Wieland wienet FS8 Series User manual

wienet FS8xx / FS16xx
Industrial Protocol Ethernet Switches
USER MANUAL
Doc.-No. BA001047
Updatet: 06/2018 (Rev. A)

Industrial Protocol Ethernet Switch User Manual
2 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
COPYRIGHT
This document is copyright-protected. The rights derived from this cop-
yright are reserved for Wieland Electric GmbH. Reproduction of this doc-
ument or parts of this document is only permissible within the limits of
the statutory provision of the Copyright Act. Any modification or abridg-
ment of the document is prohibited without the express written agree-
ment of Wieland Electric GmbH.
Any other product or trade names listed in these operating instructions
are the trademarks or registered trademarks of the respective owners.
NOTE
Every effort has been made to ensure that the information contained in
this document was complete and accurate at the time of publishing.
Nevertheless, the authors retain the right to modify the information. This
customer document describes all the hardware units and functions
known at the present time. Descriptions may be included for units which
are not present at the customer site. The exact scope of delivery is de-
scribed in the respective purchase contract.
Conformity
Information
For more information regarding CE marking and Declaration of Conform-
ity (DoC), please contact your local Wieland Electric customer service
organization.
Technical support
Information concerning the product is available from the following
websites:
http://www.wieland-electric.com/
http://eshop.wieland-electric.com/
Hotline: +49 951 / 93 24-995
E-Mail: [e-mail]
Address
Wieland Electric GmbH
Brennerstraße 10-14
96052 Bamberg
Phone: +49 951 / 9324 - 0
Fax: +49 951 / 9324 - 964
E-mail: [e-mail]

Table of Contents
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 3
Table of Contents
1About this manual ........................................................................................9
1.1 Target groups and qualification of personnel.........................................................9
1.2 Structure of the manual .........................................................................................9
1.3 Presentation of safety-relevant information...........................................................9
2Product Disposal Instructions ....................................................................11
3Product Overview.......................................................................................12
3.1 Specifications.......................................................................................................12
3.2 Hardware Views...................................................................................................14
3.2.1 Front View ...............................................................................................14
3.2.2 Rear View.................................................................................................16
3.2.3 Top View..................................................................................................18
3.2.4 Bottom View............................................................................................19
4Switch Installation......................................................................................20
4.1 Installation Guidelines ..........................................................................................20
4.1.1 Connecting Hardware..............................................................................20
4.2 Verifying Switch Operation ..................................................................................20
4.3 Installing the Switch.............................................................................................21
4.3.1 DIN Rail Mounting...................................................................................21
4.3.2 Wall-Mounting.........................................................................................22
4.4 Connecting the Switch to Ethernet Ports.............................................................24
4.4.1 RJ45 Ethernet Cable Wiring ....................................................................24
4.5 Power Supply Installation.....................................................................................25
4.5.1 Overview..................................................................................................25
4.5.2 Considerations.........................................................................................25
4.5.3 Grounding the device ..............................................................................26
4.5.4 Wiring a Relay Contact............................................................................27
4.5.5 Wiring the Power Inputs..........................................................................27
5Managing Switch .......................................................................................30
5.1 First Time Setup ...................................................................................................30
5.1.1 Overview..................................................................................................30
5.1.2 Introduction .............................................................................................30
5.1.3 Administrative Interface Access..............................................................30
5.1.4 Using the Graphical (Web) Interface .......................................................30
5.1.5 Configuring the Switch for Network Access...........................................31
5.1.6 Configuring the Ethernet Ports................................................................31
5.2 Web Browser Configuration.................................................................................33
5.2.1 Preparing for Web Configuration ............................................................33
5.3 Log In ...................................................................................................................34
5.4 Recommended Practices .....................................................................................35
5.4.1 Changing Default Password....................................................................35
5.5 Monitoring............................................................................................................36
5.5.1 Device Information ..................................................................................36
5.5.2 Logging Message....................................................................................37
5.5.3 Port Monitoring .......................................................................................38
5.5.4 Link Aggregation .....................................................................................39

Table of Contents
4 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
5.5.5 LLDP Statistics........................................................................................ 39
5.5.6 IGMP Statistics........................................................................................ 40
5.6 System................................................................................................................. 41
5.6.1 IP Settings............................................................................................... 41
5.6.2 DHCP Client Option 82 ........................................................................... 42
5.6.3 DHCP Auto Provision.............................................................................. 43
5.6.4 IPv6 Settings........................................................................................... 43
5.6.5 Management VLAN ................................................................................ 44
5.6.6 System Time ........................................................................................... 45
5.7 L2 Switching........................................................................................................ 47
5.7.1 Port Configuration................................................................................... 47
5.7.2 Port Mirror............................................................................................... 47
5.7.3 Link Aggregation..................................................................................... 48
5.7.4 802.1Q VLAN.......................................................................................... 51
5.7.5 GARP....................................................................................................... 55
5.7.6 802.3az EEE ............................................................................................ 56
5.7.7 Multicast ................................................................................................. 56
5.7.8 Jumbo Frame.......................................................................................... 62
5.7.9 Spanning Tree......................................................................................... 62
5.7.10 X-Ring Elite ............................................................................................ 67
5.7.11 MRP....................................................................................................... 68
5.7.12 Loopback Detection............................................................................... 69
5.8 MAC Address Table............................................................................................. 71
5.8.1 Static MAC.............................................................................................. 71
5.8.2 MAC Aging Time..................................................................................... 71
5.8.3 Dynamic Forwarding Table..................................................................... 72
5.9 Security................................................................................................................ 73
5.9.1 Storm Control.......................................................................................... 73
5.9.2 Port Security ........................................................................................... 75
5.9.3 Protected Ports ....................................................................................... 75
5.9.4 DoS Prevention ....................................................................................... 76
5.9.5 Applications ............................................................................................ 78
5.9.6 802.1x ..................................................................................................... 79
5.10 QoS...................................................................................................................... 81
5.10.1 General................................................................................................... 81
5.10.2 QoS Basic Mode.................................................................................... 86
5.10.3 Rate Limit............................................................................................... 87
5.11 Management ....................................................................................................... 90
5.11.1 LLDP ...................................................................................................... 90
5.11.2 SNMP..................................................................................................... 93
5.11.3 TCP Modbus .......................................................................................... 95
5.12 Diagnostics.......................................................................................................... 97
5.12.1 Cable Diagnostics.................................................................................. 97
5.12.2 Ping Test................................................................................................ 97
5.12.3 IPv6 Ping Test........................................................................................ 98
5.12.4 System Log............................................................................................ 99
5.12.5 DDM .................................................................................................... 101
5.13 Tools .................................................................................................................. 103
5.13.1 IXM ...................................................................................................... 103
5.13.2 Backup Manager.................................................................................. 103
5.13.3 Upgrade Manager................................................................................ 104
5.13.4 Dual Image........................................................................................... 105
5.13.5 Save Configuration .............................................................................. 105

Table of Contents
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 5
5.13.6 User Account........................................................................................105
5.13.7 Reset System........................................................................................106
5.13.8 Reboot Device ......................................................................................106
6Troubleshooting .......................................................................................107

Table of Figures
6 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
Table of Figures
Figure 3.1 Front View.................................................................................................................................. 14
Figure 3.2 Front View.................................................................................................................................. 15
Figure 3.3 System LED Panel...................................................................................................................... 16
Figure 3.4 Rear View................................................................................................................................... 16
Figure 3.5 Rear View................................................................................................................................... 17
Figure 3.6 Top View.................................................................................................................................... 18
Figure 3.7 Top View.................................................................................................................................... 18
Figure 3.8 Bottom View .............................................................................................................................. 19
Figure 3.9 Bottom View.............................................................................................................................. 19
Figure 4.1 Installing the DIN-Rail Mounting Kit.......................................................................................... 21
Figure 4.2 Removing the DIN-Rail .............................................................................................................. 21
Figure 4.3 Installing Wall Mount Plates...................................................................................................... 22
Figure 4.4 Securing Wall Mounting Screws............................................................................................... 22
Figure 4.5 Wall Mount Installation.............................................................................................................. 23
Figure 4.6 Ethernet Plug & Connector Pin Position.................................................................................... 24
Figure 4.7 Power Wiring for wienet FS 8/16-EI-W ..................................................................................... 25
Figure 4.8 Grounding Connection............................................................................................................... 26
Figure 4.9 Terminal Receptor: Relay Contact ............................................................................................. 27
Figure 4.10 Terminal Receptor: Power Input Contacts............................................................................... 27
Figure 4.11 Removing a Terminal Block..................................................................................................... 28
Figure 4.12 Installing DC Wires in a Terminal Block................................................................................... 28
Figure 4.13 Installing DC Wires in a Terminal Block................................................................................... 28
Figure 4.14 Securing a Terminal Block to a Receptor ................................................................................ 29
Figure 5.1 Login Screen.............................................................................................................................. 34
Figure 5.2 Changing a Default Password ................................................................................................... 35
Figure 5.3 Monitoring > Device Information .............................................................................................. 36
Figure 5.4 Monitoring > Logging Message ................................................................................................ 37
Figure 5.5 Monitoring > Port Monitoring > Port Statistics......................................................................... 38
Figure 5.6 Monitoring > Port Monitoring > Port Utilization........................................................................ 38
Figure 5.7 Monitoring > LLDP Statistics..................................................................................................... 39
Figure 5.8 Monitoring > IGMP Statistics .................................................................................................... 40
Figure 5.9 System > IP Settings ................................................................................................................. 41
Figure 5.10 System > DHCP Client Option 82............................................................................................ 42
Figure 5.11 System > DHCP Auto Provision .............................................................................................. 43
Figure 5.12 System > IPv6 Settings ........................................................................................................... 43
Figure 5.13 System > Management VLAN................................................................................................. 44
Figure 5.14 System > System Time............................................................................................................ 45
Figure 5.15 L2 Switching > Port Configuration.......................................................................................... 47
Figure 5.16 L2 Switching > Port Mirror...................................................................................................... 48
Figure 5.17 L2 Switching > Link Aggregation > Load Balance.................................................................. 48
Figure 5.18 L2 Switching > Link Aggregation > LAG Management .......................................................... 49
Figure 5.19 L2 Switching > Link Aggregation > LAG Port Settings........................................................... 50
Figure 5.20 L2 Switching > Link Aggregation > LACP Priority Settings.................................................... 50
Figure 5.21 L2 Switching > Link Aggregation > LACP Port Settings......................................................... 51
Figure 5.22 L2 Switching > 802.1Q VLAN > VLAN Management ............................................................. 52
Figure 5.23 L2 Switching > 802.1Q VLAN > PVID Settings....................................................................... 52
Figure 5.24 L2 Switching > 802.1Q VLAN > Port to VLAN........................................................................ 54
Figure 5.25 L2 Switching > GARP > GARP Settings.................................................................................. 55
Figure 5.26 L2 Switching > GARP > GVRP Settings .................................................................................. 56
Figure 5.27 L2 Switching > 802.3az EEE.................................................................................................... 56
Figure 5.28 L2 Switching > Multicast > Multicast Filtering+..................................................................... 57
Figure 5.29 L2 Switching > Multicast > IGMP Snooping > IGMP Settings ............................................... 57
Figure 5.30 L2 Switching > Multicast > IGMP Snooping > IGMP Querier................................................. 58
Figure 5.31 L2 Switching > Multicast > IGMP Snooping > IGMP Static Groups....................................... 59
Figure 5.32 L2 Switching > Multicast > MLD Snooping > MLD Settings.................................................. 59

Table of Figures
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 7
Figure 5.33 L2 Switching > Multicast > MLD Snooping > MLD Querier....................................................60
Figure 5.34 L2 Switching > Multicast > MLD Snooping > MLD Static Group ...........................................61
Figure 5.35 L2 Switching > Jumbo Frame..................................................................................................62
Figure 5.36 L2 Switching > Spanning Tree > STP Global Settings.............................................................62
Figure 5.37 L2 Switching > Spanning Tree > STP Port Settings.................................................................63
Figure 5.38 L2 Switching > Spanning Tree > STP Bridge Settings.............................................................64
Figure 5.39 L2 Switching > Spanning Tree > STP Port Advanced Settings ...............................................65
Figure 5.40 L2 Switching > Spanning Tree > MST Config Identification....................................................65
Figure 5.41 L2 Switching > Spanning Tree > MST Instance ID Settings....................................................66
Figure 5.42 L2 Switching > Spanning Tree > MST Instance Priority Settings............................................66
Figure 5.43 L2 Switching > X-Ring Elite > X-Ring Elite Settings ................................................................67
Figure 5.44 L2 Switching > X-Ring Elite > X-Ring Elite Groups..................................................................67
Figure 5.45 L2 Switching > MRP > MRP Settings......................................................................................68
Figure 5.46 L2 Switching > Loopback Detection > Global Settings ...........................................................68
Figure 5.47 L2 Switching > Loopback Detection > Global Settings ...........................................................69
Figure 5.48 L2 Switching > Loopback Detection > Port Settings...............................................................70
Figure 5.49 MAC Address Table > Static MAC...........................................................................................71
Figure 5.50 MAC Address Table > MAC Aging Time..................................................................................71
Figure 5.51 MAC Address Table > Dynamic Forwarding Table ..................................................................72
Figure 5.52 Security > Storm Control > Global Settings.............................................................................73
Figure 5.53 Security > Storm Control > Port Settings ................................................................................74
Figure 5.54 Security > Port Security ...........................................................................................................75
Figure 5.55 Security > Protected Ports .......................................................................................................75
Figure 5.56 Security > DoS Prevention > DoS Global Settings...................................................................76
Figure 5.57 Security > DoS Prevention > DoS Port Settings ......................................................................78
Figure 5.58 Security > Applications > HTTP ...............................................................................................78
Figure 5.59 Security > 802.1x > 802.1x Settings........................................................................................79
Figure 5.60 Security > 802.1x > 802.1x Port Configuration........................................................................80
Figure 5.61 QoS > General > QoS Properties..............................................................................................81
Figure 5.62 QoS > General > QoS Settings.................................................................................................81
Figure 5.63 QoS > General > QoS Scheduling............................................................................................82
Figure 5.64 QoS > General > CoS Mapping................................................................................................83
Figure 5.65 QoS > General > DSCP Mapping .............................................................................................84
Figure 5.66 QoS > General > IP Precedence Mapping................................................................................85
Figure 5.67 QoS > QoS Basic Mode > Global Settings...............................................................................86
Figure 5.68 QoS > QoS Basic Mode > Port Settings...................................................................................87
Figure 5.69 QoS > Rate Limit > Ingress Bandwidth Control.......................................................................87
Figure 5.70 QoS > Rate Limit > Egress Bandwidth Control........................................................................88
Figure 5.71 QoS > Rate Limit > Egress Queue............................................................................................88
Figure 5.72 Management > LLDP > LLDP System Settings.......................................................................90
Figure 5.73 Management > LLDP > LLDP Port Settings > LLDP Port Configuration.................................91
Figure 5.74 Management > LLDP > LLDP Port Settings > Optional TLVs Selection..................................91
Figure 5.75 Management > LLDP > LLDP Port Settings > VLAN Name TLV VLAN Selection...................92
Figure 5.76 Management > LLDP > LLDP Remote Device Info..................................................................92
Figure 5.77 Management > SNMP > SNMP Settings.................................................................................93
Figure 5.78 Management > SNMP > SNMP Community ...........................................................................93
Figure 5.79 Management > SNMP > SNMP User Settings ........................................................................94
Figure 5.80 Management > SNMP > SNMP Trap.......................................................................................95
Figure 5.81 Management > TCP Modbus > TCP Modbus Settings............................................................95
Figure 5.82 Diagnostics > Cable Diagnostics..............................................................................................97
Figure 5.83 Diagnostics > Ping Test............................................................................................................97
Figure 5.84 Diagnostics > IPv6 Ping Test....................................................................................................98
Figure 5.85 Diagnostics > System Log > Logging Service .........................................................................99
Figure 5.86 Diagnostics > System Log > Local Logging ..........................................................................100
Figure 5.87 Diagnostics > System Log > System Log Server...................................................................101
Figure 5.88 Diagnostics > DDM................................................................................................................101
Figure 5.89 Diagnostics > DDM................................................................................................................102

Table of Figures
8 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
Figure 5.90 Tools > IXM ........................................................................................................................... 103
Figure 5.91 Tools > Backup Manager....................................................................................................... 104
Figure 5.92 Tools > Upgrade Manager..................................................................................................... 104
Figure 5.93 Tools > Dual Image................................................................................................................ 105
Figure 5.94 Tools > User Account............................................................................................................ 106

1 About this manual
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 9
1About this manual
Please read this section carefully before you use this manual and the wienet Switch from Wieland. Here
you will find all the information required for commissioning and operation.
1.1 Target groups and qualification of personnel
Commissioning and installation of components for such types of installations must be considered.
Therefore, the system manual is targeted at the following:
Those who can verify that they have the corresponding training and already have corresponding
basic knowledge
System integrators
Electricians
1.2 Structure of the manual
As a guidance the overall table of contents is available in the manual at the beginning.
1.3 Presentation of safety-relevant information
Information that warns of personal injury or property damage are emphasized by safety instructions. Please
read this information carefully.
This operating manual uses various safety notices that are assigned according to the severity of a potential
hazard:
Danger!
Immediate or likely danger. Personal injury or death is possible.
Warning!
Possible danger. Not heeding this warning can lead to minor injuries.
Attention!
Damages to property is likely if these warnings are not heeded.
NOTE:
Supplementary information and useful tips, indirectly related to the safety of personnel or property.
"Danger" or "Warning" are strictly used for cases which present a risk to life or limb. Damage to property
only falls into these categories if there is also a risk of personal injury that corresponds to these levels.
DANGER
WARNING
ATTENTION
NOTE

1 About this manual
10 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
Please, observe the following instructions:
Attention!
The Switch must be used in compliance with all applicable international and national laws and in compliance with
any special restrictions regulating the utilization of the Switch in prescribed applications and environments.
To prevent possible injury to health and damage to appliances and to ensure that all the relevant provisions have
been complied with, use only the original accessories.
Unauthorised modifications or utilization of accessories that have not been approved may result in damage to the
Switch and in a breach of applicable regulations. Unauthorized modifications or utilization of accessories that have
not been approved may result in the termination of the validity of the guarantee.
The Switch can not be opened.
Disconnect power before making any configuration changes.
If DC voltage is supplied by an external circuit, a protection device on the Power supply input is recommended.
Warning!
Voltage must not be exceeded by 57 V DC max.at the power connector on the Switch.
Do not expose the Switch to extreme ambient conditions. Protect the Switch against dust, moisture and high tem-
perature.
The Switch should not be used at petrol stations of flammable and explosive materials. We remind the users of the
duty to observe the restrictions concerning the utilization of radio devices at petrol stations, in chemical plants, or in
the course of blasting works in which explosives are used.
Turn off the Switch when travelling by plane. Utilization of the Switch in a plane may endanger the operation of the
plane or interfere with the mobile telephone network, and may be unlawful. Failure to observe these instructions
may result in the suspension or cancellation of telephone services for the respective client, or, it may result in legal
sanctions; it may also result in both eventualities.
When using the Switch in the close proximity of personal medical devices, such as cardiac pacemakers or hearing
aids, you must proceed with heightened caution.
If the Switch is in the proximity of TV sets, radio receivers and personal computers, it may cause interference.
It is recommended that you should create an appropriate copy or backup of all the important settings that are stored
in the memory of the device.
ATTENTION
WARNING

2 Product Disposal Instructions
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 11
2Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive has been introduced to en-
sure that electrical/electronic products are recycled using the best available recovery techniques to mini-
mize the impact on the environament. This product contains high quality materials and components which
can be recycled. At the end of its life this product MUST NOT be mixed with other commercial waste for
disposal. Check the terms and conditions of your supplier for disposal information.

3 Product Overview
12 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
3Product Overview
Standard Models:
Type
Order no.
WIENET FS 8-PN-W
83.040.1510.0
WIENET FS 8-EI-W
83.040.1500.0
Wide Temperature Models:
Type
Order no.
WIENET FS 16-PN-W
83.040.1511.0
WIENET FS 16-EI-W
83.040.1501.0
3.1 Specifications
Specifica-
tions
Description
Interface
I/O-Port
WIENET FS 8-XX-W: 8 x 10/100BaseT(X)
WIENET FS 16-XX-W: 16 x 10/100BaseT(X)
Power
6-pin screw Terminal Block (including relay)
Physical
Enclosure
Metal Shell
Protection
Class
IP30
Installation
DIN-Rail and Wall-Mount
Dimensions
(W x H x D)
WIENET FS 8-XX-W: 43mm x 120mm x 84mm
(1.69in x 4.72in x 3.3in)
WIENET FS 16-XX-W: 74mm x 120mm x 84mm
(2.91in x 4.72in x 3.3in)
LED-Display
System LED
PWR1, PWR2, P-Fail, Loop detection
Port LED
Link / Speed / Activity
Environment
Operating
Temperature
Standard Temperature: -10°C ~ 60°C (14°F ~140°F)
Wide Temperature: -40°C ~ 75°C (-40°F ~167°F)
Storage
Temperature
-40°C ~ 85° C (-40°F ~ 185° F)
Ambient
Relative
Humidity
10 ~ 95% (non-condensing)
Switch
Properties
MAC Ad-
dress
WIENET FS 8-XX-W: 8K entries
WIENET FS 16-XX-W: 8K entries
Switching
Bandwidth
WIENET FS 8-XX-W: 16 Gbps
WIENET FS 16-XX-W: 32 Gbps

3 Product Overview
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 13
Specifica-
tions
Description
Power
Power
Consump-
tion
WIENET FS 8-XX-W: 5.2 Watts
WIENET FS 16-XX-W: 8 Watts
Power Input
12V ~ 48V (8.4V ~ 52.8V), redundant dual inputs
Certifica-
tions
Safety
IEC/EN 60950-1, UL508
EMC
CE, FCC
EMI
EN 55011/ 55022 Class A, EN 61000-6-4,
FCC Part 15 Subpart B Class A
EMS
EN 55024/ EN 61000-6-2
EN 61000-4-2 (ESD) Level 3
EN 61000-4-3 (RS) Level 3
EN 61000-4-4 (EFT) Level 3
EN 61000-4-5 (Surge) Level 3
EN 61000-4-6 (CS) Level 3
EN 61000-4-8 (Magnetic Field) Level 3
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6

3 Product Overview
14 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
3.2 Hardware Views
3.2.1 Front View
The following view applies to to WIENET FS 8-PN-W, WIENET FS 8-EI-W.
Figure 3.1 Front View
No.
Item
Description
1
System LED panel
See section "System LED Panel" for further details.
2
ETH port
Eight 10/100BaseT(X) ports.
Port numbers in black are designated for port based Quality of Service
(QoS) functionality.
3
LNK/ACT LED
Link activity LED.
4
Speed LED
Fast Ethernet:
Amber: 100M
Off: 10M

3 Product Overview
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 15
The following view applies to WIENET FS 16-PN-W, WIENET FS 16-EI-W.
Figure 3.2 Front View
No.
Item
Description
1
System LED panel
See section "System LED Panel" for further details.
2
ETH port
Sixteen 10/100BaseT(X) ports.
Port numbers in black are designated for port based Quality of Service
(QoS) functionality.
3
LNK/ACT LED
Link activity LED.
4
Speed LED
Fast Ethernet:
Amber: 100M
Off: 10M

3 Product Overview
16 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
3.2.1.1System LED Panel
Figure 3.3 System LED Panel
No.
LED
Name
LED Color
Description
1
PW1 LED
Solid green
Powered up.
Off
Powered down or not installed.
2
PW2 LED
Solid green
Powered up.
Off
Powered down or not installed.
3
P-Fail
Solid red
When PW1 or PW2 is disconnected.
Off
When PW1 and PW2 is connected.
4
Loop
Solid red
When loop detected.
Off
No loop detected.
3.2.2 Rear View
The following view applies to WIENET FS 8-PN-W, WIENET FS 8-EI-W.
Figure 3.4 Rear View
No.
Item
Description
1
DIN-Rail mounting
plate
Mounting plate used for the installation to a standard DIN rail.
1

3 Product Overview
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 17
The following view applies to WIENET FS 16-PN-W, WIENET FS 16-EI-W.
Figure 3.5 Rear View
No.
Item
Description
1
DIN-Rail mounting
plate
Mounting plate used for the installation to a standard DIN rail.

3 Product Overview
18 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
3.2.3 Top View
The following view applies to WIENET FS 8-PN-W, WIENET FS 8-EI-W.
Figure 3.6 Top View
The following view applies to WIENET FS 16-PN-W, WIENET FS 16-EI-W.
Figure 3.7 Top View
No.
Item
Description
1
Terminal block
Connect cabling for power and alarm wiring.
No.
Item
Description
1
Terminal block
Connect cabling for power and alarm wiring.
1
1

3 Product Overview
Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018 19
3.2.4 Bottom View
The following view applies to WIENET FS 8-PN-W, WIENET FS 8-EI-W.
Figure 3.8 Bottom View
The following view applies to WIENET FS 16-PN-W, WIENET FS 16-EI-W.
Figure 3.9 Bottom View
No.
Item
Description
1
Ground Terminal
Screw terminal used to ground chassis.
No.
Item
Description
1
Ground Terminal
Screw terminal used to ground chassis.
1
1

4 Switch Installation
20 Wieland Electric GmbH | BA001047 (Rev. A) | 06/2018
4Switch Installation
4.1 Installation Guidelines
The following guidelines are provided to optimize the device performance. Review the guidelines before
installing the device.
Make sure cabling is away from sources of electrical noise. Radios, power lines, and fluorescent
lighting fixtures can interference with the device performance.
Make sure the cabling is positioned away from equipment that can damage the cables.
Operating environment is within the ranges listed range, see "Specifications" in section 3.1.
Relative humidity around the Switch does not exceed 95 percent (noncondensing).
Altitude at the installation site is not higher than 10,000 feet.
In 10/100 fixed port devices, the cable length from the Switch to connected devices can not exceed
100 meters (328 ft).
Make sure airflow around the Switch and respective vents is unrestricted. Without proper airflow
the Switch can overheat. To prevent performance degradation and damage to the Switch, make
sure there is clearance at the top and bottom and around the exhaust vents.
4.1.1 Connecting Hardware
These instructions will explain how to find a proper location for your Switch, how to connect to the net-
work, hook up the power cable, and connect to wienet FS 8/16-XX-W.
4.2 Verifying Switch Operation
Before installing the device in a rack or on a wall, power on the Switch to verify that the Switch passes the
power-on self-test (POST). To connect the cabling to the power source, see "Power Supply Installation" in
section 4.5.
At startup (POST), the System LED blinks green, while the remaining LEDs are a solid green. Once the
Switch passes POST self-test, the System LED turns green. The other LEDs turn off and return to their
operating status. If the Switch fails POST, the System LED Switches to an amber state.
After a successful self-test, power down the Switch and disconnect the power supply. The Switch is now
ready for installation on its final location.
