Model No. 30875.0
Serial No.
Write the serial number in the
space above for reference.
USERʼS MANUA
QUESTIONS?
If you have questions, or if parts are
damaged or missing, P EASE
CONTACT OUR CUSTOMER SER-
VICE DEPARTMENT DIRECT Y.
CA TO -FREE:
1-888-936-4266
Mon.–Fri., 8:00 until 17:00 ET
(excluding holidays)
OR E-MAI US:
[email protected]
www.weslo.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

TAB E OF CONTENTS
WARNINGDECA P ACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMB Y ...............................................................................5
HOWTOUSETHEE IPTICA EXERCISER ..................................................11
MAINTENANCEANDTROUB ESHOOTING ...................................................18
EXERCISEGUIDE INES ...................................................................19
PART IST ..............................................................................20
EXP ODEDDRAWING ....................................................................22
ORDERINGREP ACEMENTPARTS ..................................................BackCover
IMITEDWARRANTY ..............................................................BackCover
2
WARNING DECA P ACEMENT
This drawing shows the location(s) of the
warning decal(s). If a decal is missing or
illegible, see the front cover of this
manual and request a free replacement
decal. Apply the decal in the location
shown. Note: The decal(s) may not be
shown at actual size.

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. Keep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is at least 3 ft. (0.9 m)
of clearance in the front and rear of your
elliptical exerciser and 2 ft. (0.6 m) on each
side.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 250 lbs.
(113 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the upper
body arms when mounting, dismounting, or
using your elliptical exerciser.
10. Keep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the userʼs move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. If you feel pain or dizziness while exercising,
stop immediately and cool down.
14. Use your elliptical exerciser only as
described in this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
BEFORE YOU BEGIN
Pulse Sensor
Upper Body Arm
Pedal Disc
Wheel
Adjustment Knob
Pedal
Console
Water Bottle Holder*
Fan
*Water bottle is not included
Thank you for selecting the new WES O PRO™
13.8E elliptical exerciser. The 13.8E elliptical exerciser
provides a selection of features designed to make
your workouts at home more effective and enjoyable
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.

5
M10 x 112mm Carriage Bolt (34)–4
M10 x 88mm Button Screw (63)–2
M10 x 52mm Bolt Set (27)–2
M10 Split
Washer (70)–2
M8 Large
Washer (53)–10
Wave Washer
(95)–2
M8 Split
Washer (100)–4
M8 x 65mm Button Screw (99)–4
M8 x 50mm Button
Screw (89)–4
M10 Locknut
(29)–4
M8 Locknut
(46)–12
M4 x 16mm
Screw (66)–4
M4 x 22mm
Screw (91)–2
M8 x 25mm Patch
Screw (22)–2
M8 x 45mm Button
Bolt (50)–4
M8 x 38mm Button
Bolt (112)–4
ASSEMB Y
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART IST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: If a part is not in the hardware
kit, check to see if it has been preassembled.

6
1.
Identify the Front Stabilizer (3). Make sure that
the Front Stabilizer is turned so that the
Wheels (32) are not touching the floor.
While another person lifts the front of the Frame
(1), attach the Front Stabilizer (3) to the Frame
with two M10 x 112mm Carriage Bolts (34) and
two M10 ocknuts (29).
3
29
29
32
32
34
1
1
2. While another person lifts the rear of the Frame
(1), attach the Rear Stabilizer (4) to the Frame
with two M10 x 112mm Carriage Bolts (34) and
two M10 ocknuts (29).
34
4
1
29
29
2
To make assembly easier, read the
information on page 5 before you begin.

7
3
2
86
87
1
63
83
70
70
91
105
83
3. While another person holds the Upright (2) near
the Frame (1), connect the Upper Wire Harness
(86) to the ower Wire Harness (87).
Tip: Avoid pinching the Wire Harnesses (86,
87). Insert the Upright (2) into the Frame (1).
Next, slide an M10 Split Washer (70) and a
Frame Spacer (83) onto each of the two M10 x
88mm Button Screws (63).
Insert the M10 x 88mm Button Screws (63) into
the Frame (1) and the Upright (2). Make sure
that the concave sides of the Frame Spacers
(83) are facing the Frame. Do not tighten the
Button Screws yet.
Attach the Water Bottle Holder (105) to the
Upright (2) with two M4 x 22mm Screws (91).
Avoid pinching the Wire
Harnesses (86, 87)
4. Identify the eft Pulse Bar (107), which is
marked with a “ eft” sticker.
Have another person hold the eft Pulse Bar
(107) near the left side of the Upright (2). Make
sure that the hexagonal holes are in the
indicated location.
See the inset drawing. ocate the wire tie in
the Upright (2). Tie the lower end of the wire tie
to the left Pulse Wire (113). Next, pull the upper
end of the wire tie upward out of the top of the
Upright. Then, untie and discard the wire tie.
Tip: Avoid pinching the wires. Slide the eft
Pulse Bar (107) onto the Upright (2). Attach the
eft Pulse Bar with two M8 x 38mm Button
Bolts (112) and two M8 ocknuts (46). Make
sure that the ocknuts are in the hexagonal
holes.
Repeat this step for the Right Pulse Bar
(108).
107
46
2
108
112
113
113
Hexagonal
Holes
4
Avoid pinching
the wires
86
Wire Ties
Wire Tie
113

8
5. The Console (5) can use four D batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Remove the battery cover, insert the bat-
teries into the battery compartment, and reat-
tach the battery cover. Make sure to orient the
batteries as shown by the diagram inside the
battery compartment.
To purchase an optional AC adapter, contact
the store where you purchased this product
or call the telephone number on the cover of
this manual. To avoid damaging the console,
use only a manufacturer-supplied AC
adapter. Plug one end of the AC adapter into
the jack on the console; plug the other end into
an outlet installed in accordance with all local
codes and ordinances.
5
5
Batteries
Battery
Cover
6. While another person holds the Console (5)
near the Upright (2), connect the console wire
to the Upper Wire Harness (86). Then, connect
the console pulse wires to the Pulse Wires
(113). Insert the excess wire downward into the
Upright.
Tip: Avoid pinching the wires. Attach the
Console (5) to the Upright (2) with four M4 x
16mm Screws (66).
5
86
113
66
2
Console
Wire
Pulse
Wires
6

9
7. Identify the eft Upper Body Arm (9), which is
marked with a “ eft” sticker.
Insert the eft Upper Body Arm (9) into an
Upper Body eg (79). Make sure that the
hexagonal holes are in the indicated loca-
tion.
Attach the eft Upper Body Arm (9) to the
Upper Body eg (79) with two M8 x 45mm
Button Bolts (50) and two M8 ocknuts (46).
Make sure that the ocknuts are inside the
hexagonal holes. Do not tighten the Button
Bolts yet.
Repeat this step for the Right Upper Body
Arm (not shown) and the other Upper Body
eg (not shown).
8. Apply a generous amount of the included
grease to the Pivot Axle (97) and to two Wave
Washers (95).
Insert the Pivot Axle (97) into the Upright (2).
Slide a Upper Body Arm Spacer (25) onto the
short tube on the eft Upper Body Arm (9), and
rotate the Upper Body Arm Spacer so that the
small arrow is pointing toward the floor.
Slide a Wave Washer (95) onto the left end of
the Pivot Axle (97). Then, slide the eft Upper
Body Arm (9) onto the left end of the Pivot Axle.
Repeat this action for the Right Upper Body
Arm (10).
7
9
50
46
Hexagonal
Holes
79
8
2
9
10
Grease
Tube
Arrow
97
25
95

10
10. Apply grease to the barrel of an M10 x 52mm
Bolt Set (27) and to the two eg Bushings (28)
in the left Upper Body eg (79).
Attach the left Upper Body eg (79) to the eft
Pedal Arm (14) with the M10 x 52mm Bolt Set
(27). Do not overtighten the Bolt Set; the left
Upper Body eg must pivot freely.
Attach the right Upper Body eg (79) to the
Right Pedal Arm (103) in the same way.
See step 3. Tighten the M10 x 88mm Button
Screws (63).
See step 7. Tighten the M8 x 45mm Button
Bolts (50) in the Upper Body egs (79).
14
103
27
27
28 28
Grease
Grease
10
79
79
9
23
23
22 53
22
53
97
25
25
9. Tighten an M8 x 25mm Patch Screw (22) and an
M8 arge Washer (53) into each end of the Pivot
Axle (97).
Attach the Axle Caps (23) by pressing the small
tabs into the Upper Body Arm Spacers (25).
12. Make sure that all parts are properly tightened. Note: Some hardware may be left over after assembly is
completed. To protect the floor or carpet from damage, place a mat under the elliptical exerciser.
11
12
16
99
14
13
11. Attach a Pedal Bracket (16) to the eft Pedal
Arm (14) with two M8 x 65mm Button Screws
(99), two M8 arge Washers (53), and two M8
ocknuts (46).
Identify the eft Pedal (13), which is marked
with a “ eft” sticker. Attach the eft Pedal to the
eft Pedal Arm (14) with two M8 x 50mm Button
Screws (89), two M8 Split Washers (100), and
two M8 arge Washers (53).
Attach the other Pedal Bracket (not shown)
and the Right Pedal (12) to the Right Pedal
Arm (103) in the same way.
103
53
53
53
46
89
100
