long press the up button to quickly shut down.
In the video recording interface, long press the OK button once to switch to the setting interface.Use the up/down buttons to
select the player icon. After selecting, short press the OK button once to enter the playback mode.Then select the video you want
to play, and short press the OK button once to start the video.The default is the front camera video, long press the up button to
switch to the rear camera video file
Down Button：
①In the video recording interface and in the split screen mode of the front and rear cameras,short
press the down button to switch to a single full front camera screen.Short press the down button again
to switch toa single full rear camera screen. Then short press the down button again toreturn tothe
front and rear camera split screens.
.
Connect to
the main unit
◆
LED Red Light：
- Red light slow flashes - Camera is recording normally，the video file name is REC-XXXXXXX.
- Red light constant lights - Camera pauses recording.
- Red light fast flashes - Camera triggered the gravity sensor to record emergency vide, the video file
name is GSR-XXXXXXX.
※If there are more than 10 videos named GSR-XXXXXXX in the memory card, the system will
automatically delete the oldest video.
◆ Recorder Video Playback Operation
W3 Wire Controller Operating Instructions
Function operation
OK Button：
①In the video recording interface, short press the OK button once to enter the emergency video
mode, and the front and rear cameras will capture a photo at the same time.The emergency
recording locked video filename is: KEY-XXXXXX.
※If there are more than 10 videos named KEY-XXXXXXX in the memory c ard, the system will
automatically delete the oldest video.
②In the video recording interface, long press the OK button to enter the setting interface.You can use the
up/down button to operate the settings required by the main unit. When the required functions are set long
press the OK button to return to the video recording interface.
※The software defaults to split screen images for front and rear cameras. When you select which display mode, the
recorder will remember it. Next time you turn on the recorder,it will be the previous display mode you selected.
②In the video recording interface, long press the down button to enter the auxiliary mode, you can view
Speed, Battery Power Display, Location, Short-term Memory, Date &Time.

- 6 -
① Long press the down button of the wire controller
to enter the auxiliary display mode, and the battery
power is displayed on the first interface.
④ Short press the down button again to
enter GPS information interface.
⑤ Short press the down button again to enter the
year, month, and day interface
③ Short press the down button again to enter short
term memory interface.
ODO 92Km
0:09
92km/h
12.31V
Sleeping: 00.0V
Parking: 00.0V
Short-term Memory
Battery Power Display
15:15:50
2021-06-26
Tuesday
Date &Time
Auxiliary Display Mode
24m
Location
599 HPA
55 41' 16"
N
55 41' 16"
E
② Short press the down button again to
enter driving speed interface.
km/h
115
TRIP:0 Km
Speed
Current Voltage
The voltage after flameout for
one hour.
The voltage after flameout for
one minute.
Current speed
while driving
Time of short time driving
Average speed of short-term
Altitude
GPS Longitude
GPS Latitude
Atmospheric
pressure
Current Time
Year Month Day
Current day

- 7 -
Scan the corresponding QR code above and download the App.
Conditions of use and product association:
1.Smart terminal with Android 5.0 or higher or Apple terminal.
2.Purchase a recorder terminal device that uses VSYSTO design scheme, and connect the mobile
phone WiFi to the camera correctly
DVR WiFi Default Name: MotoDV_XXX
Default password: 1234567890
※To ensure the normal use of APP functions, please update the APP to the latest version in time.
WiFi APP is a mobile phone control software used with VSYSTO DVR device. This software is connected to the DVR device
via Wi-Fi, it can directly preview and playback the video on the mobile phone, easily realize that viewing the camera
documents on the screen of mobile phone, setting or other operations. Subverting the control method of traditional cameras,
bring you a new experience.
Mobile Phone APP Installation and Operation
App download for Android user App download for Apple user

- 8 -
Installation Guide
♦Shock Absorption Camera Bracket
Cameras♦
shock absorption ring
① Put the rubber shock absorption ring on the camera body. ② Install the camera body on the bracket, and tighten
the screws to fix it after adjusting the proper angle.
Extension cable
During installation, it is recommended to install the extension cable first, and then connect the main unit and camera separately (so that the
installation is easier). If the distance between the main unit and the camera is less than 0.5 meters, it is recommended not to use the camera
extension cable (please keep the camera extension cable for future needs).
The concave and convex bayonet of
the joint shall be matched correctly
Connect to the main unit
Bracket Double side tape
Screw
Double
side tape
shock absorption ring
Waterproof
Camera
Main Unit
Waterproof wire controller
Power Cable
Waterproof GPS module
It is suggested to install
it on the handlebar
Waterproof camera Main
Unit
OK
It needs to be exposed in the
place where there is no
obstruction. And the distance
from GPS to camera and main
unit shall be about 30CM to
avoid signal interference.
Screw ring (After the cables are connected,tighten
the screw ring. Do not twist the wire position.)
Screw (Loosen the screw to
adjust the height of the camera)
Viewing the screen or smart phone screen via
WiFi and adjust the bracket around to find a
suitable horizontal view angle before fixed by
double-sided foam tape
Install the bracket downwards, tear off the double- sided
tape and paste it in a suitable position
（Adjust the position of the bracket to a satisfactory angle,
and finally stabilize the cameras）
The bracket is installed upwards, after
tearing off
the double-sided adhesive, it is
recommended to screw on the lens to
stabilize the cameras
