REPLACEMENT PARTS
LISTING FOR ISB
SERIES STROBES
ENGINEERING COMPANY, INC ISB SERIES
STROBE LIGHT BEACONS
ISB24, 12/24 VOLTS DC, COMET FLASH
ISB120, 120 VOLTS AC, COMET FLASH
Doc No. 04-0113078-01
Route 145, Winthrop Road
Chester, CT 06412-0684
TELEPHONE: [phone]
TOLL FREE: 1-800-637-4736
1996 Whelen Engineering Company, Inc. Doc No. 04-0113078-01
February 8, 1996. 13078
BASE GASKET
BASE
POWER SUPPLY ASSEMBLY
STROBE TUBE ASSEMBLY
CLAMP RING
DOME
WARNING...
DISCONNECT THE
POWER SOURCE AND
WAIT 10 MINUTES
BEFORE INSTALLING
OR SERVICING THE
STROBE LIGHT.
SEE OTHER SIDE
OF PAGE FOR
REPLACEMENT
PARTS LISTING.

ITEM DESCRIPTION QTY. PART NUMBER ISB24 ISB120
OPTIC DOME, AMBER 1 68-2180347-10 ■■
OPTIC DOME, BLUE 1 68-2180347-20 ■■
1 OPTIC DOME, CLEAR 1 68-2180347-30 ■■
OPTIC DOME, GREEN 1 68-2180347-40 ■■
OPTIC DOME, RED 1 68-2180347-50 ■■
2 STROBE TUBE ASSEMBLY 1 01-0468256-00 ■■
3 STROBE POWER SUPPLY, 120 VAC 1 02-0167154-00 ■
STROBE POWER SUPPLY, 12/24 VDC 1 01-0267042-00 ■
4 FUSE, 10 AMP, AUTO 1 32-0632010012 ■
MOUNTING INSTRUCTIONS
PERMANENT MOUNT
The ISB Series must be disassembled to drill
mounting holes for permanent mounting.
1. Remove the clamp ring, remove the optic dome
and disassemble the strobe as shown in the drawing.
2. Locate the three dimples in the base casting and
drill three mounting holes. Drill and deburr a hole for
the power wires.
3. Place the base gasket between the base and
mounting surface. Route the strobe power wires
through the gasket and the mounting hole. Mount the
base with three screws.
4. Connect the power wires to the power source.
5. Re-assemble the strobe. Make sure that the wires
are not pinched.
PIPE MOUNT
The ISB Series may be mounted to a 1” NPT
pipe.
1. Feed the power source cable through the pipe
and connect the cable to the ISB Series strobe.
2. Screw the strobe to the pipe threads. Make
sure that the wires are not pinched or severely
twisted.
WIRING INSTRUCTIONS
MODEL ISB24
1. Connect the RED wire to the positive DC voltage (+).
2. Connect the BLACK wire to DC ground (-).
MODEL ISB120
1. Connect the GREEN wire to the AC service green wire (ground).
2. Connect the BLACK wire to the AC service black wire (hot).
3. Connect the WHITE wire to the AC service white wire (neutral).
WARNING - THE STROBE POWER
SUPPLY IS A HIGH VOLTAGE DEVICE. DO
NOT REMOVE TUBES OR DISMANTLE
STROBE LIGHT ASSEMBLY WHILE IN
OPERATION. WAIT 10 MINUTES AFTER
TURNING OFF POWER BEFORE
WORKING ON THE STROBE.
