Woodbridge B0950S/V8300 Assembly instructions

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
110618 REV. 1
www.woodbridgebath.com
R
WOODBRIDGE
INSTALLATION AND CARE GUIDE
Remote Control Illustration
STOP
ENERGY
SAVER
NOZZLE
CLEANING
TEMPERATURE WATER DRY SEAT
MASSAGE
AUTO
Thank you for choosing our product.Please read the instructions carefully before
installation and keep it available for future maintenance or reference.
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help.[email protected]

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
1
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
106mm
Hole
Hole
106mm
The position of
anti-theft screw
Remote control installation
(1)Drill two holes, which are parallel to the floor, on the wall with depth of 35mm,
and center distance between two holes of 106mm.
(2)Insert expansion tube into the hole on the wall, install the hanger to the wall with
a screw, and paste the double faced adhesive tape on hanger to the wall, tighten
the screw.
(3)
Notice：Please do not install and use the product in moist place, such as steam
room, and prohibit to place in the space where is easily got wet.
In public place, please use screw to fix the remote control with bracket in
avoid remote control missing.
Installation Preparation
STOP
Remote control hanger installation
Install battery and place remote control to the hanger.
NOZZLE
CLEANING
TEMPERATURE
Installation Preparation
Make sure end-user be able to reach the
remote control when sitting on the seat.
WATER DRY SEAT
ENERGY
SAVER

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
2
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Remote control illustration
STOP
Water temperature,Dry temperature, Seat temperature
Usage Instruction
Energy saver
Flush button
Nozzle cleaning Rear
Front
Massage
Drying
Temperature
Stop
Adjustment of nozzle position
Water pressure adjustment
Temperature adjustment
Auto rear cleaning
Auto Front cleaning
Auto rear/front cleaning
TEMPERATURE
NOZZLE
CLEANING
WATER
DRY
SEAT
WATER
DRY
SEAT
ENERGY
SAVER
ENERGY SAVER 3 6 9 H
PRESSURE
POSITION
MASSAGE
AUTO

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
3
www.woodbridgebath.com
R
WOODBRIDGE
Rear/Front cleaning
Press “Rear”/“Front” button, the water comes out of wand to clean the rear/front
portion of body. It automatically stops after a cycle of cleaning. If press “STOP”
button when using, the function will stop immediately.
Massage
Press “MASSAGE” button to activate massage function, the nozzle moves forward
and back to extend the cleaning scope; Press “MASSAGE” button again to stop the
function.
Drying Operation
Press “DRY” button, warm wind comes out of wand to dry. After a cycle or user
leaves the seat, it automatically stops.
Dry
Massage
Front
Rear
Usage Instruction
SAVER 3 6 9 H
MASSAGE
AUTO
REMOTE CONTROL ILLUSTRATION

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
4
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Auto function
Full-automatic function can be achieved by three “AUTO” buttons, convenient
and practical. User can pre-set the suitable nozzle position, water pressure
and temperature and save the setting. Full-automatic function will be activated by
pressing the related function button when using afterwards.
Rear cleaning 90s Dry 180s
Dry 180s
Dry 180s
Front cleaning 90s
Rear cleaning 90s Front cleaning 90s
Automatic stop
Automatic stop
Automatic stop
Usage Instruction
MASSAGE
AUTO
Auto rear cleaning

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
5
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
9:00 15:00
STOP
Usage Instruction
TEMPERATURE
NOZZLE
CLEANING
WATER DRY SEAT
WATER DRY SEAT
WATER
DRY
SEAT
Energy saver time
ENERGY SAVER 6 H
ENERGY SAVER
POWER
energy saver icon
ENERGY SAVER 3 H
ENERGY
SAVER
ENERGY
SAVER
PRESSURE POSITION
PRESSURE POSITION
The toilet enters the energy saver
mode from 9:00 to 15:00.
Energy saver light is on
Energy saver
Setting energy saver time
Press “ENERGY SAVER” button, LCD screen shows energy saver and figures. It
shows three options of energy saver period as 3-6-9-off, which can be selected
accordingly. For example, user can set from 9:00 to 15:00 as energy saver
according to following operation.
(1)Press“ENERGY SAVER”button, LCD screen shows
“ENERGY SAVER” icon.
(2)Press“ENERGY SAVER”button again, LCD screen shows figure “6”, and the “ENERGY SAVER”icon
disappear after 3 seconds, the setting succeeds. The toilet enters the energy saver mode from 9:00 to
15:00 every day. During this period, power light is off, and the energy saver light is on. It goes back to
normal operation mode after energy saver time.
Energy saver:
The toilet will be under energy saver mode automatically after setting. Under energy saver mode,
seat temperature is on low temperature status (first level) to achieve energy saver.
Notice:
If user sits on the seat, the energy saver mode is paused, and enters into the function mode, the
seat starts to heat immediately (under opening seat temperature circumstance). The energy saver mode
restores after user leaves.
When the energy saver mode is set, the icon disappears automatically, which is normal set.
(3)Cancel energy saver set: Press“ENERGY SAVER”button continuously until this function is
cancelled. (Nothing display on the screen.)

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
6
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Spray nozzle position adjustment
During “REAR” or “FRONT”, press spray nozzle button of
“ ” and “ ”, to move the position forward and backward by adjusting 5 levels.
Water pressure adjustment
During “REAR” or “FRONT”, press water pressure button of “+” and “-”, to adjust
pressure for rear and front cleaning.
Automatic deodorization
Remark:
The deodorization function starts to work automatically as the user sits on the seat
and stops automatically 3 seconds after the user leaves the seat. When drying, the
function of automatic deodorization stops.
Massage Deodorization
STOP
Usage Instruction
TEMPERATURE
NOZZLE
CLEANING
WATER
DRY
SEAT
ENERGY
SAVER
PRESSURE
POSITION

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
7
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Temperature adjustment
Press “TEMPERATURE” button twice, “DRY ” light is
on, and icon on the screen lights on, then adjust
wind temperature by “+”, “-” button. It is regarded as
operation completed if there is no operation in 5
seconds, and then “DRY ” light is off, icon
disappears. Long press “-” button until the “DRY ” icon
disappears to close the “DRY ” function.
Water temperature adjustment:
Press “TEMPERATURE” button one time, “WATER ”
light is on,icon on the screen lights on, then adjust
water temperature by “+”, “-” button. It is regarded as
operation completed if there is no operation in 5 seconds,
and then “WATER ” light is off, and icon disappears.
Long press “-” button until the “WATER ” icon disappears
to close the “WATER ” function.
Press “TEMPERATURE” button three times, “SEAT ”
light is on, and icon on the screen lights on, then
adjust seat temperature by “+”, “-” button. It is regarded
as operation completed if there is no operation in 5
seconds, and then “SEAT ” light is off, icon
disappears. Long press “-” button until the “SEAT ” icon
disappears to close the “SEAT ” function.
STOP
Usage Instruction
TEMPERATURE
NOZZLE
CLEANING
TEMPERATURE
TEMPERATURE
TEMPERATURE
WATER DRY SEAT
WATER
DRY
SEAT
WATER DRY SEAT
WATER
WATER DRY SEAT
WATER DRY SEAT
DRY
SEAT
WATER DRY SEAT
WATER DRY SEAT
ENERGY
SAVER
PRESSURE POSITION
PRESSURE POSITION
PRESSURE POSITION

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
8
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Full flush
Press “FLUSH” button to activate full flushing.
Nozzle cleaning
Usage Instruction
STOP
TEMPERATURE
NOZZLE
CLEANING
WATER
DRY
SEAT
WATER
DRY
SEAT
ENERGY
SAVER
ENERGY SAVER 3 6 9 H
PRESSURE
POSITION
MASSAGE
AUTO

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
9
Nozzle cleaning
Quick press “NOZZLE CLEANING”
button, the nozzle self-cleans for a while
and moves to the front position (no
spray). People can continue to clean
nozzle manually.
Nozzle self-cleaning by long press：
Long press “NOZZLE CLEANING” button,
the spray won’t move forward and nozzle
self-cleans for 90 seconds.
self-clean for
90 seconds.
STOP
Usage Instruction
TEMPERATURE
NOZZLE
CLEANING
Nozzle self-cleaning by quick press:
WATER
DRY
SEAT
WATER
DRY
SEAT
ENERGY
SAVER
ENERGY SAVER 3 6 9 H
PRESSURE
POSITION
MASSAGE
AUTO

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
www.woodbridgebath.com
R
WOODBRIDGE
10
REMOTE CONTROL ILLUSTRATION
Usage Instruction
Night light
Press “STOP” button, then “DRY” button, night light will be often in the off state;
Repeat the process, night light will switch to intelligent state. Repeat above process
constantly, the night light will switch between off state and intelligent state.
Quiet mode
Press “STOP” button and then “MASSAGE” button to turn off buzzer to avoid noise in
the night; Repeat the process to start buzzer function.
User code
The user code needs to be set to avoid disturbance from remote controls when more
than one toilets are used in the house.Turn on the toilet for setting while turn off others.
(1) Press“STOP”button and then“REAR” button to enter into user code setting.
The remote control shows only water pressure and spray position level,and characters
are blinking on the screen.
(2) Press water pressure buttons of “+”and “-”,to choose user code 1-9.
(3) Press“STOP”button and then“REAR” button again,remote control will save the
setting and exit user code setting window,the buzzer will ring “click” to indicate
successful setting.
The sum of water pressure and position level on LCD is the user code.Restart to clear
the user code and re-set.
Automatic flush button
Press “STOP” button and then “FLUSH” button to start or close automatic flushing function.
When the automatic flushing function is turned on, toilet will automatically flush after
detecting user sitting for more than 6 seconds and leaving the seat for more than
3.5 seconds.
Combination button
Remark:
By pressing the button, the signal indicator will flash which means the signal is sent
out;Then the buzzer rings “click”, which means the main unit receives the signal and
executes the instruction. If the signal indicator doesn't flash, that means the button is not
efficiently pressed and needed to be re-pressed. If the buzzer does not ring, that means the
main unit doesn’t receive the signal. Please regulate the remote control direction and
re-press the button.
In case of power cut during wand’s spray operation, the wand cannot go back to
place,please wait until the power is reset. In case of a power cut for a long period, please
push the wand softly back by hand. Do not push hard, to avoid damage to wand and
electrical machine.
The body should touch the seat and the buzzer rings “click”, which means functions of
front cleaning, rear cleaning and drying are in operation. The nozzle will continue to spray for
1-2 seconds after user stands up during spray operation, so please press"STOP" button
before standing up.
Use nozzle self-cleaning function after user leaves the seat. After cleaning, if user doesn't
press "NOZZLE CLEANING" or "STOP" button, nozzle wand will go back after 10 minutes or
user sits on the seat.

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
11
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Set auto function
Set automatic Rear cleaning function
The default setting of automatic function is water pressure on level three, nozzle
position on level three, water temperature, wind temperature and seat temperature
on level three, the massage function is in the off state. User can re-set based on
personal preference.
(1)Adjust water pressure, nozzle position, temperature by function button in below
grey circle, and open/close massage function.
(2)After setting is completed, long press rear cleaning automatic button for 3
seconds to save the setting.
(3)After above steps, quick press “ ” afterwards when using, LCD displays the
previous saved settings of rear cleaning level, temperature level and massage
status. By this time, the toilet operates rear cleaning 90s, and then dry 180s
automatically without pressing other buttons.
(4)During automatic rear cleaning, user still can change the level, temperature
and massage status, and press “REAR” button 3 seconds to save the
new settings.
For example, the nozzle position is
on level 2, and massage function is
open; the water pressure is on level
4; water temperature is on level 2,
while dry temperature and seat
temperature are on level 1.
STOP
NOZZLE
CLEANING
TEMPERATURE WATER DRY SEAT
WATER DRY SEAT
WATER DRY SEAT
ENERGY
SAVER
PRESSURE POSITION
PRESSURE POSITION

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
12
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Set auto function
Set automatic Front cleaning function
(1)Press spray nozzle position adjustment button to adjust nozzle to suitable
position; Press “+”, “-” to adjust water pressure; set temperature level; open/
close massage function.
(2)Press “ ” front cleaning automatic button for 3 seconds, see below picture,
and save the setting.
(3)After above steps, quick press “ ” afterwards when using, LCD displays
the previous saved settings of front cleaning level, temperature level and
massage status. By this time, the toilet operates rear cleaning 90s, and
then dry 180s automatically without pressing other buttons.
(4)During automatic front cleaning, user still can change the level, temperature
and massage status, and press “FRONT” button 3 seconds to save the
new settings.

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
13
www.woodbridgebath.com
R
WOODBRIDGE REMOTE CONTROL ILLUSTRATION
Set auto function
Set automatic Rear and Front cleaning combination function
Note: During using toilet, user can find the suitable level and temperature after
comparing repeatedly. Please set the automatic Rear and Front cleaning
combination function during using toilet.
1. After user sits on the toilet, press automatic Rear and Front
cleaning button, it starts to rear cleaning about 90s.
2. Adjust nozzle position, water pressure, wind temperature,
seat temperature and open/close massage function during
rear cleaning.
3. After adjust the parameters, remote control saves the parameters
under the first stage.
4. During adjusting, if user adjusts many times, the remote control
saves the latest parameter.
The first stage: rear cleaning 90s
(1)Automatic Rear and Front cleaning combination function includes rear
cleaning 90s, front cleaning 90s and drying 180s. User can adjust level
and temperature in different stages.
The second stage: front cleaning about 90s
(2)After finishing rear cleaning, toilet enters front cleaning stage automatically.
User can set nozzle position, water pressure, temperature and open/close
massage function, and the remote control saves the latest parameter
under the second stage.
The third stage: Drying about 180s
(3)After finishing front cleaning, toilet enters drying stage automatically. User
can set wind temperature, and the remote control saves the latest parameter
under the third stage.
(4)After set all parameters, quick press “ ” button afterwards when using, LCD
displays the previous saved settings. By this time, the toilet operates rear
cleaning, front cleaning and drying automatically by one-button operation.
If user needs to change previous settings, please repeat step 1-3.
AUTO
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: [email protected]om
Thank you for using WoodBridge products!
