Wolf ICBCG304T/S User manual

Guía de uso y mantenimiento
Guide d’utilisation et d’entretien
Guida all’uso e alla manutenzione
Bedienungs- und Pflegeanleitung
Gids voor gebruik en onderhoud
使用和维护指南
Gas Cooktop
Use and Care Guide

2 | English
Contents
2Gas Cooktop
3Safety Precautions
7Gas Cooktop Features
7Cooktop Operation
8Care Recommendations
9Troubleshooting
9Wolf Warranty
Gas Cooktop
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 7 for rating plate
location. For warranty purposes, you will also need the
date of installation and name of your authorized Wolf
dealer. Record this information below for future reference.
If your product ever needs attention, be sure to use a Wolf
Factory Certified Service provider.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certified Service Name
Certified Service Number
Authorized Dealer
Dealer Number
Important Note
To ensure this product is installed and operated as safely
and eciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or prod-
uct damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.

wolfappliance.com | 3
IMPORTANT INSTRUCTIONS
CAUTION
This appliance is for cooking purposes only. It must not be
used for other purposes such as heating a room. Doing so
may result in carbon monoxide poisoning.
WARNING
These instructions are only valid if the country symbol
appears on the appliance. If the symbol does not appear
on the appliance, it is necessary to refer to the technical
instructions which will provide the necessary instructions
concerning modification of the appliance to the conditions
of use of the country.
•Clean only those parts listed in this guide. A steam cleaner is
not to be used.
•Do not use cooking vessels smaller than 120 mm or vessels
that extend beyond the cooking surface.
•The performance of this product has been verified according
to EN 30-1-1, this appliance is Class 3.
Safety Precautions

4 | English
Behavior: When the cooktop control knob is pushed in and
turned to the open position, the system creates a spark to ignite
the burner. The spark continues for five seconds or until the
electronic ignition system senses a flame, whichever comes first.
If the igniter fails to ignite the gas within five seconds, the gas
safety shuto valve closes, eliminating the gas flow for five
seconds. After five seconds, the valve opens, and the igniter
automatically attempts to re-ignite. After the fifth attempt, the
burner knobs must be turned to the closed position. To verify
the cooktop burner operation, push in and turn the control
knob to the open position. If the burner does not ignite within
five seconds, turn the control knob to the closed position. Verify
the burner is in the proper position. Verify the power cord is
plugged in and the circuit breaker or house fuse is not blown.
Verify operation again. If the burner does not ignite within five
seconds, turn the control knob to the closed position, and open
an exterior door or window. Wait one minute. If the flames
are extinguished (for any reason), turn the control knob to the
closed position, and wait one minute. Verify the flames do not
extinguish when reduced to low quickly. Verify correct opera-
tion of each burner individually and in combination.
IMPORTANT NOTE: Surface burners automatically ignite after a
power interruption.
IMPORTANT INSTRUCTIONS
•Automatic Burner Control System Instructions
Description: A spark electrode ignites each surface burner,
eliminating the need for open flame pilots. For safety and con-
venience, each burner is equipped with an automatic ignition
system which automatically ignites any burner if extinguished.
Safety Precautions

wolfappliance.com | 5
IMPORTANT INSTRUCTIONS
WARNING
Unattended cooking with fat or oil can be dangerous and
may result in fire. Never try to extinguish a fire with water.
Switch o the appliance and cover the flame with a lid or
fire blanket.
CAUTION
The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
WARNING
The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating ele-
ments. Children less than 8 years of age shall be kept away
unless continuously supervised.
WARNING
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the haz-
ards involved. Children should not play with the appliance.
Cleaning and user maintenance should not be made by
children without supervision.
Safety Precautions

6 | English
IMPORTANT INSTRUCTIONS
CAUTION
The use of a gas cooking appliance results in the produc-
tion of heat and moisture in the room in which it is installed.
Ensure that the kitchen is well ventilated; keep natural ven-
tilation holes open or install a mechanical ventilation device
(mechanical extractor hood).
Prolonged intensive use of the appliance may call for addi-
tional ventilation such as opening a window, or more eec-
tive ventilation such as increasing the level of mechanical
ventilation where present.
CAUTION
The use of hob guards and non-listed accessories can cause
accidents.
WARNING
Danger of fire: do not store items on the cooking surfaces.
Safety Precautions

wolfappliance.com | 7
Gas Cooktop Features
Gas Cooktop Features
FEATURES
1Product Rating Plate (bottom of cooktop)
2Control Knob
3Surface Burner (large)
4Burner Grate
5Burner Pan
Cooktop Operation
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use and care guide.
Whether you are an occasional cook or an expert chef, it
will be to your benefit to familiarize yourself with the safety
practices, features, operation and care recommendations
of your Wolf gas cooktop.
• To ensure all residual oil from the manufacturing pro-
cess has been removed, clean the cooktop thoroughly
with hot water and a mild detergent prior to use. Rinse
and dry with a soft cloth. Refer to care recommenda-
tions on page 8.
• Verify surface burner components are assembled
correctly.
762 mm Gas Cooktop (model ICBCG304T/S)
5
3
4
2
1
914 mm Gas Cooktop (model ICBCG365P/S)
5
3
4
1
2
Sabbath
This appliance is certified by Star-K to meet strict religious
regulations in conjunction with specific instructions found
on www.star-k.org.

8 | English
Care Recommendations
Care Recommendations
CLEANING
Stainless steel Use a nonabrasive stainless steel cleaner and apply with a soft lint-free cloth. To bring out the natural luster,
lightly wipe surface with a water-dampened microfiber cloth followed by a dry polishing chamois. Always
follow the grain of stainless steel.
Burner grates Remove and place on a flat surface near the sink. Clean with hot water and mild detergent or paste of baking
soda and water. Do not immerse in water. Towel dry.
Surface burners Allow to cool. Use mild detergent or spray degreaser to clean. Rinse with water and towel dry.
Control knobs Using a damp cloth, wipe with mild detergent or spray degreaser; rinse and dry. Do not place in dishwasher.
Cooktop Operation
Cooktop Operation
SURFACE BURNERS
To light a burner, push and turn the corresponding con-
trol knob counterclockwise to . The igniter will
begin to click until burner is lit. Once lit, continue to turn
knob counterclockwise to desired setting. Each burner is
designed with electronic re-ignition which reignites the
burner if accidentally extinguished.
To select a simmer setting, turn control knob to the detent
at the lowest setting. Push and continue to turn counter-
clockwise. The flame will transition to the second tier on
the burner cap. Continue to turn knob to desired simmer
setting.
SURFACE BURNER RATING
The front left burner is 5.3 kW. The rear center burner is
3.5 kW (rear right for model ICBCG304). Any additional
burners are 2.7 kW.
CAUTION
Never leave pans on a high setting unattended. Be
careful when cooking food in fat or grease; it can
become hot enough to ignite.
WARNING
Turn o the burner if clicking is not audible within
five seconds. Do not operate and contact Wolf
Factory Certified Service.
CAUTION
Do not use pans smaller than 120 mm in diameter.
Do not use pans that extend beyond the cooktop
frame. Heat may be trapped beneath the pan causing
damage.
CONTROL KNOBS
For 381 mm and 914 mm models, the control knobs are
positioned to correspond with the surface burners they
regulate. For 762 mm models, a diagram above each knob
indicates which surface burner it regulates.
BURNER GRATES
For 610 mm models, the grates must be positioned cor-
rectly to ensure proper burner performance. The grates
have an indicator on the bottom of the front edge. Position
the grates with the indicator toward the front of the cook-
top. Refer to the illustration below.
FRONT
Grate placement (610 mm model)

wolfappliance.com | 9
Troubleshooting
OPERATION
Cooktop does not operate.
• Verify power is on.
• Verify electrical power to unit and home circuit breaker
is on.
Erratic flame, poor ignition or no ignition.
• Verify burner caps are positioned properly.
• Clean burner and igniter properly.
• If water spilled over recently, let area dry completely.
Use hair dryer, if desired.
• If burner cap secures to burner head, verify it is tightly
fastened.
• Push in knob, then release. Verify knob springs back.
SERVICE
• Maintain the quality built into your product by contact-
ing Wolf Factory Certified Service.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 7 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 2 of this
guide.
Wolf Appliance International Limited Warranty
FOR RESIDENTIAL USE
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, this Wolf Appliance product warranty covers all parts and labor to repair or
replace, under normal residential use, any part of the product that proves to be defective in materials or workmanship. All service
provided by Wolf Appliance under the above warranty must be performed by Wolf Factory Certified Service, unless otherwise speci-
fied by Wolf Appliance, Inc. Service will be provided during normal business hours.
LIMITED FIVE YEAR WARRANTY
For five years from the date of original installation, Wolf Appliance will repair or replace the following parts that prove to be defective
in materials or workmanship: stainless steel briquette trays, gas valves, drip pans, electronic control boards and electric heating ele-
ments. If the owner uses Wolf Factory Certified Service, the service provider will repair or replace these parts with the owner paying
for all other costs, including labor. If the owner uses non-certified service, the owner must contact Wolf Appliance, Inc. (using the
information below) to receive repaired or replacement parts. Wolf Appliance will not reimburse the owner for parts purchased from
non-certified service or other sources.
For more information regarding your Wolf product warranty, contact your authorized Wolf dealer. Warranties must comply to all
country, state, city, local and or ordinance.
*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited 60-day parts and labor warranty
for cosmetic defects.
Warranty
Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowflake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &
Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.
All other trademarks are property of their respective owners in the United States and other countries.
Troubleshooting
SERVICE (FOR AUSTRALIA ONLY)
• Yearly maintenance is recommended.
• Maintain the quality built into your product by contact-
ing Wolf Factory Certified Service.
• When contacting service, you will need the model and
serial number of your product. Both numbers are listed
on the product rating plate. Refer to page 7 for rating
plate location.
• For warranty purposes, you will also need the date of
installation and name of your authorized Wolf dealer.
This information should be recorded on page 2.
• For Australia only, contact:
Sub-Zero Group Australia Pty Ltd
Level 10, 469 La Trobe Street
Melbourne Victoria 3000
Phone [phone]
subzero-wolf.com.au
SERVICE (FOR UNITED KINGDOM ONLY)
• Sub-Zero & Wolf Ltd
9 The Street, Heybridge, Maldon, Essex, CM9 4XB
020 8418 3800
[email protected]
www.subzero-wolf.co.uk

WOLF APPLIANCE, INC. P.O. BOX 44848 MADISON, WI 53744 USA WOLFAPPLIANCE.COM 800.222.7820
9017232 REV-A 4/2021
