Walker Edison W60CGS1 User manual

Item # :W60CGS 1
Assembly Instructions
  
 
Revised 03/2017
Copyright © 2014, by Walker Edison Furniture Co., LLC. All rights reseed. P.1

Use wrench (Q), bolt (U) to secure the side frame (18) to the side panel (2,5).
Disassemble keyboard tray slider (V) by sliding the tray arm and tray bracket apart. Depress
the small lever of the tray bracket and carefully pull the two pieces apart. Repeat this process
for both keyboard tray sliders (V).

Secure screw (L) to the tray arm of keyboard tray slider (V) to the middle side panel (7,8).
Secure screw (L) to the tray bracket of keyboard tray slider (V) to the drawer side panel (15,16).

Secure cam bolts (C) into top panel (1), side panels (2,5) and drawer panel (14). Insert
wooden dowels (A) into top panel (1).
Insert wooden dowels (A) into panels (3,4).

Insert wooden dowels (A, B) into panels (6, 7, 8) as shown in the diagram. Secure left door
stopper (K) to panel (7) using screws (L). Secure right door stopper (T) to panel (8) using
screws (L).
Secure legs (13) to bottom panel (4) using screws (G).

Attach side panels (7, 8) to bottom panel (4) using screws (G).
Slide back panel (9) into the slots in side panels (7, 8).

Insert cam bolts (D) into panel (7) and secure one side using cam locks (E) as shown in
the diagram.
Insert cam bolts (D) into panel (8) and secure one side using cam locks (E) as shown in
the diagram.

Place panel (3) carefully onto panels (7, 8) as shown in the diagram.
Slide back panel (10) into the slots in panels (3, 4). Attach panel (6) and secure using cam
locks (E).

Repeat Step 10 on the opposite side of the unit.
Place top panel (1) carefully onto panels (6) as shown in the diagram. Secure using cam
locks (E).

Attach the side frame (2) to the center assembly using cam locks (E) as shown in the
diagram.
Attach the side frame (5) to the center assembly using cam locks (E) as shown in the
diagram.

Cover all cam locks using stickers (S).
Attach hinges (N) to doors (11) using screws (P). Attach handles (H) using bolts (J).

Attach doors (11) to assembled unit using screws (P).
Attach panels (15, 16) to panel (17) using screws (M).

Carefully slide drawer bottom (12) into thin grooves on drawer assembly.
Attach drawer front (14) to drawer assembly and secure using cam locks (F).
Attach handle (H) using bolts (J).

Carefully insert drawer assembly into assembled unit as shown in the diagram.
