weinor Sottezza II Stretch/LED Assembly instructions

Sottezza II Stretch/LED
Sottezza II OptiStretch/LED
Instructions for assembly
Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 1/68
Conservatory awning with electric
drive
ENGLISH
Please read these instructions and observe their content and warnings before
commencing any installation work. This information is important for the installation and
the proper use of the material.
Follow the specified installation steps precisely and observe the details and
recommendations.
Only trained personnel may put the units into operation.

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 2/68
Navigating through the instructions for assembly
weinor patio roof
With Sottezza II provision
Without Sottezza II provision
Third-party
roof
Indented standard installation
for side glazing elements
Non-indented installation when
there are no side glazing
elements
Headplate bracket:
•Section 4.2.1, point 1
Headplate bracket:
•Section 4.2.1, point 2a
•Section 4.2.1, point 3a
Headplate bracket
•Section 4.2.1, point 2b
•
Section 4.2.1, point 3b
•Section
4.2.1
Information
•Section 8.1,
point C
Side channel bracket:
•Section 4.2.2, point 1
Side channel bracket:
•Section 4.2.2, point 2a
•Section 4.2.2, point 3a
Side channel bracket:
•Section 4.2.2, point 2b
•
Section 4.2.2, point 3b
OptiStretch
Stretch
•Section 4.2.4,
point 3a + 4
•Section 4.2.4,
point 3b + 4
•Section 6
•Section 5 Aligning the system
•Section 6 Fault analysis
•Section 10 Aligning the unit
•Section 11 Electrical connection
•Section 12 LED lighting
•Section 13 Fault analysis
Section 4.2.3 Installing the cassette
Section 10 Multi-section units
Section 9.3
Niche angle
bracket
Section 9.2 Rectangular profile
Section 9.1 A and B
Fixing plates
Section 8
Retracting cam
Section 6.2.1
Opening the
cassette
Section 7
Distance ropes
Section 4.2.5
Tensioning rope
Section 4.2.4 Installing the
side channels

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 3/68
List of contents
1Details on instructions for assembly..........................................................................5
1.1 Validity of these instructions.................................................................................................. 5
1.2 CE mark ................................................................................................................................ 5
1.3 Depiction ............................................................................................................................... 6
Warnings............................................................................................................................6
Tips and recommendations ...............................................................................................6
Illustrations.........................................................................................................................6
Instructions requiring action...............................................................................................6
Symbols used ....................................................................................................................6
2Safety instructions .......................................................................................................7
2.1 Fundamental safety instructions............................................................................................ 7
2.2 Qualifications......................................................................................................................... 7
Electrical operations ..........................................................................................................7
2.3 Transport............................................................................................................................... 8
2.4 Lifting with ropes ................................................................................................................... 8
2.5 Headplate/Side channel brackets.......................................................................................... 8
2.6 Fixing material....................................................................................................................... 8
2.7 Ladders ................................................................................................................................. 8
2.8 Anti-fall guards ...................................................................................................................... 9
2.9 Electrical connection ............................................................................................................. 9
2.10 Intended use..................................................................................................................... 9
2.11 Unsupervised operation.................................................................................................... 9
2.12 Test run............................................................................................................................. 9
2.13 Crushing and cutting zones ............................................................................................ 10
2.14 Note on the generation of noises (creaking) on the system in the event of temperature
changes !............................................................................................................................. 10
2.15 Handover ........................................................................................................................ 10
3Product description....................................................................................................11
3.1 Schematic diagram.............................................................................................................. 11
4Installation ..................................................................................................................12
4.1 Safety instructions............................................................................................................... 12
4.2 Installation on a weinor patio roof without Sottezza II provision.......................................... 13
Installing the headplate brackets .....................................................................................14
Installing the side channel brackets.................................................................................19
Installing the cassette ......................................................................................................24
Installing the side channels..............................................................................................26
Tensioning rope ...............................................................................................................29
5Aligning the unit .........................................................................................................32
5.1 Possible incorrect positions of the Sottezza II..................................................................... 33
5.1 Slideability oft he cassette in the bracket headplate ........................................................... 35
6Functional check ........................................................................................................36
6.1 Safety instructions............................................................................................................... 36
6.2 Checking the functions of the unit ....................................................................................... 36
Opening the cassette and test run...................................................................................37
7Installing the distance ropes .....................................................................................40
8Installing retracting cams ..........................................................................................42

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 4/68
9Special installation cases ..........................................................................................43
9.1 Installation with base plates or fixing plates ........................................................................ 43
9.2 Installing the unit at a distance from the roof supports........................................................ 46
9.3 Installation in a niche........................................................................................................... 47
10 Installation as multi-section unit...............................................................................48
11 Electrical connection .................................................................................................49
11.1 Safety instructions .......................................................................................................... 49
11.2 Setting the end position .................................................................................................. 49
Distances from the projection profile to the end cap when setting the end position ........50
11.3 Setting the end position of the Becker motor.................................................................. 50
Setting the end position with BiConnect radio programming ...........................................50
11.4 Setting the end position of the Somfy motor................................................................... 51
Programming the Somfy radio .........................................................................................51
11.5 Deleting the end position, general .................................................................................. 52
Deleting the end position example: Sottezza II LED with BiConnect...............................52
11.6 Circuit diagrams for connection of the adjustment kit ..................................................... 53
11.7 Sottezza II with Hirschmann connection assembly......................................................... 56
11.8 Laying cables.................................................................................................................. 57
Standard procedure for laying motor cable......................................................................57
Optional Hirschmann fastening for shortened cable........................................................57
Laying cables for multi-section units (OPTION)...............................................................57
12 Sottezza II LED lighting..............................................................................................58
12.1 Safety instructions on LED lighting ................................................................................. 58
12.2 Technical details – LED lighting...................................................................................... 58
Lighting device.................................................................................................................58
LED lamps .......................................................................................................................58
13 Fault analysis..............................................................................................................62
14 Handover.....................................................................................................................63
15 Dismounting and disposal.........................................................................................63
16 Handover certificate ...................................................................................................64
17 Declaration of performance .......................................................................................65
18 GB EU Declaration of Conformity Sottezza II.........................................................66
19 GB EU Declaration of Conformity Sottezza II LED..................................................67

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 5/68
1 Details on instructions for assembly
These instructions are geared towards trained technicians and require knowledge of
installation techniques. Sun protection systems may only be installed by specially
qualified personnel with corresponding installation experience.
1.1 Validity of these instructions
The sun protection systems have been approved for export and for use in Germany.
1.2 CE mark
We, weinor GmbH & Co. KG, hereby expressly confirm that the sun protection system
complies with the fundamental requirements and other relevant stipulations of the EN
standards.
weinor GmbH & Co. KG
Mathias-Brüggen-Straße
110
50829 Cologne,
Germany
14
EN 13 561
Conservatory awning for
outdoor use
Wind resistance class:
Class 2

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 6/68
1.3 Depiction
Warnings
The warnings differentiate between personal injury and damage to property. The signal word
"Danger" is used for personal injury, and "Caution" for property damage.
Immediate danger to life and limb!
Immediate danger to the product and environment!
Tips and recommendations
Highlights useful tips and information that enable fast and correct installation.
Illustrations
References to item numbers can be found in the text in parentheses, e.g. (1).
Instructions requiring action
Instructions requiring action are written in bold print. If the instruction requiring action consists of
several individual steps, these have been numbered in the order in which they are to be carried
out, e.g.:
1.
Installing the headplate brackets
Mark holes to be drilled using a drill template.
Drill holes in the roof support.
Symbols used
Symbol
Explanation
Remarks
Incorrect
Change necessary settings
Correct
Leave settings unchanged.
DANGER
CAUTION

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 7/68
2 Safety instructions
Personal injury
Risk of personal injury due to improper installation of the sun protection system.
Please read and observe the safety instructions contained in this section.
Product and property damage
Risk of damage to the product and property due to improper installation of the sun protection
system.
Please read and observe the safety instructions contained in this section.
2.1 Fundamental safety instructions
•The installation and operating manual must be read and observed.
•Observe the corresponding accident prevention regulations.
•Ensure when installing the awning that all existing electrical connections are disconnected.
•Cordon off a large space around the installation site.
•Check that all scaffolding and building facilities are duly safe and secure.
•Observe the stipulations relating to dowels and fixings.
•Only work with fully intact and appropriate tools.
•Keep plastic sheeting, packaging material and small parts away from children – risk of
suffocation!
•At least two technicians are required for the installation.
2.2 Qualifications
The instructions for assembly are aimed at qualified technicians who have knowledge of and
are experienced in the following areas:
•Safety at work, operating safety and accident prevention regulations
•Use of ladders and scaffolding
•Handling and transporting long, heavy components
•Handling and transporting glass panes
•Handling tools and machines
•Fitting the fixing materials
•Estimation of the building structure
•Start-up and operation of the product.
If one of these qualifications is lacking, a qualified installation firm must be brought in.
Electrical operations
In accordance with VDE 100 safety regulations, electrical work may only be carried out by an
electrically skilled person. The installation instructions accompanying the supplied electrical
equipment must be observed.
CAUTION
DANGER

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 8/68
2.3 Transport
The maximum permissible axle loads and gross vehicle weight of the goods vehicles must not
be exceeded. Loading a vehicle can alter its handling characteristics.
The transported goods must be mounted properly and securely. The packaging must be
protected against moisture. Softened packaging can come loose and cause accidents.
Packaging which has been opened for incoming goods inspections must be sealed again
properly for further transport.
When unloaded, the sun protection system must be carried to the place of installation the right
way round so it does not have to be turned round again in a confined space. The note on the
box about which way up the unit should be placed must be observed.
2.4 Lifting with ropes
If the unit needs to be raised to a higher level using ropes, it must be
•removed from the packaging;
•attached to the hauling ropes so that it cannot slide out;
•lifted horizontally and evenly.
The same applies when dismounting the unit.
2.5 Headplate/Side channel brackets
Before beginning the installation work, check
•that the headplate/side channel brackets supplied are of the same type and of the same
quantity as ordered,
•that the information provided in the order about the installation surface tallies with the actual
installation surface on site.
If any deviations should be found whatsoever which compromise the safety of the installation,
the installation work must not be carried out.
2.6 Fixing material
The sun protection system complies with the requirements of the wind resistance class shown
on the CE conformity mark. When fitted, it only complies with these requirements provided that
•the sun protection system is fitted with the type and number of headplate/side channel
brackets recommended by the manufacturer, and
•the manufacturer's recommendations for the fixing material to be used have been complied
with.
2.7 Ladders
Do not lean ladders against the sun protection system or fix them to the system. Ladders must
be on a firm base and provide adequate support. Only use ladders with adequate load-bearing
capacity.

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 9/68
2.8 Anti-fall guards
Workers run the risk of falling when working at elevated heights. Suitable anti-fall guards must
be used.
2.9 Electrical connection
The sun protection system may only be connected to an electricity supply if the specifications
provided on the tag attached to the system and/or the specifications provided in the supplied
instructions for assembly tally with the power supply voltage. At the very least, the tag and/or
specifications must specify the voltage, frequency and output values.
The installation instructions accompanying the supplied electrical components must be
observed. A permanent electrical connection may only be made to power grids fitted with an all-
pole cutting off plate cylinder with a minimum 3 mm wide contact gap.
2.10 Intended use
This is a sunscreen installation and may only be used as a sunscreen. Failure to use the
product as intended may result in severe danger.
The unit must only be fitted under a roof.
Alterations such as attaching items or conversions not envisaged by weinor may only be carried
out with weinor's written consent.
Additional loads on the sun protection system caused by hanging objects from it or by
anchoring ropes may result in damage or cause the system to fall and are therefore not
permissible.
2.11 Unsupervised operation
When working in the range of the sun protection system's movement, the automatic controls
must be switched off. There is a danger of trapping or the system falling down.
Measures must also be taken to ensure that the sun protection system cannot be operated
unintentionally. These include cutting off the power source, e.g. by disconnecting the fuses or
removing the connector coupling from the rear of the sun protection system.
If sun protection systems are operated by several users, a priority locking device must be
installed (controlled interruption of power supply from outside), making it impossible to open or
retract the system at all.
2.12 Test run
When opening the sun protection system for the first time, its working range and the area below
it must be kept clear. A visual inspection of the fixing material must be performed after the
system has been opened for the first time.
When carrying out test runs, never use automatic system controls or switches if the sun
protection system is not in the operator's line of vision (danger of system starting unintentionally).
We recommend that you connect a test cable to the motor input.
The installation and adjustment instructions supplied by the manufacturer of the motor, switches
and controls must be observed.

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 10/68
2.13 Crushing and cutting zones
Beware of crushing and cutting zones between e.g. the projection profile and the cassette, the
distance rope and the projection profile, the projection profile and the cross members of the roof
vents, as well as profiles that come into contact with each other. Beware of clothing and/or limbs
getting caught in the unit and pulled in!
If the sun protection system is installed at a height of less than 2.5 metres, the system may only
be operated using a key switch with all moving parts in sight. Electrical controls, radio controls
with latch switches, stand-alone latch switches, etc. are not permissible here.
The key switch must be fitted in the line of sight of the projection profile, but far enough removed
from the moving parts, at a height of 1.5 metres (national regulations relating to disabled people
must be observed).
2.14 Note on the generation of noises (creaking) on the system in the event of
temperature changes !
Noises which occur on the system after proper assembly and/or
maintenance are unavoidable and are mostly due to the expansion of
components due to the effect of heat.
•Ensure stress-free assembly when screwing the individual components together
in order to minimise subsequent noise generation, particularly in the event of
temperature influences!
2.15 Handover
All operating manuals as well as the manufacturer's installation and adjustment instructions for
motors, switches and controls must be handed to the user who must be instructed in the
operation of the unit. Detailed instruction on the safe and proper operation of the sun protection
system must be given.
If this is not adhered to and the sun protection system is operated incorrectly, the system may be
damaged or accidents may occur.
The instructions must be kept by the customer and passed on to the new owner if ownership of
the sun protection system passes to a third party.
After noting the on-site structural conditions and completing installation, the installation firm is to
inform the user whether the wind resistance class given by the manufacturer was achieved when
the sun protection system was installed. If not, the installation firm must record the wind
resistance class actually achieved.
Automatic controls must be set to this level.
The customer must confirm to the technician in writing that the sun protection system is the right
model and has been installed correctly, indicating the installation time, and that final acceptance
of the system has taken place during which the safety instructions were discussed (see
Handover section).

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 11/68
3 Product description
3.1 Schematic diagram
Figure 1: Schematic diagram of the Sottezza II Stretch
1
Headplate bracket
5
LED spotlight
2 Side channel bracket 6 Cassette
3
Side channel
7
Fabric
4 Projection profile
Figure 2: Schematic diagram of the Sottezza II OptiStretch
1
Headplate bracket
5
LED spotlight
2 Side channel bracket 6 Distance rope
3
Side channel
7
Cassette
4 Projection profile 8 Fabric

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 12/68
4 Installation
4.1 Safety instructions
Danger due to missing or incorrect fixings and pre-tensioned rope clamping system.
Check before beginning the installation work
•that the fixings supplied are of the same type and of the same quantity as ordered.
•that the pre-tensioned rope clamping system is in the correct position and is fixed securely.
If any deviations are found which pose a safety risk, do not carry out the installation work.
•A gap of 40 mm to the wall is required at the back in order to attach the Sottezza II to
the headplate brackets.
•The same gap between the unit and the wall applies to the option with the light.
Figure 3: Gap between the Sottezza II and the wall
DANGER

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 13/68
4.2 Installation on a weinor patio roof without Sottezza II provision
Figure 4: Side view of the Sottezza II
Figure 5: Drill hole positions
Distance between centre lines A
Distance between centre lines A
Cassette width K
Projection

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 14/68
Installing the headplate brackets
•Before beginning the installation work, check that the substructure is square and that
it has adequate load-bearing capacity.
•In the case of a third-party roof or a weinor roof without Sottezza II bracket provision,
attachment screws for the brackets must be chosen in accordance with the structural
conditions and requirements. They must always be sealed so that no rainwater can
get inside.
•The prescribed number of brackets must be used as a minimum.
•In the case of the Sottezza II, the standard installation is always indented so that side
glazing elements can be retrofitted.
1.
Drill template 1 (headplate brackets)
•"Drill template 1" (headplate brackets)
is supplied pre-punched.
•If it is missing, there is a drill template
which can be cut out on page 55.
•"Drill template 1" (headplate brackets)
is designed for use with both the
indented standard installation for side
glazing elements (in this case, fold
towards the printed side) and the non-
indented installation when there are no
side glazing elements (in this case, fold
towards the non-printed side).
•It can also be used on both the left and
right side of the unit if folded
accordingly.
CAUTION:
"Drill template 1" (headplate brackets) is
only suitable for third-party roofs to a
certain extent. The spacing of the drill holes
in the direction of the projection can be
used. This is not suitable in the case of
installation with the 100x30 mm rectangular
profile or the fixing plates.

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 15/68
•In the case of a weinor patio roof with Sottezza II provision, the headplate/side
channel brackets can be screwed in place directly. The fixing slider is sealed in place
in the roof support at the factory.
•When fixing the headplate/side channel brackets to a weinor patio roof with 4.8x16
filister-head self-tapping screws, max. 3.8 mm holes must be drilled. There is no fixing
slider. The fixings must be sealed (see point "Sealing the fixings"). In the case of
retrofitting, 4 4.8x16 filister-head self-tapping screws are required for the headplate
bracket.
•In the case of third-party roofs, suitable screws for installation on site have to be
selected. The recommended maximum screw head diameter is 9.5 mm.
2a.
Using the drill template to drill holes for
the headplate brackets (indented
standard installation for side glazing
elements)
CAUTION:
Check the width, projection and installation
position of the unit first.
1. The drill hole positions for the
headplate brackets can be marked
using the supplied "drill template 1"
(headplate brackets) (1).
2. "Drill template 1" (headplate brackets)
must be placed on the inside of the left
(A) or right (B) roof support in the case
of "indented standard installation".
3. The gap between the Sottezza II and
the wall is already specified as 40 mm
in the drill template
4. Mark the drill hole position for the
headplate brackets on the bottom side
of the roof support, then punch and drill
the hole.
5. Remove accumulated drilling chips.
Left-hand side
of the unit
Right-hand
side of the unit
A
B
Inside the
roof support
Photo of an indented unit (left-
hand side of the unit)
Drill hole
position on the
roof support

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 16/68
3a.
Installing the headplate brackets with
socket head cap screws (indented
standard installation for side glazing
elements)
1. Place the 60x8x3 mm fixing slider (1)
on top of the two drill holes in the roof
support (2), hold the headplate bracket
(3) in place on the roof support (2) from
below (opening for the fixing slider must
point towards the guttering) and screw
in place with the two M5 hexagon
socket head cap screws (4).
2. If necessary, the headplate bracket (3)
can be aligned before it is screwed into
place (using the stop bracket).
3. The drill holes are repeated on the
other side of the untrussed roof.
CAUTION:
In the case of weinor roofs, the thickness of
the glazing elements must not exceed 50
mm if they are to be installed directly on the
roof support.
Note:
Alternative screw position
(This only applies in the case of indented
standard installation for side glazing
elements)
1. It is possible to use a spacing of 6.5
mm instead of 17 mm when drilling into
the sealing groove of the roof support.
Do not drill deeper than 10 mm.
The drill template provided is not
applicable in this instance.
2. Two of the self-tapping screws
provided are used per bracket.

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 17/68
2b.
Using the drill template to drill holes for
the headplate brackets (non-indented
installation when there are no side
glazing elements)
CAUTION:
Check the width, projection and installation
position of the unit first.
1. The drill hole positions for the
headplate brackets can be marked
using the supplied "drill template 1"
(headplate brackets) (1).
2. "Drill template 1" (headplate brackets)
must be placed on the outside of the
left (A) or right (B) roof support in the
case of "non-indented" installation.
3. The gap between the Sottezza II and
the wall is already specified as 40 mm
in the drill template
4. Mark the drill hole position for the
headplate brackets on the bottom side
of the roof support, then punch and drill
the hole.
5. Remove accumulated drilling chips.
Outside of the
roof support
A
B
Left-hand side
of the unit
Right-hand side
of the unit
Photo of a non-indented unit
(left-hand side of the unit)
Drill hole
position on the
roof support

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 18/68
3b.
Installing the headplate brackets (non-
indented installation when there are no
side glazing elements)
1. Place the 60x8x3 mm fixing slider (1) on
top of the two drill holes in the roof
support (2), hold the headplate bracket
(3) in place on the roof support (2) from
below (opening for the fixing slider must
point towards the guttering) and screw in
place with the two M5 hexagon socket
head cap screws (4).
2. If necessary, the headplate bracket (3)
can be aligned before it is screwed into
place (using the stop bracket).
3. The drill holes are repeated on the other
side of the untrussed roof.
The following points apply to "indented standard installation for side glazing elements" and to
"non-indented installation when there are no side glazing elements":
Sealing the fixings
The screw connections between the
headplate brackets and the water guiding
grooves in the roof support should be
sealed from above using adhesive and
sealant when installation is complete, a test
run has been performed and it is certain
that the fixings do not need to be realigned.
The illustration shows the indented
standard version of the Sottezza II (with
fixing slider and socket head cap screws)
for side glazing elements. In the case of the
non-indented version of the Sottezza II, the
sealing point is on the opposite side of the
roof support.
When using filister-head self-tapping
screws, these must also be sealed either
by applying the sealant directly to the
thread or into the drill hole in the roof
support.
Screwing the filister-head self-tapping
screws into place
If the brackets are installed with filister-
head self-tapping screws, each of the
headplate brackets must be fixed in place
with 4 screws. The two screws in the long
slots 1must be tightened before drilling the
other two holes in the roof support. Finally,
the two screws on the inside 2are screwed
into place in the roof support.
Adhesive
and
sealant
Seal the slider with
adhesive and
sealant in such a
way that water can
still flow past in the
roof support groove
(view of the roof
support from above)
1
2
2
1

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 19/68
Installing the side channel brackets
The distance between centre lines of the side channels must be checked.
Check the cassette width in relation to the distance between the side channel brackets.
1.
Drill template 2 (side channel brackets)
•"Drill template 2" (side channel
brackets) is supplied pre-punched.
•If it is missing, there is a drill template
which can be cut out on page 56.
•"Drill template 2" (side channel
brackets) is designed for use with both
the indented standard installation for
side glazing elements (in this case, fold
towards the printed side) and the non-
indented installation when there are no
side glazing elements (in this case, fold
towards the non-printed side).
•It can also be used on both the left and
right side of the unit if folded
accordingly.
CAUTION:
"Drill template 2" (side channel brackets) is
only suitable for third-party roofs to a
certain extent. The spacing of the drill holes
in the direction of the projection can be
used. This is not suitable in the case of
installation with the 100x30 mm rectangular
profile or the fixing plates.
If there are barriers in the area of the
guttering, the spacing of 20 mm to the
guttering cannot be adhered to. This
spacing must be increased accordingly and
cannot be created using "drill template 2"
(side channel brackets).

Sottezza II Stretch/LED / Sottezza II OptiStretch/LED
Instructions for assembly
Version 11
2021-03-23
We reserve the right to make technical changes
Item number
118078-0000
Page 20/68
•In the case of a weinor patio roof with Sottezza II provision, the headplate/side
channel brackets can be screwed in place directly. The fixing slider is sealed in place
in the roof support at the factory.
•When fixing the headplate/side channel brackets with filister-head self-tapping
screws, max. 3.8 mm holes must be drilled.
There is no fixing slider. The fixings must be sealed (see point "Sealing the fixings").
•In the case of third-party roofs, suitable screws for installation on site have to be
selected. The recommended maximum screw head diameter is 9.5 mm.
2a.
Using the drill template to drill holes for
the side channel brackets (indented
standard installation for side glazing
elements)
Note:
The first side channel bracket is always
100 mm away from the outside edge of the
end cap on the side channel.
1. The drill hole positions for the side
channel brackets can be marked using
the supplied "drill template 2" (side
channel brackets) (1).
2. "Drill template 2" (side channel
brackets) must be placed on the inside
of the left (A) or right (B) roof support in
the case of "indented standard
installation".
3. "Drill template 2" includes 20 mm
spacing from the end cap to the
guttering.
4. Mark the drill hole position for the side
channel brackets on the bottom side of
the roof support, then punch and drill
the hole.
5. Remove accumulated drilling chips.
6. Mark the positions of the other (in the
case of a large projection) side channel
brackets so that they are more or less
evenly spaced in relation to the other
brackets over the length of the roof
support.
7. Place "drill template 2" (side channel
brackets) in position (cut to size if
necessary), mark the drill hole position
on the bottom side of the roof support,
then punch and drill the hole.
Inside the roof
support
A
B
Photo of an indented unit (left-
hand side of the unit)
Left-hand side of
the unit
Right-hand side
of the unit
Drill hole position on
the roof support
