WolfPack HDTVHDMX0016M1 User manual

User Manual
WolfPack 8K 4x2 HDMI Matrix
Switch
MODEL No. HDTVHDMX0016M1（Includes separate audio）
HDTVHDMX0017M1（No audio）

WolfPack 8K 4x2 MATRIX FEATURES:
HDTVHDMX0016M1（Includes audio)
Picture 1.0 Front Panel
No.
Description
Introduction
①
Mini USB port
Only for factory upgrade
②
HDMI input
indicators for
channel A
The selected input channel indicator will light up.
③
HDMI output
indicator for
channel A
Lit when HDMI OUT A has signal output.
④
HDMI input
indicators for
channel B
The selected input channel indicator will light up.
⑤
HDMI output
indicator for
channel B
Lit when HDMI OUT B has signal output.
⑥
ARC status
indicator
Lit when ARC on.
⑦
IR receiving window
Receive the commands sent by the infrared remote control.
⑧
EDID mode
indicators
Include three audio EDID modes: PASS/2CH/5.1CH
⑨
Audio source
channel indicator
Lit when Audio output is to HDMI OUT A. Light is off is to HDMI
OUT B.
⑩
Input selection key
of channel A
Loop to select the input channel of HDMI OUT A
⑾
Input selection key
of channel B
Loop to select the input channel of HDMI OUT B
⑿
ARC on/off key
HDMI ARC (Audio return channel) function on/off.
⒀
EDID mode
selection key
Supports three audio EDID mode switching: PASS/2CH/5.1CH.
⒁
Power status
indicator
Lit when power on.
①
②
③
④
⑤
⑦
⑩
⑾
⒁
⒂
⑥
⑧
⑿
⒀
⑨

⒂
Power switch
Power self - lock switch, turn on when pressed, turn off when
pressed.
Picture 1.1 Rear Panel
No.
Description
Introduction
①
Power jack
Requires 6-12V power supply
②
HDMI output port
B
Connects to monitor with HDMI port. This port also supports
ARC.
③
HDMI output port
A
Connects to monitor with HDMI port
④
HDMI input port 4
Connects to your source device by WolfPack 8K HDMI cable.
⑤
HDMI input port 3
Connects to your source device by WolfPack 8K HDMI cable.
⑥
HDMI input port 2
Connects to your source device by WolfPack 8K HDMI cable.
⑦
HDMI input port 1
Connects to your source device by WolfPack 8K HDMI cable.
⑧
Analog audio
ports
Synchronized output stereo analog audio which contains left
and right channels.
⑨
Digital audio port
Synchronized output digital audio by fiber optic.
HDTVHDMX0017M1（No audio）
Picture 1.2 Front Panel
No.
Description
Introduction
①
Mini USB port
Only for factory upgrade
②
HDMI input
indicators for
channel A
The selected input channel indicator will light up.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩

③
HDMI output
indicator for
channel A
Lit when HDMI OUTA has signal output.
④
HDMI input
indicators for
channel B
The selected input channel indicator will light up.
⑤
HDMI output
indicator for
channel B
Lit when HDMI OUT B has signal output.
⑥
IR receiving window
Receive the commands sent by the infrared remote control.
⑦
Input selection key
of channel A
Loop to select the input channel of HDMI OUT A
⑧
Input selection key
of channel B
Loop to select the input channel of HDMI OUT B
⑨
Power status
indicator
Lit when power on.
⑩
Power switch
Power self - lock switch, turn on when pressed, turn off when
pressed.
Picture 1.3 rear panel showing
No.
Description
Introduction
①
Power jack
Requires 6-12V power supply
②
HDMI output port
B
Connects to monitor with HDMI port. This port also supports
ARC.
③
HDMI output port
A
Connects to monitor with HDMI port
④
HDMI input port 4
Connects to your source device by WolfPack 8K HDMI cable.
⑤
HDMI input port 3
Connects to your source device by WolfPack 8K HDMI cable.
⑥
HDMI input port 2
Connects to your source device by WolfPack 8K HDMI cable.
⑦
HDMI input port 1
Connects to your source device by WolfPack 8K HDMI cable.
①
②
③
④
⑤
⑥
⑦

Picture 1.4 IR panel showing and function introduction
Remote
keys
Panel keys
Functional description
/
Power standby on/off button
A-B
Press AUDIO
key more
than 3
seconds
Select A/B for the audio output source
channel
ARC
Press ARC
key
ARC turn on / turn off
PASS
Press AUDIO
key
Audio EDID PASS mode.
The audio output format is determined
by the EDID information of the TV.
2CH
Audio EDID 2CH mode.
Priority output stereo audio in this
mode.
5.1CH
Audio EDID 5.1CH mode.
Priority output 5.1 channel bit stream
in this mode. The analog output ports

* Please take out the film at the rear of the remote before you use. Please insert the film to
remote rear if you do not use the remote for long time.
WolfPack 8K 4x2 HDMI Matrix Switch Connection and Operation:
have no output now.
1/2/3/4
Press A/B key
Input source selection of A/B output channel.
D/W
Press A/B key
more than 3
seconds
HDMI1.4 compatibility mode turn on/off
Try to turn on this mode when there is a
problem using both HDMI1.4 signal source and
HDMI2.0 TV. When turned on, the 5 LEDs in
group A/B will flash 4 times at the same time,
and flash twice when turned off
ON/OFF
/
HDMI A/B output port enabled or disabled

NOTE:
1. Please use 8K HDMI cables and connect the cables before powering the equipment.
2. In the matrix mode (In this mode, the outputs of A and B are different), output ports
A and B cannot output 8K signals at the same time. Only one group is allowed to output 8K
and the other group output 4K or less.
3. The product has power off memory function. The setting state of the output channel
is recorded and saved. After the power is off, the saved data will be automatically retrieved
for configuration.
4. The optional AUDIO OUT is a set of multiplexed ports that allows you to select HDMI
PO W ER
SU PPL Y
PS5
X boxX
N vidia
3 0 7 0 / 3 0 8 0 / 3 0 9 0
C ableB ox
8 K H DM IC able
8 K H DM IC able
8 K H DM IC able
8 K H DM IC able
8 K H DM IC able
8 K H DM IC able
R C A audio cable
A udio fibercable
Poweramplifier
HDTVHDMX0016M1/HDTVH
DMX0017M1

OUT A & B sounds by using the "A-B" key.
5. The Audio EDID mode selection is also available for multiplexing. When the audio
source selects channel A, the audio EDID mode is valid for channel A. When the audio
source selects channel B, the audio EDID mode is valid for channel B.
6. Analog audio can only be outputted when the audio format is LPCM, so choose the
EDID mode in 2CH mode when using the analog audio output.
7. If you want to use ARC or CEC, you must connect the TV to the OUTA port. Before
using ARC, make sure your TV HDMI port supports ARC and the ARC have been turned on.
WolfPack 8K 4x2 HDMI MATRIX SWITCH SPECIFICATIONS:
Model No.
HDTVHDMX0016M1 (Includes separate audio)
HDTVHDMX0017M1 (No separate audio)
Model name
8K HDR 4x2 HDMI True Matrix Switch
Input ports
4–HDMI
Output ports
2–HDMI
RCAX2, Optical X1 (Only for HDTVHDMX0016M1)
Video format
480p/720p/1080p/2160p@24/25/30/50/60/100/120Hz
Up to 4320p@50/60Hz. Supports HDR & Dolby Vision
Deep color
8/10/12/16Bit@2160p
8/10bit@4320p
Audio format
Dolby HD/DTS HD/Dolby Atmos/Dolby AC3/DTS/LPCM Etc.
Transmission bandwidth
1200MHz Max.
Transmission rate
48Gbps Max.
IR distance
≤5m
Input cable length
2160P/AWG 26 ≤5m；1080P/AWG 26 ≤10m
Output cable length
2160P/AWG 26 ≤5m；1080P/AWG 26 ≤12m
Power adapter
specification
Input: AC 100~240V
Output: DC 12V/1.5A
Max working current
500mA
Working temperature
range
-5 ~ +40℃
Working humidity range
5 to 85%RH（No Condensation）
Storage temperature
-15 to 55℃
Storage humidity
5 ~95%RH (No Condensation)
Size
250x75x30 (mm)
Weight
440g

Accessories
Manual, Remote, Power Adaptor
