Westlab 663-890 User manual

1
PRODUCT MANUAL
Product Manual
Westlab Digital Thermostatic Water Baths
Codes 663-890, 663-891, 663-892, 663-894, 663-895, 663-896

2
PRODUCT MANUAL
1800 358 101
[e-mail]
www.westlab.com.au
[phone]
[e-mail]
www.westlab.co.nz
646 568 5391
[e-mail]
www.westlab.com
1 877 822 1455
[e-mail]
www.westlab.com
Australia New Zealand United StatesCanada
1. Product Description
1.1 Introduction
Westlab’s Thermostatic Digital Water Baths are designed for general use and are
economically priced without compromising quality.
With a high-quality corrosion resistant stainless-steel tank, the water baths are housed
in a durable paint nished outer case. Painted surfaces feature anti-bacterial nish with
good chemical resistance. Fitted with side tting handles for easy transportation.
Heating and temperature sensor concealed under the tank providing a clutter free
working area easy to wipe clean. Supplied with a removable sturdy low height stainless
steel perforated shelf, for even heat distribution. The shelf provides a deeper volume of
water, for standing containers and accessory test tube racks in the bath.
1.2 Intended Use
The Thermostatic Water Baths are designed for laboratory use only.
1.3 Features
• Digital LED Display
• Stainless Steel Tank
• Ambient + 5°C to 99°C
• Removable Low Height Stainless Steel Perforated Shelf
• Heating & Temperature Sensor Underneath Tank
• Made in the United Kingdom
1.4 Accessories
663-894 663-895 663-896
Lift Off Gable
Lid, Clear
Polycarbonate
Suits 4L Bath
(663-890)
Suits 14L Bath
(663-891)
Suits 22L Bath
(663-892)
TABLE OF CONTENT
1. Product Description
1.1 Introduction
1.2 Intended Use
1.3 Features
1.4 Accessories
2. Technical Specications
3. Safety Precautions
& Maintenance
3.1 Safety Precaution
3.2 Maintenance
4. Installation & Operation
4.1 Installation
4.2 Operation
5. Product Disposal
PRODUCT CODES
663-890
663-891
663-892
663-894
663-895
663-896
PLEASE READ THESE INSTRUCTIONS BEFORE USE.
M
a
d
e
i
n
t
h
e
U
K

3
PRODUCT MANUAL
1800 358 101
[e-mail]
www.westlab.com.au
[phone]
[e-mail]
www.westlab.co.nz
646 568 5391
[e-mail]
www.westlab.com
1 877 822 1455
[e-mail]
www.westlab.com
Australia New Zealand United StatesCanada
2. Technical Specication
663-890 663-891 663-892
Tank Capacity 4L 14L 22L
Temperature
Range
Ambient + 5°C to 99°C
Temperature
Control
Digital, LED Display – Actual or Set Temperature,
Resolution of 1°C
Water Level Range 55mm to 130mm
Sensitivity ± 0.2°C
Uniformity ± 0.1°C
Heater Power 400W 1,000W 1,500W
Voltage 120V or 230V, 50 to 60 Hz
Internal
Dimensions (mm)
300 W x 150 D
x 150 H
325 W x 300 D
x 150 H
500 W x 300 D
x 150 H
External
Dimensions (mm)
332 W x 185 D
x 290 H
361 W x 332 D
x 290 H
538 W x 332 D
x 290 H

4
PRODUCT MANUAL
1800 358 101
[e-mail]
www.westlab.com.au
[phone]
[e-mail]
www.westlab.co.nz
646 568 5391
[e-mail]
www.westlab.com
1 877 822 1455
[e-mail]
www.westlab.com
Australia New Zealand United StatesCanada
3. Safety Precautions & Maintenance
3.1 Safety Precautions
1. This product is designed for laboratory use only. Always follow good laboratory practice.
2. Fill the tank prior to connection to electrical supply.
3. Use caution when topping up or draining the tank. If this product is not used in
accordance with these instructions, then basic safety protection may be affected.
4. The mains supply cord tted to this product is heat resistant and should be replaced
with an equivalent type by a qualied electrician.
5. Ensure that the power supply has a safety earth (ground) terminal.
6. Ensure that the mains switch, and power supply connector are accessible during use.
7. Before using any cleaning or decontamination method please refer to the Maintenance
section to ensure the proposed method will not damage the unit.
8. Connect only to a power supply with the corresponding voltage to that specied on the
rating label positioned on the rear of the unit.
9. Do not block ventilation slots during use and always follow installation instructions.
10. Ensure substances being heated present no risk of a hazard (explosion, implosion, or
release of toxic or ammable gases) or that these have been addressed. When heating
substances where liberation of gases occurs, suitable extraction should be used.
11. Use only liquids specied within this Instruction Manual within their specied
temperature range.
12. Drain all liquid before moving the water bath.
13. We recommend using a lid above 60˚C. Take care when lifting the lid as steam and hot
vapours can cause scolding.
14. Use a thermometer to check the temperature - do not touch the liquid.
Liquid Level & Suitable Liquids:
Always ensure that the water bath is disconnected from the electrical supply before lling or
emptying the unit.
• Minimum Liquid Level of 55mm (Shelf Fitted Working Depth of 40mm)
• Maximum Liquid Level of 130mm (Shelf Fitted Working Depth of 115mm)
Suitable Liquids:
Operating temperatures from ambient + 5°C to + 99°C, for general use we recommend:
• Distilled Water
• Heat Transfer Liquid
• Virkon dissolved in distilled water has proven ecacy against bacteria (including
micro bacteria), viruses, spores, and fungi in a variety of independent tests using
different protocols.

5
PRODUCT MANUAL
1800 358 101
[e-mail]
www.westlab.com.au
[phone]
[e-mail]
www.westlab.co.nz
646 568 5391
[e-mail]
www.westlab.com
1 877 822 1455
[e-mail]
www.westlab.com
Australia New Zealand United StatesCanada
3.2 Maintenance
Please ensure that the washing agent and sanitising agent are BSI accredited and approved
by the H&S department for use on laboratory equipment and stainless steel within your
laboratory.
ATTENTION: Disconnect the Bath from the Power Supply Prior to Cleaning
Basic Cleaning Procedure:
The stainless-steel crevice free tank should provide years of valuable service and is resistant
to chloride containing solutions, but it is important to avoid high concentrations of halogens-
particularly chloride. Halogen deposits may show as rust which can be cleaned off with nitric
acid (10%) on a cloth. WEAR PROTECTIVE EQUIPMENT!
The water bath should be emptied at the end of each day, then for interior surfaces:
• WASH • RINSE • DRY •
For algae and slime control in water baths, please use Water Bath Conditioner AR.
Occasionally small spots may occur in the bath which resemble rust. These are usually small
ferrous particles which have oxidised. Using a stainless-steel cleanser such as Bar Keepers
Friend®will remove these marks as well as mineral deposits.
Exterior Anti-Bacterial Painted Surfaces:
The water bath should be cleaned at regular intervals by wiping external surfaces with a
cloth or sponge soaked in warm water with a mild detergent.
ATTENTION: Do Not Use Strong Solvents or Solutions Containing Chlorinated Hydrocarbons,
Esters, Ketones or Abrasive Cleaners as this may Damage the Built-In Antibacterial Properties.
4. Installation & Operation
4.1 Installation
The water bath must be placed on a smooth, level, and sturdy work surface, preferably near a
drain for emptying. Use in a ventilated room. Suitable for use in ambient temperatures 5°C to
40°C with a maximum humidity 80% (temperature 31°C) decreasing to 50% (temperature 40°C).
DO NOT block or restrict ventilation slots. DO NOT place directly next to hot heat surfaces.
ENSURE that there is sucient space around the product to allow it to provide optimum
temperature control.
When unpacking the unit, remove the packaging and retain over the warranty period.
Contents consist of:
• Water Bath
• Stainless Steel False Base
• Power Lead
• Instruction Manual
Place the false base into the bath with the legs down. Fit the power lead into the socket at
the rear.

ORDERING WITH
WESTLAB IS EASY
Online
www.westlab.com.au
Order online with our easy
Express Order form for fast,
secure ordering.
Phone
1800 385 101
Speak to one of our friendly,
ecient staff from
8.00am - 5.00pm (Mon/Fri)
Email
[email protected]
24 hours, 7 days a week
convenience.
6
PRODUCT MANUAL
1800 358 101
[e-mail]
www.westlab.com.au
[phone]
[e-mail]
www.westlab.co.nz
646 568 5391
[e-mail]
www.westlab.com
1 877 822 1455
[e-mail]
www.westlab.com
Australia New Zealand United StatesCanada
4.2 Operation
1. Ensure the stainless-steel false base is tted and ll the bath with water following Liquid
Level Instructions. SWITCHING THE BATH ON WHEN DRY WILL DAMAGE THE HEATER
AND MAY INVALIDATE YOUR WARRANTY.
2. Connect the mains power lead to an electrical supply.
3. Turn the bath on using the green mains power switch located on the front. Wait while the
controller loads, and temperature is displayed. You can now change the set point.
PTo Programme Set Point
▲Up Arrow: To Increase Set Point Value
▼Down Arrow: To Decrease Set Point Value
UTo Access Temperature Readings
4. Press the P key. Display will alternate between SP (set point) and the set value.
5. Use the UP and DOWN ARROW keys to adjust the value to the required temperature.
6. Press the P key to save and exit. Alternatively, the value will be saved, and the programme
exited if no key is pressed for 15 seconds.
7. Display will return to normal indicating actual temperature.
8. Amber heater indicator will illuminate to show heater activity.
9. Press the U key once to display lowest temperature Lt. The display will alternate between
Lt and lowest temperature in the bath during use.
10. Press the U key twice to display highest temperature Ht. The display will alternate
between Ht and highest temperature in the bath during use.
11. Press the U key three times to display the temperature probe reading Pr1. The display will
alternate between Pr1 and current water temperature. The controller will revert to actual
temperature when no keys are pressed.
ATTENTION: Do Not Stand Vessels Directly onto the Bath Base. Always use the False Base
or Shelf Otherwise Damage May Occur to the Heaters.
5. Product Disposal
In the case that the product is to be disposed of, the relevant legal regulations are to be
observed.
