VSYSTO V7T User manual

V7T Truck Dash Cam
User Manual
Thank you very much for purchasing the VSYSTO V7T dash cam.
Please read this manual carefully before use.
- 1 -

ATTENTION
Prohibit Obey
Please use this product under the premise of obeying traffic rules.
Do not install the device in a position that blocks the view or obstructs driving.
Do not disassemble or modify this product by yourself.
Do not use accessories not included.
Do not allow water to enter this product.
If the product makes an abnormal noise or smell,please stop using it immediately.
The waterproof rating of the camera is IP67, and the host is not waterproof.
When disposing of this product, please follow the classification principle and
do not discard it at will.
Do not store this product in a high temperature and humid environment.
WARNING
- 2 -
Safety Instructions
In order to use this product safely, please confirm that you fully understand the
following.
WARNING: This section indicates that mishandling can have serious
consequences.
Note: This section indicates that improper handling may cause injury to the
user or damage the product.

Features
Replace conventional lithium batteries with super capacitors for
longer life and safer.
1.HD display screen.
2.Support reversing auxiliary line.
3.Support battery voltage display.
4.Video can be recorded after inserting Micro SD card.
5.Built-in WiFi, can view real-time video on the dedicated APP.
- 3 -
Standard Accessories
※If there is any change of specification and appearance due to improvement,
we are not able to inform you in advance. Please understand.
※Please note that there are differences between the schematic diagram and
the real object in the manual.
Host Front Camera
Power Cable
Rear Camera
3.5m
UserManualRemoteControl GPSModule

- 4 -
Description of Each Part
1
2
3
4
6
5
11
14
7 9
Up Button
1
OK Button
2
3
4
5
Down Button
Card Slot
Reset Button
13
12
8 10
6
7
Microphone
Power Connector
8GPS Connector
9Camera Connector
10 Camera Connector
11 Power Cable
12 GPS Module
13 Camera
14 Camera

- 5 -
Micro SD Card
1.Please use the high-quality Class10 or above genuine SD card.
2.The recorder supports 16G-256G memory card.
3.If the memory card cannot save the file properly, please format it on
the recorder.
※Formatting will delete the data, please backup the card data before
performing formatting.
1. Insert the card into the card slot as shown in the picture.
2.When picking up the card, gently press the SD card and slowly
release it after hearing "Da”.
3.Please pay attention to the direction of the gold finger on the SD card.
If it is inserted reversely, the SD card and recorder will be damaged.
Attention:
1.The card used on other devices will be automatically formatted
after being inserted into our DVR. Please back up the data.
2.In the case of high frequency of use, it is recommended to format
the memory card every two weeks.
3.Please do not pull out the card in the recording state to avoid
damaging the video file and recorder.
Specifications
Model V7T SD Card Support up
to 256GB
Screen Size 7
lnch(1024x600) G-sensor Built-in
Video Resolution 1920*1080P Speaker Built-in
Video Format MOV(H.264) Microphone Built-in
Loop Recording Support Working Voltage DC 5V-2A

- 6 -
Installation Guide
Please connect the yellow wire on the rear camera
to the 12V positive pole of the inverted light. When
the vehicle is in reverse gear, the rear camera
screen will be displayed in full screen on the main
unit of the recorder, with a reversing auxiliary line. It
is convenient for users to observe the surrounding
environment when reversing.
Rear Camera Host
Front Camera

- 7 -
Host Fixed Installation Diagram:
1. Hang it on the windshield.
2. Stand on the center console.
Note: You can choose to rotate 180° to adjust the screen interface in
the host menu.
Host Fixed Installation Diagram

- 8 -
※This recorder uses the latest supercapacitor design to replace the traditional
lithium battery design, supercapacitor will automatically charge and can save the
last file after disconnecting the power.
After installing the recorder and inserting the SD card, insert the charger into the
cigarette lighter. Start the car to start recording automatically.
Time Setting
Manually Trigger Lock Video
Power on
Attention
Pause recording after the recorder is turned on→Enter Menu→Choose time
setting→Press↑↓to adjust time→Press ok to save the settings
In the recording state, long press the up button, the recorder will enter the emergency
lock mode, record a locked video and the front and rear cameras capture a picture at
the same time. The video file name is named after KEY-XXXXX. The locked video will
not be overwritten by the normal recorded "REC-XXXXX" file. When the SD card
video file exceeds 10 KEY-XXXXX videos, the system will delete the earliest KEY-
XXXXX emergency video.
G-sensor trigger lock video
In the recording state, if the G-sensor sensitivity is turned on, the video will be locked
after the G-sensor is triggered by a collision and reaches the system preset level. And
the locked video will not be overwritten by the normal recorded "REC-XXXXX". The
name of the locked video file is GSR-XXXXX. When the SD card video file exceeds
10 GSR-XXXXX videos,the system will delete the earliest emergency video of GSR-
XXXXX.
Recording Mode
Please format the SD card before inserting it. After inserting the SD card, turn on
the power of the motorcycle, and the recorder starts to enter the normal loop
recording mode. You can set 1/2/3/5 minutes to save a video in the menu. When
the SD card is full, new video files will overwrite the oldest saved files. To prevent
loss of important files, please backup important video files in time.
Playback Video Mode
In the recording state of the recorder, short press the OK button to pause the
recording. Then long press the OK button, the recorder enters the system setting
interface, use the up/down button to select the video to be played, and then short
press the OK button to enter the playback mode. In playback mode, long press the
up button to switch to view the video files saved by the front and rear cameras. If
you need to exit the playback mode, long press the OK button to return to the
system setting interface. Then use the up/down button to select the recording icon,
and then short press the OK button again to successfully return to the recording
mode.

- 9 -
Rear camera video files name identification: REC_ The year, month and time of current
video R.MOV
R/REC_220909-151201-001838R.MOV
1
1
"R/" indicates rear camera video playback
OK
2022/09/0 9 15:12:01 [00: 00:26]
Reversing auxiliary line
2022/09/09 15:12:01
Voltage
00:00:26 REC
-
+
14.11v
Microphone
Recording icon
Lock
video
Video time
P
50M
1007HPA
0
mi/h
GPS
Front Rear
GPS
Date&Time
Parking
Monitoring
Countdown
Altitude
Atmospheric
pressure
Rear
Camera
Speed
WiFi
Front
Camera
"F/" indicates rear camera video playback
F/REC_220909-151201-001838F.MOV
1
1
2022/09/0 9 15:12:01 [00: 00:26]
Screen Information and Menu Descriptions
1.After selecting, press
to enter recording mode.
2.The icon becomes larger
to indicate that thefunction
has been selected.
Description of characters on the display
in recording mode:
When parking is detected, the
recorder will turn off after the
progress bar is complete, which
takes about 5 minutes
OK
1.After selecting, press
to enter playback mode.
2.The icon becomes larger
to indicate that the function
has been selected.
1. Press to select the video to playback
Front camera video files
name identification: REC_
The year, month and time
of current video F
In playback mode, long press
for 3 seconds to switch to view
the list of video files saved by the
front and rear cameras .MOV

-10-
1.Video clip time
※The specific functions are subject to the actual
product received.
2.Sound record
3.MIC sensitivity
4.Flameout Detection
5.Parking Monitoring
6.Parking Monitoring
Sensitivity
7.Timed Recording
after Flameout
1/2/3/5 minutes can be selected
Set whether the recorded video needs sound
Set the sound level of MIC
On:After detecting that the vehicle is turned off, the
recorder shutdown after waiting for about 10seconds; off:
After 5 minutes without vibration, the recorder shutdown
Set whether to turn on or off parking monitoring function
Set the sensitivity of parking monitoring
Set the time to keep recording after the vehicle is turned off
Whether the recorder display needs to be flipped at 0°/180°
Whether recording video needs date watermark
Set the speed unit displayed when driving
Set the button sound on or off
Set display time
Three format options: YYYY MM DD/MM DD YY/DD MM YYYY
Set the display screen backlight to be off, or off after 1min/3min
G-Sensor sensitivity level adjustment
Display the current number of satellites, longitude, latitude, etc.
Time zone selection around the world
Restore to the factory default settings
On/Off
Delete all videos from the memory card
Information about the current software version of the recorder
Note:"Flameout Detection ", "Parking Monitoring"
"Parking Monitoring Sensitivity ", and ''Timed Recording
after Flameout " functions are optional and require the
purchase of an additional power cable to have them. If you
need these three functions, please contact us through the
Amazon message system or customer service email.
OK
1.After selecting, press to enter language selection mode.
2.The icon becomes larger to indicate that the function has been selected.
1.Language identification -- corresponding to
the selected language.
2.The number of language options depends on
the actual model.
OK
1.After selecting, press to enter setting mode.
2.The icon becomes larger to indicate that the function has been selected.
8.Flip Screen
9.Date watermark
10.Unit system
11.Button sound
12.Clock setting
13.Date format
15.Auto screen off
16.Protection Level
17.GPS Status
18.Time zone selection
19.System reset
20.WiFi MODE
21.Format SD card
22.FW version
Whether it is necessary to turn on the driving speed display
when playing videos on the computer
14.Speed watermark

-11-
App download for Android user App download for Apple user
Mobile Phone APP Installation and Operation
WiFi APP is a mobile phone control software used with VSYSTO DVR device.This
software is connected to the DVR device via Wi-Fi, it can directly preview and
playback the video on the mobile phone,easily realize that viewing the camera
documents on the screen of mobile phone,setting or other operations. Subverting
the control method of traditional cameras,bring you a new experience.
Scan the QR code above to download the latest APP from Google Play and APP
Store. Or you can search “WiFi Camera”on Google Play or APP Store to download
and install it.Conditions of use and product association:
1.Smart terminal with Android 5.0 or higher or Apple terminal.
2.Purchase are cord erterminal device that uses VSYSTO design scheme, and
connect the mobile phone WiFi to the camera correctly.
DVR WiFi Default Name: DV-V7T-XXXX
Default password: 1234567890
※To ensure the normal use of APP functions, please update the APP to the latest
version in time.
After the mobile phone is connected to the WiFi of the recorder, open the APP.
When it prompts "command successful", it means that the time of the recorder and
the time of the mobile phone have been synchronized with the mobile phone (as
shown in the figure below).
2022/09/09 15:12:01 REC OKB/S
2022/09/09 15:12:01 VSYSTO V7T OKPH
◆Synchronized Recorder Time

-12-
Click Online
browse the video files on recorder memory card(as shown in the figure below).
◆Browse Recorder Files
◆Live Preview (Video / Photo)
After connect the camera WiFi with mobile phone, open the APP and click "Connect
Device" to enter video preview status. In video preview state you can control camera
to take video or photo.Click to swtich front/rear image.Click to full screen
display(as shown in the figure below).
◆Playback Recrder Files
Browsing the recorder file interface in the "Online" option, click the file you want to
playback.Click the upper left corner to switch the front/rear camera file, F
means the front camera,R means the rear camera.
2022/09/09 15:12:01 REC OKB/S
2022/09/09 15:12:01 VSYSTO V7T OKPH

-13-
◆Local Files Management
Click to enter the browsing interface of local files to replay/delete the files stored
in the mobile phone, and the operation is similar to the online interface.
Local
◆Download or Delete Recorder Files
In the "Online" browsing recorder file interface, click to select the file you want
to download or delete, and then click "Save" or "Delete" below as needed (as shown
in the figure below).
EDIT
Video File Name
REC-XXXX— Normal recorded videos
GSR-XXXX— Emergency recorded videos
※The recorder will lock the last 10 emergency recorded videos (GSR-XXXX) that
are not overwritten by the normal recorded videos. If there are more than 10 GSR-
XXXX files, it will automatically overwrite the earliest locked emergency recorded
videos.

-14-
◆Recorder Parameter Setting
Click to enter the recorder parameter setting interface, and you can set some
parameters of the recorder in the mobile APP.
Set SSID is the WiFi name and password for setting the recorder (as shown in the
picture below).
Setting
If you need to view the video track, you can save the downloaded video in the Local
of APP. Then switch the phone to a network that can access the Internet, click to play
the video, and the track of your driving will be displayed below the video. The default
map of the APP is Baidu Map. If you need Google Map, please change Baidu Map to
Google Map in the APP settings interface.
※When you play a video on the mobile APP to view the driving track, you can only
view the video of a single camera (front/rear), and cannot play multiple cameras at
the same time.
2022/09/09 15:12:01 V7T 22Kmh

-15-

Double-click to open the software interface icon
Remote Control
1. Short press the red button once to switch to the full screen of the left camera
1. Short press the blue button once to switch the full screen of the right camera
Green Version
Model:CR2032
Wireless Remote Control
Battery Replacement Guide
① Use a screwdriver to
remove the 4 screws at
the bottom of the remote
control, and then lift off
the protective cover.
② Push the coin cell
battery out of the side
with a screwdriver or
fingernail.
③ Install the new battery into the
battery base according to the
positive and negative poles.After
ensuring that it can be used
normally that it can be used
normally,close the protective cover
and screw back the screws.
GVP Operation Guide (Optional)
Operating Systems Supported by GVPWinXP/7/8/10 Installed Version
Double-clicksetup.exe to start the installation. After the installation is complete,the
desktop and start menu automatically generate shortcuts.
Double-click the desktop shortcut icon , or click the start menu to select the
corresponding option of GVP to open the software.
2 Double-clicking either of the two buttons will trigger emergency lock .
mode. The front and rear cameras start recording emergency video, while
capturing a picture. While recording an emergency video, double-clicking
the button again cannot trigger lock mode repeatedly. Only when the last
emergency video recording is completed, double-clicking again can
trigger. The video file name is named after KEY-XXXXX. The locked video
will not be overwritten by the normal recorded "REC-XXXXX" file. When
the SD card video file exceeds 10 KEY-XXXXX videos, the system will
delete the earliest KEY- XXXXX emergency video.

-16-
Initial Interface
Playback Interface
Supports Multiple Languages and Google Maps
Click to set the player language and map
Interface Picture Example
When the mouse moves to the corresponding icon,there will be an operation prompt,
please follow the prompt to operate (as shown in the figure below).
Interface during Playback
During playback, double-click the front camera or rear camera image, the full
screen of the camera will be displayed. Double-click again to exit full screen.
