Webasto 20 Series User manual

Marine Roof Operating Instructions
20 Series Manual

20 Series Manual
TABLE OF CONTENTS
English ..........................................................................................3
Annex ..........................................................................................19

20 Series Manual
3
1 Operation
1.1 Overview
A: Rear rails
B: Sliding roof
C: Release bar
D: Guides
1.2 Safety instructions
WARNING
• Take care not to hold any body parts, animals etc. through the roof opening when closing
the roof!
• Always keep the release bar (C) in locked position, unless you want to open or close the roof.
With the release bar unlocked, the roof can be opened from outside (burglary!) and can open
or close unintentionally. This can cause injuries or leakage!
• Do not stand or walk on the roof!
• Do not use the sliding roof as escape hatch!
Make sure that another hatch is accessible for emergencies.
ATTENTION
Possible damage due to weather conditions and/or speed
Close the roof at:
• Speeds of above 30 kts.
• A sea state of more than 1 m.
• At wind speeds of more than 16 kts.
Fig. 1
A
B
C
D

20 Series Manual
4
1.3 Open and close the sliding roof
1. Rotate the release bar (C) to
unlock the tilting and sliding
mechanism
2. Pull the release bar to move the
sliding roof to the desired position
3. Rotate the release bar as far as
possible to lock the roof in the
new position
NOTE
Do not to open the sliding roof if there is moisture on the panel.
2 Maintenance
• Clean the sliding roof regularly.
• Wash the roof with lukewarm
water with a professional marine
cleaning product.
Then rinse with clean water.
• Apply a thin layer of grease (Isof-
lex®Topas L32) to the inside of
the rear rails (A) and guides (D) to
ensure smooth sliding.
• Never use:
– Alkaline products containing
sodium solutions;
– Acid products like muriatic or
those containing phosphor;
– Steel wool, abrasives or
sandpaper;
– Cleaning products for glass
containing alkaline, which can
corrode aluminium.
Fig. 2
123
Fig. 3
grease
(A)
grease
grease
(D)

20 Series Manual
5
3 In case of failure
• Poor opening/tilting of the roof:
– Clean the seal with a mild detergent and open/close the roof again.
• Poor sliding of the roof:
– Clean the inside of the rear rails (A) and guides (D)
– Apply grease to the inside of the rear rails and guides.
See Fig. 1 and Fig. 3 and paragraph 2: "Maintenance".
• If the roof still does not move smoothly, please contact the supplier of the boat for maintenance/repair.
4 Warranty
Webasto guarantees the quality and correct operation of this sliding roof. The limited warranty covers both parts
and labour and is valid for 3 years after date of first delivery of the boat.
The warranty applies only when the sliding roof has been installed by a Webasto authorized shipyard or installer
and in accordance with Webasto installation instructions.
Defects and malfunction caused by incorrect handling, misuse, lack of reasonable and necessary maintenance,
accident and broken panel are not covered by this warranty.
The warranty is only valid when proof of purchase can be submitted.
5 Declarations of conformity
See “Annex” on page 19.

20 Series Manual
19
6 Annex

20 Series Manual
20

20 Series Manual
21

Ident-No. 3394289D • 10/2022 • Errors and omissions excepted • Printed in The Netherlands • © Webasto Thermo & Comfort SE
