weinor Cassita II Assembly instructions

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 1/47
Cassita II/Cassita II LED
Cassita II / Cassita II LED
Folding arm awning with gear drive
or electric drive
ENGLISH
Please read these instructions and observe their contents and warnings before
commencing any assembly work. This information is critical to the installation and the
proper use of the material.
Follow the assembly steps precisely and observe the tips, notes and
recommendations.
Only trained personnel may put the units into operation.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 2/47
Cassita II/Cassita II LED
Contents
1Notes on assembly instructions................................................................................. 4
1.1Validity of these instructions..............................................................................................4
1.2CE mark ............................................................................................................................4
1.3Depiction ...........................................................................................................................5
1.3.1Warnings ........................................................................................................................... 5
1.3.2Tips and recommendations ...............................................................................................5
1.3.3Illustrations ........................................................................................................................ 5
1.3.4Instructions requiring action ..............................................................................................5
1.3.5Symbols used....................................................................................................................5
2Safety notes ................................................................................................................. 6
2.1Fundamental safety notes .................................................................................................6
2.2Qualifications.....................................................................................................................6
2.2.1Working with electricity......................................................................................................6 
2.3Transportation ...................................................................................................................7
2.4Lifting with ropes ...............................................................................................................7
2.5Mounting brackets .............................................................................................................7 
2.6Fixing material ...................................................................................................................7
2.7Ladders .............................................................................................................................7
2.8Anti-fall guards ..................................................................................................................7
2.9Electrical connection .........................................................................................................8 
2.10Intended use......................................................................................................................8
2.11Unsupervised operation ....................................................................................................8
2.12Test run .............................................................................................................................8
2.13Crushing and cutting zones...............................................................................................9
2.14Handover...........................................................................................................................9
3List of Tools ............................................................................................................... 10
4Product description................................................................................................... 11
4.1Schematic diagram..........................................................................................................11
5Assembly.................................................................................................................... 12
5.1Safety notes ....................................................................................................................12
5.2Wall mounting..................................................................................................................13
5.2.1Wall mounting using a 150 mm wall bracket ...................................................................13
5.3Ceiling installation ...........................................................................................................16
5.3.1Ceiling installation using compact ceiling angle ..............................................................20
5.4Rafter bracket installation................................................................................................23
5.4.1Safety notes .................................................................................................................... 23
5.4.2Fitting the rafter bracket without a mounting plate ..........................................................24
5.4.3Fit the rafter bracket with mounting plate ........................................................................26
5.5Variations of rafter assemblies ........................................................................................27
5.6Assembling the light bar ..................................................................................................29
5.7Installing the receiver box................................................................................................30
5.8Setting the angle of inclination ........................................................................................31
5.9Setting the projection in an awning with gear drive .........................................................32
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 3/47
Cassita II/Cassita II LED
6Cassita II Circuit Diagram..........................................................................................33
6.1Cassita II, standard ......................................................................................................... 33
6.2Cassita II mit BiConnect radio control ............................................................................. 34
6.3Cassita II LED, standard ................................................................................................. 34
6.4Cassita II LED with BiConnect radio control ...................................................................35
7Adjusting the arm position........................................................................................36
7.1Possible incorrect positions of the awning ......................................................................36
8Electrical connection.................................................................................................37
8.1Safety notes .................................................................................................................... 37
8.2Setting the end positions................................................................................................. 37
9Cassita II Exploded Drawing.....................................................................................39
10Test that the unit is working correctly......................................................................41
10.1Safety notes .................................................................................................................... 41
10.2Checking the functions of the unit................................................................................... 41
11Troubleshooting.........................................................................................................42
12Handover.....................................................................................................................42
13Disassembly and disposal ........................................................................................43
14Handover certificate...................................................................................................44
15Declaration of performance.......................................................................................45
16EC Declaration of Conformity ...................................................................................46
17Other weinor products...............................................................................................47
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 4/47
Cassita II/Cassita II LED
1 Notes on assembly instructions
These instructions are geared towards trained fitters and require knowledge of installation
techniques. Awnings may only be installed by specially qualified personnel with
corresponding installation experience.
1.1 Validity of these instructions
The awnings have been approved for export and Germany.
1.2 CE mark
We, weinor GmbH & Co. KG, hereby expressly confirm that the awning complies with the
fundamental requirements and other relevant stipulations of the EN standards.
weinor GmbH & Co. KG
Mathias-Brüggen-Straße
110
50829 Cologne
(Germany)
13
EN 13 561
Awning for outdoor
use
Wind resistance class:
Class 2
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 5/47
Cassita II/Cassita II LED
1.3 Depiction
1.3.1 Warnings
The warnings differentiate between personal injury and damage to property. The signal word
"Danger" is used for personal injury, and "Caution" for property damage.
Immediate danger to life and limb!
Immediate danger to the product and environment!
1.3.2 Tips and recommendations
Highlights useful tips and information that enable fast and correct assembly.
1.3.3 Illustrations
Notes on item numbers can be found in the text in parentheses, e.g. (1).
1.3.4 Instructions requiring action
Instructions requiring action are written in bold print. If the instruction requiring action consists of
several individual steps, these have been numbered in the order in which they are to be carried
out, e.g. :
1. Fit wall brackets
1. Measure the distance between the stops.
2. Align the brackets exactly using suitable
tools/aids.
1.3.5 Symbols used
Symbol Explanation Remarks
Incorrect Change required settings
Correct Leave settings unchanged.
DANGER
CAUTION
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 6/47
Cassita II/Cassita II LED
2 Safety notes
Personal injury
Risk of personal injury due to improperly installed awning.
Please read and observe the safety notes contained in this section.
Product and property damage
Risk of damage to the product and property due to improperly installed awning.
Please read and observe the safety notes contained in this section.
2.1 Fundamental safety notes
The assembly and operating instructions must be read and observed.
Observe the corresponding accident prevention regulations.
Ensure when installing the awning that all existing electrical connections are disconnected.
Cordon off a large space around the installation site.
Check that all scaffolding and building facilities are duly safe and secure.
Observe the stipulations relating to dowels and fixing materials.
Only work with fully intact and appropriate tools.
Keep plastic sheeting, packaging material and small parts away from children – risk of
suffocation!
2.2 Qualifications
The assembly instructions are aimed at qualified technicians who have knowledge of and are
experienced in the following areas:
Safety at work, operating safety and accident prevention regulations
Use of ladders and scaffolding
Handling and transporting long, heavy components
Handling and transporting glass panes
Handling tools and machines
Fitting the fixing materials
Assessment of building fabric
Start-up and operation of the product.
If one of these qualifications is lacking, a qualified assembly firm must be brought in.
2.2.1 Working with electricity
In accordance with VDE 100 safety regulations, electrical work may only be carried out by an
authorised electrician. The installation instructions accompanying the supplied electrical
equipment must be observed.
CAUTION
DANGER
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 7/47
Cassita II/Cassita II LED
2.3 Transportation
The maximum permissible axle loads and gross vehicle weight of the goods vehicles must not
be exceeded. Loading a vehicle can alter its handling characteristics.
The transported goods must be fastened properly and safely. Keep packaging dry. Softened
packaging can come loose and cause accidents. Packaging which has been opened for goods
inward purposes must be sealed again properly for further transport.
When unloaded, the awning must be carried to the place of installation the right way round so it
does not have to be turned round again in a confined space. The instructions on the packaging
about which way up the awning should be placed must be noted.
2.4 Lifting with ropes
If the awning needs to be raised to a higher level using ropes, the awning must be:
removed from the packaging;
attached to the ropes so that it cannot slide out;
lifted horizontally and evenly.
The same applies when disassembling the awning.
2.5 Mounting brackets
Before beginning the installation work, check
that the mounting brackets supplied are of the same type and of the same quantity as
ordered,
that the information provided in the order about the installation surface tallies with the actual
installation surface on site.
If any deviations should be found whatsoever which compromise the safety of the installation,
the installation work must not be carried out.
2.6 Fixing material
The awning complies with the requirements of the wind resistance class shown on the CE
conformity marking. When fitted, it only complies with these requirements provided that
the awning is fitted with the type and number of brackets recommended by the manufacturer,
and
the awning is fitted taking into account the extraction forces recommended by the
manufacturer, and
the manufacturer's recommendations for the dowels to be used have been complied with.
2.7 Ladders
Do not lean ladders against the awning or fix them to the awning. Ladders must be on a firm
base and provide adequate support. Only use ladders with adequate load-bearing capacity.
2.8 Anti-fall guards
Workers run the risk of falling when working at elevated heights. Suitable anti-fall guards must
be used.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 8/47
Cassita II/Cassita II LED
2.9 Electrical connection
The awning may only be connected to an electricity supply if the specifications provided on the
tag attached to the awning and/or the specifications provided in the supplied assembly
instructions tally with the power source. At the very least, the tag and/or specifications must
specify the voltage, frequency and output values.
The installation instructions accompanying the supplied electrical components must be
observed. A permanent electrical connection may only be made to power grids fitted with an all-
pole disconnector with a minimum 3 mm wide contact gap.
2.10 Intended use
The awning is a sun protection unit and may only be used for sun protection. Failure to use the
product as intended may result in severe danger.
Alterations such as attaching items, or conversions not envisaged by weinor may only be carried
out with weinor's written consent.
Additional loads on the awning caused by hanging objects from it or by anchoring ropes may
result in damage or cause the awning to fall and are therefore not permissible.
2.11 Unsupervised operation
When working in the range of the awning’s movement, the automatic controls must be switched
off. There is a danger of trapping or the awning falling down.
Measures must also be taken to ensure that the awning cannot unintentionally be operated.
These involve powering down the unit, e.g. by disconnecting the fuses or removing the
connector coupling from the drive.
If awnings are operated by several users, a priority locking device must be installed (controlled
interruption of the power supply from outside), making it impossible to open or retract the awning
at all.
2.12 Test run
When running the awning for the first time, the working range of the awning and the area below it
must be kept clear. A visual inspection of the fixings and brackets must be performed after the
awning has been operated for the first time.
When carrying out test runs, never use automatic controls or switches if the awning is not in the
operator's line of vision (danger of awning starting unintentionally). We recommend that you
connect a test cable to the motor input.
The installation and setting instructions supplied by the manufacturer of the drive, switches and
controls must be observed.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 9/47
Cassita II/Cassita II LED
2.13 Crushing and cutting zones
Beware of crushing and cutting zones between e.g. the drop profile and the housing, between
the folding arms, and between profiles which come into contact with each other. Beware of
clothing and/or limbs getting caught in the system and pulled in!
If the awning is installed at a height of less than 2.5 metres above areas accessed by people, the
awning may only be operated using a push button with all moving parts in sight. Electrical
controls, wireless controls with latch switches, latch switches, etc. are not permissible here.
The push button must be fitted in the line of sight of the drop profile, but far enough removed
from the moving parts, at a height of 1.5 metres (national regulations relating to disabled people
must be observed).
2.14 Handover
All operating instructions as well as the manufacturer's assembly and setting instructions for
drives, switches and controls must be handed to the user who must be instructed in the
operation of the unit. Detailed instruction on the safe and proper operation of the awning must be
given. If this is not adhered to and the awning is operated incorrectly, damage to the awning or
accidents could result.
The instructions must be kept by the customer and passed on to the new owner if ownership of
the awning passes to a third party.
After noting the on-site structural conditions and completing assembly, the installation firm is to
inform the user whether the wind resistance class given by the manufacturer was achieved when
the awning was assembled. If not, the installation firm must record the wind resistance class
actually achieved.
Automatic controls must be set to this level.
The customer must confirm to the fitter in writing that the awning is the right model and has been
installed correctly, indicating the assembly time, and that final acceptance of the awning has
taken place during which the safety issues were discussed (see Handover section).
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 10/47
Cassita II/Cassita II LED
3 List of Tools
Good tools are the key to ensuring productivity and making certain that the quality of the
assembly work is good. The following is a list of the minimum tools that we recommend you have
available for installing your weinor awning under “normal” building conditions
Tool Size Use
Tools/machines
Allen key SW 4
SW 6
SW 8
To set the projection for the free-
wheeling mechanism
To adjust the arm position on the
drop profile
To fasten the clamp part
To set the height adjustment for the
ceiling
To adjust the inclination
Open-end or ring spanner SW 19 To fasten the brackets
Phillips screwdriver 2 To mount the wall bracket cover caps
Power drill, bits To drill screw holes
Clamps To tension the cord during rafter
bracket installation
Cable reel as required
Ladder as required
Measuring and testing tools
Tape measure To measure the bracket position
To measure the installation height
and the width of the unit
Spirit level, rope or mason's cord To align the unit
Installation tools
Touch-up pencils1) For touch-up work
Pencils For tracing / marking
Test run cable To set/adjust the drive, for test runs
Protective clothing
Safety shoes To protect against falling parts
Protective gloves To protect against sharp edges on
profiles and components
1) Supplied by weinor.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 11/47
Cassita II/Cassita II LED
4 Product description
4.1 Schematic diagram
Figure 1: Schematic diagram of Cassita II/Cassita II LED
1 Wall bracket 4 Drop profile
2 LongLife arm S 5 Housing floor profile
3 Fabric 6 LED spotlight
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 12/47
Cassita II/Cassita II LED
5 Assembly
5.1 Safety notes
Beware of missing or incorrect brackets as well as incorrect assessment of installation
surface.
Check before beginning the assembly work
that the mounting brackets supplied are of the same type and of the same quantity as
ordered,
that the information provided in the order about the installation surface tallies with the actual
installation surface on site.
If any deviations are found, which pose a safety risk, do not carry out the assembly
work.
Fitting the Cassita II under the ceiling requires at least 38 mm of space.
The adjusting bracket should be installed flush with the wall bracket as standard (A).
It may be pushed into the bracket by a maximum of 100 mm (B).
DANGER
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 13/47
Cassita II/Cassita II LED
5.2 Wall mounting
5.2.1 Wall mounting using a 150 mm wall bracket
1. Fit wall brackets
1. Refer to the awning delivery note for the system width (X).
2. The system width (X) of 180 mm equates to the centred spacing of the brackets.
Brackets can be indented by 100 mm; align brackets exactly using suitable tools/aids
(e.g. mason's cord) and a spirit level.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 14/47
Cassita II/Cassita II LED
3. Mark holes to be drilled (X),
drill holes and mount brackets on
wall. Affix each bracket using 3
screws.
2. Check bracket alignment
1. Check that the brackets are fitted
flush
2. Check that the brackets are aligned to
the right height and depth; max.
permissible deviation (e.g. due to
ripples in the wall) ± 5 mm Shim
underneath if necessary.
3. Attach the awning
1. Screw the awning into the bracket
stud; the awning must rest on the
nose of the wall bracket.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 15/47
Cassita II/Cassita II LED
4.
Mount clamp part on wall bracket
1. Using the hexagonal socket head
screws (3) and shims (2), mount the
clamp part (1) on the wall bracket.
5.
Mount wall bracket cover caps and wall bracket cover profile
1. Using the self-tapping screws (2),
attach the wall bracket cover caps (1)
to the wall bracket the right way
round.
2. Mount the cover profile wall bracket
(3) to the wall bracket.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 16/47
Cassita II/Cassita II LED
5.3 Ceiling installation
A space of at least 25 mm from the back of the wall is needed to be able to install the wall
bracket on the ceiling angle without difficulty at a later stage.
1. Fit ceiling angle
1. Refer to the awning delivery note for the system width (X).
2. The system width (X) of 180 mm equates to the centred spacing of the brackets.
Brackets can be indented by 100 mm; align brackets exactly using suitable tools/aids
(e.g. mason's cord) and a spirit level.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 17/47
Cassita II/Cassita II LED
3. Mark where holes are to be drilled (X)
(first the front 2, then the back 2), drill
the holes and fit the ceiling angle to
the ceiling.
2. Check bracket alignment
1. Check the brackets are at the correct
height and aligned flush, and adjust if
necessary.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 18/47
Cassita II/Cassita II LED
3. Mount the wall bracket
1. Using the screws, partially screw the
wall bracket (2) to the ceiling angle
(1). The wall bracket is in the lower
position on the ceiling angle.
4. Fit awning
5. Mount clamp part on wall bracket
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 19/47
Cassita II/Cassita II LED
6. Screw wall bracket in place
1. Turn the grub screws clockwise as
far as they will go until they are fully
tight on the awning.
2. Tighten the M12 screws.
7. Mount wall bracket cover caps and
wall bracket cover profile
1. Mount the cover caps (1) using the
screws (2).
2. Mount the wall bracket cover profile
(3).
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk

Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 20/47
Cassita II/Cassita II LED
5.3.1 Ceiling installation using compact ceiling angle
1. Fit the compact ceiling angle
1. Refer to the awning delivery note for the system width (X).
2. The system width (X) of 180 mm equates to the centred spacing of the brackets.
Brackets can be indented by 100 mm; align brackets exactly using suitable tools/aids
(e.g. mason's cord) and a spirit level.
www.samsondoors.co.uk
0800 328 6250
www.samsondoors.co.uk
