Wells BWB-1S User manual

WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, P. O. Box 280
Verdi, NV 89439
Customer Service [phone] Ext.502
fax: [phone]
www.wellsbloomfield.com
P/N 45257 Rev. D M211 111500 cps
OPERATION
MANUAL
for
BELGIAN
WAFFLE
BAKER
Model
BWB-1S
includes:
INSTALLATION,
OPERATION
and
PREVENTATIVE
MAINTENANCE
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the BELGIAN WAFFLE BAKER
and is to be given to the OWNER or MANAGER of the restaurant, or to
the person responsible forTRAINING OPERATORS of this WAFFLE
BAKER. Additional manuals are available from your Wells Dealer.
THISMANUALMUSTBEREADANDUNDERSTOODBYALLPERSONS
USING OR INSTALLING THIS BELGIAN WAFFLE BAKER.
ContactyourWellsDealer if you have anyquestionsconcerning
installation, operation or maintenance of this appliance.
211

Allcommercial cooking equipment manufactured by
WELLS MFG. CO. is warranted against defects in
materials and workmanship for a period of one year
from the date of original installation or 18 months
from the date of shipment from our factory, which-
ever comes first, and is forthe benefit of the origi-
nal purchaser only.
THISWARRANTYISTHECOMPLETEANDONLY
WARRANTY, EXPRESSED OR IMPLIED IN LAW
OR IN FACT, INCLUDING BUT NOT LIMITED TO,
WARRANTIES OF MERCHANTABILITY OR FIT-
NESS FOR ANY PARTICULAR PURPOSE, AND/
OR FOR DIRECT, INDIRECT OR CONSEQUEN-
TIAL DAMAGES IN CONNECTION WITH WELLS
MFG. CO. PRODUCTS. This warranty is void if it is
determined that, upon inspection by an authorized
service agency, the equipment has been modified,
misused, misapplied, improperly installed, or dam-
aged in transit or by fire, flood or act of God. It also
does not apply if the serial nameplate has been re-
moved, or if service is performed by unauthorized
personnel.
The prices charged by Wells Mfg. Co.for its prod-
ucts are based upon the limitations in this warranty.
Seller’s obligation under this warranty is limited to
the repair of defects without charge by a Wells Mfg.
Co. factory authorized service agency or one of its
sub-service agencies. This service will be provided
on customer’s premises for non-portable models.
Portablemodels(adevicewith acordand plug)must
be taken or shipped to the closest authorized ser-
viceagency,transportationchargesprepaid,forser-
vice. Inadditiontorestrictions contained in this war-
ranty, specific limitations are shown in the Service
Policy and Procedure Guide. Wells Mfg. Co. autho-
rizedservice agencies are located in principalcities.
This warranty is valid in the United States and
Canada and void elsewhere. Please consult your
classified telephone directory, your food service
equipment dealer, or write the Factory Service De-
partment, Wells Manufacturing Company, P.O. Box
280, Verdi, Nevada 89439, phone [phone]
or [phone], for information and other details
concerning warranty.
LIMITED WARRANTY STATEMENT
SERVICE POLICY AND PROCEDURE GUIDE
ADDITIONAL WARRANTY EXCLUSIONS
1. Resetting of safety thermostats, circuit breakers, overload protectors, and/or fuse replacements are not covered by this warranty unless
warranted conditions are the cause.
2. All problems due to operation at voltages or phase other than specified on equipment nameplates are not covered by this warranty.
Conversion to correct voltage and/or phase must be the customers responsibility.
3. All problems due to electrical connections not made in accordance with electrical code requirements and wiring diagrams
supplied with the equipment are not covered by this warranty.
4. Calibration of heat controls after the first sixty (60) days on original equipment; replacement of items subject to normal wear, to include
such items as knobs, light bulbs; and, normal maintenance functions including adjustments of thermostats, adjustment of micro switches
and replacement of fuses and indicating lights are not covered by warranty.
5. All welding of components in the field is not covered by warranty.
6. Deterioration of aluminum components due to the insertion of metal implements or use of abrasive cleaners is not covered by warranty.
7. Full use, care, and maintenance instructions are supplied with each machine. Noted maintenance and preventative maintenance items,
such as servicing and cleaning schedules, are customer responsibility. Those miscellaneous adjustments noted are customer
responsibility. Proper attention to preventatve maintenance and scheduled maintenance procedures will prolong the life of the machine.
8. Travel mileage is limited to sixty (60) miles from an Authorized Service Agency or one of its sub-service agencies.
9. All labor shall be performed during regular working hours. Overtime premium will be charged to the buyer.
10. All genuine Wells replacement parts are warranted for ninety (90) days from date of purchase on non-warranty equipment. This parts
warranty is limited only to replacement of the defective part(s). Any use of non-genuine Wells parts completely voids any warranty.
11. Installation, labor, and job check-outs are not considered warranty and are thus not covered by this warranty.
12. Charges incurred by delays, waiting time or operating restrictions that hinder the service technician’s ability to perform service are not
covered by warranty. This includes institutional and correctional facilities.
SHIPPING DAMAGE CLAIM PROCEDURE
NOTE: For your protection, please note that equipment in this shipment was carefully inspected and packaged by skilled personnel before
leaving the factory. Upon acceptance of this shipment, the transportation company assumes full responsibility for its safe delivery.
IF SHIPMENT ARRIVES DAMAGED:
1. VISIBLE LOSS OR DAMAGE: Be certain that any visible loss or damage is noted on the freight bill or express receipt, and that
the note of loss or damage is signed by the delivery person.
2. FILE CLAIM FOR DAMAGE IMMEDIATELY: Regardless of the extent of the damage.
3. CONCEALED LOSS OR DAMAGE: if damage is unnoticed until the merchandise is unpacked, notify the transportation company
or carrier immediately, and file “CONCEALED DAMAGE” claim with them. This should be done within fifteen(15) days from the
date the delivery was made to you. Be sure to retain the container for inspection.
Wells Manufacturing cannot assume liability for damage or loss incurred in transit. We will, however, at your request, supply you with the
necessary documents to support your claim. xi

TABLE OF CONTENTS
Warranty InsideCover
Specifications 1
Featuresand OperatingControls 2
SafetyProcedures 3
InstallationInstructions 4
OperatingInstructions 6
PreventativeMaintenanceProcedures
TimerAdjustment 7
DailyCleaning 7
RemovingExcessCarbonBuild-Up 8
Troubleshooting 9
PartsandService 10
GENERAL SPECIFICATIONS
DIMENSIONS
Wide 10-1/8”
Deep 14”
High 10-9/16”
ELECTRICAL
Voltage 120 VAC 1Ø
Amperage 7.5Amp
Wattage 900 W
ElectricalPlugConfiguration NEMA 5-15P
1

2
FEATURES & OPERATING CONTROLS
8. POWER CORD 115VAC. NEMA 5-15P Plug
9. DATA PLATE Identifies Manufacturer, Model & Serial numbers;
gives voltage rating.
17. HANDLE ASSEMBLY Used to raise/lower top lid and to rotate grids for cooking.
18. SUPPORT BRACKET Supportsfront of grids.
19. HOLE PLUG ASSEMBLY Covers and protects timer control.
20. GRID COVER Covers and protects electrical wiring in grid.
28. INDICATOR LIGHT When lit, indicates timer is in “cook” cycle.
40. PIVOT ASSEMBLY Supports back of grids, allows grids to rotate for cooking.
41. RUBBER FOOT Non-skid support for baker; allow adjustments for levelling.
42. LOWER GRID ASSEMBLY Cooking element (grid); contains temperature control sensor.
43. UPPER GRID ASSEMBLY Cooking element (grid).
48. TIMER Sounds audible alarm to warn operator at end of bake cycle.
66. POWER SWITCH Energizes/de-energizesthe baker.
75. DRIP TRAY Catches batter drippings for easier clean-up.
.1
1
234
5
6
66
18
28
42
43
17
8
9
19
48
20
40
41
FRONT VIEW
RIGHT SIDE VIEW
BACK VIEW
shown in “cook” position
shown in “open” position
17
75

3
SAFETY PROCEDURES
Knowledgeof proper procedures isessential to the safeoperation of electrically energizedequipment. In
accordancewith generally accepted productsafety labeling guidelines forpotential hazards, the following
signal words and symbols are used throughout this chapter.
DANGER - Danger is used to indicate the presence of a hazard which will cause
severe personal injury, death, or substantial property damage in the event the state-
ment is ignored.
WARNING - Warning is used to indicate the presence of a hazard which can cause
personal injury, possible death or major property damage in the event the statement is
ignored.
CAUTION - Caution is used to indicate the presence of a hazard which will or can
cause minor personal injury, or property damage in the event the statement is
ignored.
NOTE -Note isused tonotify personnelofinstallation, operationor maintenanceinformation
which is important, but not hazardrelated.
DANGER
WARNING: All servicing requiring access to non-insulated electrical components
must be performed by a qualified service technician. Do not open any access panels
whichrequirethe useoftools. Failure tofollowthese directionscanresult inelectrical shock.
NOTE: Thismanualshouldbeconsideredapermanantpartofthis appliance. This
manualmustremainwiththeapplianceifitis sold or moved to another location.
CAUTION: DO NOT plug in or energize this appliance until Installation
Instructions are read and followed. Injury to the operator and damage to the Waffle
Baker may occur if these instructions are not followed.
CAUTION: ThisWellsBelgianWaffleBakerisequippedwith
athree-prongelectricalplug. Thethree-prongplugispartofa
systemthatwill protect youintheeventofan electrical wiring
failure. Besurethe three-prong plug isplugged into a matchingand
properlygroundedthree-prongreceptacle. DONOTcutorbreak
offthe ground prong ofthis plug.
OPERATING AN APPLIANCE WITHOUT PROPER GROUNDING
CAN RESULT IN SERIOUS PERSONAL INJURY
IMPORTANT: Makesurethat the incoming voltageisthe same astheunit is rated for. See
thedataplate on the back ofthewaffle baker for thespecifiedvoltage and wattage.
WARNINGS AND GENERAL PRECAUTIONS
Thisapplianceis intended for useincommercial establishments to cookfoodfor human consumption.
Nootheruseisrecommendedorauthorizedby the manufacturer or its agents.
GROUND
PRONG

4
C. EQUIPMENT SET-UP
1. Setup the Waffle Baker only on a firm, level surface. The area around the Waffle Baker must be
kept clear of combustible or flammable materials.
2. Verify that the four RUBBER FEET are in place on the bottom of the Waffle Baker legs.
3. LEVELING: Verify that the Waffle Baker sits firmly ON ALL FOUR RUBBER FEET. With a spirit
level, check that the Waffle Baker is level front-to-back and side-to-side. Adjust the rubber feet as
necessary to level the Waffle Baker.
4. Verify the voltage of the receptacle matches the nameplate voltage before plugging in the power
cord.
IMPORTANT: Plugging the Waffle Baker into greater voltage than its rating may damage internal
components. Plugging the Waffle Baker into lesser voltage than its rating will cause a significant
decreasein performance.
5. Certain codes require specific ventilation and access requirements. It is the RESPONSIBILITY OF
THE INSTALLER to check with the AUTHORITY HAVING JURISDICTION, in order to ascertain
the applicability of these requirements to THIS SPECIFIC BELGIAN WAFFLE BAKER INSTALLATION.
INSTALLATION INSTRUCTIONS
A. UNPACKING AND INSPECTION
1. Carefully remove the Waffle Baker from the carton. Remove all protective plastic film, packaging
materials and accessories from the Waffle Bakerbefore connecting electrical power or otherwise
performingany installation procedures.
NOTE: DO NOT discard the CARTON and other PACKAGING MATERIAL until you have
inspected the Belgian Waffle Baker for hidden damage and tested it forPROPER OPERATION.
Refer to SHIPPING DAMAGE CLAIM PROCEDURE on the inside front cover of this manual.
2. Read all instructions in this manual carefully before starting installation of this Waffle Baker.
READ AND UNDERSTAND ALL LABELS AND DIAGRAMS ATTACHED TO THE
WAFFLE BAKER.
3. Carefully account for all components and accessories before discarding packing materials.
Store the accessories in a convenient place for later use:
WARNING: DO NOT ATTEMPT to operate this Belgian Waffle Maker without the
rubber feet installed. The rubber feet provide non-skid support to allow the Waffle
Baker to operate without shifting or “walking”. Operating the Waffle Baker without
the rubber feet may result in serious injury to the operator.

5
D. SEASONING THE GRIDS
1. Lightly spray commercial waffle baker spray on both grid surfaces.
2. Carefully close the upper grid. Turn the power switch to theON position and allow the Waffle Baker
to pre-heat for at least twenty (20) minutes.
3. Using the handle, lift the upper grid and lightly re-coat both grid surfaces with commercial waffle
baker spray. Lower the upper grid.
4. The grids are now seasoned, and the Waffle Baker is ready to use.

6
OPERATING INSTRUCTIONS
A. PRE-HEAT
1. Turn the power switch to the ON position.
2. With the upper lid closed, allow the Waffle Baker to pre-heat for twenty (20) minutes in order to
allow the grids to reach the proper baking temperature.
B. ADD BATTER
1. Using the handle, lift the upper lid.
2. Pour the desired amount of Belgian Waffle Batter on the lower grid.
C. COOK
1. Using the handle, carefully close the upper lid. Rotate the grid assembly 180º clockwise until the
detent is engaged. This rotation will automatically activate the solid state timer. The indicator light
will come on, and will stay on for the duration of the “cook” cycle.
Note: Factory set for 3 min, adjustable for .1 to 6 minutes. See page 7 for TIMER ADJUSTMENT
PROCEDURE.
2. Allow the waffle to cook IN THE INVERTED POSITION.
3. At the end of the time delay (pre-set at the factory for 3 minutes), the buzzer will sound for a short
interval. At the end of the interval, both the buzzer and indicator light will shut-off.
4. Using the handle, rotate the grid assembly counter-clockwise 180º until the detent is engaged.
Raise the upper lid and remove the waffle from the grid.
IMPORTANT: The timer is ONLY A WARNING DEVICE and DOES NOT TURN THE ELEMENT
ON or OFF. Remove the waffle promptly when the buzzer sounds.
D. OPERATING HINTS
1. Return the upper lid to the closed position between baking periods for optimum baking performance
and to minimize carbon deposit build-up.
2. Use a soft-bristle brush to lightly brush and clean the Waffle Baker whenever waffle residue is
present on the grids.
3. Waffle grids should be re-seasoned after every 3 to 4 waffles to guard against waffles sticking to the
grids. Follow steps 3 thru 4 in the SEASONING THE GRID section. Seasoning interval may be
extended by adding oil or butter to the waffle mix.
4. Always use fresh batter which contains sufficient shortening. Add shortening if required and do not
storebatter over prolongedperiods oftime.
5. Frequent cleaning with a soft-bristle brush, and grid re-seasoning during operation will ensure a
perfect, great-tasting Belgian Waffle every time.
6. Every second or third waffle,lightly spray commercial waffle baker spray on the grids.
7. If the Waffle Baker is left on but idle for over an hour,lightly spray commercial waffle baker spray on
the grids prior to baking the next waffle.
8. NEVER apply beeswax, parafin, etc. to the grid surfaces.
9. NEVER use sharp implements (i.e. knives, forks, metal tongs) to remove waffles from the grid.

7
PREVENTATIVE MAINTENANCE PROCEDURES
A. TIMER ADJUSTMENT
TOOLS REQUIRED: Flat Blade Screwdriver - 1/32” x 1/8”
NOTE: The necessity to increase baking time may be due to carbon build-up on the grids. Always clean
and de-carbonize the grids prior to adjusting the timer.
1. Remove the hole plug from the rear panel of the Waffle Baker. DO NOT remove the hole plug from
theattached grounding wire.
2. Using the screwdriver, rotate the adjusting knob:
clockwise to increase time, or
counter-clockwiseto decrease time.
B. DAILY CLEANING PROCEDURE
1. Allow the Waffle baker to cool to room temperature.
2. Clean grids by using a soft-bristle brush to remove all excess waffle residue.
3. Clean the outside of the Waffle Baker by wiping it with a soft, clean cloth, warm water and a mild
soap or detergent. NEVER USE AN ABRASIVE CLEANSER.
4. Always re-season the grids after cleaning.
.1
12345
6
MINUTES
.1
1
234
5
6
BACK
VIEW
CAUTION - ELECTRICAL SHOCK HAZARD
DO NOT SUBMERGE THE WAFFLE BAKER IN WATER.
If internal components become wet, the operator may suffer electrical shock,
and the Waffle Baker will be damaged.

8
C. REMOVING EXCESS CARBONIZATION
Use this procedure to clean any black residue (carbonization) remaining on the grids
after the daily cleaning. Grids must be cleaned to remove the black residue, then re-seasoned, to
ensure maximum Belgian Waffle Baker performance.
1. Allow the Belgian Waffle Baker to cool to room temperature.
2. Liberally apply a commercial carbon cleaning solution to the grids with a new 1” paint brush. Be
extremely careful when applying thecarbon cleaning solution on the grid surfaces. DO NOT spill
any carbon cleaning solution or other caustic cleaning product on yourself or on the area in which
you areworking.
IMPORTANT: Read and follow all manufacturer’s instructions when using commercial carbon
cleaners. Carbon cleaner can be hazardous. It is the operator’s responsibility to use the product
safely, in the manner directed by the carbon cleaner manufacturer.
3. Close the upper lid and allow the Waffle Baker to stand for several hours, or overnight, depending
uponthe extent ofthe carbonization.
4. Thoroughly remove the carbon cleaning solution and black residue using a fiber brush. Wipe down
the grid surfaces carefully and thoroughly with water. It is important that all carbon cleaning solution
is removed.
IMPORTANT: Make certain water and cleaner are not allowed to get into internal parts. The Waffle
Baker will be damaged if internal components are allowed to get wet.
5. Clean the outside of the Waffle Baker by wiping it down with a clean cloth, warm water and a mild
detergent or soap. NEVER USE AN ABRASIVE CLEANSER.
6. Dry the Waffle Baker with a clean, dry cloth. Always re-season the grids after de-carbonizing.
CAUTION - ELECTRICAL SHOCK HAZARD
DO NOT SUBMERGE THE WAFFLE BAKER IN WATER.
If internal components become wet, the operator may suffer electrical shock,
and the Waffle Baker will be damaged.
CHEMICAL BURN HAZARD
CAUTION:
WAFFLE IRON CLEANER CAN CAUSE SERIOUS BURNS
ON CONTACT.
WEAR PROTECTIVE CLOTHINGAND SAFETY GLASSES WHEN
USING WAFFLE IRON CLEANER.
Carefullyreadand followdirectionsandwarningsonthe label.

9
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE REMEDY
WILL NOT HEATPower switch not ON Turn switch to ON position
Power cord not plugged in Plug power cord into an energized
120V receptacle
Circuit breaker tripped Reset circuit breaker
Hi-Limit tripped Contact an Authorized Wells Service
Agency for repairs
Internalcomponent damage Contact an Authorized Wells Service
Agency for repairs
DOES NOT MAINTAIN Excessivecarbonization of grids Clean grids
TEMPERATURE Internalcomponent damage Contact an Authorized Wells Service
Agency for repairs
TRIPS CIRCUIT Too many appliances on circuit Re-distribute appliances
BREAKER Havea licensedelectrician
install a dedicated 20 Amp circuit
Internalcomponent damage Contact an Authorized Wells Service
Agency for repairs
ALL OTHER Internalcomponent damage Contact an Authorized Wells Service
PROBLEMS Agency for repairs

10
CUSTOMER SERVICE DATA
please have this information available if calling for service
RESTAURANT_____________________________ LOCATION _______________
INSTALLATIONDATE ________________________TECHNICIAN_____________
SERVICECOMPANY__________________________________________________
ADDRESS___________________________STATE______ ZIP__________
TELEPHONENUMBER(_____)_____-_________
EQUIPMENTMODEL NO.______________________________________________
EQUIPMENTSERIALNO.______________________________________________
VOLTAGE: (check one)120V 208V 240V
NOTE: Accessory Parts, as well as factory authorized service, are available from your WELLS
AUTHORIZED SERVICE AGENCY.
Wells Manufacturing Co., Service Parts Department
2 Erik Circle, P.O.Box 280
Verdi, NV 89439
phone: [phone] Ext 504 fax: [phone]
Service Parts Department can supply you with the name / telephone number of the WELLS
AUTHORIZED SERVICE AGENCY nearest you.
ACCESSORIES
DESCRIPTION PART #
DRIP TRAY, BWB-1S 21107
RUBBER FEET (pk 4) 21657
PARTS and SERVICE

11
NOTES

WELLS MANUFACTURING COMPANY
2 ERIK CIRCLE, P. O. Box 280
Verdi, NV 89439
Customer Service [phone] Ext. 502
fax: [phone]
www.wellsbloomfield.com
