Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
Thermowells model TW61
Thermowell for sanitary applications, model TW61
Schutzrohr für die sterile Verfahrenstechnik, Typ TW61
Doigt de gant pour applications sanitaires, type TW61
Vaina para procesos estériles, modelo TW61

© 03/2012 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d‘emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta!
ES
FR
DE
EN
2
WIKA operating instructions thermowell, model TW61
11593963.06 04/2019 EN/DE/FR/ES
Operating instructions model TW61 Page 3 - 18
Betriebsanleitung Typ TW61 Seite 19 - 34
Mode d'emploi type TW61 Page 35 - 50
Manual de instrucciones modelo TW61 Página 51 - 65

WIKA operating instructions thermowell, model TW61
11593963.06 04/2019 EN/DE/FR/ES
3
EN
Contents
Contents
1. General information 4
2. Design and function 5
3. Safety 10
4. Transport, packaging and storage 12
5. Commissioning, operation 13
6. Additional notes for instruments with EHEDG and 3-A 14
7. Faults 14
8. Maintenance and cleaning 15
9. Dismounting, return and disposal 16
10. Specifications 17

11593963.06 04/2019 EN/DE/FR/ES
4
WIKA operating instructions thermowell, model TW61
EN
1. General information
■The thermowells described in the operating instructions have been manufactured
using state-of-the-art technology. All components are subject to stringent quality and
environmental criteria during production. Our management systems are certified to
ISO 9001 and ISO 14001.
■These operating instructions contain important information on handling the thermowell.
Working safely requires that all safety instructions and work instructions are observed.
■Observe the relevant local accident prevention regulations and general safety
regulations for the thermowell's range of use.
■The operating instructions are part of the product and must be kept in the immediate
vicinity of the thermowell and readily accessible to skilled personnel at any time.
■Skilled personnel must have carefully read and understood the operating instructions
prior to beginning any work.
■The manufacturer's liability is void in the case of any damage caused by using the
product contrary to its intended use, non-compliance with these operating instructions,
assignment of insufficiently qualified skilled personnel or unauthorised modifications to
the thermowell.
■The general terms and conditions contained in the sales documentation shall apply.
■Subject to technical modifications.
■Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: TW 95.61
- Application consultant: Tel.: [phone]
Fax: [phone]
[e-mail]
1. General information

WIKA operating instructions thermowell, model TW61
11593963.06 04/2019 EN/DE/FR/ES
5
EN
2. Design and function
2. Design and function
2.1 Description
The model TW61 thermowell is used to adapt thermometers and measuring inserts to the
process and protects the sensor against harsh process conditions. Furthermore, it enables
the removal of the temperature probe without having to open the process.
To integrate it into the process, the thermowell is directly orbitally welded into a pipeline.The
connection ends are smooth and prepared for orbital welding.
In combination with a resistance thermometer, the rotatable threaded connection of the
connection head or the display can be loosened and turned to the desired orientation.
The measuring insert can be withdrawn together with the connection head. In this way,
it is possible to calibrate the entire measuring chain (sensor, transmitter if applicable,
connection cable) on site, without having to disconnect the electrical connection. In addition
this avoids having to open the process, and thus the risk of contamination is minimised.
The thermowell is not piggable.
2.2 Dimensions in mm
■Flow-through housing
alternative Darstellung
14000996.01
For miniature resistance thermometer model TR21-B
1)
1) In the event of replacement,
calculate the probe insertion
length, l1, as follows:
l1 (TR21-B) = U1+ M + 3 mm

11593963.06 04/2019 EN/DE/FR/ES
6
WIKA operating instructions thermowell, model TW61
EN
11528266.01
For model TR22-B resistance thermometer
2) In the event of replacement, select a resistance thermometer measuring insert model TR11-A.
The corresponding sensor length, l5, is calculated as follows:
Insertion length U1 + neck tube length M (85 mm) + 5 mm pre-load + 10 mm head dimension
Pre-load
DIN 11866 row A or metric
3) Maximum operating temperature 150 °C
4) All thermowells of this series that are internally pressurised, with a nominal diameter (DN) > 25 mm, are
manufactured and tested to module H of the pressure equipment directive.
14006093.04
2)
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
OD PN 3) 4) Ø D s TL U1M M
10 25 13 1.5 70 6 51 129
15 25 19 1.5 70 9 48 126
20 25 23 1.5 80 11 46 124
25 25 29 1.5 100 18 39 117
32 25 35 1.5 110 18 39 117
40 25 41 1.5 120 18 39 117
50 25 53 1.5 160 30 27 105
65 16 70 2.0 210 30 27 105
80 16 85 2.0 260 45 12 90
100 12.5 104 2.0 310 45 12 90
2. Design and function

WIKA operating instructions thermowell, model TW61
11593963.06 04/2019 EN/DE/FR/ES
7
EN
DIN 11866 row B or ISO pipes
2. Design and function
DIN 11866 row C or ASME BPE
3) Maximum operating temperature 150 °C
4) All thermowells of this series that are internally pressurised, with a nominal diameter (DN) > 25 mm, are
manufactured and tested to module H of the pressure equipment directive.
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
DN (OD) PN 3) 4) Ø D s TL U1M M
8 (13.5) 25 13.5 1.6 64 6 51 129
10 (17.2) 25 17.2 1.6 68 9 48 126
15 (21.3) 25 21.3 1.6 72 11 46 124
20 (26.9) 25 26.9 1.6 110 11 46 124
25 (33.7) 25 33.7 2.0 120 18 39 117
32 (42.4) 25 42.4 2.0 130 18 39 117
40 (48.3) 25 48.3 2.0 130 18 39 117
50 (60.3) 25 60.3 2.0 180 30 27 105
65 (76.1) 16 76.1 2.0 220 30 27 105
80 (88.9) 16 88.9 2.3 260 45 12 90
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
OD PN 3) 4) Ø D s TL U1M M
½" 13.8 12.7 1.65 95.2 6 51 129
¾" 13.8 19.05 1.65 101.6 9 48 126
1" 13.8 25.4 1.65 108.0 11 46 124
1 ½" 13.8 38.1 1.65 120.6 18 39 117
2" 13.8 50.8 1.65 146.0 18 39 117
2 ½" 13.8 63.5 1.65 158.8 30 27 105
3" 13.8 76.2 1.65 171.4 30 27 105
4" 13.8 101.6 2.11 209.6 45 12 90

11593963.06 04/2019 EN/DE/FR/ES
8
WIKA operating instructions thermowell, model TW61
EN
2. Design and function
11528452.01
11575795.02 14000996.01
1) In the event of replacement, calculate the
probe insertion length, l1, as follows:
l1 (TR21-B) = U1+ M + 3 mm
For miniature resistance thermometer model TR21-B
For model TR22-B resistance thermometer
1)
2) In the event of replacement, select a
resistance thermometer measuring insert
model TR11-A.
The corresponding sensor length, l5, is
calculated as follows:
Insertion length U1 + neck tube length
M (85 mm) + 5 mm pre-load + 10 mm head
dimension
2)
alternative Darstellung
■Angular housings (recommended mounting position, see chapter 5 “Commissioning,
operation”)

WIKA operating instructions thermowell, model TW61
11593963.06 04/2019 EN/DE/FR/ES
9
EN
2. Design and function
DIN 11866 row B or ISO pipes
DIN 11866 row A or metric
3) Maximum operating temperature 150 °C
4) All thermowells of this series that are internally pressurised, with a nominal diameter (DN) > 25 mm, are
manufactured and tested to module H of the pressure equipment directive.
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
DN (OD) PN 3) 4) Ø D s TL L1U1M M
8 (13.5) 25 13.5 1.6 32 55 14 43 121
10 (17.2) 25 17.2 1.6 34 55 16 41 119
15 (21.3) 25 21.3 1.6 36 58 18 39 117
20 (26.9) 25 26.9 1.6 55 81 30 27 105
25 (33.7) 25 33.7 2.0 60 91 30 27 105
32 (42.4) 25 42.4 2.0 65 102 30 27 105
40 (48.3) 25 48.3 2.0 65 108 30 27 105
50 (60.3) 25 60.3 2.0 90 145 45 12 90
65 (76.1) 16 76.1 2.0 110 173 45 12 90
80 (88.9) 16 88.9 2.3 130 203 45 12 90
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
OD PN 3) 4) Ø D s TL L1U1M M
10 25 13 1.5 35 55 14 43 121
15 25 19 1.5 35 55 18 39 117
20 25 23 1.5 40 63 18 39 117
25 25 29 1.5 50 77 30 27 105
32 25 35 1.5 55 87 30 27 105
40 25 41 1.5 60 97 30 27 105
50 25 53 1.5 80 126 30 27 105
65 16 70 2.0 105 165 45 12 90
80 16 85 2.0 130 201 45 12 90
100 12.5 104 2.0 155 241 45 12 90

11593963.06 04/2019 EN/DE/FR/ES
10
WIKA operating instructions thermowell, model TW61
EN
2.3 Scope of delivery
Cross-check scope of delivery with delivery note.
3. Safety
3.1 Explanation of symbols
WARNING!
... indicates a potentially dangerous situation that can result in serious injury or
death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in light injuries or
damage to equipment or the environment, if not avoided.
DANGER!
... identifies hazards caused by electric power. Should the safety instructions not
be observed, there is a risk of serious or fatal injury.
WARNING!
... indicates a potentially dangerous situation that can result in burns, caused by
hot surfaces or liquids, if not avoided.
2. Design and function / 3. Safety
DIN 11866 row C or ASME BPE
3) Maximum operating temperature 150 °C
4) All thermowells of this series that are internally pressurised, with a nominal diameter (DN) > 25 mm, are
manufactured and tested to module H of the pressure equipment directive.
Nominal
width of
pipe
Nominal
pressure
in bar
Outer
diameter
of pipe
Pipe
schedule
Pipe
length
Thermowell
insertion
length
Neck tube
length
TR21-B TR22-B
OD PN 3) 4) Ø D s TL L1U1M M
½" 13.8 12.7 1.65 47.6 71 14 43 121
¾" 13.8 19.05 1.65 50.8 71 18 39 117
1" 13.8 25.4 1.65 54.0 79 18 39 117
1 ½" 13.8 38.1 1.65 60.3 94 30 27 105
2" 13.8 50.8 1.65 73.0 118 30 27 105
2 ½" 13.8 63.5 1.65 79.4 134 45 12 90
3" 13.8 76.2 1.65 85.7 150 45 12 90
4" 13.8 101.6 2.11 104.8 190 45 12 90
