User Manual
Manuel d’utilisation
Manuale d’uso
Manual del usuario
Benutzerhandbuch
Manual do usuário
Catalog No Description
432-0367 Bead Mill 230V, 300W
Bead Mill
Homogeniser
User Manual

2

Legal Address of Manufacturer
United States
VWR International, LLC
100 Matsonford Rd
Radnor, PA 19087
800-932-5000
http://www.vwr.com
Europe
VWR International bv
Researchpark Haasrode 2020
Geldenaaksebaan 464
3001 Leuven
+ 32 16 385011
http://be.vwr.com
Country of Origin
Intended Use
The VWR Bead Mill is intended for milling and homogenising of a
number of substances. Not intended for medical or diagnostics purposes.
Made in USA
Warranty
VWR warrants that this product will be free from defects in material and
workmanship for a period of two (2) years from date of delivery. If a defect is
present, VWR will, at its option and cost, repair, replace, or refund the purchase
price of this product to the customer, provided it is returned during the warranty
period. This warranty does not apply if the product has been damaged by accident,
abuse, misuse, or misapplication, or from ordinary wear and tear. If the required
maintenance and inspection services are not performed according to the manuals
and any local regulations, such warranty turns invalid, except to the extent, the
defect of the product is not due to such non-performance.
Items being returned must be insured by the customer against possible damage or
loss. This warranty shall be limited to the aforementioned remedies. IT IS EXPRESSLY
AGREED THAT THIS WARRANTY WILL BE IN LIEU OF ALL WARRANTIES OF FITNESS
AND IN LIEU OF THE WARRANTY OF MERCHANTABILITY.
Compliance with Local Laws and Regulations
The customer is responsible for applying for and obtaining the necessary regulatory
approvals or other authorisations necessary to run or use the Product in its local
environment. VWR will not be held liable for any related omission or for not
obtaining the required approval or authorisation, unless any refusal is due to a defect
of the product.
Technical Service
Web Resources
Visit the VWR website at www.vwr.com for:
• Complete technical service contact information
• Access to the VWR Online Catalogue, and
information about accessories and related products
• Additional product information and special offers
Contact Us
For information or
technical assistance,
contact your local VWR
representative or visit
www.vwr.com.

Equipment Disposal
This equipment is marked with the crossed out wheeled
bin symbol to indicate that this equipment must not
be disposed of with unsorted waste. Instead it is your
responsibility to correctly dispose of your equipment
at life cycle end by handing it over to an authorized
facility for separate collection and recycling. It's also your
responsibility to decontaminate the equipment in case of
biological, chemical and/or radiological contamination,
so as to protect from health hazards the persons
involved in the disposal and recycling of the equipment.
For more information about where you can drop off your waste of equipment, please
contact your local dealer from whom you originally purchased this equipment. By
doing so, you will help to conserve natural and environmental resources and you will
ensure that your equipment is recycled in a manner that protects human health.
Thank you.
Table of Contents
Overview / Package Contents
Voltage
Loading Sample Tubes
General Operation
Troubleshooting
Technical Service
Warranty
Equipment Disposal
4
5
6
7
8

4
The Bead Mill consists of the following:
Description Quantity
Bead Mill Assembly 1
Power Cord 1
Spare Fuse 1
User Manual 1
Overview
1. Lid
2. Drive Hub
3. Tube Carriage
4. Lid Latch
5. Keypad
6. ON/Off Switch
7. 120V/220V Fuse
8. Power Cord Port
- Remove Warning stickers from the back of the unit and check that the voltage
matches the voltage delivered by your electric power supply.
CAUTION: DO NOT connect the unit to the main power supply until correct voltage is selected.
- Plug the unit into power supply using the supplied power cord.
CAUTION: If the voltage supplied to the unit is higher than what is indicated on the
back of the unit, the electronics will be irreversibly damaged, voiding the warranty.
Voltage
1.
2.
3.
4.
5.
6.
7.
8.
15 = 100 - 120V
30 = 220 - 240V

5
Loading Sample Tubes
Close the lid until the locking
handle clicks into place.
CAUTION: The unit will not run without
the lid fully closed.
2. 2.or
1.
3.
2 mL 7 mL

6
General Operation
Language Setting
Turn unit OFF. Press and hold while powering on unit.
 to select.
Choose from French, English, German, Italian, or Spanish.
Programming Mode
- When the settings are entered, press up or down to return to the program option.
- Press “Run” to start.
- At the end of the program “DONE” will be displayed followed by “REMOVE SAMPLES”.
- If run is stopped system status will read “PROGRAM PAUSED”.
- Pause or Stop a run anytime by pressing the “STOP” button.
- Press “STOP” again to cancel current run.
PARAMETER OPERATING RANGE
SSpeed / Energy From 0.8 m/s to 6.5 m/s
TTime From 0:01 to 9:59 in increments of
1 second
CNumber of Cycles 1 to 10
DDwell
(Pause between Runs) 0:01 to 9:59
PROG 01 20oC
S =4.50 C=02
T=0:10 D=0:10
READY
UP and DOWN - navigate through menu.
LEFT and RIGHT - adjust the parameters.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
1. Program Number
2. Speed
3. Cycle Time
4. Navigation Buttons
5. Parameters Adjustment Buttons
6. Processing Chamber Temperature
7. Number of Cycles
8. Dwell or Time interval between cycles
9. Run Button
10. Stop Button

7
Troubleshooting
Error Cause Possible Solution
Unclosed Lid
The lid is not latched
properly
1. Check that nothing prevents the lid from
closing.
2. Press lid and ensure the handle is locked
properly.
Detection system is faulty 1. Turn off the unit.
2. Contact technical assistance.
Fan not working
No Power
1. Check main voltage
2. Check that the voltage of the unit matches
that being delivered by the main power
supply.
3. Make sure that the unit is plugged in
properly.
4. Check and replace fuses if blown.
Faulty Fan 1. Turn off the unit.
2. Contact technical support.
Display screen shows
incomplete or
unusual characters
CPU needs to be reset
1. Turn off the unit.
2. Wait 10 seconds.
3. Turn the unit back on.
No display on the screen
No Power
1. Check main voltage.
2. Check that the voltage of the unit matches
that being delivered by the main power supply.
3. Make sure the unit is plugged in properly.
4. Check and replace fuses if blown.
Faulty display screen 1. Turn off the unit.
2. Contact technical support.
One or several tubes are
not sealed tightly
The cap is not
properly sealed or the tube
is faulty
If dangerous or potentially dangerous sample
is contained in the tube, apply the proper
decontamination procedure.
Unit powers on with
a loud “BANG”
Motor control device
damaged due to incorrect
voltage selection
Return unit to VWR for replacement
of motor control device.
Unit powers on but
motor does not turn Incorrect voltage selected
Power off the unit and select appropriate
voltage. If problem persists, contact VWR for
assistance.
Tube leakage
Speed is too high,
high temperature or
pressure inside tubes
Reduce processing time or speed
DO NOT:attempt to service the Bead Mill in a manner other than those discussed
in this manual. For any issue that is unsuccessfully corrected using this guide, please
contact your authorized dealer or call VWR 1.800.932.5000 | vwr.com

8
Warranty
VWR warrants that this product will be free from defects in material and
workmanship for a period of two (2) years from date of delivery. If a defect is
present, VWR will, at its option and cost, repair, replace, or refund the purchase
price of this product to the customer, provided it is returned during the warranty
period. This warranty does not apply if the product has been damaged by accident,
abuse, misuse, or misapplication, or from ordinary wear and tear. If the required
maintenance and inspection services are not performed according to the manuals
and any local regulations, such warranty turns invalid, except to the extent, the
defect of the product is not due to such non-performance.
Items being returned must be insured by the customer against possible damage or
loss. This warranty shall be limited to the aforementioned remedies. IT IS EXPRESSLY
AGREED THAT THIS WARRANTY WILL BE IN LIEU OF ALL WARRANTIES OF FITNESS
AND IN LIEU OF THE WARRANTY OF MERCHANTABILITY.
Compliance with Local Laws and Regulations
The customer is responsible for applying for and obtaining the necessary regulatory
approvals or other authorisations necessary to run or use the Product in its local
environment. VWR will not be held liable for any related omission or for not
obtaining the required approval or authorisation, unless any refusal is due to a defect
of the product.
Equipment Disposal
This equipment is marked with the crossed out wheeled
bin symbol to indicate that this equipment must not
be disposed of with unsorted waste. Instead it is your
responsibility to correctly dispose of your equipment
at life cycle end by handing it over to an authorized
facility for separate collection and recycling. It's also your
responsibility to decontaminate the equipment in case of
biological, chemical and/or radiological contamination,
so as to protect from health hazards the persons
involved in the disposal and recycling of the equipment.
For more information about where you can drop off your waste of equipment, please
contact your local dealer from whom you originally purchased this equipment. By
doing so, you will help to conserve natural and environmental resources and you will
ensure that your equipment is recycled in a manner that protects human health.
Thank you.
Technical Service
Web Resources
Visit the VWR website at www.vwr.com for:
• Complete technical service contact information
• Access to the VWR Online Catalogue, and
information about accessories and related products
• Additional product information and special offers
Contact Us
For information or
technical assistance,
contact your local VWR
representative or visit
www.vwr.com.

9
Le Bead Mill est composé des éléments suivants :
Description Quantité
Bead Mill Assembly 1
Cordon d’alimentation 1
Fusible de rechange 1
Manuel d’utilisation 1
Aperçu
Tension
1. Couvercle
2. Moyeu d’entraînement
3. Portoir pour tubes
4. Loquet du couvercle
5. Clavier
6. Interrupteur ON/OFF
7. Fusible 120V/220V
8. Port du cordon d’alimentation
- Enlever les autocollants d’avertissement du dos de l’appareil et vérifier si la
tension correspond à la tension de votre alimentation électrique.
ATTENTION : NE PAS brancher l’appareil dans l’alimentation électrique
principale avant d’avoir sélectionné la tension correcte.
- Brancher l’appareil dans l’alimentation électrique à l’aide du cordon d’alimentation.
ATTENTION : si la tension délivrée à l’appareil est plus élevée que celle indiquée
au dos de l’appareil, les circuits électroniques subiront des dommages irréversibles,
ce qui annulera la garantie.
1.
2.
3.
4.
5.
6.
7.
8.
15 = 100 - 120V
30 = 220 - 240V
