Winco TransMotion TMM4 Setup guide

TMM PUSH HANDLE ASSEMBLY
FIELD INSTALLATION AND USAGE INSTRUCTIONS
FOR TMM4, TMM5, TMM4 PLUS, TMM5
PLUS, TMM4-X, TMM5-X, TMM4 PLUS-X,
AND TMM5 PLUS-X
IMPORTANT - DO NOT DISCARD THESE INSTRUCTIONS.
KEEP FOR FUTURE REFERENCE.

This page has been intentionally left blank.

Page 3 of 12
Document No.: IM tma227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
TABLE OF CONTENTS
IMPORTANT NOTES ABOUT THIS MANUAL ............................................................................. 4
SPECIAL NOTES - SIGNAL WORDS.............................................................................................. 4
TOOLS REQUIRED........................................................................................................................... 5
PARTS INCLUDED............................................................................................................................ 5
REMOVING AN OLD PUSH HANDLE ASSEMBLY...................................................................... 6
INSTALLING A NEW PUSH HANDLE ASSEMBLY....................................................................... 7
PUSH HANDLE PLUNGER KNOB INSTALLATION ..................................................................... 9
REMOVING AN OLD PLUNGER KNOB ........................................................................................ 9
INSTALLING A NEW PLUNGER KNOB ......................................................................................... 10
UPHOLSTERY CARE AND CLEANING INSTRUCTIONS ........................................................... 11
PREVENTATIVE MAINTENANCE................................................................................................... 11

Page 4 of 12
Document No.: IM TMA227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
IMPORTANT NOTES ABOUT THIS MANUAL
This Field Installation and Usage Instruction document is designed to assist you with the installation of the
TransMotion by Winco product. Read this document thoroughly before using the equipment or performing service
or maintenance. If you are unable to understand the warnings, cautions, or instructions, contact Winco Customer
Service before attempting to operate or service the equipment, otherwise injury or damage may result.
To assure safe operation of this device, it is essential that methods and procedures be established for educating
and training sta on the safe and eective operation of the product.
Winco, Mfg., LLC reserves the right to change specifications without notice.
The information contained in this document is subject to change without notice.
Specifications listed are nominal and may vary slightly from unit to unit due to tolerance variations or power supply
variations.
Photographs and illustrations contained within this document may not depict exactly the model you have. This
document can cover many closely related models.
SPECIAL NOTES - SIGNAL WORDS
Signal words are used in this manual and apply to hazards which could result in injury or property damage. The
following is a definition of those signal words as used in this document:
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. It
may also be used to alert against unsafe practices or potential property damage hazards.
Provides important information, makes special instructions clearer, or provides service personnel
information to make maintenance easier.

Page 5 of 12
Document No.: IM tma227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
TOOLS REQUIRED
• (1) 3/16” Allen Wrench
• (1) 1/2” Socket Wrench
• (2) Thin 3/8” Open End Wrenches
PARTS INCLUDED
1. Push Handle Assembly (TMA227-15)
PART NUMBER DESCRIPTION QUANTITY IMAGE
TMM-374-06 TMM5 PUSH BAR ASSEMBLY - LEFT 1 A
TMM-373-06 TMM5 PUSH BAR ASSEMBLY - RIGHT 1 B
TMM-406-11 PUSH BAR GRIP 2 C
TMM-489-11 ADHESIVE BACKED BUMPER 2 D
TMM-080-04 SHOULDER SCREW 5/16 X 1-3/4” 2 E
TMM-165-04 HEX ACORN LOCKING NUT 5/16” 2 F
TMM-1023-04 NYLON WASHER 0.328” 4 G
TMM-194-04 NYLON WASHER 3/8” 2 H
TMM-2439-04 LOCK-TITE 1 I
TMM-057-12 PLUNGER KNOB 2 J
D
C
B
A
H
F
E
GIJ

Page 6 of 12
Document No.: IM TMA227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
REMOVING AN OLD PUSH HANDLE ASSEMBLY
1. Using the pendant, adjust the device into the chair position
(Fig. 1).
2. Locate the bolt connecting the push handle to the back
frame. The position of this bolt will be slightly dierent on the
TMM4 and TMM5 Models (Fig. 2 and Fig. 3).
NOTE: FOR THE TMM5 MODEL CHAIR, THE BOTTOM BOLT
OF THE SURGICAL BAR WILL NEED TO BE REMOVED AND
THE SURGICAL BAR WILL NEED TO BE MOVED OUT OF
THE WAY BEFORE CONTINUING TO THE NEXT STEP. THIS
WILL ALLOW ACCESS TO THE BOLT CONNECTING THE
PUSH HANDLE TO THE BACK FRAME (FIG. 3).
3. Using the 3/16” allen wrench and 1/2” socket wrench, remove
the bolt and fastener nut connecting the push handle to the
back frame (Fig. 4).
4. Once the bolt and fastener nut are removed, locate the red
plunger knob and pull to release the old push handle from
the back frame (Fig. 4).
5. Repeat this entire process on the opposite side of the device.
Fig. 1
Fig. 2
TMM4
Fig. 4
Fig. 3
TMM5
←
←
←

Page 7 of 12
Document No.: IM tma227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
INSTALLING A NEW PUSH HANDLE ASSEMBLY
NOTE: FOR A TMM5 MODEL CHAIR, THE BOTTOM BOLT OF
THE SURGICAL BAR WILL NEED TO BE REMOVED USING A
3/16” ALLEN WRENCH AND THE SURGICAL BAR WILL NEED
TO BE MOVED OUT OF THE WAY BEFORE INSTALLING A
NEW PUSH HANDLE ASSEMBLY. SEE PAGE 6 FOR IMAGES
SHOWING DIFFERING BOLT LOCATIONS.
NOTE: If there was never a push handle assembly installed on
the device, the red plunger knob will need to be installed first.
See “Push Handle Plunger Knob Installation” on page 9.
1. Align the bolt with the holes of the back frame and insert through the backrest frame tube. Slide one
(1) thicker nylon washer (closest to the outside of the chair) onto the bolt, followed by the push handle
assembly tube, and one (1) or two (2) thinner nylon washer(s) on the opposite side (closest to the inside of
the chair) of the bolt. Hand thread the cap nut onto the bolt (Fig. 1).
NOTE: The correct placement of two (2) or all three (3) nylon washers should be as indicated. Depending
on the need for adjustment, there should be either one (1) thinner nylon washer on the inside of the chair
with one (1) thicker nylon washer on the outside of the chair OR two (2) thinner washers on the inside of
the chair with one (1) thicker washer on the outside of the chair (Fig. 2).
INSTRUCTIONS CONTINUED ON NEXT PAGE
←
Fig. 1
Fig. 2
←
←
←

Page 8 of 12
Document No.: IM TMA227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
INSTALLING THE NEW PUSH HANDLE ASSEMBLY (CONTINUED)
2. Securley tighten the cap nut onto the bolt using the
3/8” allen wrench and 1/2” socket wrench (Fig. 3).
3. Slide one (1) push bar grip onto the push handle
assembly (Fig. 4).
4. If the device does not already have one installed,
add one (1) adhesive backed bumper to the back of
the device as shown (Fig. 5). If the device already
has one installed, you may remove the old one and
replace it with a new one if necessary.
5. Repeat this entire process on the opposite side of
the device.
←
Fig. 3
Cap Nut
Fig. 4
←

Page 9 of 12
Document No.: IM tma227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
PUSH HANDLE PLUNGER KNOB INSTALLATION
REMOVING AN OLD PLUNGER KNOB
1. Pull knob to release handle. Swing handle down and out of
way (Fig. 1).
2. Place one 3/8” open end wrench near the knob. Pull the
spring loaded inner section out with your fingers (Fig. 2).
3. Use an additional 3/8” open end wrench to hold the piece if
you cannot grip it with your fingers. Loosen knob by turning
the wrench near the knob and remove (Fig. 3).
←
←
Fig. 1
Fig. 2
Fig. 3

Page 10 of 12
Document No.: IM TMA227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
INSTALLING A NEW PLUNGER KNOB
1. Pull the inner rod out of the handle plunger knob (Fig. 1).
2. Slide the 3/8” open end wrench onto the flat grooves of the
inner rod to hold it in place. Either unscrew the back portion
counter clockwise with your fingers or use the 2nd 3/8” open
end wrench to remove the inner rod from the plunger knob
(Fig. 2).
3. Apply Locktite to the inner rod threading.
4. Push the inner rod into the mounting hole (Fig. 3).
5. Leaving the 3/8” open end wrench in place to keep the spring
extended, screw the inner rod into place clockwise with
fingers. Securely tighten the plunger knob onto the bracket
with the 2nd 3/8” open end wrench (Fig. 4).
Fig. 1
Fig. 2
Fig. 3
Fig. 4

Page 11 of 12
Document No.: IM tma227-15
Revision: A
TMM PUSH HANDLE
FIELD INSTALLATION AND USAGE INSTRUCTIONS
UPHOLSTERY CARE AND CLEANING INSTRUCTIONS
Proper care is essential in ensuring the durability and reliability of TransMotion Medical upholstery. In general, all
products should be:
1. Cleaned
2. Disinfected (in accordance with facility policy)
3. Rinsed
4. Allowed to air dry
It is important to note that the terms “disinfecting” and “cleaning” should not be used interchangeably.
Disinfectants alone will not provide adequate cleaning since they do not have the appropriate properties to cut
grease or oil and remove grime, hair or skin oils. The appearance, feel and performance of your upholstery may
diminish if not cleaned properly.
Cleaning:
Remove hair, grime and body oils. Your upholstery should be cleaned on a regular basis with a damp cloth soaked
in a mild soap and water solution. Avoid harsh detergents or chemicals that could damage the finish of your
product. If disinfecting with manufacturer approved chemicals or bleach, the upholstery MUST be wiped o using
clean water on a damp cloth and allowed to air-dry as a final step. Failure to rinse upholstery with clean water
can result in a build-up of residues that, over time, may lead to drying, cracking or other undesirable changes to
appearance, feel and performance.
Retain all instructional tags for future use.
Contact the manufacturer of the fabric used in your upholstery for a current list of approved disinfectants.
TransMotion Medical Customer Care can assist with identifying which upholstery was used with your Stretcher-
Chair.
For customer supplied and non-standard materials, please refer to the individual manufacturer’s cleaning
instructions.
PREVENTATIVE MAINTENANCE
To ensure proper operation, this service part should be inspected and maintained as described below:
COMPONENT FREQUENCY PROCEDURE TOOL
All fastened joints Every 3 months
Inspect all fasteners
to ensure proper fit &
tightness. Retighten as
needed.
⁄” Allen wrench &
⁄” socket wrench

CONTACT US
To arrange a demonstration or to speak with one of our associates, please feel free to contact us at:
800-237-3377 | WincoMfg.com | 5516 SW 1st Lane, Ocala, FL 34474 | [email protected]
Copyright © 2020 Winco Mfg., LLC
TMM Push Handle Assembly
Field Installation and Usage Instructions
Document No.: IM TMA227-15
Revision: A
