WARN INDUSTRIES PAGE 1 39445 Rev A0
INSTALLATION INSTRUCTIONS
ATV WINCH MOUNT
Mount Kit: PN 28878
Application: HONDA TRX 300, 4X4
WARNING
SEVERE INJURY OR DEATH MAY RESULT IF YOU IGNORE ANY OF THE
FOLLOWING.
•Read the Winch Operator’s Manual, ATV Operator’s Manual, and all warning
labels before operating the winch and ATV.
•Stay clear of moving parts and cable. Keep others away when operating the winch.
•Inspect the winch mechanism, fasteners, and cable, before operating. Replace all
worn or damaged parts before operating.
•Make sure the winch is deactivated when leaving the ATV unattended.
PARTS LIST:
As you read these instructions, you will see NOTES, CAUTIONS and WARNINGS. Each message has
a specific purpose. NOTES are additional information to help you complete a procedure. CAUTIONS
are safety messages that indicate a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury. A CAUTION may also be used to alert against unsafe practice or possible
equipment damage. WARNINGS are safety messages that indicate a potentially hazardous situation,
which, if not avoided could result in serious injury. CAUTIONS and WARNINGS identify the hazard,
indicate how to avoid the hazard, and advise of the probable consequence of not avoiding the hazard.
PLEASE WORK SAFELY!
PART NO. QUANTITY DESCRIPTION
39424 1 Winch mounting plate
39423 1 Bracket support, right
39422 1 Bracket support, left
38917 2 Support bracket
37524 4 5/16-18
2583 2 7/16-14 Hex Nut
2146 2 7/16 Lock Washer
22513 2 3/8-16 x 2 ¼ Hex Bolt
1828 2 3/8-16 Hex Nut
1829 2 3/8 Lock Washer
2008 2 ¼-20 x 2 Hex Bolt
1322 2 ¼-20 Hex Nut
1321 2 ¼ Lock Washer

WARN INDUSTRIES PAGE 2 39445 Rev A0
INSTRUCTIONS:
1. Place winch directly to mounting plate without using the combination mounting plate/fairlead
supplied with the winch. Looking at the ATV from the front, the winch motor would be on the left
side of ATV and drum rotation arrow will be facing forward, as pictured. Attach winch to mounting
plate using (4) 5/16 x 1 hex bolts and lock washers supplied with winch. Tighten bolts securely.
2. Place winch and mounting plate into frame as pictured.
3. Fasten rear of mounting plate using (2) 1” U-clamps (2) 3/8 x 2 hex bolts and (2) 3/8 hex nuts and
lock washers.
4. Fasten front of mounting plate using (2) ¾ U-clamps (2) ¼-20 x 1 ¾ hex bolts and (2) ¼-20 hex nuts
and lock washers.
5. Fasten cast hawse fairlead to front tube assembly as pictured, using (2) 1” x 1 ¾ U-clamps, (2) 7/16-
14 x 2 ¼ hex bolts and (2) 7/16-14 hex nuts and lock washers.
6. Make electrical connections using manual supplied with winch.
