Operation Manual
Pressure Filter CPF Series
50105, 50123, 50977–50980, 50121, 51042–51044
Illustrations similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignific -
antly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

The information contained in this document may alter at any time without previous notice. It is prohib-
ited to copy or spread any parts of this document in any way without prior written allowance. ll rights
reserved.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously
or placing your order via the webshop.
E-mail: [email protected]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. tten -
tion! To allow for a smooth execution of your complaint or return, it is important to contact our cus -
tomer service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: service wiltec.info
Tel:[phone]
Fax: [phone]
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 2
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our cli-
ents take some basic safety precautions when using this device. Please read the operation in-
structions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety guideline
BEWARE:
The use of this device is allowed on standing water bodies, garden pond water or swimming ponds
and their surrounding areas is only allowed with a fault current protection-switch with a triggering nom-
inal current up to 30>m (according to VDE 0100 article 702 and 738).
The device is not suitable for use in swimming pools, paddling pools and other water bodies where
there are people or animals during operation. The operation of the device during the presence of
people and animals in the danger zone is not allowed. sk your electrician.
The device is not intended for use by persons (including children) with impaired or limited physical,
sensory and mental abilities or lack of experience and/or real knowledge, unless they are supervised
by a person responsible for their safety or follow the instructions made by this person on how to use
the device correctly.
Children should be supervised to make sure that they do not play with the device.
ATTENTION:
Run a visual inspection of the device before every use. Do not use the device if the safety ap-
pliances are damaged or worn out. Never override safety regulations.
Use the device exclusively according to the intended purpose stated in the instructions for
use.
You are responsible for the safety of the working environment.
If the cable or the plug is damaged due to external influences, the cable must not be repaired!
It has to be replaced with a new one. This work can be carried out only by an electrician.
The voltage indicated on the type plate of the device of 230>V C has to correspond to the ex-
istent mains voltage.
Never lift, carry or fixate the device by using the power cable.
Make sure that the electrical plug connection is placed in a flood-proof area and is protected
from moisture.
Before working on the pond filter disconnect the appliance by taking the plug out of the socket.
void exposing the appliance to a direct water jet or rain.
The user is responsible for the compliance with local safety and installing regulations. sk an
electrician.
Consequential damage arising from flooded rooms caused by dysfunctions of the appliance
must be avoided by means of the appropriate measures (e.>g. installing an alarm system, re-
serve pump).
In case of malfunction, the repair work can be carried out only by a qualified electrician.
The appliance must not run dry or with an intake port completely closed. The manufacturer’s
warranty is no longer valid if the damage is caused by dry running.
The appliance must not be used for swimming pools.
The appliance must not be used for drinking water circuits.
The device has to be installed out of water.
The distance from the device to the pond has to be at least 2>m.
You have to make sure that the filter cannot fall into the water.
You have to make sure that the filter is not exposed directly to sunlight.
The pond pressure filter has to be horizontally fixed with screws on a suitable mounting place.
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 3
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

The universal hose stepped tails can be shortened according to the hose diameter if neces-
sary.
ttach hoses and hose clamps.
lthough the ultraviolet radiation is the lowest of the ionizing radiation, it can be dangerous for
people and other organisms as well. UV radiation with longer wavelengths can destroy the
chemical bonds of the organic molecules, too. Therefore a responsible approach is necessary
when dealing with technical UV sources.
Only operate the tubes inside a housing that is closed and not cracked.
WARNING:
Read carefully all the safety guidelines and the instructions.
Non-compliance with the safety rules and regulations can lead to an electric shock, fire and/or serious
injury. Keep the instructions and the safety guidelines in a safe place in case you need them in the fu-
ture.
Stability
The temperature of the conveyed liquid should not exceed +35>℃ in permanent operation.
The conveyance of flammable, gassing or explosive fluids is forbidden. This pump cannot be
used for other fluids particularly not for motor fuels, cleaning agents or other chemical
products.
Electrical connection
The electrical connection takes place via an electric safety socket 230>V ~ 50>Hz. Fuse protection at
least 10> .
Warning:
The UVC filter should be placed in such a way so that the water cannot reach it. The distance
between the pond edge and the filter should reach at least 2>m. The UV lamp cannot be oper-
ated under water.
The power supply of the UVC filters must not be turned on before the water circulation has
been carried out.
Please position the UVC filter on a safe and stable place because the pond filter light tube (the
tube that conveys the light) is made of quartz glass that can burn easily.
Do not turn the power on before all the component parts of the device are installed.
If the quartz glass tube or the upper part of the UVC filter is damaged, the pond pressure filter
cannot be used.
The UVC filter cannot be used either if there are people in the pond water.
Make sure that the used voltage and the frequency correspond to those indicated on the filter
label.
When the device is installed, you have to pay attention to the domestic installation rules.
Please do not pull on the connecting cord. Keep it away from heat, grease and sharp objects.
Make sure the upper part of the filter is exposed to pressure lower than 0,3>bar.
In frosty weather please remove the UV filter.
When you install the UV filter, do not expose it to direct sunlight.
Dirt influences the efficiency of the quartz glass tube; therefore it needs to be regularly
cleaned.
To secure the proper functioning of the device, the UV-quartz tube should be replaced after
8000 operating hours.
If the upper part is blocked by sand, the quartz tube can be destroyed. Please place the filter
sponge in the inlet of the water pump.
UV light is harmful for the eyes and skin. Do not look directly into the UV light, and do not ex-
pose your skin to it.
If you install the device or repair it, switch off the power supply of the lamp and the pump.
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 4
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

The device must be installed on a horizontal flat surface with the feet downwards. For safety
reasons, it not allowed to install the device otherwise.
Application area/functioning
This UVC device ensures clear water for healthy fish. The water is pumped by a pump through the
UVC device. There it flows past the UV lamp and is exposed to UVC radiation. Thus the bacteria,
germs and floating algae in the water are destroyed, and the water is clarified.
To achieve an optimal result the device should be operated 24 hours in the frost-free seasons.
Commissioning
Switch on the pump and wait until the device is filled with water. Check if all connections are well
sealed. By plugging in the power cable, the device is put into operation.
Technical data
Model Item
number
Power
(W)
Ten-
sion/
fre-
quency
Suitable for … up to
(ℓ)
Recom-
mended
max. flow
rate (ℓ⁄h)Input/output
(㎜)
Fish
ponds
Decorat-
ive
ponds
CPF-180 50123
11
230>V/
50>Hz
3000 6000 9000 19/25/32/40
CPF-250 50105 5000 10000 10000
CPF-280 51042 4000 8000 9000
19/25/32/38CPF-380 51043 6000 12000 10000
CPF-500 51044 18 10000 30000
CPF-2500 50978
11
3000 6000 6000 19/25/33
CPF-5000 50976 4000 8000 9000
19/25/32/40CPF-10000 50977 6000 12000 10000
CPF-15000 50121 18 10000 30000
CPF-20000 50979 36 20000 40000 12000 32/38
CPF-30000 50980 55 30000 60000 32/38
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 5
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Safety
This device emits dangerous radiation. Being harmful, direct contact to skin and eyes must be
avoided.
If the pond filter is damaged, it must not be operated.
When no water is transported, the device must be switched off.
By frosty weather, the device must be removed and kept dry in a place free of frost.
Description
CPF-180/CPF-250
Water inlet from the pump into the filter
Water flow from the filter into the pond
Clean water outlet from the filter to waste water or flower bed
Function position “Filter”
Function position “Clean”
CPF-2500/CPF-5000/CPF-10000/CPF-15000/CPF-20000/CPF-30000
Water inlet from the pump into the filter
Water flow from the filter into the pond
Clean water outlet from the filter to waste water or flower bed
The WilTec pressure filter is an ideal filter system for your garden pond. The filter has more advant-
ages:
high cleaning capacity
combine mechanical and biological (depending on model) filtering
performant filter material
built-in UVC unit and dirt indicator
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 6
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

remains waterproof also by high pressure
water delivery 3>m height (dependent on pump output which is connected)
easy installation and maintenance of the filter
WilTec pond filter functions
The WilTec pond filter clarifies the water in 3>phases:
1. The first stage is mechanic. The visible particles of dirt are removed by means of a 3-layer fil-
ter foam, arranged from coarse to fine.
2. The second stage is biologic. With the help of the so-called bio-balls (depending on model)
the settling of bio-organisms is stimulated. These bio-organisms remove the organic compon-
ents from the pond water (depending on model).
3. The third stage comprises a UVC water treatment. The UV light destroys swimming algae
and germs. The result is healthy water.
Commissioning
The pressure filter should be placed at least at a 2-meter distance from the pond edge. The
water outlet back to pond should be placed max. 2>m over the filter cover (0,2>bar water pres-
sure!).
The pump must be started first. The UVC lamp must not be operated as long as no water
flows through it. Do not use the UVC lamp if the lamp or the connections show damage signs.
Do not use the UVC-filter if there are people inside the water.
The built-in UV filter temperature sensor stops the UVC lamp. fter cooling down, it is auto -
matically re-started.
The WilTec filter is delivered with all the necessary filter mats. Carefully wash the filter mats
with pond water before using. The bio-balls (depending on model) are placed at the bottom of
the filter, above put the grating with the protective tube for the UVC unit. Then put the filter
foam layers on it, arranged from fine to coarse. Put the cover lid on the housing and close the
filter with the supplied cramping bracket.
If properly installed, the filter is waterproof up to a 0,5>bar working pressure. The power supply
has to be equipped with an earth leakage circuit breaker that does not exceed 30>m .
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 7
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Install stepped hose tails
Place the coupling rings around the black hose tails, insert the flat gaskets in the coupling ring and
screw it on the water inlet and outflow connection. Screw the hose tails with the flat gaskets on the
device.
Connection to the water inlet
The pump is connected to the hose tail whose arrow is directed towards the filter. Use a hose diameter
which is exactly the same as the diameter of the pump outlet. Saw off the hose steps that you do not
need.
Connection to the water outlet
The hose tail with the arrow showing away from filter is the outflow towards the pond. Connect a suit -
able hose to the large diameter step of the hose tail and saw off the other hose steps. Use hose
clamps to prevent the loosening of the hoses.
Connection to the cleaning outlet
To install a permanent drain hose to the cleaning connection (Clean), you have to unscrew/remove the
stepped tail to the cleaning connection (Clean), install the third stepped hose tail and connect a suit-
able hose. In the filter operation, the cleaning connection or a connected drain hose must be always
closed and sealed with a hose tail (closure cap) and gasket seal, for safety means, in case the func -
tion switch is accidentally set on “Clean.”
Attention! Do not operate the device
without water flow or
pump
fil-
te
r
!
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 8
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Operating principle of the pressure filter
The pressure filter with the integrated UV lamp is a sealed filter system for biological and mechanical
cleaning of pond water.
CPF-180/CPF-250 CPF-2500-5000-10000-15000-20000-30000
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 9
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

CPF-280/CPF-500
Part Name Explanation
AWater inlet The pump is connected to the water inlet via a pressure hose.
BWhirl system The water permeates through the bio-filter materials due to the cent-
rifugal and gravitational forces.
CMechanical filter Dirt particles are retained on the surface of the sponge filter before
the water flows towards the inner of the filter.
DBiological cleaning
Microorganisms settle on the filter sponge pores. The blue and the
yellow filter sponge differ in size and density. This generates zones/
areas through which the water flows at different speeds. In the
zones/areas with a high flow speed (blue filter), mainly microorgan-
isms settle that convert ammonium to nitrate. In the areas in which
the water flows faster (yellow filter), mainly anaerobic microorgan-
isms accumulate that reduce the nitrate to nitrogen.
EPre-cleaning of the pond
water
When the water flows out, it is shortly exposed to the UV radiation
emitted by the UV lamp. s a result, germs, bacteria, and algae are
destroyed. The water circulates when flowing through the filter from
inside outwards.
FWater discharge with
flow display The cleaned water flows back into the pond.
G
Hose tails for rinsing water when on cleaning (CPF-180/CPF-250)
Flow indicator (CPF-280/CPF-500)
Hose tails for rinsing water when on cleaning (CPF-2500-5000-10000-15000-20000-30000)
HThe function switch changes between “filtration” and “clean filter.”
I
Flow indicator (CPF-
180/CPF-250)
When there is too much dirt on the sponge, the turbidimeter will
change from green to yellow to warn you to clean the sponge.
Cleaning crank (CPF-2500-5000-10000-15000-20000-30000)
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 10
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Cleaning the filter sponge with crank (CPF-2500-5000-10000-15000-20000-30000)
The filter sponge can be cleaned by turning around the cleaning handle. Installation guidelines
with regard to the clear water guarantee, the following installation guidelines must be ob-
served.
Please read the following notes in order to ensure that the water always is cleaned sufficiently:
◦The filter system has to remain switched on for 24>hours a day.
◦The UV lamp should be changed after 8000 operating hours so that the device can work
effectively and efficiently. The filter system must be cleaned regularly.
Connecting the pump
On the filter cover/lid, there are three connections equipped with hose tails:
◦The pump is connected to the first hose tail. Use a hose diameter that is the same with the
diameter of the pump outlet. Saw off the diameter-hose steps that you do not need.
◦The hose tail in the middle of the filter cover/lid is the outflow to the pump. Connect to the
large diameter of the tail a suitable hose and cut away the rest of the tail diameter. To
avoid the loosening of the hoses please use hose clamps.
Never use the filter with a built-in UVC unit with a water pressure higher than 0,2>bar! The
height difference between the filter lid and the pressure-free outflow point of the supply line
can amount to max. 2>m. The pressure of the water pumped to the filter cannot exceed
0,5>bar. Use the filter only with hoses that can withstand at least a pressure of 0,2>bar, the
max. pressure of the pump.
Make sure that outflow /discharge in the pond is positioned on a clean place. If the outflow is
blocked a higher pressure may result. Higher pressure can lead to leaking spots in the filter
and therefore to a complete emptying of the pump.
When the filter is used in “filter-modes,” the user should be careful and make sure that all
seals are properly installed in order to avoid the emptying of the pond. The sealing cap func -
tions simultaneously as safety measure in “Clean” mode. Make sure that filter always operates
in the “Filter” mode as long as the pump is running. The filter should be set on “Clean,” if the
filter sponges are cleaned. Before you start the filter, check and make sure that all hoses and
seals are correctly fastened. Filter only water and no other fluids. By frost the filter has to be
removed. Do not expose the filter to the direct sun light.
fter the filter has been placed on the right place and the pump has been connected the integ-
rated UV-unit can be switched on.
UV unit
The WilTec filter is delivered with all the equipment you need, and an integrated UV unit. The
UV lamps have approx. 8000 working hours that correspond to a season period of use from
March till November. The UV lamps can be replaced by loosening the screws from the spher-
ical upper part of the cover lid.
It is recommended to change the UV lamp with a new one at the beginning of the season.
The UV lamp clears as the green water and destroys germs. The WilTec filters have a separ-
ate chamber, through which UVC rays are not exposed to contact with the filter media. Be-
cause of this the micro organisms in the filter material are not damaged.
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 11
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Maintenance/cleaning/adjustment possibilities (setting options) (CPF-180/CPF-250 only)
A
B
C
B1
D
= Pump connection
B = Return pond (backflow)
B1 = Setting – filter operation
C = Watering connection
D = Setting – cleaning
E = Switch/cleaning mechanism
Filter operation: Bring the rotating switch E into position B1. With the help of a pump, the water is led
to the filter through the connection A, where it is cleaned and discharged back into the pond via con-
nection B.
Cleaning operation: Bring the switch E into position D. This setting enables the cleaning mechanism
by pressing down the setting switch E. By means of this pressure, the sponges inside the filter are
squeezed. By using this switch setting the dirty water is not led back into the pump but it is discharged
via connection C and it can be used for garden watering.
The pond filter of the series CPF-2500-5000-10000-15000-20000-30000 have a fast cleaning function
that can be activated with the aid of the crank. Instead of the setting switch (press button) described
above, turn the crank handle (like the one of a salad spinner) until the filter sponges have lost enough
dirt.
The filter materials as well as the lamp should be replaced 1× year
to ensure a problem-free operation of the filter.
When the filter is used for normal operation, “the watering connection” (C) with the screwed ring plus
sealing and the viewing glass (included in the delivery) should be closed to avoid leaking. The pres-
sure filter model of the series CPF-2500-5000-10000-15000-20000-30000 have a stepped hose tail
with integrated ball valve to close the connection.
Other notes and remarks:
Before every commissioning of the filter the user should check if sealings and connections are
fitted correctly.
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 12
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Pressure pond filters are exclusively designed for filtering pond water with typical impurities.
Do not expose the filter to the direct sun light over a longer period.
By frost the filter has to be completely emptied, if necessary dug out and stored in a dry, frost-
free place.
fter work that requires the removal of the lid, please make sure when attaching the cover lid
that the sealing rings are fitted correctly! Fit the clamp ring around the lid, press on the cover
lid and close the sealing clam.
CPF-180-250
CPF-280-380-500
CPF-2500-5000-10000-15000-20000-30000
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 13
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Changing the light tube
If the algae proliferate, it is necessary to check the correct the functioning of the UV-C lamp. You re -
cognise on the UV-indicator if the lamp lights at all. Change it every season.
CPF-180/CPF-250 CPF-2500-5000-10000-15000-20000-30000
Before changing the UV lamp disconnect the pump.
Release the 8>screws of the UV unit from the filter lid.
Carefully remove the UV lamp.
fter the UV unit has cooled down and dried up, grab the base of the light tube (not the glass!)
with a soft cloth and pull it cautiously out of its socket.
Now the quartz glass inside which the light bulb is placed must be cleaned. For this purpose
the lime has to be dissolved under heating with appropriate agents (coffee machine or kettle
descaler like citric acid). fter this rinse the quartz glass from residues remaining from the
cleaning agents.
fter rinsing all parts are reassembled in reverse order. The pump and the device are connec-
ted again to the power supply.
The wear parts (filter materials, light tubes, quartz sleeves, seals) are usually available in
stock at WilTec Wildanger Technik GmbH – www.wiltec.de.
CPF-2500-5000-10000-15000-20000-30000
With this mode, you only have to loosen 4>screws to take off the UV unit.
WARNING:
For all maintenance work the UVC has to be disconnected from the power supply!
The filter can be put into operation only if the UVC is FULLY assembled!
Never tinker with the running UVC lamp!
The UVC must NOT be carried by the cable!
lways place the UVC outside the pond (not in the water)!
Remove the UVC by frosty weather!
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 14
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
ll WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry E R under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equip-
ment. By contributing to the correct disposal of this art-
icle you protect the environment and the health of your
fellow men. Environment and health are threatened by
inappropriate disposal.
Material recycling helps reduce the consumption of raw materials.
dditional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
ddress:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
© by WilTec Wildanger Technik GmbH Item 50105, 50123, 50977–50980, 50121, 51042–51044 Page 15
http://www.WilTec.de
http://www.aoyue.eu 04 2021-1
http://www.teichtip.de
