Warmup W3115 User manual

TH115 Controller
W3115 AF
eratn
nstrtns

Model W3115 - A closer look
Comfort
Economy
Vacation
Adjust the
temperature
Program
your
settings
Switch between
Manual, Automatic
and Vacation settings
Page 1

The thermostat comes with pre-programmed schedule for easy and economic heating control
of most homes. Below are the factory settings or the preset schedule.
Wake Up Leave Home Come Home Go to Sleep
5:30 8:00 18:00 21:30
24°C 16°C 24°C 16°C
Pre-programmed schedule
Page 2

Select your option
Open the doors on either side of the LCD display in order to access the controls. Set
the ON/OFF switch to ON.
If power has been applied for the first time:
•Set the current time by using the hour and minute buttons
•Set the day using the Day button
Page 6
Page 9
o2 settings a day
eg Heating will be ‘ON’ at 7am and “OFF” at 10pm
o4 settings a day
eg Heating will be ‘ON’ at the following times 7am
to 10am
6pm to 9pm
oManual setting
oVacation setting Page 9
Personalise your settings
Page 4
Page 3

Press the Mode button and check that
the Automatic icon is displayed.
Press Pgm
to access the
programming
mode
The little house is on 1 – this is
the P1 setting
Press the Day button and select the day
to be programmed – Hold the
day
button for 3 secs if you want the same
setting for all days of the week
Set the time to 7am using the Hour
button and press Pgm to go to step 4.
Setting the Comfort temperature Setting the Economy temperature
1. Press the ‘sun’ button
2. Set the temperature at 24°C
using the arrow keys
3. Press and hold the ‘sun’ button
for 3 seconds till the ‘sun’ icon
appears on the screen
2 settings a day
( Heating will be set to come ‘ON’ at 7am and ‘OFF’ at 10pm)
12
3
Page 4
1. Press the ‘moon’ button
2. Set the temperature at 10°C
using the arrow keys
3. Press and hold the ‘moon’
button for 3 seconds till the
‘moon’ icon appears on the
screen
Set your preferred heating times - P1
7:00
24.0
C
22:00
10.0
C
1
2
3
1
2
3
7:00
24.C 0
1
1
2
3
4
1
2
3
4
MO TU WE TH FR SA SU
3
3
+
+

If your settings for Saturday and Sunday are different from the rest of the
week - go to page 5. It is faster to program the same schedule for the entire
week and then modify the exception days eg weekends – Saturday and
Sunday.
5
6
Page 5
7Press ‘Mode/Ret’ to exit this function
Press the Day button and select the day
to be programmed – Hold the
day
button for 3 secs if you want the same
setting for all days of the week
Set the time to 10pm using the Hour
button and press Pgm to go to step 5.
4Set your preferred heating times - P2. The little house is on 2 – this is
the P2 setting
22:00
10. C
0
1
2
1
2
MO TU WE TH FR SA SU
2
Press ‘Clear’
Press ‘Clear’
Clear programs P3 and P4
The house is on 3 -
Press Pgm – the house moves to 4 -
Settings for Saturday and Sunday

4 settings a day
( eg 7am – 10am (morning) and 6pm – 9pm (evening/night)
Press the Mode button and check that
the Automatic icon is displayed.
Press Pgm
to access the
programming
mode - the little house is on 1 – this is
the P1 setting
Press the Day button and select the day
to be programmed – Hold the
day
button for 3 secs if you want the same
setting for all days of the week
Set the time to 7am using the Hour
button and press Pgm to go to step 4.
Setting the Comfort temperature Setting the Economy temperature
1. Press the ‘sun’ button
2. Set the temperature to 24°C
using the arrow keys
3. Press and hold the ‘sun’ button
for 3 seconds till the ‘sun’ icon
appears on the screen
1
3
1. Press the ‘moon’ button
2. Set the temperature to 10°C
using the arrow keys
3. Press and hold the ‘moon’
button for 3 seconds till the
‘moon’ icon appears on the
screen
Set your preferred heating times - P1
7:00
24.0
C
10:00
10.0
C
1
2
3
1
2
3
7:00
25.C 0
1
1
2
3
4
1
2
3
4
MO TU WE TH FR SA SU
3
3
++
2
++3
Page 6

The little house is on 4– this is the P4
setting
Press the Day button and select the day
to be programmed – Hold the
day button
for 3 secs if you want the same setting for
all days of the week
Set the time to 9pmusing the Hour
button
4 settings a day (cntd)
Page 7
4
10:00
10. C
0
1
2
1
2
MO TU WE TH FR SA SU
2
Setting P3 - 6pm
Press the Day button and select the day
to be programmed – Hold the
day
button for 3 secs if you want the same
setting for all days of the week
Set the time to 10am using the Hour
button and press Pgm to go to step 5
5
18:00
24.0
C
21:00
10.0
C
Set your preferred heating times - P2
The little house is on 2 – this is the
P2 setting
6
4
The little house is on 3 – this is the P3
setting
Press the Day button and select the day to
be programmed – Hold the
day button for
3 secs if you want the same setting for all
days of the week
Set the time to 6pm using the Hour button
and press Pgm to go to step 6.
1
2
1
2
1
2
1
2
34
Setting P4- 9pm
MO TU WE TH FR SA SU MO TU WE TH FR SA SU

If your settings for Saturday and Sunday are different from the rest of the
week follow the steps below . It is faster to program the same schedule for the
entire week and then modify the exception days eg weekends – Saturday and
Sunday.
1. Press PGM to access the programming mode
2. Press the day button until SA is displayed
3. Change the times for P1, P2, P3 and P4
4. Press Mode/Ret to exit the function
5. Now repeat the schedule for Sunday.
If you would like only 2 settings for Saturday and Sunday then follow the steps
below:
1. Press PGM to access the programming mode
2. Press the day button until SA is displayed
3. Change the times for P1 and P2.
4. Go to P3 and press 'Clear'
5. Go to P4 and press 'Clear'
6. Now repeat the schedule for Sunday.
Page 8
7
Ensure that you can see the Automatic icon on the LCD display. If you see the
manual icon instead, press the mode button again.
Your settings have now been programmed. The LCD display will now show
•The Comfort or Economy temperatues being used and
•The Active Program

aatn setting
2








OR





100

1

3
Page9
Manual setting
1
2
Press ‘Mode/Ret’todisplaythe
manual icon
Pressthearrowkeysfortherequired
temperature



OR




0

2

Press ‘Pgm’ and go to the program to
be erased (P1, P2, P3 or P4)
Erase your program
Press ‘Clear’
2
1
Press the ‘day’ button and select the
day
3
1
2
3
Press and hold the arrow key ▲
Reset the TH115
2
1
Position the switch from 'ON' to
'OFF' and back to 'ON'.
Warning: this will clear all
programming.
1
2
Page 10

The measured temperature is below the thermostat's display range.
Heating is activated.
The measured temperature is above the thermostat's display range. Heating
is deactivated.
Verify the thermostat and sensor connections
For more information please refer to the Warmup website :http://www.warmup.co.nz/thermostats.
Error messages –If a fault or error occurs, the thermostat will display one of the following error
messages:
Warmup New Zealand Ltd
T0800 927 687 E [email protected].nz W www.warmup.co.nz
Troubleshooting
LO
HI
Er
