Winco 3420 Reference guide

Page 1 of 4
006240 Rev N Date 02-14-17 SLC
1. READ AND FOLLOW ALL DIRECTIONS.
2. NEVER place screen on a cart, table, stand or other objects; Screen could fall and SERIOUS INJURY MAY
OCCUR.
3. NEVER place screen near open flame or over a radiator or heat register.
4. NEVER place screen in front a door, In case of emergeny screen could block or hinder evacuation.
5. SUFFOCATION DANGER to children if vinyl is not attached to screen; Screen could block nose and mouth and
prevent breathing. VINYL SCREEN IS NOT A TOY.
6. DO NOT allow children to play with screen; Screen could fall and INJURY MAY OCCUR.
7. Periodically, recheck tightness of all nuts, bolts and screws.
8. Screen should ALWAYS be positioned on level surface.
9. NEVER stand or ride on screen legs; INJURY MAY OCCUR.
10. DO NOT use screen in or with ANY type of vehicle or trailer.
11. DO NOT attach objects to screen frame; Screen can tip over and INJURY MAY OCCUR.
12. Immediately remove from service; Any screen with broken or missing parts, torn vinyl, or other visible damage.
13. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
14. SAVE THESE INSTRUCTIONS for future reference and training.
3420 & 3429
Single-Panel Wide Screen
CUSTOMER INSTRUCTIONS
Tools needed:
•Phillips-Head Screwdriver
•7/16” wrench (mulitple size wrench included)
•Scissors or box cutter
•- If using powered tools always start hardware together by hand first –
1. Insert caster inserts into ends of screen legs. (This is done for crutch tip or caster installation)
2. You must choose either casters or crutch tips for your screen – both are provided to you. Casters must be
inserted into the caster inserts. Crutch tips must be installed over the ends of the legs.
LEG INSTALLATION
3. Install legs on mainframe using (4) ¼” x 1-1/2” phillips head screws and locknuts.
NOTE: Make sure the legs are installed so that the bends of the legs face the outside of the frame. This is
necessary to provide the maximum footprint.
4. Use your phillips head screwdriver and 7/16” wrench to tighten.
Bolts must fit snugly into holes for secure leg mount.
5. Verify that your screen is level. If necessary the legs can be slightly bent so that all legs touch the floor.
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions contact your dealer or Winco customer support, [phone]
before attempting to use this product; otherwise injury may occur.
Winco assumes no responsibility for damage or injury caused by the
improper assembly, installation or use of these products.

Page 2 of 4
006240 Rev N Date 02-14-17 SLC
PANEL REPLACEMENT
6. To replace Vinyl Panels, grasp Curtain Rod at end away from Spring Retainer Clip, and slide Curtain Rod
towards clip. This will release Curtain Rod from Main Frame.
7. Periodically check all fasteners for tightness. To clean Vinyl Panels use only mild liquid soap and water .
Wrinkles in Vinyl Panel – Storage and shipping causes wrinkles of the vinyl panel of your Winco Screen; This is
normal. Please allow 1-2 weeks at room temperature (approx. 70+ degrees) to allow for vinyl to return to original
appearance.
Visit our website www.wincomfg.com/product-documents/parts-lists for a complete parts list catalog of your chair or
call Customer Service @ 1-800-237-3377 to request it by mail.
NEVER stand or ride on screen legs.
Do not over tighten nuts and bolts. Periodically recheck all fasteners for tightness.

Page 3 of 4
006240 Rev N Date 02-14-17 SLC
GENERAL CARE & CLEANING:
Periodically inspect tightness of all screws, bolts, and nuts.
Winco furnishings are built to provide durable reliable service when properly cared for. In general all of our products
should be 1) Cleaned 2) Rinsed 3) Allowed to air dry. It is important to note that disinfecting a product is not the
same as cleaning the product. Disinfectants alone will not provide adequate cleaning, they do not have grease
or oil cutting properties to remove grime or hair and skin oils. Over time, the appearance and feel and
performance of your upholstery may diminish if not cleaned properly
CLEANING:
Remove grime, hair and body oils; Your furnishings should be cleaned with mild soap & water solution and a damp
cloth on a regular basis. Avoid harsh detergents that could damage the finish of your product. If the furnishing is
disinfected with bleach, it MUST be wiped off using only clean water on a damp cloth and then be allowed to air dry.
Failure to rinse with clean water can result in a build-up of residues over time that can damage your product.

Page 4 of 4
006240 Rev N Date 02-14-17 SLC
Design, appearance, parts, & construction are subject to change without notice
