Whittier Wood 7018GDRC User manual

P.O. Box 2827
Eugene, OR 97402 USA
Production Code:
VN 08/11
Model #
7018GDRC
Northgate
8-Drawer Dresser
Glazed Dark Chestnut finish
Assembly Instructions
Congratulations!
This fine piece of furniture will make a gorgeous
addition to your home. For the best results, read the
Assembly Instructions before you begin your project.
IMPORTANT NOTES:
•For normal household use only. Not recommended to
use in a commercial setting.
•Do not climb, sit or stand on this piece of furniture.
•Do not overload the drawers.
•Unload items before you move this unit.
•Before you load or move this unit, tighten all screws
and supports.
•Before you begin your project, completely read the
Assembly Instructions.
•Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40°F to 90°F (not on a cold
and possibly damp cement floor).
•Periodically inspect your furniture for any loose glue
joints, screws or any other problem that might affect the
stability of your furniture. Tighten or repair as needed.
WARNING
Serious or fatal crushing injuries can occur from
furniture tip-over. To help prevent tip-over:
•Place heaviest items in the bottom drawers.
•Unless specifically designed to accommodate, do not
set TVs or other heavy objects on top of this product.
•Never allow children to climb or hang on drawers,
doors or shelves.
•Never open more than one drawer at a time.
Properly installing tip-over restraints may reduce but
not eliminate the risk of tip-over.
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE
CALL US FIRST! Do not return this item to the store
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, contact Whittier Wood Products customer service
department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
To Order: Provide the furniture model number (upper
portion of this page), the part letter, production code,
quantity needed, reason for replacement and your full
name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: [phone]
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.

7018GDRC Northgate 8-Drawer Dresser
Parts List
7018GDRC — Page 2 — 08/11
Please identify the parts and check that quantities received match those on this list.
If you need to replace a part, refer to the following letter and part name.
Part Description Quantity
A Top Assembly 1
B Case 1
C
Top Drawer Box (inserted) 2
D
Upper Middle Drawer Box (inserted) 2
E Lower Middle Drawer Box (inserted) 2
F Bottom Drawer Box (inserted) 2
G Top Drawer Face (installed) 2
H Upper Middle Drawer Face (installed) 2
I Lower Middle Drawer Face (installed) 2
J Bottom Drawer Face (installed) 2
K Assembled Foot (attached) 1
L Hanger Bolt (inserted) 1
M 1/4" x 20mm Insert Nut (inserted) 5
N
Small Adjustable Glide (installed) 5
O 1/4" x 1/2" Insert Nut (inserted) 1
P M4 x 10mm Insert Nut (inserted) 4
Q Pull (attached) 8
R M4 x 25mm Machine Screw (installed) 16
S Drawer Slides (pre-installed sets) 6
T #6 x 1/2" Philtruss Screw (inserted) 36
U #6 x 3/4" Philtruss Screw (inserted) 36
V #8 x 1" Lo-Profile Screw (inserted) 48
W #8 x 1-1/4" Pan Head Screw (inserted) 43
TR Furniture Tipping Restraint 2 sets

7018GDRC Northgate 8-Drawer Dresser
Assembly Instructions
7018GDRC — Page 3 — 08/11
Tools Required: Phillips Screwdriver
1. Place the dresser at its final destination. Rotate the Small Adjustable Glides (N) on the bottoms
of the legs until the unit is level. See Figure 1.
2. Tipping restraint: Locate two studs in the wall behind the unit. Attach a Clip (T1) to one wall
stud with two #8 x 2" Black Screws (T3). See Figure 2a. Attach a second clip to the unit with two
#8 x 1" Pan Head Screws (T4). See Figure 2b. Connect the two clips with the Nylon Restraint
Strap (T2). Pull the Nylon Restraint Strap (T2) tight so there is no slack. See Figures 2c and 2d.
Repeat this procedure to attach the second tipping restraint. If you cannot locate two studs,
purchase the proper wall attachment hardware for your type of wall and secure the unit.
Fig. 2a
T1
T
3
Pull tight
Fig. 2d
T1
T
2
T
3
T
4
Fig. 2c Pull the Nylon Restraint
Strap (T2) tight
so there is no slack.
T
4
T
1
Fig. 2b
K
N N
Fig. 1
N
