WAGNER SuperCoat 0556730W User manual

Edition 7 / 2014 0533 814D
Ausgabe
D F
GB
Operating manual
Betriebsanleitung............p. 26
Mode d’emploi.................p. 52
Air Powered Airless Sprayer
Mit Druckluft betriebenes Airless-Spritzgerät
Pulvérisateur sans air pneumatique
SuperCoat
Models:
0556730C
0556745C
0556940C
0556960C
0556975C
Models:
0556730W
0556745W
0556940W
0556960W
0556975W

2 SuperCoat
GB
Warning!
Attention: Danger of injury by injection!
Airless units develop extremely high spraying pressures.
Be safety conscious!
1
2
3
Never put your ngers, hands or any other parts of the body into
the spray jet!
Never point the spray gun at yourself, other persons or animals.
Never use the spray gun without safety guard.
Do not treat a spraying injury as a harmless cut. In case of injury
to the skin through coating materials or solvents, consult a doctor
immediately for quick and expert treatment. Inform the doctor
about the coating material or solvent used.
The operating instructions state that the following points must
always be observed before starting up:
1. Faulty units must not be used.
2. Secure Wagner spray gun using the safety catch on the trigger.
3. Ensure that the unit is properly earthed.
4. Check allowable operating pressure of high-pressure hose and spray
gun.
5. Check all connections for leaks.
The instructions regarding regular cleaning and maintenance of
the unit must be strictly observed.
Before any work is done on the unit or for every break in work the
following rules must be observed:
1. Release the pressure from spray gun and hose.
2. Secure the Wagner spray gun using the safety catch on the trigger.
3. Switch o unit.
Original Operating Manual

SuperCoat 1
GB
Contents
Contents
Page
1. Safety regulations for Airless spraying...................................... 2
1.1 Explanation of symbols used.............................................................. 2
1.2 Compressor safety .................................................................................. 3
1.3 Setting up on uneven surfaces........................................................... 4
1.4 Freezing Parts ........................................................................................... 4
2. General view of application............................................................. 5
2.1 Application ................................................................................................ 5
2.2 Coating materials .................................................................................... 5
3. Description of unit................................................................................ 5
3.1 Airless process.......................................................................................... 5
3.2 Functioning of the unit ......................................................................... 5
3.3 System diagram....................................................................................... 6
3.4 Technical data for SuperCoat units................................................... 7
4. Operation.................................................................................................. 8
4.1 Setup............................................................................................................ 8
4.2 Automatic lubricator.............................................................................. 9
4.3 Preparing a new sprayer.....................................................................10
4.4 Preparing to spray.................................................................................10
4.5 Spraying....................................................................................................11
4.6 Pressure relief procedure ...................................................................12
4.7 Cleaning a clogged tip ........................................................................12
5. Cleanup....................................................................................................12
5.1 Special cleanup instructions for use with
ammable solvents ..............................................................................12
5.2 Cleaning the sprayer............................................................................12
5.3 Cleaning the air lter............................................................................13
6. Maintenance..........................................................................................13
6.1 Daily maintenance................................................................................13
6.2 Maintaining the lter assembly........................................................14
6.3 Maintaining the air motor..................................................................14
6.4 Maintaining the uid pump ..............................................................14
Page
7. Troubleshooting .................................................................................15
7.1 Airless gun ...............................................................................................15
7.2 Air motor ..................................................................................................15
7.3 Spray patterns ........................................................................................16
7.4 Fluid pump ..............................................................................................17
8. Servicing..................................................................................................18
8.1 Servicing the air motor........................................................................18
 ..............20
 ..............22
  ..........................24
Accessories and spare parts ........................................................................78
Spare parts list for the main assembly.................................................. 78/79
Spare parts list for the wall mount assembly..................................... 80/81
.................................. 82/83
.................... 84/85
Spare parts list for the uid pump assembly
................................................................................. 86/87
Spare parts list for the uid pump assembly
................................................................................. 88/89
...... 90/91
Spare parts list for automatic lubricator assembly........................... 92/93
Spare parts list for the high-pressure lter ................................................94
Spare parts list for bleed valve .......................................................................95
Accessories for SuperCoat units................................................................96
Nozzle Chart | Wagner Tip HP.......................................................................97
Sales and service companies........................................................... 100/101
Important notes on product liability ....................................................104
3+2 years guarantee for professional nishing ..............................104

2 SuperCoat
GB
Safety precautions
1. Safety regulations for Airless spraying
1.1 Explanation of symbols used
This manual contains information that must be read and understood
before using the equipment. When you come to an area that has one
of the following symbols, pay particular attention and make certain
to heed the safeguard.
This symbol indicates a potential hazard that
may cause serious injury or loss of life. Important
safety information will follow.
At
tention
This symbol indicates a potential hazard to you
or to the equipment. Important information that
tells how to prevent damage to the equipment or
how to avoid causes of minor injuries will follow.
Danger of skin injection
Danger of fire from solvent and paint fumes
Danger of explosion from solvent, paint fumes
and incompatible materials
Danger of injury from inhalation of harmful
vapors
i
Notes give important information which should
be given special attention.
HAZARD: INJECTION INJURY
A high pressure stream produced by this equipment
can pierce the skin and underlying tissues, leading to
serious injury and possible amputation.
Do not treat a spraying injury as a harmless cut. In
case of injury to the skin through coating materials
or solvents, consult a doctor immediately for quick
and expert treatment. Inform the doctor about the
coating material or solvent used.
PREVENTION:
  
  
DO NOT allow body to touch a leak in the uid hose.
  
provide protection against an injection injury.
  
and release all pressure before servicing, cleaning the tip
guard, changing tips, or leaving unattended. Pressure will
not be released by turning o the compressor. The PRIME/

appropriate positions to relieve system pressure.
  
provides some protection but is mainly a warning device.
  
system.
  
trigger guard in place.
  
operating pressure range of the sprayer. This includes spray
tips, guns, extensions, and hose.
HAZARD : HIGH PRESSURE HOSE
The paint hose can develop leaks from wear, kinking
and abuse. A leak can inject material into the skin.
Inspect the hose before each use.
PREVENTION:
  
smallest bending radius amounts to about 20 cm.
  
sharp objects and edges.
  
  
  
hose is discharged through the high-pressure hose. For this
reason the electric resistance between the connections of the
high-pressure hose must be equal to or lower than 1M.
  
Wagner high-pressure hoses.
  
or bulging of cover. Check for damage or movement of
couplings. Immediately replace the hose if any of these
conditions exist. Never repair a paint hose. Replace it with
another earthed high-pressure hose.
  
such a manner to minimize slip, trip and fall hazard.

SuperCoat 3
GB
Safety precautions
HAZARD: EXPLOSION OR FIRE
Solvent and paint fumes can explode or ignite.
Severe injury and/or property damage can occur.
PREVENTION:
  
Flashpoint is the temperature at which a uid can produce
enough vapors to ignite.
  
explosion protection regulations.
  
keep the air within the spray area free from accumulation of
ammable vapors.
  
electrical appliances, ames, pilot lights, hot objects, and
sparks from connecting and disconnecting power cords or
working light switches.
  
  

vapors are often heavier than air. Floor area must be
extremely well ventilated. The pump contains arcing parts
that emit sparks and can ignite vapors.
  

  

  
pressure, with spray tip removed. Hold gun rmly against side
of container to ground container and prevent static sparks.
  

sheet and technical information to ensure safe use.
  
  
never be sprayed or pumped back into a container with a

arise. The container must be earthed.
HAZARD: HAZARDOUS VAPORS
Paints, solvents, and other materials can be harmful
if inhaled or come in contact with body. Vapors can
cause severe nausea, fainting, or poisoning.
PREVENTION:
  
instructions supplied with the mask to be sure it will provide
the necessary protection.
  
vapors must be observed.
  
  
are necessary for the protection of the skin. Observe the
regulations of the manufacturer concerning coating materials,
solvents and cleaning agents in preparation, processing and
cleaning units.
HAZARD: GENERAL
This product can cause severe injury or property
damage.
PREVENTION:
  
governing ventilation, re prevention, and operation.
  
holding the spray gun. The recoil force of the spray gun is
particularly powerful when the tip has been removed and
a high pressure has been set on the airless pump. When
cleaning without a spray tip, set the pressure control knob to
the lowest pressure.
  
risks and liabilities when using parts that do not meet the
minimum specications and safety devices of the pump
manufacturer.
  
safe handling of paint and solvents.
  
slip hazard.
  

  
children or anyone not familiar with the operation of airless
equipment.
  
  
  
disposed of in an environmentally friendly way.
1.2 Compressor Safety

Follow all safety precautions given by the compressor manufacturer
regarding electrical and general safety.

clogged air intake of the compressor with overspray.
If lacquer or other flammable materials are to be
sprayed, ALWAYS locate the compressor outside the
immediate spraying area. Failure to do so may cause
an explosion.
SuperCoat units are equipped with an internal relief valve that is set
to automatically release air pressure if regulated air pressure exceeds



regulator by turning it counter-clockwise. This action will reset the
relief valve.

4 SuperCoat
GB
Safety precautions
1.3 Setting up on uneven surfaces
The front side of the unit must point downwards to prevent sliding
away.
1.4 Freezing Parts
The temperature of some components of the unit can drop below 32º

diagram below for the area of the pump most likely to reach freezing
temperatures. Avoid touching any components in this area during
usage.
Operating Temperature
This equipment will operate correctly in its intended ambient, at a

Relative Humidity
The equipment will operate correctly within an environment at 50%

Measures shall be taken by the Purchaser to avoid the harmful eects
of occasional condensation.
Altitude
This equipment will operate correctly up to 2100 m above mean sea
level.
Transportation and Storage
This equipment will withstand, or has been protected against,


It has been packaged to prevent damage from the eects of normal
humidity, vibration and shock.

SuperCoat 5
GB
 
2. General view of application
2.1 Application
Priming and nal coating of large areas, sealing, impregnation,
construction sanitation, façade protection and renovation, rust
protection and building protection, roof coating, roof sealing,
concrete sanitation, as well as heavy corrosion protection.
Examples of objects to be sprayed

towers, bridges, sewage treatment plants and terraces.
2.2 Coating materials
Processible coating materials
i
Pay attention to the Airless quality of the coating
materials to be processed.

zinc dust and micaceous iron ore paints, airless spray primer,
sprayable glue, anti-corrosive agents, thick coating materials and
bitumen-like coating materials.

approval.
Filtering
In spite of the high-pressure lter, ltering of the coating material is


Stir coating material before commencement of work.
iMake sure when stirring with motor-driven agitators
that no air bubbles are stirred in. Air bubbles disturb
when spraying and can, in fact, lead to interruption
of operation.
Viscosity
It is possible to work with high-viscosity coating materials with these
devices.
If highly viscous coating materials cannot be sucked up, they must be

Two-component coating material
The appropriate processing time must be adhered to exactly. Within
this time rinse through and clean the unit meticulously with the
appropriate cleaning agents.
Coating materials with sharp-edged additional materials
These have a strong wear and tear eect on valves, high-pressure
hose, spray gun and tip. The durability of these parts can be reduced
appreciably through this.
3. Description of unit
3.1 Airless process
The main area of application are thick layers of highly viscous coating
material for large areas and a high consumption of material.
A piston pump takes in the coating material by suction and conveys it
to the tip. Pressed through the tip at very high pressures, the coating
material is atomized. This high pressure has the eect of micro ne
atomization of the coating material.



This method of spraying has the advantages of nest atomization,
cloudless operation and a smooth, bubble-free surface. As well as
these, the advantages of the speed of work and convenience must be
mentioned.
3.2 Functioning of the unit
The following section contains a brief description of the technical
construction for better understanding of the function.
Wagner SuperCoat are high-pressure spraying units driven by air
power provided by an air compressor.

which then moves the piston up and down in the material feed pump


the system, and is directly proportionate to the uid pressure being
produced.
Example: SuperCoat 30:1

pump outlet
The inlet valve is opened automatically by the upwards movement
of the piston. The outlet valve is opened when the piston moves
downward.
The coating material ows under high pressure through the high-
pressure hose to the spray gun. When the coating material exits from
the tip it atomises.
1
3
5
24

6 SuperCoat
GB
Description of unit
3.3 System diagram
  
2 Air motor
3 Air pressure gauge
4 Air lter / moisture separator
5 Pressure bleed valve
6 Fluid pump
7 Siphon hose
  
9 Automatic lubricator adjustment
10 Air regulator
11 Air hose connection
  
13 Filter assembly
  
  
  
  
1
7
2
3
4
10
8
11
12
15
9
13
14
16
5
6
12
15
17

SuperCoat 7
GB
Description of unit
SuperCoat 30 SuperCoat 45 SuperCoat 40 SuperCoat 60 SuperCoat 75
Model Number
Cart 0556730C 0556745C 0556940C 0556960C 0556975C
Wall 0556730W 0556745W 0556940W 0556960W 0556975W
Max. operating pressure
    
Max. air inlet pressure
    
Pressure Ratio
30:1 45:1 40:1 60:1 75:1
Cycle rate per gallon / liter
21,2 / 5,6 31,1 / 8,2 21,2 / 5,6 31,1 / 8,2 39,6 / 10,5
Volume per double stroke
178,3 cm 121,6 cm 178,3 cm 121,6 cm 95,5 cm
Max. volume ow @ Cycles per minute (CPM)
60 CPM 10,7 l/min 7,3 l/min 10,7 l/min 7,3 l/min 5,7 l/min
90 CPM 16,0 l/min 10,9 l/min 16,0 l/min 10,9 l/min 8,6 l/min
Fluid inlet
    
Fluid outlet
    
Hose connection
    
Approximate air requirement (SCFM) per gallon of output @ 6,9 bar (0,69 MPa) air pressure
    
Air inlet
    
Max. sound pressure level
    
Sound pressure output
    
Weight
Cart 59,9 kg 60,3 kg 63,5 kg 63 kg 61,2 kg
Wall 41,7 kg 42,2 kg 45,3 kg 44,4 kg 43,1 kg
Max. viscosity
50.000 mPa·s 50.000 mPa·s 50.000 mPa·s 50.000 mPa·s 50.000 mPa·s
Dimensions L x W x H
Cart 88,3 cm x 66,7 cm x 124,5 cm
Wall 48,9 cm x 34,3 cm x 105,4 cm
Max. temperature of pre-heated coating material
60º C
Filter insert (standard equipment)
50 mesh, 18 in
Max. tire pressure
Cart 

3.4 Technical data for SuperCoat units

8 SuperCoat
GB
Operation
4. Operation
This equipment produces a fluid stream at extremely
high pressure. Read and understand the warnings
in the Safety Precautions section at the front of this
manual before operating this equipment.
4.1 Setup
  


male end of the hoses and should be wrench tight.
iTo orient the siphon hose, loosen the swivel (5) and
orient the siphon tube to the desired location.
1
3
25
4
  
the sprayer. Do not use Teon tape or thread sealant on the
spray hose connection.
3. Attach an airless spray gun to the spray hose. Do not attach
the tip to the spray gun yet. Remove the tip if it is already
attached.
a. To use two guns, remove the plug from the second gun outlet
on the lter assembly. Connect a hose and gun to the outlet.
iFor multiple gun operation, connect a multiple gun
manifold to the single gun outlet. Connect a hose
and gun to each outlet. All connections that are not
used must be plugged.
  
extends packing life.
Attention
EasyGlide prevents increased wear and tear to the
packings.
  
necessary to eectively power the sprayer. See “Technical
Data”, section 3.4 to determine air requirements.
i
The requirements will vary on each model.
6. Prior to connecting the compressor to the unit, perform the
following in order to prevent accidental startup:
  
handle in the closed position.
  
pressure setting.
  
1
2
3
  


1
Proper earthing (grounding) is important. The
passage of some materials through the nylon uid
hose will build up a static electric charge, which if
discharged, could ignite solvent vapors present and
create an explosion.

SuperCoat 9
GB
Operation
  

of the grounding cable to a true earth ground.
1
9. Strain all paints with a nylon strainer to ensure trouble free
operation and freedom from frequent cleaning of the inlet
screen and gun lter.
10. Make sure the spray area is well ventilated to prevent
hazardous operation with volatile solvents or exhaust fumes.
If lacquer or other flammable materials are to be
sprayed, ALWAYS locate the compressor outside the
immediate spraying area. Failure to do so may cause
an explosion.
  
to avoid clogged air intake of the compressor with overspray.
4.2 Automatic Lubricator

air that is being delivered to the system. It is set at the factory for the
correct injection rate and should not be adjusted until the reservior


After relling the reservoir, the automatic lubricator will need


decrease it.
1
2
Check the injection rate by observing the ow through the openings
in the side of the air motor shroud.
  
minute.
  
rate.

4.4 Preparing to Spray

system is compatible with the paint that is going to be used.
iIncompatible uids and paint may cause the valves
to become stuck closed, which would require
disassembly and cleaning of the sprayer’s uid
section.
Attention
Always keep the trigger lock on the spray gun in the
locked position while preparing the system.
1. Place the siphon tube into a container of the appropriate
solvent for the material being sprayed.
iIf you are spraying a water-based latex, ush with
warm, clean water. If you are using any other
material, check with the material manufacturer for a
compatible solvent.
2. Place the bleed hose into a metal waste container.
  
handle in the closed position.
4. Turn on the air compressor.
  
pressure setting.
  
  
with the valve.
  
the sprayer cycles evenly and solvent ows freely from the
bleed hose.
9. Allow the sprayer to run for 15–30 seconds to ush the test
uid out through the bleed hose and into the waste container.
10. Turn o the sprayer.
a. Turn the air regulator fully counterclockwise to its lowest
pressure setting.
b. Close the shuto valve.
i
Make sure that the spray gun does not have a tip or
tip guard installed.
11. Close the bleed valve by turning it fully clockwise.
  
with the valve. The system is now under pressure.
13. Turn the air regulator clockwise to increase pressure until the
sprayer cycles evenly. The air regulator gauge should read
between 4 - 5,5 bar.
iThe air regulator can be locked into place by pushing
down on the knob. Unlock the regulator by pulling
the knob out.
  
unlocked position.
Earth the gun by holding it against the edge of the
metal container while flushing. Failure to do so may
lead to a static electric discharge, which may cause
a fire.
4.3 Preparing a New Sprayer
If this unit is new, it is shipped with test uid in the uid section to
prevent corrosion during shipment and storage. This uid must be
thoroughly cleaned out of the system with cleaning agent before you
begin spraying.
Attention
Always keep the trigger lock on the spray gun in the
locked position while preparing the system.
1. Place the siphon tube into a container of mineral spirits.
2. Place the bleed hose into a metal waste container.
  
handle in the closed position.
4. Turn on the air compressor.
  
pressure setting.
  
1
2
3
  
with the valve.
  
the sprayer cycles evenly and solvent ows freely from the
bleed hose.
9. Allow the sprayer to run for 15–30 seconds to ush the test
uid out through the bleed hose and into the waste container.
10. Turn o the sprayer.
a. Turn the air regulator fully counterclockwise to its lowest
pressure setting.
b. Close the shuto valve.
10 SuperCoat
GB
Operation

  
unlocked position.
Earth the gun by holding it against the edge of the
metal container while flushing. Failure to do so may
lead to a static electric discharge, which may cause
a fire.
15. Trigger the gun into the metal waste container until all air and
solvent is ushed from the spray hose and paint is owing
freely from the gun.
  
position.
  
handle in the closed position.
18. Attach tip guard and tip to the gun as instructed by the tip
guard or tip manuals.
POSSIBLE INJECTION HAZARD. Do not spray
without the tip guard in place. Never trigger the
gun unless the tip is in either the spray or the unclog
position. Always engage the gun trigger lock before
removing, replacing or cleaning tip.
19. Open the shuto valve. The handle should now be in line
with the valve.
20. Increase the pressure by turning the air regulator slowly
clockwise and test the spray pattern on a piece of cardboard.
Adjust the regulator until the spray from the gun is completely

  
pressure.
  
  
pump outlet
DO NOT exceed an air regulator gauge reading of 6,9
bar (0,69 MPa).
21. Once the correct air pressure has been established, lock the air
regulator by pushing down on the knob.
iUsing a higher pressure than required will only
wear out tips. Use the guidelines in establishing the
lowest pressures for proper atomization.
Consult the materials manufacturer for guidelines in
establishing the correct uid pressure.
15. Trigger the gun into the metal waste container until the old
solvent is gone and fresh solvent is coming out of the gun.
  
position.
POSSIBLE INJECTION HAZARD
Refer to your spray gun manual for information
regarding the locking mechanism and how to
properly lock the spray gun.
17. Set down the gun and increase the pressure by turning the air

DO NOT exceed an air regulator gauge reading of 6,9
bar (0,69 MPa).
18. Check the entire system for leaks. If leaks occur, turn the
sprayer o and follow the “Pressure Relief Procedure” in this
manual before tightening any ttings or hoses.
  
manual before changing from solvent to paint.
Be sure to follow the Pressure Relief Procedure when
shutting the unit down for any purpose, including
servicing or adjusting any part of the spray system,
changing or cleaning spray tips, or preparing for
cleanup.
4.5 Spraying
1. Place the siphon hose into a container of paint.
2. Place the bleed hose into a metal waste container.
  
handle in the closed position.
4. Turn on the air compressor.
  
pressure setting.
  
  
now be in line with the valve.
  
the sprayer cycles evenly and material ows freely from the
bleed hose.
9. Turn o the sprayer.
a. Turn the air regulator fully counterclockwise to its lowest
pressure setting.
b. Close the shuto valve.
10. Remove the bleed hose from the waste container and place it
into the container of material.
11. Close the bleed valve by turning it fully clockwise.
12. Open the shuto valve. The handle should now be in line
with the valve.
13. Turn the air regulator clockwise to increase pressure until the
sprayer cycles evenly. The air regulator gauge should read
between 4 - 5,5 bar.
SuperCoat 11
GB
Operation

12 SuperCoat
GB
Operation Cleanup
4.6 Pressure Relief Procedure
Be sure to follow the Pressure Relief Procedure when
shutting the unit down for any purpose, including
servicing or adjusting any part of the spray system,
changing or cleaning spray nozzles, or preparing for
cleanup.
  
locked position.
2. Close the shuto valve.
3. Open the bleed valve by turning it fully counterclockwise.
  
unlocked position.
5. Hold the metal part of the gun rmly to the side of a metal
waste container to earth the gun and avoid a build up of static
electricity.
6. Trigger the gun to remove any pressure that may still be in the
hose.
  
position.
4.7 Cleaning a Clogged Tip
1. Follow the “Pressure Relief Procedure” found in the Operation
section of this manual, section 4.6.
  
the handle is facing the opposite of the spray direction and
the handle clicks in the reverse position.
3. Trigger the gun once so that the pressure can blow the clog

ONE trigger pull at a time. This procedure can be repeated
until the tip is free of clogging.
The flow from the spray tip is at very high pressure.
Contact with any body part may be dangerous. Do
not place finger on gun outlet. Do not point the gun
at any person. Never operate the spray gun without
the proper tip guard.
5. Cleanup
Attention
The sprayer, hose, and gun should be cleaned
thoroughly after daily use. Failure to do so permits
material to build up, seriously aecting the
performance of the unit.
Always spray at minimum pressure with the gun
nozzle tip removed when using mineral spirits or
any other solvent to clean the sprayer, hose, or
gun. Static electricity buildup may result in a re or
explosion in the presence of ammable vapors.
5.1 Special cleanup instructions for use with
ammable solvents
  
hose length from spray pump.
  
place it into an empty ve gallon container, then ush
solvents.
  
  
5.2 Cleaning the sprayer
1. Follow the “Pressure Relief Procedure” found in the Operation
section of this manual, section 4.5.
2. Remove the gun tip and tip guard and clean with a brush
using the appropriate solvent.
3. Place the siphon tube into a container of the appropriate
solvent.
Attention
Use only compatible solvents when cleaning
out oil based enamels, lacquers, coal tar, and
epoxies. Check with the uid manufacturer for the
recommended solvent.
4. Place the bleed hose into a metal waste container.
  
handle in the closed position.
6. Start the compressor.
  
pressure setting.
  
1
2
3
  
now be in line with the valve.
10. Allow the solvent to circulate through the sprayer and ush
the material out of the bleed hose into the metal waste
container.

SuperCoat 13
GB
Cleanup Maintenance
  
handle in the closed position.
12. Close the bleed valve by turning it fully clockwise.
  
now be in line with the valve.
Earth the gun by holding it against the edge of the
metal container while flushing. Failure to do so may
lead to a static electric discharge, which may cause
a fire.
14. Trigger the gun into the metal waste container until the paint
is ushed out of the hose and solvent is coming out of the
gun.
15. Continue to trigger the spray gun into the waste container
until the solvent coming out of the gun is clean.
i
For long-term or cold weather storage, pump
mineral sprits through the entire system.
16. Follow the “Pressure Relief Procedure” found in the Operation
section of this manual.
17. Store the sprayer in a clean, dry area.
Attention
Do not store the sprayer under pressure.
5.3 Cleaning the Air Filter
The air lter blocks any debris or particles that might be present in
the supplied air from the air compressor. It is important that this lter
be checked after every use.
1. Follow the “Pressure Relief Procedure” found in the Operation
section of this manual.
  
air motor shroud.
  
clean with warm, soapy water.
4. Replace the lter in the housing. Thread the housing into
position underneath the motor shroud.
iWhen the lter housing is replaced properly, the
“up” arrow (s) should be visible inside the viewing
window (3).
1
2
3
6. Maintenance
Before proceeding, follow the Pressure Relief
Procedure outlined previously in this manual.
Additionally, follow all other warnings to reduce the
risk of an injection injury, injury from moving parts
or electric shock. Always unplug the sprayer before
servicing!
6.1 Daily Maintenance
Two daily procedures are required for routine operator maintenance
on this sprayer:
  
  
A) Lubricating the Upper Packings
1. Clean out the paint that has seeped past the upper packings

section.
  

1
i
Do not over-ll the reservoir so that it overows and
drips into the paint.
B) Cleaning the Filter Screen
1. The lter screen will clog and must be cleaned at least once a
day.
  
screen to the siphon tube.
  
tube.
4. Clean thoroughly with the appropriate solvent.
2
1

14 SuperCoat
GB
Maintenance
6.2 Maintaining the Filter Assembly
Clean the lter regularly. Dirty or clogged lters can greatly reduce
ltering ability and cause a number of system problems including
poor spray patterns, clogged spray tips, etc.
Cleaning (Fig. 17)
1. Follow the “Pressure Relief Procedure” found in the Operation
section of this manual.
  
  

4. Clean inside the lter body, lter element with ball, and lter
cap assembly using the appropriate solvent.
iUse care in handling parts as dirt, debris, scratches,
or nicks may prevent o-rings or gaskets from sealing.
This lter element lters from the inside out. Be sure
to clean the lter element thoroughly on the inside.
Soak in solvent to loosen hardened paint or replace.
1
2
3
5
6
4
Inspection (Fig. 17)
Inspect all parts of the lter assembly before reassembly.
1. Inspect the ball inside the lter element. If the ball has
pressure cuts or scratches, replace the lter element.
  
cuts. Replace, if needed.
Reassembly (Fig. 17)
After cleaning and inspecting all parts, reassemble the lter.
  
i
The top and bottom of the lter element with ball
are identical.
  

  

  
6.3 Air Motor Maintenance
Air motors require a normal maintenance and service inspection
at 1500 hours service. Service procedure includes replacement of
motor service kit, minor. It is suggested that one motor service kit,


specications for correct part numbers.
6.4 Maintaining the Fluid Pump
If the sprayer is going to be out of service for an extended period


out from lack of use. This is particularly true of the upper packing

recommended in normal usage.
If the sprayer has been out of service for an extended period of time,
it may be necessary to prime the pump with solvent. It is extremely
important that the threads on the siphon hose coupling are properly
sealed. Any air leakage will produce erratic operation of the sprayer
and may damage the system. The up and the down strokes should




SuperCoat 15
GB
Troubleshooting
7. Troubleshooting
7.1 Airless Gun
Problem Cause Solution
A. Spitting gun 1. Air in system
2. Dirty gun
3. Needle assembly out of adjustment
  
1. Inspect connections for air leaks.
2. Disassemble and clean.
3. Inspect and adjust.
4. Inspect and replace.
   1. Worn or broken needle & seat
2. Needle assembly out of adjustment
3. Dirty gun
1. Replace.
2. Adjust.
3. Clean.
   1. No paint
2. Plugged lter or tip
  
1. Check uid supply.
2. Clean.
3. Replace.
7.2 Air Motor
Problem Cause Solution
A. Motor stops at top or bottom
of stroke - air does not exhaust
when gun is open.
1. Piston rod is loose where it connects to the
uid section.
2. Trip springs or valve spring broken.
3. Motor is frozen due to icing or lack of
lubrication.
1. Tighten connection.
2. Inspect and replace where neessary.
  

If condition persists, check air supply for
contamination.
  
exhaust when gun is open. 1. See above. 2. Air valve is in dead stall position.
3. O-rings were worn or damaged.
1. See above.
2. Remove one trip spring retainer, trip spring and ball.
Push spool valve up or down, lubricate, reassemble
and restart.
3. Install minor service kit and follow instructions in
Servicing section of manual.
If dust or dirt is found inside motor, check air supply for
contamination.

16 SuperCoat
GB
Troubleshooting
7.3 Spray Patterns
Problem Cause Solution
A. Tails 1. Inadequate uid delivery 1. Fluid not atomizing correctly:
Increase uid pressure. Change to smaller tip orice
size. Reduce uid viscosity. Reduce hose length.

pump.
   1. Inadequate uid delivery 1. Same as above.
C. Distorted 1. Plugged or worn nozzle tip 1. Clean or replace nozzle tip.
D. Pattern expanding and
 1. Suction leak 2. Pulsating uid delivery 1. Inspect for suction hose leak. 2. Change to a smaller tip orice size. Install pulsation
dampener in system or drain existing one. Reduce
number of guns using pump. Remove restrictions in
system; clean tip screen if lter is used.
E. Round pattern. 1. Worn tip
2. Fluid too heavy for tip 1. Replace tip. 2. Increase pressure. Thin material. Change nozzle tip.

SuperCoat 17
GB
Troubleshooting
7.4 Fluid Pump
Problem Cause Solution
A. Pump delivers on upstroke only
or goes up slowly and down fast


  
trash or wear.
2. Material to viscous to siphon.
3. Air leaking in on siphon side or damaged
siphon hose. Siphon may be too small for
heavy material.
  
upper packings are worn.
1. Remove foot valve assembly. Clean and inspect. Test
foot valve by lling with water. If ball fails to seal the
seat, replace ball.
2. Thin material - contact manufacturer for proper
thinning procedures.
3. Tighten all connections between pump and paint
container. If damaged, replace. Switch to bigger
siphon set.
4. If tightening upper packing nut does not correct,
change upper packings.
  
only or goes up fast and down
slowly.
  
wear.
  
1. Check upper seat and ball with water. If ball fails to
seal seat, replace.
2. Replace packing set is worn.
C. Pump moves up and down fast,
not delivering material. 1. Material container is empty or material is too thick to ow through the siphon hose.
  
3. Siphon hose is kinked or loose.
1. Rell with new material. If too thick, remove siphon
hose, immerse uid section in material, and start
pump to prime. Add thinner to material. Change to
bigger siphon set. Open bleed valve to remove air
and restart pump.
2. Remove foot valve. Clean ball and seat.
3. Straighten.
D. Pump moves up and down
slowly when spray gun is shut
o.
  

packing set is worn.
  
1. Check all connections between pump and gun.
Tighten as necessary. If material is owing from
bleed hose, close bleed valve or replace if necessary.
Should none of above be evident, replace lower
packing.
2. Reset balls by cleaning.
E. Not enough uid pressure at
gun. 1. Spray tip is worn.   
small. Outlet lter or gun lter is clogged.
  
4. Hose size or length is too small or too long.
1. Replace.
2. Clean or replace lter. Recommend proper hose size
and/or air compressor size.
3. Check electrical service. Correct as required.
4. Increase hose size to minimize pressure drop through
hose and/or reduce hose lengths.
F. Pump chatters on up or down
stroke 1. Solvent has caused upper packing to swell, or packing is too tight.    and restart pump. Repeat if necessary.

18 SuperCoat
GB
Servicing
8. Servicing
8.1 Servicing the Air Motor
The Air Motors require a normal mantenance inspection at 1500
hours of service on the non-circulating models.
Service procedure includes replacement of the Minor Motor


on hand for normal maintenance and emergency repairs. See

Maintenance
The 700/900 Series Air Motor should be serviced with moisture-
free air.
Accessing the Air Motor (Fig. 18)
In order to be able to access the air motor, certain components
must be removed.
1. Remove air hose connection.
  



1
7
3
4
5
6
2
8
13
14
38
39
37
36
15
25
26
27
28
29
23
34
34
17
18
19
20
21
30
31
16
10
24
32
33
12
22
35
1
5
2
6
3
4
2
7
8
9
10
11
i
The following procedure must only be performed by
a Wagner Authorized Service Center.
