Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
A2780
ISO9001
Vulcan-Hart Co.
F-31668 (8-04)
SPECIFICATIONS:
Gas fired boiler, Super Steamer, Vulcan-Hart Model No. (VL2G)
(VL3G). 6 psi pressure steam cooker. Cooker body is 8 gauge
satin finish type 304 stainless steel exterior. 200,000 BTU/hr.
input. Doors have a removable aluminum alloy inner liner with
full perimeter gasket and sealed by turning a "T" type handle.
Lift-out stainless steel wire Adapt-A-Pan™ supports eight
21/2", six 4", or four 6" deep food pans (one for 2 compartments)
(two for 3 compartments) and one manual pull out shelf. Water
fall compartment interior bottom to lip out at front. Steamer
mounted on 28" high base cabinet with stainless steel front full
height doors, slip-off stainless steel side and aluminized rear
panel with 6" adjustable legs with flanged feet for anchoring.
Gas fired steam boiler with high pressure limit control and
8 psi pressure relief valve, low water control with automatic fill
and manual blow down.
Exterior dimensions:
VL2G: 36"w x 33"d x 61"h.
VL3G: 36"w x 33"d x 76"h.
CSA design certified. Meets ASME code. Classified by U L to
NSF Std. #4.
VLG SERIES
SUPER STEAMER, GAS FIRED BOILER
TWO OR THREE COMPARTMENT MODELS
MODELS: VLG SERIES Gas Fired Super Steamer
■■VL2G (SS)
■■VL3G (SS)
STANDARD FEATURES
■Gas fired steam boiler with high pressure limit control and 8
psi pressure relief valve, low water control with automatic fill
and blow down. 200,000 BTU/hr. input.
■6 psi pressure steam cooker.
■Cooker body is 8 gauge satin finish type 304 stainless steel
exterior. Doors have a removable aluminum alloy inner liner
with full perimeter gasket and sealed by turning a "T" type
handle.
■Automatic timed cooking controls with exhaust.
■Lift-out stainless steel wire Adapt-A-Pan™ supports eight
21/2", six 4" or four 6" deep food pans (one for 2 compartments)
(two for 3 compartments) and one manual pull out shelf.
■Water fall front edge compartment interior bottom to lip out at
front.
■Steamer mounted on 28" high base cabinet with stainless
steel front full height doors, slip-off stainless steel side and
aluminized rear panel with 6" adjustable legs with flanged feet
for anchoring.
■One year limited parts and labor warranty.
OPTIONS
■■Correction package:
a. Cabinet door with hasp (lock by others).
b. Security type tamper resistant fasteners.
c. Control cover (lock by others).
■■Stainless steel cabinet base back.
■■Stainless steel main frame.
■■240,000 BTU/hr. boiler.
■■Mount and interconnect boiler base and kettle modules at
factory. Shipped on one skid.
■■Second year extended limited parts and labor warranty.
ACCESSORIES
■■Stainless steel back panel.
■■Water treatment system.

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-31668 (8-04)
SERVICE CONNECTIONS:
Gas Connection: 3/4" NPT.
Electric Connection for Controls: 120/60/1, 300 watt
maximum, power supply with grounding wire required. (For other
than 120 volt supply consult factory for location of this connection.)
Drain: Condenser box, compartment and boiler, 11/2" NPT. (Pro-
vide an open air gap type drain within 12" of condenser box and for
best results at a distance so that steam vapors will not enter the
steamer from underneath the control area.. Do not connect solidly
to any drain connection.)
Cold Water Connection: 3/8" NPT for boiler feed. Inlet water
pressure between 20 and 80 psi.
Cold Water Connection: 3/8" NPT for condensate box. Inlet water
pressure between 20 and 80 psi.
Water: For swing faucet, (single) (dual) temperature 1/4" IPS tail-
piece.
NOTE:
•Dimensions which locate the above connections have a tolerance of +
or -3" (+ or -75 mm).
•Installation of backflow preventers, vacuum breakers and other spe-
cific code requirements is the responsibility of the owner and installer.
It is the responsibility of the owner and installer to comply with local
codes.
•Plastic drains are not recommended due to inherent limited tempera-
tures of the plastic. Boiler purge temperatures may exceed 180°F. The
installer may be required to provide means to reduce boiler purge water
temperature to be that of the condensate temperature of 140°F or less.
•This appliance is manufactured for commercial installation only and is
not intended for home use.
VLG SERIES
SUPER STEAMER, GAS FIRED BOILER
TWO OR THREE COMPARTMENT MODELS
WATER QUALITY STATEMENT:
The fact that a water supply is potable is no guarantee that it is suitable for
steam generation. Your water supply must be within these general
guidelines:
SUPPLY PRESSURE 20 - 60 psig
HARDNESS* less than 3 grains
SILICA less than 13 ppm
TOTAL CHLORIDE less than 4.0 ppm
pH RANGE 7-8
UN-DISSOLVED SOLIDS less than 5 microns
*17.1 ppm = 1 grain of hardness
Other factors affecting steam generation are iron content, amount of
chloridation and dissolved gases. Water supplies vary from state to state
and from locations within a state. Therefore it is necessary that the local
water treatment specialist be consulted before the installation of any
steam generating equipment.
PAN CAPACITIES (Per compartment)
MODEL 21/2" deep 4" deep 6" deep 18" x 26"
VLG 86 4 6
EQUIPMENT CLEARANCE (Combustible):
Rear: 6" Right and left side: 6"
