weBoost DRIVE X RV User manual

User Manual
RV Cell Signal Booster
DRIVE X RV
A WILSON ELECTRONICS BRAND
NEED HELP? support.weboost.com 866.294.1660

______
Index
Package Contents 1
STEP 1: Mount Outside Antenna & Route Cable 2
STEP 2: Connect Cable To Outside Antenna 4
STEP 3: Inside Antenna Location 5
STEP 4: Booster Location & Connect Cables 6
STEP 5 & 6: Power Up The Booster 9
Using The Optional Cable Entry Accessories 10
Light Patterns 13
Troubleshooting 14
Safety Guidelines 16
Specifications 17
Warranty Back Page

DRIVE X RV CELL PHONE SIGNAL BOOSTER 1
________
Package
Contents
Drive X
Booster & Bracket
Outside Antenna
Ladder Mount
AC/DC Wall Power
Supply
DC/DC Hardwire
Power Supply
Installation
Accessories
Inside
Antenna
Outside Antenna &
25 ft. RG-6 Cable
Mast Extension,
Side-Exit Adapter
& Spring

2CELL PHONE SIGNAL BOOSTER DRIVE X RV
!!!
______
Step 1: Mount Outside
Antenna & Route Cable
Determine where you want the Outside Antenna on your RV.
Mount Outside Antenna to a ladder or pole so that the entire
Outside Antenna is above the roof line of the RV and clear of
other metal obstructions.
NOTE: Keep in mind to stay below the maximum height limit allowed by law,
which varies from state to state (generally 14’ in western states and 13’6” in
eastern states).
NOTE: This must be in a location within reach of the booster with the
25’ coax cable (installed in Step 4). The system performs best with maximum
vertical and horizontal separation.
common outside
antenna location

DRIVE X RV CELL PHONE SIGNAL BOOSTER 3
Determine where you want the cable to enter the RV.
NOTE: With this option, we recommend doing a ‘soft install’ before drilling
the hole. Set up the system by routing the cable through an open door or
window, completing the setup instructions, verifying the system works as
desired, and then drilling the hole.
WARNING: Be sure to stay clear of
any power, pipes, etc. that may be
damaged.
Option A: Using existing
cable entry point.
Option B: Through the slider on
your RV (using the slider gasket as
a seal).
Option C: Drill a hole with the
included hole saw bit.
______
(STEP 1: MOUNT OUTSIDE ANTENNA & ROUTE CABLE cont.)

4CELL PHONE SIGNAL BOOSTER DRIVE X RV
______
Step 2: Connect Cable To
Outside Antenna
Determine where you want the cable to enter the RV, then
connect the RG-6 cable to the Outside Antenna.
Spring
Side Exit
Adapter
Mast
Extension
NOTE: If installing with Spring, the Side
Exit Adapter must be used.
Thread Lock
Add thread lock on all threads
with tube provided

DRIVE X RV CELL PHONE SIGNAL BOOSTER 5
______
Step 3: Inside Antenna
Location
Place Inside Antenna where stronger signal is desired.

6CELL PHONE SIGNAL BOOSTER DRIVE X RV
______
Step 4: Booster Location &
Connect Cables
Find a location to place the booster, then mount by
removing the bracket from back side of booster and fasten
to desired surface. Snap booster back into bracket.
common booster
location
NOTE: We recommend mounting in a cabinet near a power source. Be sure it’s in a
location that cables from both Inside and Outside Antennas can reach.

DRIVE X RV CELL PHONE SIGNAL BOOSTER 7
Fasten the end with smaller SMA connection to the ‘Outside
Antenna’ port on the booster.
be sure to
finger tighten only
be sure to
finger tighten only
______
(STEP 4: BOOSTER LOCATION & CONNECT CABLES cont.)
from Outside Antenna
route to Inside Antenna
Connect the 13’ RG-58 cable to the ‘Inside Antenna’ port on
the booster. Route the cable to the Inside Antenna.

8CELL PHONE SIGNAL BOOSTER DRIVE X RV
Connect the 13’ RG-58 cable to the ‘Inside Antenna’ port
on the booster. Route the cable and connect to the Inside
Antenna.
Inside
Antenna
best when used within
4-10 feet of cellular device
______
(STEP 4: BOOSTER LOCATION & CONNECT CABLES cont.)
