Waters ACQUITY UPLC M-Class Parts list manual

ACQUITY UPLC M-Class
System Guide
715003588
Revision C
Copyright © Waters Corporation 2019
All rights reserved

General information
Copyright notice
© 2014 – 2019 WATERS CORPORATION. PRINTED IN THE UNITED STATES OF AMERICA
AND IN IRELAND. ALL RIGHTS RESERVED. THIS DOCUMENT OR PARTS THEREOF MAY
NOT BE REPRODUCED IN ANY FORM WITHOUT THE WRITTEN PERMISSION OF THE
PUBLISHER.
The information in this document is subject to change without notice and should not be construed
as a commitment by Waters Corporation. Waters Corporation assumes no responsibility for any
errors that may appear in this document. This document is believed to be complete and accurate
at the time of publication. In no event shall Waters Corporation be liable for incidental or
consequential damages in connection with, or arising from, its use. For the most recent revision
of this document, consult the Waters website (www.waters.com).
Trademarks
ACQUITYTM is a trademark of Waters Corporation.
ACQUITY UPLCTM is a trademark of Waters Corporation.
ionKeyTM is a trademark of Waters Corporation.
MassLynxTM is a trademark of Waters Corporation.
nanoACQUITY UPLCTM is a trademark of Waters Corporation.
THE SCIENCE OF WHAT'S POSSIBLETM is a trademark of Waters Corporation.
UPLCTM is a trademark of Waters Corporation.
WatersTM is a trademark of Waters Corporation.
LAC/ETM is a trademark of Waters Corporation.
VanGuardTM is a trademark of Waters Corporation.
PEEKTM is a trademark of Victrex PLC.
ZenFitTM is a trademark of Waters Corporation.
All other trademarks are property of their respective owners.
November 26, 2019, 715003588 Revision C
Page ii

Customer comments
Waters’ Customer Experience and Knowledge Management organization invites you to report any
errors that you encounter in this document or to suggest ideas for otherwise improving it. Help us
better understand what you expect from our documentation so that we can continuously improve
its accuracy and usability.
We seriously consider every customer comment we receive. You can reach us at
[email protected].
Contacting Waters
Contact Waters with enhancement requests or technical questions regarding the use,
transportation, removal, or disposal of any Waters product. You can reach us via the Internet,
telephone, fax, or conventional mail.
Waters contact information
Contacting medium Information
Internet The Waters website includes contact
information for Waters locations worldwide.
Visit www.waters.com
Telephone and fax From the USA or Canada, phone
800-252-4752, or fax [phone].
For other locations worldwide, phone and fax
numbers appear in the Waters website.
Conventional mail Waters Corporation
Global Support Services
34 Maple Street
Milford, MA 01757
USA
Safety considerations
Some reagents and samples used with Waters instruments and devices can pose chemical,
biological, or radiological hazards (or any combination thereof). You must know the potentially
hazardous effects of all substances you work with. Always follow Good Laboratory Practice
(GLP), and consult your organization’s standard operating procedures as well as your local
requirements for safety.
November 26, 2019, 715003588 Revision C
Page iii

Considerations specific to the modules that comprise the ACQUITY
UPLC M-Class system
See also: For safety considerations regarding specific system modules, consult the appropriate
information on the user documentation CD.
High-voltage hazard
Warning: To avoid electric shock, observe these precautions:
• Do not remove the mass spectrometer’s protective panels. The components they
cover are not user-serviceable.
• When the instrument is in Operate mode, avoid touching the areas marked with the
high voltage warning symbol. To touch external areas marked with the symbol, first
put the instrument in Standby mode.
FCC radiation emissions notice
Changes or modifications not expressly approved by the party responsible for compliance, could
void the user's authority to operate the equipment. This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Canada spectrum management emissions notice
This class A digital product apparatus complies with Canadian ICES-001.
Cet appareil numérique de la classe A est conforme à la norme NMB-001.
Electrical power safety notice
Do not position the device so that it is difficult to disconnect the power cord.
Safety hazard symbol notice
The symbol indicates a potential hazard. Consult the documentation for important
information about the hazard and the appropriate measures to prevent and control the hazard.
November 26, 2019, 715003588 Revision C
Page iv

Equipment misuse notice
If equipment is used in a manner not specified by its manufacturer, the protection provided by the
equipment may be impaired.
Safety advisories
Consult the "Safety advisories" appendix in this publication for a comprehensive list of warning
advisories and notices.
Operating the system
When operating the system, follow standard quality-control (QC) procedures and the guidelines
presented in this section.
Applicable symbols
The following symbols can be present on the device, system, or packaging.
Symbol Definition
Manufacturer
Date of manufacture
Confirms that a manufactured product
complies with all applicable European
Community directives
Australia EMC compliant
Confirms that a manufactured product
complies with all applicable United States and
Canadian safety requirements
Environmentally friendly use period (China
RoHS): indicates the number of years from the
date of manufacture until the product, or
components within the product, are likely to be
discarded or degrade into the environment
Consult instructions for use
November 26, 2019, 715003588 Revision C
Page v

Symbol Definition
Alternating current
Electrical and electronic equipment with this
symbol may contain hazardous substances
and should not be disposed of as general
waste
For compliance with the Waste Electrical and
Electronic Equipment Directive (WEEE)
2012/19/EU, contact Waters Corporation for
the correct disposal and recycling instructions
For indoor use only
No pushing
10kg
max
Indicates the maximum load you can place on
that item (for example, 10kg)
Serial number
REF
Part number, catalog number
Audience and purpose
This guide is intended for personnel who install, operate, and maintain ACQUITY UPLC M-Class
system modules. It gives an overview of the system’s technology and operation.
Intended use of the ACQUITY UPLC M-Class system
Waters designed the ACQUITY UPLC M-Class system to perform chromatographic separations.
The system is for research use only and is not intended for use in diagnostic applications.
Calibrating
To calibrate LC systems, adopt acceptable calibration methods using at least five standards to
generate a standard curve. The concentration range for standards must include the entire range
of QC samples, typical specimens, and atypical specimens.
November 26, 2019, 715003588 Revision C
Page vi

When calibrating mass spectrometers, consult the instrument’s online Help system for calibration
instructions.
Quality control
Routinely run three QC samples that represent subnormal, normal, and above-normal levels of a
compound. If sample trays are the same or very similar, vary the location of the QC samples in
the trays. Ensure that QC sample results fall within an acceptable range, and evaluate precision
from day to day and run to run. Data collected when QC samples are out of range might not be
valid. Do not report these data until you are certain that the instrument performs satisfactorily.
ISM classification: ISM group 1 class B
This classification has been assigned in accordance with CISPR 11 Industrial Scientific and
Medical (ISM) instrument requirements.
Group 1 products apply to intentionally generated and/or used conductively coupled radio-
frequency energy that is necessary for the internal functioning of the equipment.
Class B products are suitable for use in both commercial and residential locations and can be
directly connected to a low voltage, power-supply network.
November 26, 2019, 715003588 Revision C
Page vii

Table of contents
General information .......................................................................................................ii
Copyright notice ..................................................................................................................................... ii
Trademarks............................................................................................................................................ ii
Customer comments..............................................................................................................................iii
Contacting Waters..................................................................................................................................iii
Safety considerations.............................................................................................................................iii
Considerations specific to the modules that comprise the ACQUITY UPLC M-Class system ....... iv
FCC radiation emissions notice...................................................................................................... iv
Canada spectrum management emissions notice.......................................................................... iv
Electrical power safety notice......................................................................................................... iv
Safety hazard symbol notice .......................................................................................................... iv
Equipment misuse notice ................................................................................................................ v
Safety advisories ............................................................................................................................. v
Operating the system............................................................................................................................. v
Applicable symbols.......................................................................................................................... v
Audience and purpose.................................................................................................................... vi
Intended use of the ACQUITY UPLC M-Class system................................................................... vi
Calibrating ...................................................................................................................................... vi
Quality control.................................................................................................................................vii
ISM classification: ISM group 1 class B ................................................................................................vii
1 ACQUITY UPLC M-Class system ...........................................................................12
1.1 Configurations of system modules ................................................................................................12
1.1.1 Examples of typical ACQUITY M-Class system configurations...........................................13
1.2 System components......................................................................................................................15
1.2.1 System features...................................................................................................................15
1.2.2 Auxiliary Solvent Manager...................................................................................................16
1.2.3 µBinary Solvent Manager ....................................................................................................16
1.2.4 µSample Manager - Fixed Loop ..........................................................................................17
1.2.5 Sample Organizer................................................................................................................17
1.2.6 Trap Valve Manager.............................................................................................................17
1.2.7 Detection..............................................................................................................................17
1.2.8 Column technology .............................................................................................................18
November 26, 2019, 715003588 Revision C
Page viii

1.2.9 Software...............................................................................................................................19
1.2.10 Options ..............................................................................................................................19
1.3 Additional information....................................................................................................................20
2 Performance optimization........................................................................................22
2.1 Best practices to improve performance.........................................................................................22
2.1.1 Autozeroing the flow transducers ........................................................................................22
2.1.2 Flow ramping .......................................................................................................................22
2.1.3 Flow rate on the B flow controller .......................................................................................23
2.1.4 Initial gradient hold...............................................................................................................23
2.1.5 Trapping flow rate and trapping composition.......................................................................23
2.1.6 Re-equilibration of column at the end of analysis ...............................................................24
2.1.7 System equilibration after auto zero ....................................................................................24
2.1.8 Re-equilibration between methods .....................................................................................24
2.1.9 Temperature sensitivity........................................................................................................24
2.2 General guidelines for a microscale system .................................................................................25
2.2.1 Required solvents................................................................................................................25
2.3 Dispersion .....................................................................................................................................26
2.4 Carryover ......................................................................................................................................26
2.5 Contamination ...............................................................................................................................27
2.5.1 Contamination when operating with neutral or basic mobile phases................................... 28
2.6 Preventing leaks............................................................................................................................29
2.6.1 Installing tubing and fittings .................................................................................................29
2.7 Sample preparation.......................................................................................................................47
3 Preparation and operation......................................................................................48
3.1 Preparing the system ....................................................................................................................48
3.1.1 Powering-on the system hardware ......................................................................................48
3.1.2 Configuring the system software .........................................................................................49
3.1.3 Monitoring LEDs ..................................................................................................................49
3.1.4 Power LED...........................................................................................................................49
3.1.5 Status LEDs.........................................................................................................................49
3.2 Starting the instrument console.....................................................................................................51
3.3 Instrument control panels..............................................................................................................52
3.3.1 Solvent manager control panels ..........................................................................................52
November 26, 2019, 715003588 Revision C
Page ix

3.3.2 µSM-FL control panel ..........................................................................................................54
3.3.3 TVM control panel................................................................................................................56
4 Maintaining the system...........................................................................................57
4.1 Contacting Waters Technical Service ...........................................................................................57
4.1.1 Locating system serial numbers ..........................................................................................57
4.2 Maintenance procedure and frequency.........................................................................................58
4.3 Troubleshooting.............................................................................................................................63
4.3.1 General principles................................................................................................................63
4.3.2 Troubleshooting M-Class system devices ...........................................................................64
4.4 Configuring maintenance warnings...............................................................................................74
4.5 Spare parts....................................................................................................................................75
A Safety advisories .....................................................................................................76
A.1 Warning symbols ..........................................................................................................................76
A.2 Notices..........................................................................................................................................77
A.3 Bottles Prohibited symbol .............................................................................................................77
A.4 Required protection ......................................................................................................................78
A.5 Burst warning................................................................................................................................78
A.6 Biohazard warning ........................................................................................................................78
A.7 Warnings that apply to all Waters instruments and devices .........................................................79
A.8 Warnings that address the replacement of fuses..........................................................................83
A.9 Electrical symbols .........................................................................................................................84
A.10 Handling symbols .......................................................................................................................85
B Specifications...........................................................................................................87
B.1 Features and performance specifications.....................................................................................87
B.2 Instrument control .........................................................................................................................91
B.3 Environmental specifications ........................................................................................................91
B.4 Power requirements......................................................................................................................91
November 26, 2019, 715003588 Revision C
Page x

B.5 Physical specifications..................................................................................................................92
C External connections..............................................................................................94
C.1 System waste routing ...................................................................................................................94
C.2 External wiring connections..........................................................................................................95
C.2.1 Ethernet connections ..........................................................................................................96
C.3 Signal connections .......................................................................................................................96
C.3.1 Connecting signal cables ....................................................................................................96
C.4 Connecting to the electricity source..............................................................................................98
C.4.1 Connecting to a wall electricity source................................................................................98
C.4.2 Connecting to a cart's electricity source..............................................................................99
D Solvent considerations.........................................................................................102
D.1 Solvent guidelines ......................................................................................................................102
D.1.1 Clean solvents...................................................................................................................102
D.1.2 Solvent quality...................................................................................................................102
D.1.3 Solvent preparation...........................................................................................................102
D.1.4 Pure water is required.......................................................................................................103
D.2 Solvent recommendations ..........................................................................................................103
D.2.1 Recommended solvents....................................................................................................103
D.2.2 Solvents to avoid...............................................................................................................104
D.2.3 Recommended cleaning agents........................................................................................104
D.2.4 Operation with neutral or basic mobile phases .................................................................104
D.3 System recommendations ......................................................................................................... 113
D.3.1 Solvent manager recommendations ................................................................................. 113
D.3.2 µSM-FL recommendations................................................................................................ 114
D.4 Properties of common solvents .................................................................................................. 114
D.5 Solvent miscibility effects............................................................................................................ 115
D.5.1 Using miscibility numbers (M-numbers)............................................................................ 116
D.6 Solvent viscosity ......................................................................................................................... 117
November 26, 2019, 715003588 Revision C
Page xi

1ACQUITY UPLC M-Class system
Waters designed the ACQUITY UPLC M-Class system to perform a range of chromatographic
separations from nano-scale to micro-scale. With a maximum operating pressure of 103,421 kPa
(1034 bar, 15,000 psi), an analytical flow rate to 100 µL/min, and a trapping flow rate to 1 mL/min,
the system produces optimal linear velocity for columns that range in internal diameter from 75
µm to 1.0 mm.
The system is compatible with Waters mass spectrometers and optical detectors, supporting a
range of column diameters. Options include:
• NanoFlow ESI and NanoLockSpray sources for Waters time-of-flight and tandem MS, and
flow rate ranges from 200 nL/min to 2,000 nL/min.
• Micro-scale ESI probe for use in the ZSpray API and LockSpray dual electrospray ion sources
for flow rate ranges from 5 µL/min to100 µL/min.
• A 100-nL, light-guided flow cell for columns ranging from 300 µm to 1.0 mm ID with the
ACQUITY UPLC PDA and TUV detectors.
• A 10-nL, transverse-illuminated flow cell for nano-scale separations with the ACQUITY UPLC
TUV detector.
ACQUITY UPLC M-Class systems that include mass spectrometry, optical detection, or both can
analyze compounds found in low concentrations amid complex matrices, quantifying peptides, or
metabolites (when used with a tandem mass spectrometer).
1.1 Configurations of system modules
This section shows examples of the ACQUITY UPLC M-Class system stack consisting of the core
modules. Your system configuration may differ according to the number and types of modules it
contains. For example, if your system includes a mass spectrometer, the system modules may be
arranged in two separate stacks.
See also: For information on the ACQUITY UPLC M-Class systems with HDX technology and
the ACQUITY UPLC M-Class systems with HDX Automation, refer to the ACQUITY UPLC M-
Class with HDX Technology System Guide on the documentation CD.
November 26, 2019, 715003588 Revision C
Page 12

1.1.1 Examples of typical ACQUITY M-Class system configurations
Figure 1–1: Single-pump trapping configuration
Solvent tray
Trap valve manager
µSample manager - fixed loop
µBinary solvent manager
Figure 1–2: Dual-pump trapping configuration
Solvent tray
Trap valve manager
µSample manager - fixed loop
November 26, 2019, 715003588 Revision C
Page 13

µBinary solvent manager
Auxiliary solvent manager
Figure 1–3: 2D, 75 µm ID scale configuration
Solvent tray
µBinary solvent manager
Trap valve manager
µSample manager - fixed loop
µBinary solvent manager
November 26, 2019, 715003588 Revision C
Page 14

Figure 1–4: 2D, 300 µm ID scale configuration
Solvent tray
µBinary solvent manager
Trap valve manager
µSample manager - fixed loop
µBinary solvent manager
Auxiliary solvent manager
Micro cart
1.2 System components
The capabilities of the ACQUITY UPLC M-Class system depend on the components installed.
The following sections briefly describe the system components and their functions.
1.2.1 System features
Review M-Class system features:
November 26, 2019, 715003588 Revision C
Page 15

• The system components are optimized for use with sub-2-µm, particle liquid chromatography,
and reduced fluid volumes.
• 100-nL, 10-mm path-length, light-guided TUV, and PDA detector flow cells deliver sensitivity
and resolution to ACQUITY UPLC M-Class applications on columns ranging from 300-µm to
1.0-mm ID.
• The columns, tubings, and fittings support flow rates for a gradient elution from 200nL/min to
100 µL/min at 103,421 kPa (1034 bar, 15,000 psi).
• With mass spectrometry, NanoLockSpray achieves exact mass measurement with columns
ranging from 75-µm to 1.0-mm ID.
• Solvent managers with flow control modules provide accurate NanoFlow rates. An optional
auxiliary solvent manager comprises two isocratic pumps. The A-side provides an additional
eluent with a flow rate range from 0.0 to 1.000 mL/min. The B-side provides NanoLockSpray
addition under flow control with a flow rate range from 0.0 to 100.0 µL/min.
• A micro-scale ESI probe in the ZSpray API interface delivers superior sensitivity. As column
ID decreases, this micro-probe reduces band-broadening to maintain chromatographic
integrity.
1.2.2 Auxiliary Solvent Manager
The Auxiliary Solvent Manager (ASM) is a high-pressure pump that provides pulse-free flow rates
at operating pressures as high as 103,421 kPa (1034 bar, 15,000 psi). The ASM consists of two
isocratic pumps, pump A and pump B. Each pump is fitted with two linear-drive actuators, which
together serve as a single reciprocating “serial” pump that delivers precise flow of a single
solvent. The solvent flows to the µSM-FL or column at an overall flow rate of 0.0 to 1000.0 µL/min
from pump A and 0.0 to 100.0 µL/min from pump B. Sometimes the ASM is also used to flow lock
mass directly into the mass spectrometer, usually from the B side.
See also: The Auxiliary Solvent Manager Overview and Maintenance Guide on the
documentation CD for more information about this module.
1.2.3 µBinary Solvent Manager
The µBinary Solvent Manager (µBSM) is a high-pressure pump that provides steady (pulse-free)
solvent flow at flow rates ranging from 0.0 to 6.0 µL/min (under closed-loop control) or to 100.0
µL/min (under open-loop control) at 103,421 kPa (1034 bar, 15,000 psi).
See also: The µBinary Solvent Manager Overview and Maintenance Guide on the
documentation CD for more information about this module.
November 26, 2019, 715003588 Revision C
Page 16

1.2.4 µSample Manager - Fixed Loop
The µSample Manager - Fixed Loop (µSM-FL) manages sample injections. It uses a fixed loop-
based mechanism to inject samples. After a puncture needle pierces the covering of a well or vial,
a sample needle extends through the puncture needle and aspirates the sample. The aspirated
sample is then drawn toward the sample loop while weak-wash solvent is simultaneously
dispensed through the needle, behind the sample. The wash syringe then pressurizes the needle
from the tip, compressing the air gaps around the sample and positioning the sample completely
within the loop. When the sample is in position, the injection valve is actuated to the inject
position, and high-pressure flow from the pump impels the sample onto the chromatographic
column.
The µSM-FL employs a thermal system that maintains a set temperature in the sample
compartment. When used in conjunction with the optional sample organizer, they create a
combined, thermally controlled compartment.
See also: The µSample Manager - Fixed Loop Overview and Maintenance Guide on the
documentation CD for more information about this module.
1.2.5 Sample Organizer
The optional Sample Organizer enables automatic processing and increased throughput by
storing multiple microtiter or vial plates and transferring them to and from the µSM-FL.
The Sample Organizer’s storage-shelf compartment can hold a selection of ANSI plates. A
heater/cooler thermally conditions the shelf compartment and maintains the temperature at a
specified set point.
See also: The Sample Organizer Overview and Maintenance Guide on the documentation CD
for more information about this module.
1.2.6 Trap Valve Manager
The Trap Valve Manager (TVM) comprises two trapping valves and a column-heater
compartment. The column extends from the TVM arm and plumbs into an optional optical
detector or a mass spectrometer. In addition, the TVM accommodates several columns ranging
from 75-µm ID to 2.1-mm ID, in lengths up to 25 cm.
See also: The Trap Valve Manager Overview and Maintenance Guide on the documentation CD
for more information about this module.
1.2.7 Detection
November 26, 2019, 715003588 Revision C
Page 17

1.2.7.1 Optical detection
The ACQUITY UPLC PDA and TUV are optical detectors that detect and quantify concentrations
of sample analyte. Low-dispersion flow cells developed with Teflon-AF are available for use with
microscale 1.0-mm and 300-mm ID columns.
See also: The ACQUITY UPLC M-Class System documentation CD for the following
documents:
•ACQUITY UPLC TUV Detector Operator's Overview and Maintenance Guide
•ACQUITY UPLC Photodiode Array and e λ Photodiode Array Detector Operator's Overview
and Maintenance Guide
1.2.7.2 Mass detection
The ACQUITY UPLC M-Class system maximizes peak capacity, extending the dynamic range of
sample analysis. The ACQUITY UPLC M-Class system is frequently used with mass
spectrometers, whether analyzing complex samples in wide-ranging matrices with a high-
resolution MS, or quantifying peptides, metabolites, or other targeted experiments with tandem
MS. Engineered for the lowest dispersion, including an improved ESI micro-probe design (and
with an extended pressure envelope) complex separations are accelerated without compromising
the chromatography.
See also: The Waters Driver Pack 2019 Release 2 Installation and Configuration Guide
(715006278) for compatible mass spectrometers and the associated MassLynx software change
note (SCN).
1.2.8 Column technology
Configure columns with the TVM using no valves for direct injection, or one or two valves (when
used with two-dimensional applications, for example).
1.2.8.1 Columns
The TVM supports nano-scale (75-mm ID), capillary-scale (300-mm ID), and micro-scale (1.0-mm
ID) separations. You can choose among these options when selecting columns for the system:
• Nanoscale analytical columns:
• 75 µm to 150-µm ID
• 50 mm to 250 mm length
• Capillary-scale analytical columns:
• 300 µm-ID
• 50 mm to 150 mm length
• Microscale analytical columns:
November 26, 2019, 715003588 Revision C
Page 18

• 500-µm to 1-mm ID
• 50 mm to 150 mm length
• Filter or guard column at 35 mm length
• Trap columns:
• 180-µm to 500-µm ID
• 20 mm to 23 mm length
• Ion exchange columns with SCX material
• 180-µm ID
• 240 mm length
See also: The ACQUITY UPLC M-Class System Documentation CD for the following
documents:
• The Trap Valve Manager Overview and Maintenance Guide
• The ACQUITY UPLC M-Class Columns Care and Use Manual
1.2.9 Software
See also: The Waters Driver Pack 2019 Release 2 Installation and Configuration Guide
(715006278) on the documentation CD for more information.
1.2.9.1 MassLynx
MassLynx software controls the ACQUITY UPLC M-Class system. It acquires, analyzes,
manages, and processes mass-spectrometry data.
See also: The MassLynx 4.1 Getting Started Guide (71500113203) on the documentation CD
for more information about this module.
Note: MassLynx software version updates (later than 4.1) are available. Always visit
www.waters.com to verify the latest released version of MassLynx software.
1.2.9.2 Instrument console
The instrument console is a software application that you use to configure settings, monitor
performance, run diagnostic tests, and manage the system and its modules.
1.2.10 Options
November 26, 2019, 715003588 Revision C
Page 19

1.2.10.1 Waters micro cart
The optional Waters micro cart provides a mobile platform for the system. The cart holds the
system modules and provides electrical outlets. Used with a mass spectrometer, the cart
positions the column outlet close to the mass spectrometer’s inlet probe, minimizing system dead
volume.
Note: You cannot use the micro cart with the sample organizer.
1.2.10.2 Optional kits and fluidic connections diagrams
The following resources support the ACQUITY UPLC M-Class system:
• ACQUITY UPLC M-Class System startup kit
• ACQUITY UPLC M-Class 2D startup kit
• ACQUITY UPLC M-Class 2D HT startup kit
Other kits comprise the following:
• ACQUITY UPLC M-Class 75-µm scale tubing kit
• ACQUITY UPLC M-Class 300-µm tubing kit
• ACQUITY UPLC M-Class 1-mm column mixer kit
• ACQUITY UPLC M-Class Micro Solvent stabilization kit
Visit www.waters.com for the following fluidic connections diagrams:
• ACQUITY UPLC M-Class Fluidic Configurations with ZenFit, 721013479
• ACQUITY UPLC M-Class Fluidic Configurations (without ZenFit), 721008114
1.3 Additional information
The system documentation CD includes the following M-Class system resources:
•Auxiliary Solvent Manager Overview and Maintenance Guide
•µBinary Solvent Manager Overview and Maintenance Guide
•µSample Manager - Fixed Loop Overview and Maintenance Guide
•Sample Organizer Overview and Maintenance Guide
•Trap Valve Manager Overview and Maintenance Guide
•ACQUITY UPLC M-Class with HDX Technology System Guide
•ACQUITY UPLC TUV Detector Operator's Overview and Maintenance Guide
•ACQUITY UPLC Photodiode Array and e λ Photodiode Array Detector Operator's Overview
and Maintenance Guide
•ACQUITY UPLC BEH Columns Care and Use Manual
November 26, 2019, 715003588 Revision C
Page 20
