Whyte 29 CS Manual

MTB Hardtail Range
29 CS & 29 C Team
405
529 & 629
603, 604 & 605
801, 802, 805 & 806
901, 905 & 909
Supplementar Service Manual
2016 Edition 1

2016 Edition 1 Page 3
Table of Contents
1.0 Introduction
2.0 Geometry:
2.1: 29 CS & 29 C Team
2.2: 40
2.3: 29 & 629
2.4: 603, 60 , 801 & 80
2. : 604, 802 & 806
2.6: 901
2.7: 90 & 909
3.0 Preparations for riding:
3.1 Making Adjustments
3.2 Getta-Grip Seat Clamp
3.3 Set up of Fork
3.4 Suspension Tuning Log
4.0 Safety.
.0 Lubrication:
.1 Whyte Getta-Grip Seat Clamp
.1.1: Bolt Up
.1.2: QR Style
.2 Whyte Inter-grip Seat Clamp
.3 General Whyte Lubrication
6.0 Torque Settings:
Whyte Whyte Rear Derailleur Hanger
7.0 Notes.

2016 Edition 1
Page 4
WHYTE Service Manual
1.0: INTRODUCTION
Thanks for choosing to purchase this Whyte product. We hope you will enjoy all the bene-
fits its advanced design and engineering will bring to your riding experience.
This manual will guide you through the set-up, safety and maintenance procedures that
are specific to your Whyte bike. For other more general information, we strongly advise
that you also read thoroughly the General Instruction Manual that is also supplied with
your new bike.
Also, please note that the specification of all the components that are fitted to your bike as
standard may be obtained from the Whyte Bikes Brochure or alternatively from the Whyte
Bikes website www.wh tebikes.co.uk
Please remember, if you are in any doubt about your ability to safely service or repair your
Whyte bike, do not ride it and instead arrange for a professional bicycle mechanic at your
local Whyte dealer to do the job correctly.
Bundled with this manual, are the respective manufacturers instructions and manuals for
the branded parts that are fitted to your Whyte bike. Please take time to study all the rele-
vant instruction manuals to ensure you have a continually safe and well set-up bike before
every ride, and to help you build up a relationship of knowledge between you and your
Whyte Dealer.
Happy and safe riding,
Whyte design team. May 2015.

2016 Edition 1 Page
WHYTE Service Manual
2.0: GEOMETRY
2.1: WHYTE 29 CS & 29 C Team
Fig.1:
Geometr
Frame Size Small Medium Large
Head Angle 69.3° 69.3° 69.3°
Seat Angle 73.0° 73.0° 73.0°
Top Tube 612.2mm 627.0mm 640.8mm
BB Height* 30 mm 30 mm 30 mm
Stand Over 790mm 810mm 84 mm
Wheel Base 1117.3mm 1127.9mm 1144.9mm
Chain Sta 437. mm 437. mm 437. mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø738mm tyres fitted (2.1” / 2-622)

2016 Edition 1
Page 6
WHYTE Service Manual
2.2.2: WHYTE 405
Frame Size X Small Medium Large Extra
Large
Head Angle A 68. ° 68. ° 68. ° 68. °
Seat Angle B 73.0° 73.0° 73.0° 73.0°
Top Tube C 80. mm 94. mm 612.4mm 632.2mm
BB Height* D 30 mm 30 mm 30 mm 30 mm
Stand Over E 800mm 810mm 836mm 8 0mm
Wheel Base F 1123mm 1138mm 11 8mm 1178mm
Chain Sta G 440mm 440mm 440mm 440mm
Seat Post H 30.9mm 30.9mm 30.9mm 30.9mm
2.2.3: WHYTE 529 & 629
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø738mm tyres fitted (2.1” / 2-622)
Frame Size X 13”
Head Angle A 68. °
Seat Angle B 74.0°
Top Tube C 629.4mm
BB Height* D 30 mm
Stand Over E 711mm
Wheel Base F 1068.6mm
Chain Sta G 42 mm
Seat Post H 30.9mm
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø677mm tyres fitted (2.2 ” / 4- 9)

2016 Edition 1 Page 7
Frame Size X Small Medium Large Extra Large
Head Angle A 68. ° 68. ° 68. ° 68. °
Seat Angle B 73. ° 73. ° 73.0° 73.0°
Top Tube C 93. mm 608.1m 627.9mm 638.8mm
BB Height* D 303. mm 303. mm 303. mm 303. mm
Stand Over E 779mm 797mm 822mm 8 1mm
Wheel Base F 1107.1mm 1122.6mm 1137.4mm 1149.1mm
Chain Sta G 43 mm 43 mm 43 mm 43 mm
Seat Post H 30.9mm 30.9mm 30.9mm 30.9mm
2.2.4: WHYTE 603, 605, 801 & 805
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.2 ” / 2- 84).
WHYTE Service Manual
Frame Size X Small Medium
Head Angle A 68. ° 68. °
Seat Angle B 73. ° 73. °
Top Tube C 8 . mm 99.6m
BB Height* D 303. mm 303. mm
Stand Over E 784mm 804mm
Wheel Base F 1099.1mm 1114.1mm
Chain Sta G 43 mm 43 mm
Seat Post H 30.9mm 30.9mm
Extra Small
68. °
74.0°
70.6mm
303. mm
776mm
1089.1mm
43 mm
30.9mm
Large
68. °
73. °
613.7mm
303. mm
829mm
1129.1mm
43 mm
30.9mm
2.2.5: WHYTE 604, 802 & 806
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.2 ” / 2- 84).

2016 Edition 1
Page 8
WHYTE Service Manual
Frame Size Small Medium Large
Head Angle 66. ° 66. ° 66. °
Seat Angle 73.0° 73.0° 73.0°
Top Tube 619mm 638mm 6 mm
BB Height* 30 .0mm 30 .0mm 30 .0mm
Stand Over 778mm 794mm 816mm
Wheel Base 1139mm 1169mm 1178mm
Chain Sta 42 mm 42 mm 42 mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
66. °
73.0°
674mm
30 .0mm
833mm
1204mm
430mm
30.9mm
2.2.6: WHYTE 901
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.2 ” / 4- 84)
Frame Size Small Medium Large
Head Angle 66. ° 66. ° 66. °
Seat Angle 73.0° 73.0° 73.0°
Top Tube 619mm 638mm 6 mm
BB Height* 30 .0mm 30 .0mm 30 .0mm
Stand Over 770mm 80 mm 832mm
Wheel Base 1139mm 1169mm 1178mm
Chain Sta 42 mm 42 mm 42 mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
66. °
73.0°
674mm
30 .0mm
861mm
1204mm
430mm
30.9mm
2.2.7: WHYTE 905 & 909
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.2 ” / 4- 84)

2016 Edition 1 Page 9
WHYTE Service Manual
3.0: PREPARATIONS FOR RIDING
3.1: MAKING ADJUSTMENTS
Please refer to the specific component manufac-
turers manual or published technical information
about adjusting the components on your Whyte
bike. Instructions may be downloaded from the
relevant manufacturer’s internet site, as shown in
the table to the right.
CAUTION! If you are uncertain in any
way, about making adjustments to any
components on you Whyte bike, then DO
NOT RIDE YOUR BIKE. Contact your
Whyte dealer who will be able to advise
you on how to go about setting up you
Whyte for riding, and or making adjust-
ments to the components fitted to your
Whyte.
DT Swiss www.dtswiss.com
FSA www.fullspeedahead.com
Formula www.formulahubs.com
Fox www.foxracingshox.com
Hope www.hopetech.com
Jagwire www.jagwireusa.com
Maxxis www.maxxis.com
Prologo www.prologotouch.com
Race Face www.raceface.com
Shimano www.shimano.com
SR Suntour www.srsuntour-cycling.com
SRAM www.sram.com
Tektro www.tektro.com
VP www.vpcomponents.com
WTB www.wtb.com
Jalco www.maddux-wheels.com

2016 Edition 1
Page 10
WHYTE Service Manual
3.2: WHYTE GETTA-GRIP SEAT CLAMP
The Getta Grip seat clamp design is a patented design to allow adjustment of the saddle
height by either the use of a Quick Release (QR) Lever, or bolt-up method. This manual
covers both styles of clamps.
Bolt-up T pe: Fig.2
Tools Required: 5mm Allen Key
(Note refer to the seat-pin manufacturers instructions in conjunction with these notes).
To adjust the seat height, using the mm Allen key, undo the M6 bolt ( ) just enough to allow
the seat-pin to slide freely up and down. Set the height to the desired level, and re-tighten the
M6 bolt ( ) with the mm Allen Key just enough so as to prevent the seat-pin from slipping down
and twisting.
Item: Description
1 Whyte Seat Clamp Band
2 T-Pad
3 Whyte Main Frame Seat Tube
4 Adjuster Nut
M6 x 2 mm Long Fastener
6 M6 Washer
Fig.2: Getta-Grip Seat Clamp: Bolt-up
