WIKA NETRIS 1 User manual

Operating instructions
Betriebsanleitung
EN
DE
WIKA radio unit, model NETRIS®1
WIKA radio unit, model NETRIS®1
WIKA-Funkeinheit, Typ NETRIS®1

2
14614412.01 07/2023 EN/DE
WIKA operating instructions WIKA-radio unit, model Netris®1
EN
DE
Operating instructions model NETRIS®1 Page 3 - 41
Betriebsanleitung Typ NETRIS®1 Seite 43 - 81
© 03/2023 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!

3WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
Contents
Contents
1. General information 5
1.1 Abbreviations, definitions . . . . . . . . . . . . . . . . . .6
1.2 Explanations of symbols . . . . . . . . . . . . . . . . . .6
2. Design and function 7
2.1 Overview. . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Description . . . . . . . . . . . . . . . . . . . . . . .7
2.3 Functional principle . . . . . . . . . . . . . . . . . . . .7
2.4 Scope of delivery . . . . . . . . . . . . . . . . . . . . .8
3. Safety 8
3.1 Intended use . . . . . . . . . . . . . . . . . . . . . .8
3.2 Improper use . . . . . . . . . . . . . . . . . . . . . .9
3.3 Responsibility of the operator . . . . . . . . . . . . . . . . .9
3.4 Personnel qualification . . . . . . . . . . . . . . . . . . 10
3.5 Labelling, safety marks . . . . . . . . . . . . . . . . . . 10
3.6 Contents of the QR code on the product label (example) . . . . . . 12
3.7 Approved batteries . . . . . . . . . . . . . . . . . . . 12
3.8 Safety description for power supply . . . . . . . . . . . . . . 13
3.9 Data transmission security . . . . . . . . . . . . . . . . . 13
4. Transport, packaging and storage 14
4.1 Transport. . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Packaging and storage . . . . . . . . . . . . . . . . . . 15
5. Commissioning, operation 16
5.1 First configuration . . . . . . . . . . . . . . . . . . . . 16
5.2 Establishing the power supply . . . . . . . . . . . . . . . 16
5.3 Connecting the radio unit to a measuring instrument . . . . . . . . 17
5.4 App “myWIKA wireless device” . . . . . . . . . . . . . . . 20
5.5 Battery status . . . . . . . . . . . . . . . . . . . . . 21
5.6 Connecting the radio unit within an LPWAN . . . . . . . . . . . 21
5.7 Alarm description . . . . . . . . . . . . . . . . . . . . 21
6. Fault 24
7. Maintenance, cleaning 26
7.1 Maintenance . . . . . . . . . . . . . . . . . . . . . 26
7.2 Battery handling . . . . . . . . . . . . . . . . . . . . 26
7.3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . 28

4WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
1. General information
Declarations of conformity can be found online at www.wika.com.
8. Dismounting, return and disposal 28
8.1 Dismounting . . . . . . . . . . . . . . . . . . . . . 28
8.2 Return. . . . . . . . . . . . . . . . . . . . . . . . 29
8.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . 30
9. Specifications 31
10. Accessories and spare parts 41

5WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
1. General information
1. General information
■The instrument described in the operating instructions has been designed and
manufactured using state-of-the-art technology. All components are subject to strin-
gent quality and environmental criteria during production. Our management systems
are certified in accordance with ISO 9001 and ISO 14001.
■These operating instructions contain important information on handling the instru-
ment. Working safely requires that all safety instructions and work instructions are
observed.
■Observe the relevant local accident prevention regulations and general safety regula-
tions for the instrument's range of use.
■The operating instructions are part of the product and must be kept in the immediate
vicinity of the instrument and readily accessible to skilled personnel at any time. Pass
the operating instructions on to the next operator or owner of the instrument.
■Skilled personnel must have carefully read and understood the operating instructions
prior to beginning any work.
■In this document, the generic masculine is used for better readability. Female and
other gender identities are explicitly included.
■The general terms and conditions contained in the sales documentation shall apply.
■Subject to technical modifications.
■Factory calibrations/DAkkS calibrations are carried out in accordance with interna-
tional standards.
■Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: AC 40.03
- Additional documenta-
tion
■Special documentation for BLE®communication
protocol, model NETRIS®1, 14625126
■Special documentation for LoRaWAN®communica-
tion protocol, model NETRIS®1, 14625137

6WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
1. General information / 2. Design and function
1.1 Abbreviations, definitions
2-wire The two connection leads are used for the voltage supply.
The measuring signal also provides the supply current.
3-wire Two connection leads are used for the voltage supply.
One connection lead is used for the measuring signal.
RTD Resistance thermometer
PBT Polybutylene terephthalate
1.2 Explanations of symbols
DANGER!
... indicates a directly dangerous situation resulting in serious injury or
death, if not avoided.
WARNING!
... indicates a potentially dangerous situation that can result in serious injury
or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in light injuries
or damage to property or the environment, if not avoided.
DANGER!
... identifies hazards caused by electrical power. Should the safety instruc-
tions not be observed, there is a risk of serious or fatal injury.
DANGER!
... indicates a potentially dangerous situation in the hazardous area that can
result in serious injury or death, if not avoided.
WARNING!
... indicates a potentially dangerous situation that can result in burns,
caused by hot surfaces or liquids, if not avoided.
Information
... points out useful tips, recommendations and information for efficient and
trouble-free operation.

7WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
1. General information / 2. Design and function
2. Design and function
2.1 Overview
Example: plastic version
2.2 Description
The radio unit was developed in order to transmit sensor signals wirelessly. The instru-
ment is connected to a sensor and takes readings from it. These values are made avail-
able in the respective radio protocol.
The radio transmission is achieved via LoRaWAN®based on LPWAN technology
(low-power wide-area network) to enable large transmission ranges and long battery
life, or via Bluetooth®Low Energy.
The instrument is either powered by a battery or optionally has an external power
connection.
The radio unit meets all safety requirements of relevant standards and regulations of the
radio equipment directive for data communication.The radio unit is a product that meets
high requirements and transmits data with excellent reliability.
The transmission of the sensor signal to the IIoT platform is carried out at a preset
sending interval.The sending intervals, and also the alarm limits, can be configured over
the IIoT platform. In addition, the instrument status (current measured value, battery life,
etc.) can also be queried and set on-site via a mobile device using a local interface via
Bluetooth®Low Energy.
2.3 Functional principle
The radio unit uses the Bluetooth®Low Energy 4.2 radio standard which is designed for
energy-saving operation. In connected mode, the radio unit can be configured on-site
using a mobile device with the “myWIKA wireless device” app.
The last measured value recorded is transmitted via Bluetooth®Low Energy in “Adver-
Case top (removeable)
Battery compartment
Connector of the power supply
Case with product label
M12 x 1 connection socket






8WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
2. Design and function / 3. Safety
tising Mode” with an interval of 1.25 s.The measured value data can optionally be
removed from the advertising.
→For details on the Bluetooth®connection, see chapter 3.9 "Data transmission securi-
ty" and the additional documentation “Special documentation for BLE communication
specifications, model NETRIS®1”.
Typical applications
■Signal recording
■Setting the alarm parameters
■Fault diagnosis
■Configuration ID (for the identification of changes in the sending rate)
■Configuration change (e.g. sending rate, alarm parameter etc.)
■Setting of the analogue signal to be measured or the connected RTD signal
The analogue signal or RTD signal to be measured can only be set via
Bluetooth®.
2.4 Scope of delivery
■Radio unit
■Operating instructions
■Quick start guide login credentials for commissioning (red envelope)
■Versions with a battery: battery in the instrument
■For versions with external voltage supply:Y-cable in the packaging
3. Safety
3.1 Intended use
The radio unit wirelessly transmits the measured value of a measuring instrument
connected by cable to a higher-level system. The instrument can be used wherever an
analogue signal or an RTD value is digitalised and made available via Bluetooth®Low
Energy or LoRaWAN®. Remote monitoring of the analogue signal or RTD value can be
made through a web-based platform.
The instrument has been designed and built solely for the intended use described here,
and may only be used accordingly.
The technical specifications contained in these operating instructions must be
observed. Improper handling or operation of the instrument outside of its techni-
cal specifications requires the instrument to be taken out of service immediately and
inspected by an authorised WIKA service engineer.
Handle electronic instruments with the required care (protect from humidity, impacts,
strong magnetic fields, static electricity and extreme temperatures, do not insert any

9WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
3. Safety
objects into the instrument or its openings). Connectors and female connectors must be
protected from contamination.
The manufacturer shall not be liable for claims of any type based on operation contrary
to the intended use.
3.2 Improper use
This instrument is not permitted to be used in hazardous areas!
For applications with direct contact with foodstuffs this instrument is not suitable.
Refrain from unauthorised modifications to the instrument.
The remote monitoring function must not be used for control purposes, as it
cannot be guaranteed that data packets won't be lost during radio transmis-
sion.
The LoRaWAN®signal may only be used for mobile applications to a
limited extend.This applies particularly to high spreading factors.
Any use beyond or different to the intended use is considered as improper use.
Do not use this instrument in safety or emergency shutdown devices.This radio unit is
not suitable for use as a controller or for control and regulation purposes.
WARNING!
Danger of fire
The use of non-approved batteries can lead to personal injury, damage to
the instrument and the environment due to fire.
▶Only use approved batteries, see chapter 9 "Specifications".
3.3 Responsibility of the operator
The instrument is used in the industrial sector. The operator is therefore responsible for
legal obligations regarding safety at work.
The safety instructions within these operating instructions, as well as the safety,
accident prevention and environmental protection regulations for the application area
must be maintained.
The operator is obliged to maintain the product label in a legible condition.

10 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
3. Safety
To ensure safe working on the instrument, the operating company must ensure
■that the operating personnel are regularly instructed in all topics regarding work
safety, first aid and environmental protection and know the operating instructions and
in particular, the safety instructions contained therein.
■that the instrument is suitable for the particular application in accordance with its
intended use.
■that the requisite personal protective equipment is provided.
With increased requirements for technical cleanliness, suitability for the
application must be checked by the operator before commissioning.
3.4 Personnel qualification
WARNING!
Risk of injury should qualification be insufficient
Improper handling can result in considerable injury and damage to property.
▶The activities described in these operating instructions may only be
carried out by skilled personnel who have the qualifications described
below.
Skilled personnel
Skilled personnel, authorised by the operator, are understood to be personnel who,
based on their technical training, knowledge of measurement and control technology
and on their experience and knowledge of country-specific regulations, current stand-
ards and directives, are capable of carrying out the work described and independently
recognising potential hazards.
3.5 Labelling, safety marks
The labelling, safety markings must be maintained in a legible condition.

11WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
3. Safety
Product label (example)
1Radio standards (for LoRaWAN®with specification of the “Regional Parameter WAN”)
2 Supported sensor
3 MAC address
4DevEUI (not with Bluetooth®)
5IP ingress protection
6Pin assignment
7QR code per LoRa Alliance®specification
8Approvals
9Coded date of manufacture
10 Supply voltage of the external sensor
11 Supply voltage
12 Serial number
13 Article number
Symbols
Before mounting and commissioning the instrument, ensure you read the
operating instructions!
Do not dispose of with household waste. Ensure a proper disposal in
accordance with national regulations.
DC voltage
1 2 3 4 5 6 8
9
101213
7
11

12 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
3. Safety
3.6 Contents of the QR code on the product label (example)
LW:D0:70B3D597B0000002:70B3D597B0004D71:02A30002:S1A01FZFCOJ6:PD188
3F69EBE3:CC9B3
Contents Identifier Example Comment
SchemaID - D0 -
JoinEUI (64 bit) - 70B3D597B0000002 JoinEUI = AppEUI
DevEUI (64 bit) - 70B3D597B0004D71 -
ProfileID - 02A30002 02A3 = VendorID WIKA; 0002 last 4
digits of the JoinEUI
SerNum S 1A01FZFCOJ6 Alphanumeric WIKA serial number
(11-digit)
Proprietary P D1883F69EBE3 Bluetooth®MAX address:
D1:88:3F:69:EB:E3
CheckSum C C9B3 -
3.7 Approved batteries
To ensure proper operation and the best possible performance, use only the batteries listed, see
chapter 10 "Accessories and spare parts".
Battery
Battery pack Lithium thionyl chloride battery and hybrid layer capacitor (model Tadiran
HLC1020L) as an assembly with connection cable assembled, see
chapter 10 "Accessories and spare parts".
■Model Tadiran SL861/S
■Model Tadiran SL860/S
With version with batteries, use only the suitable case, see chapter 5.2 "Establishing the power
supply" and 9 "Specifications".

13WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
3. Safety
CAUTION!
Physical injuries and damage to property and the environment
Lithium thionyl chloride batteries are not rechargeable. Improper handling
can lead to leakage or escape of vapourised electrolyte vapours and cause
a fire or explosion.
▶Do not open the battery.
▶Do not damage the battery cells.
▶The positive and negative connections must not be short-circuited with
conductors.
▶Do not reverse the polarity.
▶Do not expose the battery to excessive mechanical loads.
▶Do not expose the battery to water or condensation.
▶Do not heat, solder or expose the battery to fire.
▶Do not use any rechargeable batteries!
▶Do not continue to use batteries that have been dropped on the ground.
3.8 Safety description for power supply
The M12 connector must only be plugged in and removed from the instrument in an
unpowered state.
Ingress protection per EN 60529 IP65 (when connected or screwed in)
Pollution degree 3
Temperature range -20 ... +60 °C [-4 ... +140 °F]
External voltage supply DC 18 ... 30 V
Voltage supply of battery 3.6 V
Current supply Max. 250 mA
Max. Altitude 2,000 m [6,562 ft]
External power supply
Only the supplied Y-cable may be used to connect the power supply. The radio unit must
be connected to a power supply with an output power limited to 15 W. Alternatively, the
radio unit can be protected with a fuse (taking into account the DC rating of the fuse) at
the DC input with a fuse rating of F 250 mA/fast-acting.
3.9 Data transmission security
LoRaWAN®
LoRaWAN®transmission uses the cryptographic principle of AES encryption in
combination with several operating modes: for a secure data transmission, CMAC2
for integrity protection and CTR3 for encryption. Each LoRaWAN®device is person-

14 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
alised with a unique 128-bit AES key (AppKey) and a globally unique identifier
(EUI-64-based DevEUI), both used during the device authentication process.
→Further details can be found in the official LoRaWAN®Security White Paper from the
LoRa Alliance®, see https://lora-alliance.org
Bluetooth®Low Energy
Bluetooth®Low Energy communicates in the licence-free 2.4 GHz ISM band and is a
globally harmonised energy-efficient radio standard. Bluetooth®Low Energy uses 40
channels between 2.402 GHz and 2.480 GHz. Encryption is performed using the AES
128 encryption algorithm in combination with distributed key replacement.
The radio unit transmits the measured value as an optional broadcast message on the
advertising channels 37, 38 and 39, in addition to the instrument name and the battery
charge status. Further information and detailed configuration and command options are
available via a point-to-point connection.
Pairing is established using a passkey entry method and requires the entry
of a security code. Instrument settings can only be accessed after pairing
has been completed.The pairing key is set individually for each instru-
ment and is made available to the customer with the quick start guide. For
individual applications, the pairing key can be configured by the user via the
app.
If the security code is entered incorrectly 5 times, the instrument is blocked
for connection with this code. After disconnecting the voltage supply or
removing the battery, 5 attempts are once again available. If this is not
possible for technical reasons, e.g. because the sensor cannot be reached
to open the case, contact technical support.
4. Transport, packaging and storage
4.1 Transport
Check the radio unit for any damage that may have been caused.
Obvious damage must be reported immediately.
CAUTION!
Damage through improper transport
With improper transport, damage to property can occur.
▶When unloading packed goods upon delivery as well as during internal
transport, proceed carefully and observe the symbols on the packaging.
▶With internal transport, observe the instructions in chapter
4.2 "Packaging and storage".
3. Safety / 4. Transport, packaging and storage

15WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
Strictly observe the following when shipping the instrument:
All instruments delivered to WIKA must be free from any kind of hazardous substances
(acids, bases, solutions, etc.) and must therefore be cleaned before being returned.
Remove the batteries before returning!
The lithium-ion rechargeable batteries or lithium-metal batteries included are subject to
the requirements of the dangerous goods law. Special requirements for packaging and
labelling must be observed when shipping. A dangerous goods expert must be consult-
ed when preparing the package. Do not send any damaged or defective rechargeable
batteries. Mask open contacts and pack the rechargeable battery so that it does not
move in the packaging and also prevents short-circuits. Observe the different dangerous
goods requirements relative to the respective modes of transport and any other national
regulations.
If the instrument is transported from a cold into a warm environment, the formation of
condensation may result in instrument malfunction. Before putting it back into operation,
wait for the instrument temperature and the room temperature to equalise.
4.2 Packaging and storage
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. change
in installation site, sending for repair).
Permissible conditions at the place of storage:
■Storage temperature: -40 ... 70 °C [-40 ... 158 °F]
■Humidity: 35 ... 85 % relative humidity (non-condensing)
Avoid exposure to the following factors:
■Direct sunlight or proximity to hot objects
■Mechanical vibration, mechanical shock (putting it down hard)
■Soot, vapour, dust and corrosive gases
Store the radio unit in its original packaging in a location that fulfils the conditions
listed above. If the original packaging is not available, pack and store the instrument as
described below:
1. Disconnect the batteries.
2. Wrap the instrument in an antistatic plastic film.
3. Place the instrument, along with the shock-absorbent material, in the packaging.
4. If stored for a prolonged period of time (more than 30 days), place a bag containing a
desiccant inside the packaging.
4. Transport, packaging and storage

16 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
5. Commissioning, operation
Personnel: Skilled personnel
Only use original parts, see chapter 10 "Accessories and spare parts".
5.1 First configuration
Check the radio unit for any damage that may have been caused. Obvious damage
must be reported immediately.
First commission the radio unit without any measuring instrument connect-
ed.The configuration with the appropriate WIKA sensor must be carried out
in advance, in order to avoid damage to the measuring instrument or the
radio unit.
5.2 Establishing the power supply
Depending on the version of the radio unit, the power supply is established via the inter-
nal battery or the enclosed Y-cable.
Connecting the battery
Version with battery In as-delivered condition, the battery is not
connected to the electronics.
Connecting the battery, see chapter
7.2 "Battery handling":
1. Open the case as required by the
version of the radio unit - a bayonet
lock (plastic version) or a screw-on lid
(metal version) is fitted.To do this, grip
the upper and lower sides of the instru-
ment with your hands and turn them as
shown by the marking on the cover.
2. Plug in the battery connector and snap
it into place (⇒ LED lights up).
3. Put the case on and close it.To do this,
grip the upper and lower sides of the
instrument with your hands and turn
them in opposite directions as shown
by the marking on the cover.
5. Commissioning, operation

17WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
Connecting the external power supply
5.3 Connecting the radio unit to a measuring instrument
1. Disconnect the radio unit from the external power supply / battery supply after
successful configuration.The selected radio unit configuration is saved.
2. Connect the radio unit to a measuring instrument
→For the version with an external power supply, connect the measuring instrument to
the end of the connector without colour-coding.
→For connections with open cable ends, see "Pin assignment of free cable ends" in
chapter 9 "Specifications".
3. Ensure that the power supply to the radio unit is restored.The radio unit restarts with
the settings made previously.
Version with external power supply 1. Connect the radio unit to the end of the
short Y-cable (marked blue).
2. Connect the (red-marked) connector to
the external power supply.
The supply voltage should not exceed or
drop below the voltage range mentioned
in chapter 9 "Specifications", in order to
ensure trouble-free operation. It may be
necessary to provide a separate fuse for
the radio unit.
The version of the radio unit with an exter-
nal power supply does not have a built-in
battery. Similar to the version with battery,
the case can be opened to check the
status of the LED.
5. Commissioning, operation

18 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
CAUTION!
Damage to property due to electrostatic discharge (ESD)
When working on open electric circuits (PCBs) there is a risk of damaging
sensitive electronic components through electrostatic discharge.
▶The correct use of grounded working surfaces and personal armbands is
required.
▶Before removing the case top, touch the grounded metal part of the
case, or an alternative adjacent grounded metal object (e.g. radiator or
pipes), in order to discharge any static from the body.
▶Do not touch the PCB and electrical components.
▶When the case is open, e.g. during connecting or changing the battery
pack, sufficient ESD protection must be ensured.
▶Avoid contact between the electronics and clothing.
For the first 25 minutes after connecting the power supply, the LED function is activated.
LED colour Mode Meaning
Blue Blinks once Internal communication between radio and sensor PCBs
Cyan ON for the
duration of the
join procedure
LoRaWAN®join procedure running
Cyan Blinks once LoRaWAN®join procedure successful
Red Blinks twice LoRaWAN®join procedure not successful
Red Blinks twice LoRaWAN®data transfer not successful (confirmed
message)
Green Blinks twice LoRaWAN®data transmission successful (confirmed
message)
Notes on the sending characteristics
■In order to achieve the best possible transmission quality, the radio link from the
terminal device to the receiving gateway should be as free of barriers as possible.
■The signal strength is from slightly to severely affected by concrete walls, metal
shielding, enclosures and hilly landscapes.
■For the best possible transmission performance of the antenna, no metal objects,
such as pipelines, may be closer than 10 cm [3.9 in] to the antenna.
■With installation, pay attention to the sending characteristic of the instrument as well
as the information from the following figure:
5. Commissioning, operation

19WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
Radiation characteristics:
Information on the installation of the receiving gateway
Position the gateway in such a way that the transmission power is optimally utilised. For
this, the following recommendations should be observed:
■Depending on the application, a gateway for indoor or outdoor use should be
selected.
■The radiation characteristics of the antenna should be taken into account when
positioning the gateway.
■If the sensors are located on one level, vertical mounting of the LoRaWAN®antenna
on the gateway is recommended.The location should ideally be in the middle of the
area to be covered.
■If the sensors are located on several levels, the gateway should be placed in the
middle of the building and the gateway antenna should be aligned horizontally.
■Another option is to place the gateway outside the building and align the antenna
vertically. In this way, a sufficient radio connection can be established from the
outside to several floors.
■In outdoor areas, ensure that the gateway is mounted at a sufficient height and is not
covered by anything in the immediate vicinity. The higher the gateway is positioned,
the further the LoRaWAN®connection reaches.
30
60
90
120
150
180
210
240
270
300
330
0
Z
Y
X
Horizontal polarisation, x-z plane
Vertical polarisation, x-y plane
-40 dB
-30 dB-20 dB -10 dB
5. Commissioning, operation

20 WIKA operating instructions WIKA-radio unit, model Netris®1
14614412.01 07/2023 EN/DE
EN
5.4 App “myWIKA wireless device”
Via the “myWIKA wireless device” app and a Bluetooth®Low Energy
connection, the functionality of the LoRaWAN®communication can be
activated and deactivated through the mobile device. Furthermore, the
instrument data and the current measured value can be read via the app.
For this, follow the instructions on the screen.
Temperature adjustment for versions with RTD sensors
The temperature adjustment can be found in the “myWIKA wireless device” app under
“Device” / “Device actions” / “Temperature adjustment”.
The associated “password” is WIKA_Calibration!.
For RTD sensors (Pt100/Pt1000 2- /3-wire), adjustment values can be saved separately
in the radio unit:
1. Set the RTD sensors to be calibrated via “sensor measurements”.
2. Manual reset of “offset” and “gain” via “user calibration”. Reset “gain” to 1.0f
and “user calibration” “Offset” to 0.0f or reset the instrument to factory settings.
The user calibration is set at the factory and offers a high level of accuracy,
so calibration by the customer is not necessary.
Resetting the radio unit to the factory settings resets the settings for all RTD
variants (PT100/PT1000 2-/3-wire).
Two calibration points (P1 in K < P2 in K) must then be measured. In order to achieve a
high degree of accuracy, it is advisable to wait a short time until the measured value has
settled and to record this and the reference value.
The calculation of “offset” and “gain” will be carried out in accordance with the follow-
ing formulae:
Finally, the calculated values of “gain” and “offset” are entered and these are trans-
ferred to the radio unit using the “apply” button.
5. Commissioning, operation
