Woodbridge V8300 Assembly instructions

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
110518 REV. 1
www.woodbridgebath.com
R
WOODBRIDGE
INSTALLATION AND CARE GUIDE
• 2015 Uniform Plumbing Code ( UPC )
• 2018 International Plumbing Code ( IPC )
• 2018 International Residential Code ( IPC )
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
®
®
®
Compliance with the following codes & standard:
PREFERED
EDUCATION
PROVIDER
LISTED
TM
ICC
SCC Accredited
CB-P/S
OCPS
Accrédité CCN
ANSI
ACCREDITED
ISO/IEC 17065
Product Certification Body
#1000
ELECTRONIC WASHLET TOILET :V8300/B0950S
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help.[email protected]

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
TOILET COMPONENTS
1
So Cloth
or Blanket
Silicone Silicone/
Caulk Gun
OTHER TOOLS MAY BE REQUIRED
Tape
Measure
Pencil/Marker Safety Glass Knife
During unpacking the product and prior to installation inspect your new product for any damages or
missing parts. Do not attempt to install or operate the product if the product is damaged.
Adjustable
Wrench
Channel
Lock Pliers
Adjustable
Socket Extension
Philips
Screwdriver Level Puy Knife
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
2 PEOPLE ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
INSTALLATION OF THIS PRODUCTS BY AN
INEXPERIENCED INSTALLER MAY RESULT
PERSONAL INJURY OR DEATH!
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
We reserves the right to change, update, modify, alter, redesign this manual/product or its policies without prior noce!
We shall not be liable for any injuries or property damages in connection with this product during installation or use of this product!
This products must be installed by a fully insured and licensed plumber only. Installation of any our product by anyone other
than fully insured and licensed plumber shall void limited warranty. We recommends that such licensed plumber have experience
in the installation of products.
Limited warranty is void on any commercial installation
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-state in
accordance to your location. We are not resonsible for providing any compliance certifications.
Under no circumstances we are shall not be liable for any and all incidental damages sustained in connection with this product
Neither manufacture, nor distributor, nor retailer is responsible for water damage or flood caused due to use of this product.
Under no circumstances We shall not be liable for any and all fees, cost of installation/reinstallation/removal, subsequent
damage or transportation in case of the product defect
TOOLS REQUIRED FOR INSTALLATION
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
Remote controller
components
Main Unit
Sealing Flange
Installaon Cardboard

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
2
www.woodbridgebath.com
R
WOODBRIDGE
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING
When using electrical products, especially when children are present, basic safety precautions
shouldalways be followed, including the following:
1.The appliance is not to be used by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction.
2.Children being supervised not to play with the appliance.
3.This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
4.Children shall not play with the appliance.
5.Cleaning and user maintenance shall not be made by children without supervision.
DANGER –To reduce the risk of electrocution:
1. Do not use while bathing.
3. Do not place in or drop into water or other liquid.
4. Do not reach for a product that has fallen into water. Unplug immediately.
5. Do not wash the main unit or electrical plug with water or detergent.
6. Do not handle the electrical plug with wet hands.
7. Do not put a hand or other staff over the outlet of air dryer or block the outlet of air dryer.
8. Never disassemble,repair or modify this product.
9. During installation, disassembly, repaire and maintenance of the product,the power plug must be
switched off and water supply be shut off.
WARNING–To reduce the risk of burns, electrocution, fire, or injury to persons.
1. Close supervision is necessary when this product is used by, on, or near children or invalids.
2. Use this product only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the product to a service center for examination
and repair.
4. Keep the cord away from heated surfaces.
5. Never use while sleeping or drowsy.
6. Never drop or insert any object into any opening or hose.
7. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is
being administered.
8. Connect this product to a properly grounded outlet only. See Grounding Instructions.
9. Do not throw cigarettes and other burning stuff into toilet, otherwise it might cause fire.
10.This product is electric appliance, so it must be placed far away from water. Please don’t drench urine
and other liquid to it.
11.Do not lay on side or upside the product during the electrical circuit.
12.It is prohibited to use other electric appliances in the same socket.
13.It is forbidden to use the power extension or unstable loose outlet.
14.The old aging water supply hose can not be used, otherwise it might cause leakage, fire or electrical
shock.Installation of the bidet seat should include specified components and new water supply hose.
2. Do not place or store product where it can fall or be pulled into a tub or sink.
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
3
www.woodbridgebath.com
R
WOODBRIDGE
CAUTION– Indicates that failure to follow the instruction may cause body injury or property
damage.
GROUNDING INSTRUCTIONS
This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This product is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
DANGER– Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to either flat
blade terminal. The wire with insulation having an outer surface that is green with or without yellow
stripes is the grounding wire.
This product is factory equipped with a specific electric cord and plug to permit connection to a proper
electric circuit. Make sure that the product is connected to an outlet having the same configuration as
the plug. No adapter should be used with this product. Do not modify the plug provided — if it will not fit
the outlet, have the proper outlet installed by a qualified electrician. If the product must be reconnected
for use on a different type of electric circuit, the reconnection should be made by qualified service
personnel. SAVE THESE INSTRUCTIONS
1. Do not install or use the product in wet places as steam room etc.This product must be connected to
properly grounded power outlet socket.
2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place where is
not easily got wet.
3. This product should be used with AC 110V-120V,50/60Hz electrical current only,load current is at
least 15A. P ower plug must be equipped with ground fault circuit interrupter or ground fault electrical
leakage protector or similar high sensitive, rapid type leakage switch (Rated sensitive current under
15mA).
4. When it thunders,it is strongly recommended to pull out the power plug.
5. Do not stand on ceramic toilet.
6. Ceramic toilet must install floor fixing bolt.
7. Do not stand on product unit,seat and cover.
8. Do not lean against the seat cover when using the product,to avoid damage.
9. This product is equipped with soft-closing seal cover.Heavy pressing or pushing may damage the
soft-closing damper.
10. Do not use lacquer thinner,petrol,liquid medicine,detergent,insecticide,toilet cleanser and scrubbing
brush to clean the product.
11.Exposure to direct sunlight is prohibited.
12.Only use tap water or potable water;otherwise it may cause chafing.
13.Do not connect water supply to heater outlet.Make sure inlet water temperature at 3~35℃.
14.When the room temperature is under zero degree,please dry up the water tank,to avoid freezing.
15.Raise rest room temperature to prevent the toilet from damage due to freezing.
16.When move the product from cold or wet environment into normal room temperature,wait for 2 hours
until the condensation water is fully volatilized.Doing so can prevent the product fromelectrical short
-circuit.
17.When not using the product over three(3) days,drain the water out of the container and pull the
elelctrical plug from the wall outlet. 18.Stop using the product and shut off the power when product
malfunctions,please contact the service people for professional service.
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
4
www.woodbridgebath.com
R
WOODBRIDGE
Heated seat
Caring
device
Surface
temperature
Heating power
Open and close
device
Heated burning
protection
Safety device
Night light
assembly
User ID setting
Automatic flushing
Auto lid open/
close(optional)
50W
Quiet soft-closing device,Auto open and close
The seat temperature will automatically lower to level 1 in 10 minutes
after using
Seat sensor,Temperature sensor, Bimetallic thermostat,Temperature fuse
intelligent,often in the off state
To avoid disturbance from remote controls by multi-user
Toilet will automatically flush as user walks away from bowl
Intelligent lid open/close or by remote controller
Rating power
Main Unit
Toilet
Rating pressure
Water pressure
range
Electrical wire
Flush volume
Flushing mode Siphonic jet
length is about 1.8m
Minimum water pressure 0.07MPa (20L/min. flow).
Maximum water pressure 0.8MPa (Hydrostatic pressure)
Hole distance
Radius of
discharging hole
Drainage method Down-drain
Heating power
Water
temperature 6 different level adjustment
Water volume 5 different level adjustment
Cleansing mode Rear cleaning/Rear massage,Front cleansing for ladies
Pressure stabilizer,Automatic pressure discharging
Over 4 M/S
Temperature sensor, Bimetallic thermostat, temperature fusec
Activated carbon or photocatalyst absorption
250W
1200W
88mm
305mm
1200W-1400W
AC 110V-120V,50/60Hz
Spray cleansing
location
Water pressure
protector
Anti-fouling
device
Safety device
Warm wind speed
Warm wind
temperature
Heating power
Safety device
Deodorization
Method
Deodorization
Cleaning
device
Drying
device
1.6/1.1GPF(6.0/4.0 L)
5 different level adjustment
Speedy water discharge device, Automatic cleansing nozzle, Anti
-syphon device, Anti-backflow device, Filter device
Temperature sensor, fail safe device, Bimetallic thermostat,
Temperature fuse, Grounding protection, Leakage protector
6 different level adjustment
6 different level adjustment
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
5
www.woodbridgebath.com
R
WOODBRIDGE
DIMENSIONS/TECHNICAL DATA
IMPORTANT INFORMATION
• Measurements are +3/8" and subject to change without noce
• Specificaons & Configuraons are subject to change without noce
• Pls measure toilet on-site before installaon
• Please note that installer(s) must be cerfy or warranty will be voided.
• Measurements herein supersede all others published prior to
purblicaon date shown below
15 3/8"
20 3/4"
22 5/8"
17 7/8"
16"
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
6
www.woodbridgebath.com
R
WOODBRIDGE
Spray nozzle
Ceramic toilet
Seat
Human body
sensing window
Bumper
Lid
Human body sensing window
Remote sensing window
Half flush button
Full flush button
Deodorization window
Remote sensing window
Main unit disassembly
button
Power indicator
Energy saving indicator
Power button
Flush button
Drying button
Front cleaning button
Nozzle baffle
Drying baffle
Rear
cleaning
Front cleaning
Water discharging
Right side
Left side
PARTS IDENTIFICATION
Rear cleaning button
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
7
www.woodbridgebath.com
R
WOODBRIDGE
Toilet drain outlet
Angle valve
1.Water supply angle valve installation
Line
Drain outlet
2.Cardboard installation
Cardboard 01
Cardboard 02
sealing flange
3.Ceramic toilet installtion
•Draw drain outlet centerline on the floor,
Install angle valve at proper position on
wall according to dimension of toilet.
•Align cardboard with the centerline of
drain outlet;
•Draw contour line according to cardboard;
•Please mark the position of floor fixing bolts.
•Install sealing flange into drain outlet，
without bolts fixation;
•Install ceramic toilet on corresponding
position according to contour line.
Warm prompt:
The toilet is heavy, and it needs to open the seat
cover to carry it by two people.
12"
15 3/4"
2 3/4"
2 3/4"
ELECTRONIC WASHLET TOILET
Installation of ceramic toilet

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
8
www.woodbridgebath.com
R
WOODBRIDGE
Note: Recommend strongly to install floor fixing
bolt!lt can make product more stable to
avoid damage of toilet or toilet or personal
injury because of shifting or turning over
by misusing(squat or stand on toilet).
4.Glass cement application
Glass Cement
angle valve
new hose
water inlet
5.Installation of hose
•Connect water inlet and angle valve by new
hose.
Note:
Please clean the drain outlet;
Please make sure ceramic toilet outlet sits
perfectly on drain outlet.
•Glue the edge of toilet bottom with glass
cement.
ELECTRONIC WASHLET TOILET

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
www.woodbridgebath.com
R
WOODBRIDGE
Previous preparateion
1.Turn on the angle valve
Check thread connection,make sure no leakage is found.
Angle valve
2.Switch the power supply
Indicator light
Electric leakage test button
Protection switch
Press
protection
switch
3.Self-inspection
3. Start function mode for normal usage.
CASE 1 CASE 2
Insert electric leakage protection plug into power socket.
Grounding pin
Grounded
outlet
NOTE: If it’s an electric leakage protection plug,press protection
switch, indicator light is on which means there is electricity.
Press electric leakage test button prior to usage,protection
switch bounces to show that protection function works normally.
1. The main unit buzzer rings first "click", power indicator (POWER) and Energy-conservation
indicator (ENERGY SAVER) flash. Power indicator lights on and Energy-conservation indicator
2.gets off to start self-inspection.
The main unit buzzer rings second "click" to indicate finish of self-inspection, power indictator
lights on, and Energy-conservation indicator keeps off.
NOTE:
If it’s not an electric leakage protection
plug, insert power plug into power
socket directly.
ELECTRONIC WASHLET TOILET
9

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
10
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
Daily maintenance
Main unit care and maintenace Spray nozzle maintenance and care
1.Shut off power supply at maintenance.
2.Turn the seat upward open,
press down the button located
on the right side of main unit and
pull out the seat.Wipe the stain
with a soft damp cloth.
3. Safety self- inspection
After cleaning, re-connect the toilet with
the power supply.
1.Nozzle self-cleaning
Press “nozzle cleaning” button and nozzle
will move forward and self-clean.
2.Spray nozzle disassemble
When the wand moves forward,the nozzle
can be disassembled to clean.
3.Use soft cloth or soft brush to clean
Do not pull or push the wand,to avoid
damage.
4.Nozzle assembly
Re-install the nozzle to the wand and press
"nozzle cleaning" button, then the nozzle will
move back to the original position.

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
11
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
1. Power failure
2.Water failure
Barrel
Operation panel
Newspaper
Electricity and water supply cut-off
•Manually press button of full/half
flush to perform the toilet flushing.
•Put around 8L water into a barrel and
flush the bowl of ceramic.
Note:Avoid water spilling from bowl.
Emergency Troubleshooting

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
12
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
2.Battery replacement
Failure of remote control
To discharge water
4.Handle the remaining water in bowl
1.Operate the panels on ebidet seat to perform.
•Press the “power” button on panel
and electricity indicator will turn off.
•Take remote control from hanger.
•Open battery cover to replace battery
and put back to hanger.
•Press the “power” button again and
electricity indicator will turn on.
Remarks:When replacing the battery,
the automatic function and
timing function will be cancelled
and need to be reset.
When the product is left unused for
long time
•Especially in winter season,the water
inside the tank should be discharged
to avoid freezing.
1.Turn off the water supply angle valve
2.Cut off the electricity
3.Discharge water
•Slightly press inward
the discharging button
to discharge water.
•It is suggested to put some
antifreeze into water inside
the bowl.
Note：Before water discharging,
the power must be cut off!

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
13
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
Power
Flush
Press "flush" button to activate full flushing.
Dry
Front
Rear
Remark:
,
1. Long press "power" button to enter standby mode; and then quick
press "power" button to restore functional mode.
2. When people sit, press "power" button to stop the function of
rear, front cleaning or drying. When no one sits, press "power"
button to switch between function mode and power save mode.
Press "dry" button, warm wind will come out. After a circle or
user leaves the seat, it will automatically stop.
Press "front cleaning" button, the water will come out to clean
the front portion of body. It will automatically stop after a circle
of cleaning. If press "stop" or "power" button when using, the
function will stop immediately.
1. Press " rear cleaning" button, the water will come out to clean
the rear portion of body. It will automatically stop after a circle
of cleaning. If press "stop" or "power" button when using, the
function will stop immediately.
2. When no one uses, press "rear cleaning" button, then the wand
will stretch out to clean the nozzle and spray lance.
1. When main unit is in functional mode, the light of Power goes on; When
in energy save function, the light of Power goes off, and energy saver
lights on; When in standby mode, both lights are off.
2. The default setting of all function is on middle level, after using controller,
shift to the level setted last time.
The illustration of main unit keys

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
14
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
Troubleshooting Guide
Problem Cause
No flushing fill valve is off
Water supply is cut off
Poor flushing Fill valve is not fully
turned on
The water is not hot
Seat temperature
is not hot
In standby mode
Solution
solve the buckling
turn on the fill valve
Connect water supply and
wait for the water
Solve the buckling
Clean the filter
Reset the water temperature
Reset the seat temperature
Shift to function mode for
3 minutes
Wind temperature
is not hot
No wind out
spray wand
cannot retracted
Spray wand
cannot stretch out
Controller cannot
display
Malfunction of
deodorization
Caution
Get stuck by impurities
Power off
Do not sit in sensing area
Reverse the polarity of
battery
User doesn't reach the
sensing area in seat
Adjust to reach the sensing area
Reload the battery
Sit right in the sensing area
Push back the wand lightly and
wait for the power
Clear away the impurities
Shift to function mode to use
dry function
Reset the wind temperature
water supply hose buckling
causes block
Water supply hose buckling
causes partial block
Turn on the fill valve fully
Filter is dirty and causes block
The water temperature is setted
on normal temperature level
The seat temperature is setted
on normal temperature level
The wind temperature is setted
on normal temperature level
In standby mode or power
save mode
Power off Push back the wand lightly and
wait for the power
Deodorization function
keeps working after user
leaves
It's a normal phenomenon if
deodorization function keeps
working after user leaves to
ensure eliminating smell entirely
If the problems cannot be solved as per above methods, please
shut-off the power, and contact service providers for maintenance.
If the leakage circuit breacker often trips off, it means the
products has electricity leakage, so please shut-off the
power, and contact service provider for maintenance.

R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
R
WOODBRIDGE
WOODBRIDGE WOODBRIDGE
WOODBRIDGE
15
www.woodbridgebath.com
R
WOODBRIDGE ELECTRONIC WASHLET TOILET
Produdct Limited Warranty
Remark.
Thank you for choosing out product. This product is warranted for one(1)year
since the purchasing date for free repair of problems arising out of defects in
workmanship while using in accordance with installation manual and usage
cations for intended purposes.
lf the product does not work properly with warranty period, please contact your
nearest service center. This certificate must be presented to obtain free service
under this warranty.
Our company reserves the rights to replace the product by other similar models.
We can serve to fix or repair the product at a reasonable service charge, after
expiration of warranty period.
Service charges shall be paid even during the warranty period, if breakage or
damage is caused by any of the following events(including but without limitation)
1. The user's negligence or mistake in operation, unreasonable repair or alteration.
2. Product are damaged by negligence or mistake during installation
3. The movement of installation location of the product.
4. Using the product outside of intended use in residential housing or commerical hotels
5. The use of non specified powersupply(voltage, rating pressure)
6. The dirt, sand and impurities that causing invalid operation.
7. Damages due to force majeure(including but not limitation to natural disaster) or
other incidents.
8. The user fails to use in compliance with the warning or caution described in the
installation manual
Please fill in date, seller correctly. lf there are some mistakes, the warranty will get invalid.
This one year warranty for free of charge of repair service is only for the items listed in the
warranty.
The purchasing dte is subject to the purchasing invoice or receipt.
Please keep this warranty and invoice/receipt available for repair or maintenance.
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help.[email protected]
Thank you for using WoodBridge products!
