Wenglor P1KK008 User manual

Operating Instructions
EN
Translation of the Original Operating Instruction
Subject to change without notice
Available as PDF version only
Version: 1.5.0
Status: 07.12.2023
www.wenglor.com
P1KKxxx
Retro-Reex Sensors for Transparent Objects
High-End with Teach-in

2Table of Contents
Table of Contents
1. General��������������������������������������������������������������������������������������������������������������������������������������3
1.1 Information Concerning these Instructions .............................................................................................3
1.2 Explanations of Symbols ........................................................................................................................3
1.3 Limitation of Liability ...............................................................................................................................4
1.4 Copyrights...............................................................................................................................................4
2. For Your Safety ������������������������������������������������������������������������������������������������������������������������5
2.1 Use for Intended Purpose.......................................................................................................................5
2.2 Use for Other than the Intended Purpose...............................................................................................5
2.3 Personnel Qualifications .........................................................................................................................6
2.4 Modification of Products .........................................................................................................................6
2.5 General Safety Precautions....................................................................................................................6
2.6 Approvals and protection class...............................................................................................................6
3. Technical Data�������������������������������������������������������������������������������������������������������������������������� 7
3.1 Technical Data........................................................................................................................................7
3.1.1 Spot diameter...............................................................................................................................8
3.1.2 Smallest detectable part...............................................................................................................8
3.1.3 Switching distance .......................................................................................................................8
3.2 Complementary Products .......................................................................................................................9
3.3 Layout .....................................................................................................................................................9
3.4 Control Panel ........................................................................................................................................10
3.5 Scope of Delivery..................................................................................................................................10
4. Transport and Storage�����������������������������������������������������������������������������������������������������������10
4.1 Transport ..............................................................................................................................................10
4.2 Storage .................................................................................................................................................10
5. Installation and Electrical Connection���������������������������������������������������������������������������������11
5.1 Installation.............................................................................................................................................11
5.2 Electrical Connection ............................................................................................................................11
5.3 Diagnostics ...........................................................................................................................................12
6. Settings�����������������������������������������������������������������������������������������������������������������������������������14
7� I/O-Link������������������������������������������������������������������������������������������������������������������������������������14
7.1 Teach-In Mode......................................................................................................................................14
7.1.1 Minimal Teach-In (default setting)..............................................................................................14
7.1.2 Normal Teach-In ........................................................................................................................14
7.2 Dynamic readjustment ..........................................................................................................................14
7.3 Pin Function, E/AO2 .............................................................................................................................15
7.3.1 Input External Teach-In..............................................................................................................15
7.3.2 Error Output ...............................................................................................................................15
7.4 Additional functions and settings via IO-Link ........................................................................................16
8� I/O-Link������������������������������������������������������������������������������������������������������������������������������������16
9� Maintenance Instructions������������������������������������������������������������������������������������������������������16
10. Proper Disposal��������������������������������������������������������������������������������������������������������������������� 16
11� Appendix���������������������������������������������������������������������������������������������������������������������������������17
11.1 List of Abbreviations ...........................................................................................................................17
11.2 Change Index, Operating Instructions ................................................................................................17
11.3 Declarations of Conformity .................................................................................................................17

3Retro-Reflex Sensors for Transparent Objects
1� General
1�1 Information Concerning these Instructions
• These instructions apply to the product with ID code P1KKxxx.
• They make it possible to use the product safely and efficiently.
• These instructions are an integral part of the product and must be kept on hand for the entire duration of its
service life.
• Local accident prevention regulations and national work safety regulations must be complied with as well.
• The product is subject to further technical development, and thus the information contained in
these operating instructions may also be subject to change. The current version can be found at
www.wenglor.com in the product’s separate download area.
NOTE!
The operating instructions must be read carefully before using the product and must be kept
on hand for later reference.
1�2 Explanations of Symbols
• Safety precautions and warnings are emphasized by means of symbols and attention-getting words
• Safe use of the product is only possible if these safety precautions and warnings are adhered to
The safety precautions and warnings are laid out in accordance with the following principle:
Attention-Getting Word!
Type and Source of Danger!
Possible consequences in the event that the hazard is disregarded.
• Measures for averting the hazard.
The meanings of the attention-getting words, as well as the scope of the associated hazards, are listed below.
DANGER!
This word indicates a hazard with a high degree of risk which, if not avoided, results in death
or severe injury.
WARNING!
This word indicates a hazard with a medium degree of risk which, if not avoided, may result
in death or severe injury.
CAUTION!
This word indicates a hazard with a low degree of risk which, if not avoided, may result in
minor or moderate injury.
ATTENTION!
This word draws attention to a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTE!
A note draws attention to useful tips and suggestions, as well as information regarding effi-
cient, error-free use.

4General
1�3 Limitation of Liability
• The product has been developed in consideration of the current state-of-the-art and applicable standards
and guidelines. Subject to change without notice.
• A valid declaration of conformity can be accessed at www.wenglor.com in the product’s separate download
area.
• wenglor sensoric elektronische Geräte GmbH (hereinafter referred to as “wenglor”) excludes all liability in
the event of:
• Non-compliance with the instructions
• Use of the product for purposes other than those intended
• Use by untrained personnel
• Use of unapproved replacement parts
• Unapproved modification of products
• These operating instructions do not include any guarantees from wenglor with regard to the described pro-
cedures or specific product characteristics.
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating
instructions, unless wenglor was verifiably aware of such errors at the point in time at which the operating
instructions were prepared.
1�4 Copyrights
• The contents of these instructions are protected by copyright law.
• All rights are reserved by wenglor.
• Commercial reproduction or any other commercial use of the provided content and information, in particular
graphics and images, is not permitted without previous written consent from wenglor.

5Retro-Reflex Sensors for Transparent Objects
2� For Your Safety
2�1 Use for Intended Purpose
The product is based on the following functional principle:
Retro-Reflex Sensors for Transparent Objects
Reflex sensors for transparent objects can be adjusted so precisely that they can reliably recognize highly
transparent objects such as glass, glass bottles or sheet products. Even shiny, chromed or reflective surfaces
can be reliably detected thanks to the integrated polarization filter.
The transmitter and receiver are located in a single housing and require a reflector to work. The output switch-
es if the light beam between the sensor and reflector is interrupted. The visible light spot of retro-reflex sensors
facilitates adjustment and commissioning. Depending on the sensor type, even small objects up to 0.1 mm can
be reliably detected over long distances.
This product can be used in the following industry sectors:
• Special machinery manufacturing
• Heavy machinery manufacturing
• Logistics
• Automotive industry
• Food industry
• Packaging industry
• Pharmaceuticals industry
• Plastics industry
• Woodworking industry
• Beverages industry
• Consumer goods industry
• Paper industry
• Electronics industry
• Glass industry
• Steel industry
• Aviation industry
• Chemicals industry
• Alternative energy
• Raw materials extraction
2�2 Use for Other than the Intended Purpose
• Not a safety component in accordance with 2006/42/EC (Machinery Directive).
• The product is not suitable for use in potentially explosive atmospheres.
• The product may only be used with accessories supplied or approved by wenglor, or combined with
approved products. A list of approved accessories and combination products can be accessed at
www.wenglor.com on the product detail page.
DANGER!
Risk of personal injury or property damage in case of use for other than the intended
purpose!
Use for other than the intended purpose may lead to hazardous situations.
• Observe instructions regarding use for intended purpose.

6For Your Safety
2�3 Personnel Qualifications
• Suitable technical training is a prerequisite.
• In-house electronics training is required.
• Trained personnel must have uninterrupted access to the operating instructions.
DANGER!
Risk of personal injury or property damage in case of incorrect initial start-up and
maintenance!
Personal injury and damage to equipment may occur.
• Adequate training and qualification of personnel.
2�4 Modification of Products
DANGER!
Risk of personal injury or property damage if the product is modified!
Personal injury and damage to equipment may occur. Non-observance may result in loss of
the CE and/or UKCA marking and the guarantee may be rendered null and void.
• Modification of the product is impermissible.
2�5 General Safety Precautions
NOTE!
• These instructions are an integral part of the product and must be kept on hand for the
entire duration of its service life.
• In the event of possible changes, the respectively current version of the operating
instructions can be accessed at www.wenglor.com in the product’s download area.
• Read the operating instructions carefully before using the product.
• Protect the sensor against contamination and mechanical influences.
2�6 Approvals and protection class

7Retro-Reflex Sensors for Transparent Objects
3� Technical Data
3�1 Technical Data
Order Number
Technical Data
P1KK
002 008 004 009
Optical Data
Range 2,000 mm
Reference reflector RQ100BA
Clear glass recognition yes
Switching hysteresis < 5 %
Light source Red light
Polarization filter yes
Service life (ambient temp. = +25° C) 100,000 h
Max. permissible ambient light 10,000 Lux
Aperture angle 3°
Single-lens optics yes
Spot diameter See table 1
Electrical Data
Supply power 10…30 V DC
IO-Link supply voltage 18…30 V DC
Current consumption (operating voltage = 24 V) < 20 mA
Switching frequency 1000 Hz
Switching frequency (speed mode) 2000 Hz
Response time 0,5 ms
Response time (speed mode) 0,25 ms
Temperature drift < 5 %
Temperature range −40…60 °C
Switching output voltage drop < 2 V
Switching output switching current 100 mA
Switching output residual current < 50 µA
Short-circuit protection yes
Reverse polarity protected yes
Overload-proof yes
Lockable yes
Interface IO-Link
IO-Link version 1.1
Protection class III
Output
function
PNP ×
NPN ×
NC, NO antivalent × ×
Mechanical Data
Setting method Teach-in
Housing material Plastic
Degree of protection IP67/IP68
Connection M8 × 1; 4-pin Cable,
4-wire, 2 m M8 × 1; 4-pin Cable, 4-wire, 2 m
Lens cover PMMA
Connection diagram 221 867 221 867

8Technical Data
3�1�1 Spot diameter
Range 0,5 m 1,3 m 2,0 m
Spot diameter 30 mm 100 mm 150 mm
Table 1
3�1�2 Smallest detectable part
Range 0,4 m 1 m 2 m
Smallest detectable part 2 mm 5 mm 8 mm
Table 2
3�1�3 Switching distance
Achievable switching distance depends on the utilized reflector. Nominal switching distance is achieved with
reflector types RQ100BA. Achievable ranges for other reflectors are listed in the following tables:
Reector Range
RQ100BA 0…2,00 m
RE18040BA 0…1,10 m
RQ84BA 0…1,60 m
RR84BA 0…1,90 m
RE9538BA 0…0,70 m
RE6151BM 0…1,50 m
RR50_A 0…1,05 m
RE6040BA 0…1,20 m
RE8222BA 0…0,85 m
RR34_M 0…1,00 m
RE3220BM 0…0,70 m
RE6210BM 0…0,45 m
RR25_M 0…0,55 m
RR25KP 0…0,30 m
RR21_M 0…0,50 m
ZRME01B01 0…0,25 m
ZRME03B01 0…0,90 m
ZRAE02B01 0…0,70 m
ZRMR02K01 0…0,35 m
ZRMS02_01 0…0,45 m
ZRAF08K01 0…0,40 m
ZRDF03K01 0…1,20 m
ZRDF10K01 0…1,30 m
RF505 0…0,40 m
RF508 0…0,40 m
RF258 0…0,40 m
Z90R004 0…0,70 m
Z90R005 0…1,00 m
Z90R006 0…1,00 m
NOTE!
In order to increase the stability in
the detection of highly transparent
objects, it is recommended to use
reflectors with micro structure.

9Retro-Reflex Sensors for Transparent Objects
3�2 Complementary Products
wenglor can provide you with suitable connection technology for your product.
Suitable mounting technology no.
Suitable connection technology no.
7
PNP-NPN converter BG7V1P-N-2M
IO-Link master
wTeach2 software DNNF005
3�3 Layout
P1KK002, P1KK004
P1KK008, P1KK009
1= Optical axis M3 screw = 0.5 Nm Dimensions specified in mm (1 mm = 0.03937”)

10 Transport and Storage
3�4 Control Panel
06 = teach-in key
30 = switching status indicator / contamination warning
68 = supply power indicator
3�5 Scope of Delivery
• Sensor
• Safety precautions
• Mounting-Set 01
4� Transport and Storage
4�1 Transport
Upon receipt of shipment, the goods must be inspected for damage in transit. In the case of damage, con-
ditionally accept the package and notify the manufacturer of the damage. Then return the device, making
reference to damage in transit.
4�2 Storage
The following points must be taken into condition with regard to storage:
• Do not store the product outdoors.
• Store the product in a dry, dust-free place.
• Protect the product against mechanical impacts.
• Protect the product against exposure to direct sunlight.
ATTENTION!
Risk of property damage in case of improper storage!
The product may be damaged.
• Storage instructions must be complied with.

11Retro-Reflex Sensors for Transparent Objects
5� Installation and Electrical Connection
5�1 Installation
• Protect the product from contamination during installation.
• Observe all applicable electrical and mechanical regulations, standards, and safety rules.
• Protect the product against mechanical influences.
• Make sure that the sensor is mounted in a mechanically secure fashion.
• Specified torque values must be complied with (see section “3. Technical Data”, page 7).
ATTENTION!
Risk of property damage in case of improper installation!
The product may be damaged.
• Installation instructions must be complied with.
CAUTION!
Risk of personal injury or property damage during installation!
Personal injury and damage to the product may occur.
• A safe installation environment must be assured.
5�2 Electrical Connection
Legend
Wire Colors according to IEC 60757
Platinum measuring resistor
not connected
Test Input
Test Input inverted
Trigger Input
Ground for the Trigger Input
Analog Output
Ground for the Analog Output
Block Discharge
Valve Output
Valve Control Output +
Valve Control Output 0 V
Synchronization
Ground for the Synchronization
Receiver-Line
Emitter-Line
Grounding
Switching Distance Reduction
Ethernet Receive Path
Ethernet Send Path
Interfaces-Bus A(+)/B(–)
Emitted Light disengageable
Magnet activation
Input confirmation
Contactor Monitoring
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Grey
White
Pink
Green/Yellow
Supply Voltage +
Supply Voltage 0 V
Supply Voltage (AC Voltage)
Switching Output (NO)
Switching Output (NC)
Contamination/Error Output (NO)
Contamination/Error Output (NC)
Input (analog or digital)
Teach Input
Time Delay (activation)
Shielding
Interface Receive Path
Interface Send Path
Ready
Ground
Clock
Output/Input programmable
Power over Ethernet
Safety Input
Safety Output
Signal Output
Ethernet Gigabit bidirect. data line (A-D)
Encoder 0-pulse 0-0 (TTL)
Encoder A/A (TTL)
Encoder B/B (TTL)
Encoder A
Encoder B
Digital output MIN
Digital output MAX
Digital output OK
Synchronization In
Synchronization OUT
Brightness output
Maintenance
reserved
PT
PT

12 Installation and Electrical Connection
DANGER!
Risk of personal injury or property damage due to electric current!
Voltage conducting parts may cause personal injury or damage to equipment.
• The electric device may only be connected by appropriately qualified personnel.
5�3 Diagnostics
Causes for Triggering the Contamination Warning (blinking LED):
Display LED Diagnosis/Cause Elimination
Continuous blinking
at approx. 2.5 Hz
Contamination Carefully clean the optic cover with a cloth.
Aged emitter diode Replace the sensor.
Unreliable working range • Increase the sensor’s switching distance.
• Reduce distance between sensor and reflector.
Continuous blinking
at approx. 5 Hz
Short-circuit Check electrical wiring and eliminate the short-circuit.
Over-temperature Disconnect the sensor from supply power
and allow it to cool down.
Hardware error Replace the sensor.

13Retro-Reflex Sensors for Transparent Objects
Contamination Warning Flowcharts
not detected not detecteddetected
beginning contamination
not detected not detecteddetected
Retro Reflective Barrier no contamination
Object
Switching Status Indicator
Object
Switching Status Indicator
Object
Switching Status Indicator
not detected not detectednot detected
advanced contamination
on onoff
off
off off off
blinkingblinking
Object
t
Sensor
Reflector
Sensor
Reflector
Object
Sensor
Reflector
Object
Object
Sensor
Reflector
Sensor
Reflector
Object
Sensor
Reflector
Object
Object
Sensor
Reflector
Sensor
Reflector
Object
Sensor
Reflector
Object
Required action in case of fault:
NOTE!
• Shut down the machine.
• Analyze and eliminate the cause of error with the help of the diagnostics information.
• If the error cannot be eliminated, please contact wenglor’s support department.
• Do not operate in case of indeterminate malfunctioning.
• The machine must be shut down if the error cannot be unequivocally clarified or reliably
eliminated.
DANGER!
Risk of personal injury or property damage in case of non-compliance!
The system’s safety function is disabled. Personal injury and damage to equipment.
• Required action as specified in case of fault.

14 Settings
6� Settings
• Align the sensor to the reflector.
• Make sure that the sensor and the reflector are mounted in a mechanically secure fashion.
• Press and hold the teach-in key until the switching status indicator LED starts blinking.
• Release the teach-in key after 2 seconds.
• Teach-in is conducted which is acknowledged when the LED lights up.
• Move the object into the light barrier and check for correct functioning.
7� I/O-Link
Further settings are possible via the IO-Link interface. The IODD can be found at www.wenglor.com in the
product’s download area.
7�1 Teach-In Mode
7�1�1 Minimal Teach-In (default setting)
With this teach-in mode, the switching point is to a value just below momentary signal strength in considera-
tion of signal quality. This makes it readily possible to detect transparent objects such as glass, PET and sheet
materials.
7�1�2 Normal Teach-In
With this teach-in mode, the switching point is set to a value which corresponds to half of the signal strength.
As a result, this mode has more switching reserve for the detection of opaque objects.
7�2 Dynamic readjustment
Readjustment of the Sensor switching threshold within regular intervals. The time interval for the readjustment
can be adjusted via interface.
Intensity of Light
Teach-In process Switching
treshold
beginning contamination
The switching threshold is readjusted in
preselectionable intervals in order that
the distance between signal and
threshold stays the same.
t

15Retro-Reflex Sensors for Transparent Objects
7�3 Pin Function, E/AO2
The function of E/A2 can be configured either as an output or an input.
7�3�1 Input External Teach-In
Teach in output A1 via the teach-in input.
1. Set the E/A2 pin function to external teach-in.
With Ub setting active (default):
2. Apply 18…30 V to pin E/A2 for at least 1 second, but for no more than 4 seconds.
3. As soon as voltage drops at the input, A1 is taught in.
With Ub setting inactive:
2. Disconnect pin I/O2 or connect it to 0 V for at least 1 second, but for no more than 4 seconds.
3. As soon as voltage is applied to the input, O1 is taught in.
Locking
If the teach-in input is continuously activated, the teach-in key is locked and protected against inadvertent
changes.
1. Change the E/A2 pin function to external teach-in input.
With Ub setting active (default):
2. Permanently connect pin E/A2 to voltage within a range of 18 to 30 V DC.
3. The sensor is protected against inadvertent changes caused by the teach-in key.
With Ub setting inactive:
2. Permanently disconnect pin I/O2 or connect it to 0 V.
3. The sensor is protected against inadvertent changes caused by the teach-in key.
7�3�2 Error Output
The error output is switched in the following cases:
• Contamination
• Aged emitter diode
• Unreliable working range
• Short-circuit
• Over-temperature
• Hardware error

16 I/O-Link
7�4 Additional functions and settings via IO-Link
• PNP/NPN/push-pull
• NC/NO
• Switching hysteresis
• On/off-delay
• Operating mode
• Switch emitted light off
• Test mode
• Data storage
8� I/O-Link
Process and parameters data, as well as the IODD, can be found at www.wenglor.com in the product’s sepa-
rate download area.
9� Maintenance Instructions
NOTE!
• This wenglor sensor is maintenance-free.
• Cleaning and inspection of the plug connections at regular intervals are advisable.
• Do not clean the sensor with solvents or cleansers which could damage the product.
• The product must be protected against contamination during initial start-up.
10� Proper Disposal
wenglor sensoric GmbH does not accept the return of unusable or irreparable products. Respectively valid
national waste disposal regulations apply to product disposal.

17Retro-Reflex Sensors for Transparent Objects
11�Appendix
11�1 List of Abbreviations
Abbreviation Meaning
Tu Ambient temperature
Ub Supply voltage
IODD IO Device Description
MTTFd Mean Time to Dangerous Failure
11�2 Change Index, Operating Instructions
Version Date Description/Change
1.0.0 22.05.17 Initial version of the operating instructions
1.0.1 21.11.17 “3.1.1 Spot diameter” on page 8
“3.1.2 Smallest detectable part” on page 8
“3.1.3 Switching distance” on page 8
“3. Technical Data” on page 7
1.1.0 04.12.17 “3. Technical Data” on page 7
1.2.0 14.03.19 “7.2 Dynamic readjustment” on page 14
1.3.0 11.07.19 “7.3 Pin Function, E/AO2” on page 15
1.4.0 17.05.22 “3.1.3 Switching distance” on page 8
1.5.0 07.12.23 Addition of new types: P1KK008, P1KK009
11�3 Declarations of Conformity
The declarations of conformity can be found on our website at www.wenglor.com in the product’s download
area.

18
