Wood Stone DESIGNER SERIES 6348 WS-DS1-4048 User manual

Toll Free 800.988.8103
Tel [phone]
Fax [phone]
www.woodstone-corp.com
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
DESIGNER SERIES 1
Stone Hearth Oven
Gas-Fired, Gas/Wood Combination
with Broiler Option Models
DESIGNER SERIES 6348 WS-DS1-4048
DESIGNER SERIES 7248 WS-DS1-7248
DOC NO M0078.03 REVISED November 2014
Installation and
Operation Manual

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
2
TABLE OF CONTENTS
TABLE OF CONTENTS
DESIGNER SERIES � � � � � � � � � � � � � � � � � � � � 3
CAUTIONS & WARNINGS � � � � � � � � � � � � � � � 4
6348 SPECIFICATIONS � � � � � � � � � � � � � � � � � 6
7248 SPECIFICATIONS � � � � � � � � � � � � � � � � � 7
MOVING THE OVEN � � � � � � � � � � � � � � � � � � � 8
INSTALLATION CLEARANCES � � � � � � � � � � � � 9
VENTING � � � � � � � � � � � � � � � � � � � � � � � � � � 10
UTILITY CONNECTIONS � � � � � � � � � � � � � � � 11
OVEN GAS SPECIFICATIONS � � � � � � � � � � � � 12
BROILER GAS SPECIFICATIONS� � � � � � � � � � 13
OVEN CONTROLLER� � � � � � � � � � � � � � � � � � 14
INITIAL OVEN START-UP � � � � � � � � � � � � � � � 15
DAILY OPERATION � � � � � � � � � � � � � � � � � � � 16
BROILER INFORMATION � � � � � � � � � � � � � � � 17
DAILY MAINTENANCE� � � � � � � � � � � � � � � � � 18
TROUBLESHOOTING GUIDE � � � � � � � � � � � � 19
INTERIOR LIGHT CIRCUIT � � � � � � � � � � � � � � 20
ELECTRICAL DIAGRAM� � � � � � � � � � � � � � � � 21
LIMITED WARRANTY � � � � � � � � � � � � � � � � � 23

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
3
DESIGNER SERIES
Shown: WS-DS1-7248-RFG-BB-IR-MB
INSTALLATION AND OPERATION MANUAL FOR
THE WOOD STONE DESIGNER SERIES OVEN
NATURAL GAS OR PROPANE FUELED STONE HEARTH OVEN
DESIGNER SERIES MODELS
WS-DS1-(6348,7248)-(RFG)-(MB)-(NG, LP)-(W)
(-MB MODELS WITH BROILER OPTION)
ADDITIONAL COPIES AVAILABLE UPON REQUEST

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
4
CAUTIONS & WARNINGS
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Additional copies of this manual at woodstone-corp�com�
For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�
INSTALLATION AND OPERATING INSTRUCTIONS FOR THE
WOOD STONE DESIGNER SERIES OVEN WITH BROILER OPTION
It is recommended that this oven be installed, maintained and serviced by authorized professionals.
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
Please read this entire manual before you install the oven. Failure to follow instructions may result in property
damage, bodily injury or even death. Contact your local building or fire officials about restrictions and installation
inspection in your area.
IMPORTANT: Consult your local gas supplier for a statement outlining a procedure to be followed in the event you
smell gas. Post the statement in a prominent location.
IF THIS OVEN IS NOT PROPERLY INSTALLED A FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THESE
INSTALLATION INSTRUCTIONS.
WARNING: Improper installation, adjustment, alteration, service or maintenance can result in property damage, injury
or death. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this
equipment.
AVERTISSEMENT: L’installation, le réglage, la modification, la réparation ou l’entretien incorrect de cet appareil
peut causer des dommages matériels, de blessures ou la mort. Lire attentivement les instructions d’installation, de
fonctionement et d’entretien avant de procéder à son installation ou entretien.
CAUTION: Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid or similar liquids to start
of freshen a fire in this oven. Keep all such liquids well away from the oven when in use.
DO NOT USE PRODUCTS NOT SPECIFIED FOR USE WITH THIS OVEN.

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
5
CAUTIONS & WARNINGS
WARNING: This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth
of Massachusetts.
A MAJOR CAUSE OF OVEN RELATED FIRES IS A
FAILURE TO MAINTAIN REQUIRED CLEARANCES
TO COMBUSTIBLE MATERIAL. IT IS OF UTMOST
IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY
IN ACCORDANCE WITH THESE INSTRUCTIONS.
SAVE THE INSTRUCTIONS
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any
other appliance.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser d’essence ou d’autres vapeurs de liquides inflammables ou
des liquides dans les environs de ce ou de tout autre appareil.
DISCONNECT POWER TO THE OVEN BEFORE SERVICING OR CLEANING.
NO ATTEMPT SHOULD BE MADE TO OPERATE THIS APPLIANCE DURING A POWER FAILURE
Wood Stone’s Designer Series ovens have been tested and approved
by Intertek Testing Services and are ETL listed to ANSI Z83.11b-2009 / CSA 1.8b-2009,
UL Subject 2162, UL 737, ULC-S627-00
and to ANSI/NSF 4 - 2009.

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
6
6348 SPECIFICATIONS
Designer Series 6348 - Broiler, Hearth Oven
General Arrangement
bena
4/22/2014
0
1 of 1
WS-DS-6348-BR-SH
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name: N/A
Oven Model: WS-DS-6348-RFGIR-BR
Options Shown In General Arrangement
Gas Stone Hearth Oven
Gas Charbroiler
Designer Series 6348 - Broiler, Hearth Oven
General Arrangement
bena
4/22/2014
0
1 of 1
WS-DS-6348-BR-SH
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name: N/A
Oven Model: WS-DS-6348-RFGIR-BR
Options Shown In General Arrangement
Gas Stone Hearth Oven
Gas Charbroiler
UTILITIES SPECIFICATIONS
Gas: 3/4 inch FNPT gas inlet
Varies depending upon configuration
47,000 BTU/hr: IR Burner (ea)
50,000 BTU/hr: Radiant Flame Burner (ea)
57,000 BTU/hr: Broiler (ea)
Maximum gas inlet pressure
1/2 psi (14 inches W�C�)
Electrical:
120 VAC, 1�2 A, 50/60 Hz
Optional: 240 VAC, 1�2 A, 50/60 Hz
Gas inlet available on both sides of oven�
Electrical connection side variable–
specify at time of order�
Refer to the data plate when installing�
Venting: Designer Series ovens must be vented using a Listed
Type 1 exhaust hood, or a hood constructed and installed in
accordance with NFPA 96 and all relevant local and national
codes, and in a manner acceptable to the authority having
jurisdiction�
IMPORTANT: Models with -W in the model number must be
vented as a solid fuel appliance�
Shipping weight:
4,200 lbs
1,905 kgs
Air intake: Do not
facade or cover over
Must be left
removable for service
Utility connections shown
in left side configuration�
SHOWN WITH OPTIONAL BROILER
Plan view
Front view Side view
Designer Series 6348 - Broiler, Hearth Oven
General Arrangement
bena
4/22/2014
0
1 of 1
WS-DS-6348-BR-SH
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
An Ongoing Program Of Product Improvements May Require Us To Change Specifications Without Notice
LINEAR TOLERANCES ± 1/2" / ± 10mm UNLESS NOTED OTHERWISE THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION ANY REPRESENTATION OR USE IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED.
SHEET:
AUTH:
DWG #:
DATE:
REV:
\\woodstone.net\dfs\CAD\0_Ovens\0_General_Arrangement\Designer_Series WS-DS\6348\WS-DS-6348-RFGIR-BroilerHearth-0_Manual.dwg
Job Name: N/A
Oven Model: WS-DS-6348-RFGIR-BR
Options Shown In General Arrangement
Gas Stone Hearth Oven
Gas Charbroiler
AIR INTAKE AIR INTAKE
AIR INTAKE AIR INTAKE

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
7
7248 SPECIFICATIONS
UTILITIES SPECIFICATIONS
Gas: 3/4 inch FNPT gas inlet
Varies depending upon configuration
47,000 BTU/hr: IR Burner (ea)
50,000 BTU/hr: Radiant Flame Burner (ea)
57,000 BTU/hr: Broiler (ea)
Maximum gas inlet pressure:
1/2 psi (14 inches W�C�)
Plan view
Front viewSide view
Electrical:
120 VAC, 1�2 A, 50/60 Hz
Optional: 240 VAC, 1�2 A, 50/60 Hz
Gas inlet available on both sides of oven�
Electrical connection side variable–
specify at time of order�
Refer to the data plate when installing�
Venting: Designer Series ovens must be vented using a Listed
Type 1 exhaust hood, or a hood constructed and installed in
accordance with NFPA 96 and all relevant local and national
codes, and in a manner acceptable to the authority having
jurisdiction�
IMPORTANT: Models with -W in the model number must be
vented as a solid fuel appliance�
REV:
LEGEND:
PART #:
001-50DS7248-PBR
DS7248 Pizza-Broiler Oven
General Arrangement
4/29/2013 bena
4
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-DS-7248_General_Arrangement-4.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, Less than 5A
GAS INLET: 3/4" NPT
154,000 BTU, NG
154,000 BTU, LP
1 of 1
AIR INTAKEAIR INTAKE AIR INTAKE
G
G
56 1/2"
1430mm
8 1/4"
210mm
55 3/4"
1410mm
7 1/2"
190mm
72"
1830mm
5 1/2"
140mm
9 1/4"
240mm
36"
910mm 36"
910mm
74 1/2"
1890mm
23 1/4"
590mm
23 1/4"
590mm
9 3/4"
250mm 14 1/4" 360mm 4"
100mm
48 1/4"
1230mm
40 1/4"
1020mm
29 1/2"
750mm
12"
300mm
9 3/4"
250mm
1"
20mm
73 1/2"
1870mm
34"
870mm
15 1/2"
400mm
12 1/2"
320mm
9 3/4"
250mm
27 3/4"
710mm
3 3/4"
90mm 47 3/4"
1210mm
5"
130mm
1"
30mm
REV:
LEGEND:
PART #:
001-50DS7248-PBR
DS7248 Pizza-Broiler Oven
General Arrangement
4/29/2013 bena
4
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-DS-7248_General_Arrangement-4.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, Less than 5A
GAS INLET: 3/4" NPT
154,000 BTU, NG
154,000 BTU, LP
1 of 1
AIR INTAKEAIR INTAKE AIR INTAKE
G
G
56 1/2"
1430mm
8 1/4"
210mm
55 3/4"
1410mm
7 1/2"
190mm
72"
1830mm
5 1/2"
140mm
9 1/4"
240mm
36"
910mm 36"
910mm
74 1/2"
1890mm
23 1/4"
590mm
23 1/4"
590mm
9 3/4"
250mm 14 1/4" 360mm 4"
100mm
48 1/4"
1230mm
40 1/4"
1020mm
29 1/2"
750mm
12"
300mm
9 3/4"
250mm
1"
20mm
73 1/2"
1870mm
34"
870mm
15 1/2"
400mm
12 1/2"
320mm
9 3/4"
250mm
27 3/4"
710mm
3 3/4"
90mm 47 3/4"
1210mm
5"
130mm
1"
30mm
REV:
LEGEND:
PART #:
001-50DS7248-PBR
DS7248 Pizza-Broiler Oven
General Arrangement
4/29/2013 bena
4
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-DS-7248_General_Arrangement-4.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, Less than 5A
GAS INLET: 3/4" NPT
154,000 BTU, NG
154,000 BTU, LP
1 of 1
AIR INTAKEAIR INTAKE AIR INTAKE
G
G
56 1/2"
1430mm
8 1/4"
210mm
55 3/4"
1410mm
7 1/2"
190mm
72"
1830mm
5 1/2"
140mm
9 1/4"
240mm
36"
910mm 36"
910mm
74 1/2"
1890mm
23 1/4"
590mm
23 1/4"
590mm
9 3/4"
250mm 14 1/4" 360mm 4"
100mm
48 1/4"
1230mm
40 1/4"
1020mm
29 1/2"
750mm
12"
300mm
9 3/4"
250mm
1"
20mm
73 1/2"
1870mm
34"
870mm
15 1/2"
400mm
12 1/2"
320mm
9 3/4"
250mm
27 3/4"
710mm
3 3/4"
90mm 47 3/4"
1210mm
5"
130mm
1"
30mm
Shipping weight:
4,450 lbs
2,10 kgs
Air intake: Do not
facade or cover over
Must be left
removable for service
Utility connections shown
in left side configuration�
SHOWN WITH OPTIONAL BROILER
AIR INTAKE AIR INTAKE

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
8
MOVING THE OVEN
LIFTING THE OVEN – 6,000 LBS. FORKLIFT REQUIRED
The Wood Stone Designer Series 7248 oven weighs approximately 4,500 lbs� The oven may be moved using a forklift using the
forklift pockets provided at the front and rear of the unit� The oven may also be moved using a pallet jack� If the oven is to be
installed against a wall, you may need to leave access to the back of the oven to complete the utility connections�
CAUTION: These ovens are extremely heavy� If using a pallet jack to move the oven DO NOT ATTEMPT to move the oven over
anything but a smooth flat surface� Attempting to move the oven with a pallet jack over anything but a smooth flat surface could
cause the oven to tip over resulting in potential serious injury, damage to the oven and property damage�
IF YOU ARE PLANNING TO USE A CRANE TO UNLOAD THE OVEN,
PLEASE SPECIFY A FLATBED TRUCK DELIVERY!
NOTE: This is a general example of forklift
pockets� Forklift pocket locations may vary
as Designer Series ovens are custom built�
Side forklift pockets
DELIVERY NOTE: The customer will receive an Oven Shipping Notification when the oven leaves the Wood Stone factory� This
will include a PRO# and a trucking company contact number� Wood Stone recommends that you confirm the delivery date/time
with the trucking company before committing to heavy equipment and/or labor� Our goal is a smooth and safe delivery�
DO NOT TURN THE OVEN ON ITS SIDE!
Moving a Wood Stone oven can present interesting challenges
to even the most experienced riggers� Make sure to secure the
proper equipment and make safety your first priority� Please
don’t hesitate to call the factory for technical support�

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
9
INSTALLATION CLEARANCES
1. The Wood Stone Designer Series Oven must have a minimum 1-inch clearance to combustibles from all sides, 7 inch clearance
to combustibles from the top� If building a facade that will contact the oven, use completely non-combustible materials� Any
facade wall on the front of the oven must be of non-combustible construction� Please note that standard Drywall (or Sheetrock)
is considered a combustible� Any walls perpendicular to the front of the oven in the area 30 inches to either side of the doorway
and 36 inches in front of the oven should have a non-combustible surface�
2. This oven should be installed on a non-combustible floor surface� For use only on noncombustible floors (installér sur un
plancher incombustible seulement)� The non-combustible floor surface must extend 36 inches in front of and 30 inches to
either side of the oven doorway�
3. If equipped, do not cover the glass viewing windows� If constructing a facade wall around the oven, provide openings for the
viewing windows� Seal the openings to the oven using a non-combustible insulation and an appropriate flashing, (i�e� steel or
ceramic tile)� Facade materials 6 inches on each side and above the window must be non-combustible�
WARNING: DO NOT FILL REQUIRED AIR SPACE WITH INSULATION OR OTHER MATERIALS.
DO NOT BLOCK AIR INTAKE AREA ON SERVICE PANELS AT FRONT OF THE OVEN.
DO NOT BLOCK SERVICE PANELS.
THESE MUST REMAIN REMOVABLE TO ALLOW ACCESS FOR MAINTENANCE AND SERVICE.
A MAJOR CAUSE OF OVEN RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO
COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY IN ACCORDANCE WITH
THESE INSTRUCTIONS.
WARNING: Installation and servicing of this product could expose you to glasswool/ceramic fibers as well as
calcium silicate dust�ALWAYS WEAR RESPIRATORY AND EYE PROTECTION WHEN INSTALLING OR SERVICING THIS
APPLIANCE� Please read this entire manual before you install the oven� Failure to follow instructions may result
in property damage, bodily injury or even death� Contact your local building or fire officials about restrictions and
installation inspection in your area�
!
!WARNING: Do not pack required air spaces (clearance) with insulation or other material.
EN AVERTISSANT: n’emballez pas les espaces aériens requis avec l’isolation ou tout autre matériel.
When non-combustible building materials contact the body of the oven, the clearances to combustibles
are transferred to those non-combustibles.

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
10
VENTING
All Wood Stone Designer Series ovens must be vented using a Listed Type 1 exhaust hood or one that is constructed and installed in
accordance with all relevant local and national codes� Wood Stone offers eyebrow-type hoods designed specifically for Wood Stone
ovens� The hood should be installed in accordance with the hood manufacturer’s instructions, and with the Standard for Ventilation
Control and Fire Protection of Commercial Cooking Operations, NFPA 96 and/or the applicable local and national codes� Solid fuel
burning ovens must be vented separately from non-solid fuel burning equipment�
It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone oven. All duct material
must be manufactured to the specifications of a grease duct� Due to the possibility of sparks entering the duct, exhaust systems
serving solid fuel equipment MUST not be combined with exhaust systems serving other (non-solid fuel) equipment� The venting
system should be cleaned and inspected at least every 3 months, and at least monthly with wood-fired applications�
WOOD BURNING MODELS
Designer Series ovens with model numbers containing a -W should be vented in accordance with codes concerning solid fuel
appliances, NFPA 96� Due to the dangers of creosote buildup and of sparks entering the duct, these models should be vented
separately from all other kitchen equipment or in such a manner as is acceptable to the authority having jurisdiction� The Wood
Stone customer support staff is available at 1-800-988-8103 for technical support�
Solid fuel exhaust contains creosote and other substances that accumulate in ducts, creating a risk of fire� The rate of accumulation
will vary with respect to flue gas temperature, wood type and moisture content� Frequent, regularly scheduled, thorough flue
cleaning is the best way to minimize the risk of flue fires� Wood Stone recommends cleaning and inspection at least monthly
on any ventilation system serving solid fuel equipment.
CREOSOTE - AND THE NEED FOR ITS REMOVAL
When wood is burned slowly, it produces tar and other organic vapors, which combine with expelled moisture to form creosote�
The creosote vapors condense in the relatively cool oven flue of a slow-burning fire� As a result, creosote residue accumulates in
the duct� When ignited, this creosote makes an extremely hot fire� The duct serving this oven should be inspected at least twice a
month during the first two months of operation, to establish rate of creosote buildup and necessary cleaning schedule� If creosote or
soot has accumulated, it should be removed to reduce the risk of a flue fire� The interior floor and dome of the oven do not require
creosote or soot removal� The oven flue and exhaust system will require inspection and cleaning� The exhaust system should be
inspected and cleaned per the manufacturer's and or local code official's recommendations� Wood Stone recommends cleaning
and inspection at least monthly on any ventilation system serving solid fuel equipment.
Wood Stone recommends that you refer to the exhaust hood manufacturer's recommendations for inspection,
maintenance and cleaning.
Wood Stone recommends that you consult with a qualified mechanical engineer
and submit your venting plans to local code authorities before proceeding with installation.
Contact local building or fire officials concerning any installation restrictions
or need for inspection of the oven installation.
VENTING

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
11
UTILITY CONNECTIONS
ELECTRICAL CONNECTIONS
A junction box is provided on one side of the oven (specified at time of order) towards the back of the oven� The incoming power
is connected to oven at this junction box� Check the equipment data plate to verify proper voltage before connecting the oven� If
needed, the location of the junction box may be easily relocated to the opposite side of the oven by the installer�
This appliance must be electrically grounded in accordance with local code, or in the absence of local code, with the
national electrical code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.2, as applicable. An electrical diagram is
provided inside the oven control box, and on the transformer box beneath the oven as well, and at the end of this manual.
GAS CONNECTION
Connect the incoming gas supply to the 3/4 inch FNPT gas inlet located on one side of the oven� A gas inlet is available on each side
of the oven� Both inlets are plugged at the factory� Remove the plug from the inlet to which the connection will be made� Verify that
the unused inlet remains plugged� A 3/4 inch full-flow gas shut-off valve (supplied by others) must be installed on the gas supply
near the oven in such a way that it is readily accessible�
UTILITY LOCATIONS
Utility locations shown below as left-side configuration� Right-side configuration would mirror left-side configuration�
ASSEMBLY -- CONNECTIONS

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
12
OVEN GAS SPECIFICATIONS
GAS CODE LIMITATIONS
The installation of this appliance must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code,
ANSI Z223�1 or the Natural Gas Installation Code CAN/CGA-B149�1, as applicable including:
1. The appliance and its individual shutoff valve (supplied by others) must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psi (3�45 kPa)�
2. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve (supplied by
others) during any pressure testing of the gas supply piping system at test pressure, equal to or less than 1/2 psi (3�45 kPa)�
The incoming gas supply pressure must not exceed 1/2 psi (14 inches W�C�)� If the incoming gas pressure exceeds 1/2 psi, an
external gas regulator must be installed in the supply line� If the supply pressure is less than 1/2 psi, no external regulator is
required�
The installer should bleed any air out of the gas line supplying the oven� All gas connections and fittings on the oven should be leak
checked with an approved soap solution�
CHECKING THE BURNER MANIFOLD PRESSURE
The burner manifold pressure has been set at the factory� However it should be checked by the installer� The pressure should be
checked at the outlet tap on the Honeywell gas valve, located on the back of the control box� Once the manometer is connected,
turn the oven on and use the knob on the oven to adjust the flame to its maximum height� Then check the manifold pressure�
FACTORY SPECIFIED MANIFOLD PRESSURE
Radiant Flame Burner(s)
Natural Gas (NG): 5" W�C�
Propane (LP): 9�5" W�C�
TOTAL BTU/HR RATING
See data plate for your specific model.
This information can also be found on the data plate located beneath the oven�
GAS SPECIFICATIONS

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
13
BROILER GAS SPECIFICATIONS
Broiler pressure tap
Located behind the broiler
faceplate at the front of the oven
MANIFOLD PRESSURES FOR OPTIONAL BROILER
This information can also be found on the data plate located beneath the oven�
Broiler Manifold Pressures
Natural Gas (NG): 6" W�C�
Propane (LP): 10" W�C�
Pressure adjustments for the broiler are made at the regulator located beneath the oven� This regulator serves the broiler only and
does not effect the oven burners� A pressure tap is located on the broiler manifold, behind the broiler faceplate�
Broiler pressure regulator
Located underneath the broiler,
accessed behind the front
service panel
Broiler pressure regulator
Close-up view

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
14
OVEN CONTROLLER
ON/OFF button
Press to turn
display on and
off�
Temperature
units
Press and hold to
switch between
Fahrenheit
and Celsius�
Hearth Temperature
The hearth (floor)
temperature will
be displayed when
the oven is turned
on� Display will
read “LO” when the
temperature is below
38 °C (100 °F)�
1-800-988-8103 www.woodstone-corp.com
HEARTH SET POINT
HEARTH
TEMPERATURE
F
C
OFF
ON
POWER DOME HEARTH
FLAME HEAT
Push ON/OFF
button to turn
burners off.
Presser le bouton
ON/OFF pour
arreter le bruleur.
Push ON/OFF
button to light
burners.
Presser le bouton
ON/OFF pour
allumer le bruleur.
WAIT 5 MINUTES BEFORE RELIGHTING
ATTENDRE 5 MINUTES AVANT DE RÉALLUMER
On/Off button
Press to turn oven on/off
Hearth Set Point display
Indicates Hearth Set
Point temperature of
Underfloor IR burner
Hearth Temperature display
Displays temperature of
oven floor (hearth)� Sensor is
embedded 1" below hearth
surface� Arrow buttons
Pressing appropriate
directional arrow to
adjusts Hearth Set Point
temperature up or down�
Temperature unit selector
Toggles between Fahrenheit
and Celsius temperature
scales in display screens
Power indicator light
Indicates the oven is
turned ON�
Dome Flame
indicator light
Indicates the pilot for
Radiant flame has lit�
Hearth Heat indicator light
Indicates that the pilot for the underfloor IR burner
is lit� This light will go off whenever the hearth
temperature is above the Hearth Set Point�
TYPE 4 CONTROLLER
RFG, RFG-W models
TYPE 2 CONTROLLER
RFG-IR,
RFG-IR-W models
CONTROLLER

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
15
INITIAL OVEN START-UP (RFG)
INITIAL OVEN START-UP
NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity
or damp conditions during shipment from the factory or extended periods of storage before installation� Occasionally, through the
course of the Initial Start-Up, as the oven heats up it is possible that you will see some water dripping from the sides of the oven
as moisture is driven out of the ceramic� This is not a defect in the oven, and once the oven has been fully saturated with heat, the
moisture will be driven fully from the oven� After this initial process, you will not see any additional moisture from the oven unless
the oven is not used for an extended period of time AND it is exposed to excessive moisture or high humidity�
FIRST DAY
1. Make sure exhaust fan is properly wired and interlocked to the appliance and main gas supply is ON (valve parallel with gas
line)�
2. Push I/O button on Controller(s), leaving Broiler off during the Start-Up process� (See BROILER OPERATION section for Broiler
Lighting instructions�) It may take a while for the gas to purge all the air from the gas lines� The exhaust fan should come on
as well�
3. Once the burner ignites, make sure the flame is at its lowest setting, “1” and allow the appliance to operate at this setting for
about 1 hour�
4. After 1 hour, raise Radiant flame to 25% (~5-inch flame, or ~2 on the Flame Height Control Index Scale) and hold this setting
for 4 hours�
5. After 4 hours, raise radiant flame height to 50% (~3 on the Flame Height Index Scale) and hold another 4 hours� The oven can
be left at this setting all night�
6. At this point, the oven is ready for use�
NOTE: Small “crazing” cracks will occur with normal heating and cooling� They will not affect the performance or durability of the
oven� If cracks of 1/8" wide or more develop, contact Wood Stone for evaluation�
For more information regarding Flame Height
Control, go to the Resource Center section of our
web site at:
www.woodstone-corp.com
Flame Height Index Scale
Flame Height Control Knob
FLAME HEIGHT INDICATOR
Comprised of two parts

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
16
INITIAL OVEN START-UP (RFG-IR)
INITIAL RFG-IR OVEN START-UP
NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity
or damp conditions during shipment from the factory or extended periods of storage before installation� Occasionally, through the
course of the initial start-up, as the oven heats up it is possible that you will see some water dripping from the sides of the oven
as moisture is driven out of the ceramic� This is not a defect in the oven, and once the oven has been fully saturated with heat, the
moisture will be driven fully from the oven� After this initial process, you will not see any additional moisture from the oven unless
the oven is not used for an extended period of time AND it is exposed to excessive moisture or high humidity�
FIRST DAY
1. Make sure exhaust fan is properly wired and interlocked to the appliance and main gas supply is ON (valve parallel with gas
line)�
2. Light pilots for the broiler, but leave broiler off at this time� (See BROILER OPERATION section for lighting instructions�
3. Push I/O button on Controller� There may be more than one Controller, depending on how your oven is configured� The
exhaust fan should come on as well�
4. Use the arrows on the Controller to set the Hearth Set Point to 100 °F� It may take a while for the gas to purge all the air from
the gas lines�
5. Once the Radiant burner ignites, using the Flame Height Control Knob(s) (depending upon configuration), set the Radiant
flame to its lowest setting, "1" on the Flame Height Index Scale, and allow the oven to operate at this setting for about 1
hour� (See previous page for Flame Height Indicator details�)
6. After 1 hour, raise radiant flame to 25% (~5-inch flame, or ~2 on the Flame Height Index Scale) and hold this setting for 4
hours�
7. After 4 hours, raise radiant flame height to 50% (~3-inch flame, or ~3 on the Flame Height Index Scale) and hold another 4
hours� The oven can be left at this setting all night�
8. At this point, the oven is ready for use�
NOTE: Small “crazing” cracks will occur with normal heating and cooling� They will not affect the performance or
durability of the oven� If cracks of 1/8" wide or more develop, contact Wood Stone for evaluation�

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
17
DAILY OPERATION
DAILY OVEN OPERATION
The oven floor temperature is displayed on the Controller readout�
DO NOT OVER FIRE! WHEN FLAMES SPILL OUT OF THE DOOR, OR IF THE OVEN FLOOR (HEARTH)
TEMPERATURE EXCEEDS 700 °F, YOU ARE OVER FIRING THE OVEN.
END OF THE DAY
Push I/O button on the Controller� All gas will go off, even the pilots, in the oven� Broiler pilots can be left on overnight in the stand
by position (Check with your local jurisdiction for proper safety requirements�) When the oven is turned off, use the Night Heat
Retention Door(s) to help retain heat in the oven� The night door is placed into the oven doorway� IMPORTANT: Do not cook with the
Night Heat Retention Door(s) in place� Remove before starting the oven�
BEGINNING OF THE DAY
1. Push the On/Off button on the Controller to start the oven� IMPORTANT: Make certain Night Heat Retention doors have been
removed�
2. Set the Hearth Set Point temperature to desired temperature—typically 500 °F, using the Up or Down arrow on the controller�
3. Turn Temperature Control Knob(s) (depending upon configuration) to “5” on the Flame Height Index Scale – the heat up flame
position�
4. Wait until Hearth Temperature on the controller reaches 500 °F� Heat up time from room temperature will be approximately 2
hours, 40 minutes�
5. Maintain temperature range—typically 500–530 °F, using a holding flame of 3�2-ish (approximately a 10" flame) on the
Flame Height Index Scale(s)�
6. When cooking, adjust flame upwards 2-3 inches� Return to holding flame after removing product�
See woodstone-corp.com for detailed information on cooking in your Wood Stone oven�
DURING THE DAY
Wood Stone recommends the use of long-handled brushes for sweeping up surface debris that will accumulate on the floor of the
oven during use� Use a natural fiber brush—always brushing away from the radiant burner well� For deeper cleaning, use a brass
bristled brush� The oven floor can be then cleaned with a damp rag wrapped around the brass bristled brush head� (Wood Stone
offers an assortment of oven brushes available through your dealer� Specification sheets may be viewed on the Wood Stone website
under Tools & Accessories�)

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
18
BROILER OPERATION
OPTIONAL BROILER LIGHTING INSTRUCTIONS
OVERVIEW
The broiler utilizes a standing pilot ignition system� This system incorporates a pilot flame and pilot sensor for each of the (3) broiler
burners� If a pilot goes out or cannot be detected by the sensor, the system will shut down the gas supply to that broiler burner� Each
pilot must be lit manually� NOTE: The broiler operates independently of the oven controls, turning the oven controller ON or
OFF has no effect on the broiler. When turning the oven off, turn the broiler off as well. Pilots can be left on overnight in the
1 o’clock stand by position� However, check with your local jurisdiction for proper safety requirements�
b. Pilot access holes
c. Depressing broiler control knob in the
1 o’clock position
e. Broiler control knobs in cooking position
d. Broiler control knobs in standby position
f. Broiler control knob in
pilot off position
Radiant
a. Removing broiler grates & radiants
4. Release the knob� If the pilot
does not remain lit after the
knob is released, wait for
5 minutes before repeating
the pilot lighting procedure�
Note: The 1 o’clock position
is also the burner standby
position (d)�
5. Replace the radiants and
broiler grates once all
3 pilots are lit�
6. Turn the burner knobs
counterclockwise to adjust
the burners (e)�
End of day
Turn off oven by pushing the
On/Off button on the controller
(Power indicator light on the
controller will turn off)� Turning
off the oven has no effect on
the broiler� To turn pilots off,
push in and rotate each broiler
control knob clockwise as far
as it will turn (f)�
Lighting the broiler pilot lights
1. Remove the 3 broiler grates
and 3 radiants from the broiler
(photo a)� The radiants are
the sheet metal pieces that
sit over each burner strip� The
pilots are located towards
the front of each burner,
accessible through a cut out
section of the rectangular
metal cover (b)�
2. Use a long neck lighter that
will reach the pilot� Ignite the
lighter, then turn the corre-
sponding broiler control knob
to the pilot (1 o’clock) position�
You’ll feel the stop� Push the
knob and hold it in (c)�
3. Lite the pilot and continue to
hold the knob in once the pilot
has ignited for approximately
one minute to ensure the pilot
remains lit�
If a pilot goes out, wait five minutes before attempting to relight it. Do not attempt to relight the pilot if you smell gas.
Turn off the oven and broiler until the gas smell clears. If you suspect a problem with the oven or broiler, contact
the Wood Stone Service Department immediately. Do not attempt to run the oven or the broiler until the problem is
identified and corrected.

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
19
DAILY MAINTENANCE
OVEN INTERIOR
Wood Stone recommends the use of long-handled brushes for sweeping up surface debris that will accumulate on the floor of the
oven during use� Use a natural fiber brush—always brushing away from the radiant burner well� For deeper cleaning, use a brass
bristled brush� The oven floor can be then cleaned with a damp rag wrapped around the brass bristled brush head�
Wood Stone offers an assortment of oven brushes available through your dealer� Specification sheets may be viewed on the Wood
Stone website under Tools & Accessories�
DO NOT POUR OR SPRAY LIQUIDS ONTO THE OVEN DECK OR INTO THE OVEN INTERIOR AS
THIS CAN DAMAGE THE CERAMIC AND WILL VOID THE WARRANTY.
There is a stainless steel burner guard to prevent food from falling on and thereby obstructing the gas orifices of the radiant flame�
If food gets into the radiant flame well and the flame is visibly obstructed, turn the oven off immediately, and call for service�
DO NOT USE THE RADIANT BURNER WELL AS A DUMP FOR DEBRIS OR TRASH INCINERATION;
MAKE EVERY ATTEMPT TO KEEP DEBRIS FROM DROPPING INTO THE WELL.
OVEN EXTERIOR
All painted and stainless steel surfaces should be cleaned as necessary using a mild detergent, hot water and a soft cloth or
sponge� Stubborn residues may be removed using a nonmetallic scouring pad� When scouring stainless steel surfaces, scrub with
the grain of the metal to prevent scratching� Do not use any type of scouring pad on glass surfaces�

Designer Series 1 w/ Broiler Option
Installation and Operation Manual
An ongoing program of product improvement may require us to change
specifications without notice. Designer Series-1 w/ Broiler Option,
Revised November 2014. Doc no: M0078.00
[email protected] or visit woodstone-corp.com
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free 800.988.8103
Tel [phone]
Fax [phone]
20
TROUBLESHOOTING GUIDE
Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your
oven. Our service hours are 8am to 4:30pm Pacific Standard Time. Follow the recorded instructions for Emergency
Service if you require assistance during non-business hours. A Wood Stone technician will promptly respond to your call.
Controller will not turn on
Flame does not light
Flame cuts out
Display reads “OPEN”
1. Incoming power to oven turned off� Check circuit breaker for circuit
supplying the oven� Check that any wall switches external to the oven that
control oven power are turned on� Check that any interlocks external to the
oven are turned on�
2. If controller still does not turn on, please contact Wood Stone for assistance�
1. Debris in burner�
2. Oven is being run with the night door in place� Night Heat Retention Door
must be removed whenever the oven is turned on�
3. Wind blowing into the oven, or other venting issues�
1. Thermocouple is not plugged into control box�
2. Damaged thermocouple� Contact Wood Stone for assistance�
PROBLEM CAUSE/SOLUTION
1. Is gas turned on to the oven? Is gas shut-off valve turned all the way on?
2. Debris in burner� Burner may require cleaning� Contact Wood Stone for
assistance�
3. Damaged igniter or gas valve� Contact Wood Stone for assistance�
If the oven is being started for the first time:
- Has all air been bled from the gas line?
- Is the switch on the SV-2 valve in the ON position?
NOTE: Valve is locate on the back of the control box, beneath the oven�
