VSYSTO M6L User manual

1
USER MANUAL
1 INTRODUCTION.............................................................................................. 2
2 PACKAGE CONTENTS................................................................................... 2
3 CAMERA OVERVIEW ..................................................................................... 2
3.1 Structure.................................................................................................... 2
3.2 Optional accessories.................................................................................. 4
4 SPECIFICATIONS........................................................................................... 5
5 Getting Started................................................................................................. 5
5.1 Installation ................................................................................................. 5
5.2 Inserting a Memory Card ........................................................................... 5
5.3 Powering On and Off ................................................................................. 6
6 OPERATION.................................................................................................... 6
6.1 Video Recording........................................................................................ 6
6.2 Playback.................................................................................................... 7
6.3 Wi-Fi Connection & Operation ................................................................... 7
7 WARRANTY & SUPPORT............................................................................... 9
7.1 Warranty.................................................................................................... 9
7.2 FAQ......................................................................................................... 10
7.3 Support...................................................................................................... 9
7.4 Your Opinion Matters................................................................................. 9

2
1 INTRODUCTION
Thank you for choosing VSYSTO 2CH motorcycle dash cam system. This device is especially
designed for motorcycles, aimed to simplify the use of cameras, for security, and pleasure.
With the VSYSTO dual dash cam system, you can easily record high resolution videos of your
ride from 2 viewpoints. Install and forget it, just enjoy your ride!
Please read this Use Manual carefully before using the camera.
Product Features
● Separate dual cameras
●HD high resolution
● Built-in Wi-Fi with mobile APP
● Support loop recording
● Support emergency mode
● Support maximum 128G micro SD card
● Super capacitor design instead of Li-ion battery
● Continuous uninterrupted power supply
● Automatic power on and off
●Waterproof design (main unit is not waterproof)
● Support GPS track (optional)
2 PACKAGE CONTENTS
Main unit (1)
Waterproof cameras (2)
2.0 meters camera extension cable (2)
Power cable (1)
Mounting bracket (1)
USB test cable (1)
3 CAMERA OVERVIEW
3.1 Structure

3
Icon
Meaning
Icon
Meaning
Pause/Play
Front camera
Card slot
Y split cable
LED indicators1
Wired remote (optional)
GPS tracker (optional)
Emergency button
Rear camera port
LED indicators2
Power port
Power cable
Front camera port
Rear camera extension cable
Front camera extension cable
Rear camera
LED Indicator1
When turn on the motorcycle, the dash cam automatically power on and enter video mode,
both red and blue LED Indicator will be on at the same time.
Definition
Red Light
Blue Light
Solid light
The device is ON
Standby mode
Slow blinking light
/
Video mode
Fast blinking light
/
Emergency mode
No light
The device is OFF
The device is OFF

4
3.2Optional accessories
Wired Remote
1) Short press any button of wired remote to activate manual emergency mode and save 2
photos and video files named ‘’Key 001 002 003….’’which won’t be overwritten.
2) Long press the button for 5 seconds to reset the Wi-Fi SSID and password.
3) LED indicator2:
LED Light Frequency
Dash Cam Status
0.5 s
Recording properly
0.1 s
Emergency mode
0 s (light on)
Standby mode
Off (light off)
Power off
GPS Tracker
Optional GPS Tracker will show your movement (in Google map) and speed when playback
the video in our GV Player.
Tips
※It costs a few minutes to receive the GPS signal at first connection.
※The weather and environment like indoor, high buildings will affect the GPS signal.
※Please fix the GPS module exterior and don’t put it in a metal case or interior.
※The GPS player is supported on Windows platform only.
※You can download the GPS player from official website or contact seller to get it.

5
4 SPECIFICATIONS
Model
M6L
Processor
MSC8328
Screen
2.0 TFT , 960 X 240
Resolution
Front: 1920*1080; SONY IMX323 sensor
Rear: 1280*720; OV9712 sensor
Video frame rates
30fps
Lens
6-layer full glass
Lens waterproof level
IP67
Collision G-Sensor
Three-axis stereo collision detection
Loop recording
Support (Off/1min/2min/3min/5min)
Wi-Fi
Support
Microphone
Built-in
Video format
MOV (H.264)
Memory card
TF Card Up to 128GB
Language
English/French/Deutsch/Italian/Spanish/Portuguese/
Russian/Turkish/Korean/Japanese...
Operating humidity
15%~60% RH
Operating temperature
0~60 °C
Battery capacity
Super Capacitor + RTC
Power supply
INPUT: DC 12-24V ; OUTPUT: DC 5V 2A
Note: Specifications are subject to change without notice.
5 Getting Started
5.1 Installation
Please refer to the 'Quick Installation Guide', and also installation video guide can be found on
our YouTube channel.
NOTE: Please test the dash cam before installing it on your motorcycle. You can read the user
manual or contact the seller if there is any question.
5.2 Inserting a Memory Card
Insert the memory card into the card slot until it clicks. To remove the memory card, push to
eject the memory card out of the slot.

6
NOTE:
1. Make sure inserting the memory card with right direction: The golden finger side of memory
card facing the screen of the DVR.
2. Do not remove or insert the memory card when the device is being powered on. This may
damage the memory card.
3. Please use high speed micro SD card with CLASS⑩
4. Please format cards before use and anytime a significant amount of data has been collected
to ensure that device and SD cards are working properly together.
5.3 Powering On and Off
The dash cam will automatically power on once the ignition switch is on, and start recording
when there is a TF card inserted. It will automatically power off and stop recording once the
bike is not being used (still keep recording about 3 minutes for smart power cable).
NOTE:
1. When you get the ACC power cable, please must connect the yellow wire to 12V ACC port
of your motorcycle (KEY ignition)
2. The smart power cable is connected to the motorcycle battery directly. It works by detecting
the voltage change and continuous vibration.
6 OPERATION
6.1 Video Recording
1) Normal Video Mode
It starts video recording automatically when power on. The LED indicator of wired remote will
flash slowly and you will hear a voice prompt, “Start Recording”. Stop recording automatically
when power off (still keep recording around 3 minutes for smart power cable), to stop recording
manually, press the ‘OK’ button, you will hear a voice prompt, “Stop Recording”.
Loop on (by default): Loop recording mode continuously records videos to create footages of
assigned length of time (default setting: 3 Minutes). If the memory reaches maximum, then the
oldest footage will be deleted to store the most recent footage. Set the video clip time in the
dash cam configuration.
Loop off: It records as 30 minutes per clip for both front and rear camera without overwriting
until the memory reaches maximum and then stop.
NOTE: You cannot record videos without a micro SD card.
2) Emergency Video Mode
G-Sensor Event Recording: It will automatically activate emergency recording mode when
detecting a collision. The LED indicator of wired remote will flash quickly.

7
It will save a video file named ‘’GSR 001 002 003….’’
Manual Event Recording: Press the emergency button of wired remote during the recording
to manually activate emergency recording mode. The LED indicator of wired remote will flash
quickly.
It will save a video file named ‘’KEY 001 002 003….’’
NOTE: Video files recorded in emergency mode are protected from being overwritten.
6.2Playback
1) Playback on mobile device
Wi-Fi: Connect to your DVR with Wi-Fi APP (Android & iOS), you can easily play back videos
through your mobile device.
OTG: Plug the micro SD card into your mobile device with an OTG card reader (need your
mobile device support OTG). You will find FRONT and REAR video file folder when you
access the memory card and then select the video you want to play.
2) Playback on PC
Plug the micro SD card into an available USB port on your PC with a USB card reader. You will
find FRONT and REAR video file folder when you access the memory card and then select the
video you want to play.
You can get some information from the video file name:
“REC” means normal video file
“KEY” means file recorded by pressing controller
“GSR” means file recorded by triggering G-sensor
“170809” means date 9th August, 2017
“163256” means time 16oclock 32 minutes 56seconds
“F” means front camera video file
“MOV” means video file format
“KEY” and “GSR” file won’t be overwritten in normal loop recording.
6.3Wi-Fi Connection & Operation
When successfully connected with your smartphone via built-in Wi-Fi, you can save and
playback the driving recording videos on your smartphone. You can also change settings of
dash cam via Wi-Fi app.
1) Scan the QR code below to download the App from Google Play and App Store.

8
2) Select ‘MotoDV_P6’ from available Wi-Fi network to connect. Default password
is ’1234567890’.
3) Wi-Fi app operation
The dash cam will stop recording when you open Wi-Fi App (connected successfully) during
the recording, and if there is no operation within 30 seconds, or 30 seconds after you quit the
app, it will start recording automatically. Also you can also start/stop recording manually on the
Wi-Fi App.
Click to stop recording manually. Click to start recording manually.
Click to take photo.
Click to switch front and rear camera. Click to enter/exit full screen view.
Click to go back to previous menu.

9
NOTE:
● GST OFF means the G-sensor is turned off; GST LEVEL4 is the most sensitive level.
●When you connect the DVR failed, please make sure your mobile device is in the Wi-Fi
range (<5 meters) and connected the correct Wi-Fi successfully, and then you can turn off the
cellular network to try again.
● Contact seller if it encounters an error when setting the SSID.
7WARRANTY & SUPPORT
7.1 Warranty
We provide customers with a warranty of 12 MONTHS from the date of purchase. Please visit
our official website for details.
7.2 FAQ
There may be some information not fully covered on our user manual, take a look at our FAQ
page which may have the answers to your questions.
7.3 Support
If you have any questions regarding your product, please do not hesitate to contact us, please
contact us by below ways.
Please include your order number and product model number.
Email: [e-mail]
Facebook: https://www.facebook.com/szvsys/
Twitter: https://twitter.com/vsysto
YouTube: https://www.youtube.com/c/szvsys
7.4 Your Opinion Matters
Our products are designed to do amazing things.
We constantly optimize and strive for excellence to make driving safer, and more fun. Share
your product experience and story with us to inspire someone else.
If you have any thoughts on how we can do even better, we welcome your constructive
feedback and suggestions.
