Wolf ICBCG304T User manual

GAS COOKTOP
USE AND CARE GUIDE

2 | English
Contents
3Safety Precautions
6Gas Cooktop Features
6Cooktop Operation
7Care Recommendations
7Troubleshooting
7Wolf Warranty
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 6 for rating plate
location. For warranty purposes, you will also need the date
of installation and name of your authorized Wolf dealer.
Record this information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
GAS COOKTOP

subzero-wolf.com.au | 3
IMPORTANT INSTRUCTIONS
WARNING
If the information in this guide is not followed exactly, a re
or explosion may result, causing property damage, per-
sonal injury or death.
Do not store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the re
department.
This appliance must be properly installed and serviced by a
qualied installer, service agency or gas supplier and grounded
(earthed) by a qualied technician.
GENERAL SAFETY PRECAUTIONS
•Read this guide carefully before using this appliance to reduce
risk of re, electric shock or injury.
•Before performing service, shut off gas supply by closing the
gas shut-off valve and shut off electricity to this appliance.
•Keep appliance area clear and free from combustible material.
•For safety when cooking, set burner controls so ame does not
extend beyond the bottom of pan.
•Do not use aluminum foil to line any part of this appliance.
CAUTION
This appliance is for cooking purposes only. It must not be
used for other purposes, for example room heating. Doing so
may result in carbon monoxide poisoning.
SAFETY PRECAUTIONS

4 | English
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
•Wear proper apparel. Loose-tting or hanging garments should
never be worn using this appliance.
•Use extreme caution when moving a grease kettle or disposing
of hot grease.
•Always use dry pot holders when removing pans from this
appliance. Wet or damp pot holders can cause steam burns.
Do not use a towel or bulky cloth in place of pot holders.
•Clean only those parts listed in this guide. A steam cleaner is
not to be used.
•Do not repair or replace any part of this appliance unless
specically recommended in literature accompanying this
appliance.
•Do not obstruct the ow of air to ensure proper combustion
and ventilation.
•When using this appliance, do not touch grates, burner caps,
burner bases or any other parts in proximity to the ame.
These components may be hot enough to cause burns.
•Do not leave children alone or unattended in the area where
this appliance is in use. Never allow children to sit or stand on
the appliance.
•Do not store items of interest to children above or at the back
of this appliance, as they could climb on the appliance to reach
items and be injured.
•Do not use water on grease res. Smother the ame or use a
dry chemical or foam-type extinguisher.
•Never leave this appliance unattended when in use. Boilovers
and greasy spills may smoke or ignite.
•Do not heat unopened food containers, such as baby food jars
and cans. Pressure build-up may cause the container to burst
and cause injury.
•Do not store ammable materials near burners or let grease or
other ammable substances accumulate on this appliance.

subzero-wolf.com.au | 5
SAFETY PRECAUTIONS
IMPORTANT INSTRUCTIONS
GENERAL SAFETY PRECAUTIONS
WARNING
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the haz-
ards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by chil-
dren without supervision.
CAUTION
The use of a gas cooking appliance results in the produc-
tion of heat and moisture in the room in which it is installed.
Ensure that the kitchen is well ventilated; keep natural ven-
tilation holes open or install a mechanical ventilation device
(mechanical extractor hood).
Prolonged intensive use of the appliance may call for addi-
tional ventilation, for example opening of a window, or more
effective ventilation, for example increasing the level of
mechanical ventilation where present.
WARNING
FOR AUSTRALIA ONLY:
•Do not use or store ammable materials in the appliance
storage drawer or near this appliance.
•Do not spray aerosols in the vicinity of this appliance while
in operation.
•Do not modify this appliance.
•This appliance is for indoor use only.

6 | English
GAS COOKTOP FEATURES
Gas Cooktop Features
FEATURE
1Product Rating Plate (bottom of cooktop)
2Control Knob
3Surface Burner
4Burner Grate
5Burner Pan
COOKTOP OPERATION
BURNER RATING kW
381 mm GAS COOKTOP HIGH
Medium 3.5
Small 2.7
762 mm GAS COOKTOP HIGH
Large 5.3
Medium 3.5
(2) Small 2.7
914 mm GAS COOKTOP HIGH
Large 5.3
Medium 3.5
(3) Small 2.7
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use and care guide.
Whether you are an occasional cook or an expert chef, it
will be to your benet to familiarize yourself with the safety
practices, features, operation and care recommendations of
your Wolf gas cooktop.
•To ensure all residual oil from the manufacturing process
has been removed, clean the cooktop thoroughly with
hot water and a mild detergent prior to use. Rinse and
dry with a soft cloth. Refer to care recommendations on
page 7.
•Verify surface burner components are assembled
correctly.
Sabbath
This appliance is certied by Star-K to meet strict religious
regulations in conjunction with specic instructions found
on www.star-k.org.
762 mm Gas Cooktop (model ICBCG304T/S).
5
3
4
2
1
914 mm Gas Cooktop (model ICBCG365P/S).
5
3
4
1
2
Cooktop Operation
SURFACE BURNERS
To light a burner, push and turn the corresponding control
knob counterclockwise to . The igniter will begin to
click until burner is lit. Once lit, continue to turn knob coun-
terclockwise to desired setting. Each burner is designed
with electronic re-ignition which reignites the burner if acci-
dentally extinguished.
To select a simmer setting, turn control knob to the detent
at the lowest setting. Push and continue to turn counter-
clockwise. The ame will transition to the second tier on
the burner cap. Continue to turn knob to desired simmer
setting.
CAUTION
Never leave pans on a high setting unattended. Be
careful when cooking food in fat or grease; it can
become hot enough to ignite.
CAUTION
Do not use pans smaller than 120 mm in diameter. Do
not use pans that extend beyond the cooktop frame.
Heat may be trapped beneath the pan causing damage.
CONTROL KNOBS
For 381 mm and 914 mm models, the control knobs are
positioned to correspond with the surface burners they
regulate. For 762 mm models, a diagram above each knob
indicates which surface burner it regulates.
381 mm Gas Cooktop (model ICBCG152TF/S).
1
2
3
4
5
The height from the benchtop to the top of the trivert (Pan Support) is 34mm.

subzero-wolf.com.au | 7
CARE RECOMMENDATIONS
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner
and apply with a soft lint-free cloth. To
bring out the natural luster, lightly wipe
surface with a water-dampened microber
cloth followed by a dry polishing chamois.
Always follow the grain of stainless steel.
Burner grates Remove and place on a at surface near
the sink. Clean with hot water and mild
detergent or paste of baking soda and
water. Do not immerse in water. Towel dry.
Surface burners Allow to cool. Use mild detergent or spray
degreaser to clean. Rinse with water and
towel dry.
Control knobs Using a damp cloth, wipe with mild deter-
gent or spray degreaser; rinse and dry. Do
not place in dishwasher.
TROUBLESHOOTING
Troubleshooting
OPERATION
Cooktop does not operate.
•Verify power is on.
•Verify electrical power to unit and home circuit breaker
is on.
Erratic ame, poor ignition or no ignition.
•Verify burner caps are positioned properly.
•Clean burner and igniter properly.
•If water spilled over recently, let area dry completely.
Use hair dryer, if desired.
•If burner cap secures to burner head, verify it is tightly
fastened.
•Push in knob, then release. Verify knob springs back.
SERVICE
•Maintain the quality built into your product by contacting
Wolf factory certified service.
•When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 6 for rating
plate location.
•For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 2 of this
guide.
• Wolf recommends that your gas cooking hob
is cleaned after every use and annual
inspection by authorised agent is
recommended.
Wolf Appliance International Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts
and labor to repair or replace, under normal residential use, any part of the product that proves to be
defective in materials or workmanship. All service provided by Wolf Appliance under the above warranty
must be performed by Wolf factory certied service, unless otherwise specied by Wolf Appliance, Inc.
Service will be provided during normal business hours.
LIMITED FIVE YEAR WARRANTY
For ve years from the date of original installation, Wolf Appliance will repair or replace the following parts
that prove to be defective in materials or workmanship: stainless steel briquette trays, gas valves, drip
pans, electronic control boards and electric heating elements. If the owner uses Wolf factory certied
service, the service provider will repair or replace these parts with the owner paying for all other costs,
including labor. If the owner uses non-certied service, the owner must contact Wolf Appliance, Inc. (using
the information below) to receive repaired or replacement parts. Wolf Appliance will not reimburse the
owner for parts purchased from non-certied service or other sources.
For more information regarding your Wolf product warranty, contact your authorized Wolf dealer. Warranties
must comply to all country, state, city, local and or ordinance.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited
60-day parts and labor warranty for cosmetic defects.
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design, are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.

WOLF APPLIANCE, INC. P.O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820
9012994 REV-A 10/2017MF088
