woodmizer LT15 Series Manual instruction

Table of Contents Section-Page
Table of Contents SW-07doc1207091

Wood-Mizer®
Safety, Setup, Operation
& Maintenance Manual
LT15 S2-4 E11S rev. F2.00
LT15 M2-3 E11S rev. F2.00
Safety is our #1 concern! Read and understand all safety
information and instructions before operating, setting up or
maintaining this machine.
May 2005
Form #796
!

4 15doc120709
Sawmill and Customer Identification
Each Wood-Mizer LT15 sawmill is identified with a revision and VIN numbers. See the
table below for VIN description.
When you pick up your mill, you will receive a customer number. The VIN number, revi-
sion, and your customer number expedite our service to you. Please write these numbers
below so you have quick, easy access to them.
MODEL & REVISION NUMBERS DESCRIPTION
456 A 5 24 1 X S N A F9 017 F9 .01
V.I.N. DESCRIPTION
LT15
Base Model E11
Engine/Motor
A1.
Major Revision Code 00
Minor Revision
Model Type
Revision Number
Configuration
Code
Company Identification Number
456=Wood-Mizer Indiana
Weight Class; A=Under 3,000 lbs B=3,001-4,000 lbs
C=4,001-5000 lbs
Product No.; 1=LT15, 2=LT20, 4=LT40 Series,
7=LT70 Series
Length of the Trailer;
20=20 Ft., 24=24’, 35=35’
Number of axles on the trailer
Year of Manufacture;
Y=2001, Z=2002, A=2003, B=2004, C=2005, D=2006
State of Manufacture
N=Indiana, P=Poland
Month of Manufacture
A=January, B=February, C=March, etc...
Revision Level
Sequence Number
Ranging from 000-999
End of 17-Digit VIN
Revision Level (Repeated)
Two-Digit Minor Revision Level
Check Digit
Add all the number and divide by 11

15doc120709 5
If You Need To Order Parts...
From Europe call our European Headquarters and Manufacturing Facility in Kolo-Poland,
Nagorna 114 St., at [phone] or [phone]. From the continental U.S., call
our toll-free Parts hotline at 1-800-448-7881. Please have the vehicle identification num-
ber and your customer number ready when you call. Wood-Mizer will accept these meth-
ods of payment:
Visa, Mastercard, or Select Purchase
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If You Need Service...
From Europe call our European Headquarters and Manufacturing Facility in Kolo-Poland,
Nagorna 114 St. at [phone] or [phone]. From the continental U.S., call us
toll-free at 1-800-525-8100. Ask to speak with a Customer Service Representative.
Please have your vehicle identification number and your customer number ready when
you call. The Service Representative can help you with questions about alignment of your
mill, blade sharpening, or cutting a particular species of wood. He also can schedule you
for a service call.
Office Hours: All times are Eastern Standard Time. Please remember that Indiana does
not go on Daylight Savings Time in the summer.
IMPORTANT! Read the entire Operator's Manual before
operating the sawmill. Take notice of all safety warnings
throughout this manual and those posted on the machine.
Keep this manual with this machine at all times, regardless
of ownership.
Customer No. Model Type VIN No. Revision Number
Country Monday - Friday Saturday Sunday
U.S., Indiana 8 a.m. to 5 p.m. 8 a.m. to 4 p.m. Closed
Poland 8 a.m. to 4:30 p.m. 8 a.m. to 1 p.m. Closed
!

6 15doc120709

15doc120709 1
SECTION 1 SAFETY & GENERAL INFORMATION 1-1
1.2 Blade Handling.......................................................................................................... 1-1
1.3 Sawmill Setup............................................................................................................1-2
1.4 Sawmill Operation.....................................................................................................1-2
1.5 Sawmill Maintenance................................................................................................ 1-3
1.6 Belt Sizes...................................................................................................................1-7
1.7 Blade Sizes ................................................................................................................ 1-8
1.8 Cutting Capacity........................................................................................................ 1-8
1.9 Engine/Motor Specifications.....................................................................................1-9
1.10 Noise level.................................................................................................................1-9
1.12 Overall Dimensions.................................................................................................1-11
1.13 Components.............................................................................................................1-12
SECTION 2 SAWMILL ASSEMBLY 2-1
2.1 Mounting Parts of LT15 Sawmills with Electric Motors.......................................... 2-1
2.2 Unpacking the Sawmill .............................................................................................2-7
2.3 Bed Frame Assembly ................................................................................................ 2-9
2.4 Frame Leg Adjustment............................................................................................2-15
2.5 Saw Head Assembly................................................................................................2-16
2.6 Manual Feed Rope Assembly..................................................................................2-21
2.7 Power Feed Rope Assembly....................................................................................2-24
2.8 Auxiliary Bed Rail...................................................................................................2-25
SECTION 3 SETUP & OPERATION 3-1
3.1 Sawmill Setup............................................................................................................3-1
3.2 Replacing The Blade ...............................................................................................3-10
3.3 Tensioning The Blade..............................................................................................3-11
3.4 Tracking The Blade.................................................................................................3-12
3.5 Starting The Motor..................................................................................................3-13
3.6 Loading, Turning, And Clamping Logs.................................................................. 3-14
3.7 Up/Down Operation ................................................................................................ 3-17
3.8 Blade Guide Arm Operation....................................................................................3-18
3.9 Blade Drive Operation.............................................................................................3-19
3.10 Feed Operation ........................................................................................................3-20
3.11 Cutting The Log ......................................................................................................3-22
3.12 Edging......................................................................................................................3-23
3.13 Blade Height Scale..................................................................................................3-23
3.14 Water Lube Operation.............................................................................................3-25
3.15 Transporting the Sawmill........................................................................................3-28
SECTION 4 MAINTENANCE 6-1
4.1 Wear Life...................................................................................................................6-1
4.2 Sawdust Removal...................................................................................................... 6-1
4.3 Carriage Track & Rollers .......................................................................................... 6-2
4.4 Vertical Mast Rails.................................................................................................... 6-2
4.5 Miscellaneous Lubrication ........................................................................................6-3
4.6 Blade Wheel Belts..................................................................................................... 6-4
4.7 Up/Down System.......................................................................................................6-4
4.8 Miscellaneous Maintenance ......................................................................................6-7

2 15doc120709
SECTION 5 TROUBLESHOOTING GUIDE 7-1
5.1 Sawing Problems....................................................................................................... 7-1
SECTION 6 ALIGNMENT 8-1
6.1 Pre-Alignment Procedures......................................................................................... 8-1
6.2 Preparing The Sawmill For Alignment ..................................................................... 8-1
6.3 Blade Installation and Alignment.............................................................................. 8-1
6.4 Blade Wheel Alignment ............................................................................................ 8-2
6.5 Blade Guide Arm Alignment.....................................................................................8-6
6.6 Aligning The Blade Guides.......................................................................................8-7
6.7 Blade Deflection........................................................................................................ 8-8
6.8 Blade Guide Vertical Tilt Adjustment.......................................................................8-9
6.9 Blade Guide Spacing...............................................................................................8-10
6.10 Horizontal Tilt Adjustment......................................................................................8-11
6.11 Side Supports...........................................................................................................8-12
6.12 Blade Height Scale Adjustment...............................................................................8-13
6.13 Motor Drive Belt Adjustment..................................................................................8-14

Safety & General Information
Blade Handling
Safety & General Information 15doc120709 1-1
1
SECTION 1 SAFETY & GENERAL INFORMATION
1.1 Safety Symbols
This symbol calls your attention to instructions concerning your personal safety. Be sure to observe and
follow these instructions. This symbol accompanies a signal word. The word DANGER indicates an
imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING
suggests a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION refers to potentially hazardous situations which, if not avoided, may result in minor or moderate
injury to persons or equipment. Read all safety instructions before operating this equipment and observe all
safety warnings!
Warning stripes are placed on areas where a single decal would be insufficient. To avoid serious injury, keep
out of the path of any equipment marked with warning stripes.
Read and observe all safety instructions before operating this equipment! Also read any additional
manufacturer’s manuals and observe any applicable safety instructions including dangers, warnings, and
cautions.
Always be sure that all safety decals are clean and readable. Replace all damaged safety decals to prevent
personal injury or damage to the equipment. Contact your local distributor, or call your Customer Service
Representative to order more decals.
IMPORTANT! It is always the owner's responsibility to comply with all applicable federal, state and local
laws, rules and regulations regarding the ownership and operation of your Wood-Mizer sawmill. All
Wood-Mizer mill owners are encouraged to become thoroughly familiar with these applicable laws and
comply with them fully while using the mill.
Always properly dispose of all sawing by-products, including sawdust and other debris, coolant, oil, oil filters
and fuel filters.
Safety instructions are listed in this section by the following operations:
Blade Handling
Sawmill Setup
Sawmill Operation
Sawmill Maintenance
1.2 Blade Handling
DANGER! Always disengage the blade and shut off the sawmill engine
before changing the blade. Failure to do so will result in serious injury.
WARNING! Always wear gloves and eye protection when handling
bandsaw blades. Changing blades is safest when done by one person!
Keep all other persons away from area when coiling, carrying or changing a
blade. Failure to do so may result in serious injury.

Safety & General Information
Sawmill Setup
1
1-2 15doc120709 Safety & General Information
1.3 Sawmill Setup
WARNING! Do not set up the mill on ground with more than a 10 degree
incline. If setup on an incline is necessary, put blocks under one side of the
mill or dig out areas for the legs to keep mill level. Setting up the mill on an
incline could cause it to tip over, resulting in serious personal injury.
WARNING! Keep all persons out of the path of the saw head while loading
and unloading the sawmill. Failure to do so may result in serious injury or
death.
1.4 Sawmill Operation
DANGER! Make sure all guards and covers are in place and secured
before operating or towing the sawmill. Failure to do so may result in
serious injury.
DANGER! Be sure the blade housing and pulley covers are in place and
secured.
DANGER! Always keep hands away from moving bandsaw blade. Failure
to do so will result in serious injury.
DANGER! Keep all persons out of the path of moving equipment and logs
when operating sawmill or loading and turning logs. Failure to do so will
result in serious injury.
DANGER! Maintain a clean and clear path for all necessary movement
around the mill and lumber stacking areas. Failure to do so will result in
serious injury.
DANGER! Always be sure the blade is disengaged and all persons are out
of the path of the blade before starting the engine or motor. Failure to do so
will result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot protection when
operating the sawmill. Failure to do so may result in serious injury.
WARNING! Secure all loose clothing and jewelry before operating the
sawmill. Failure to do so may result in serious injury or death.
WARNING! Always make sure log is clamped securely before sawing.
Failure to do so may result in serious injury or death.
WARNING! Use ONLY water or alcohol solution with the water lube
accessory. Never use flammable fuels or liquids. If these types of liquids are
necessary to clean the blade, remove it and clean with a rag. Failure to do
so may result in serious injury or death.
CAUTION! Be sure the log clamps are all the way down before loading a
log onto the bed. Failure to do so may result in machine damage.
CAUTION! Before loading a log, be sure the cutting head is moved far
enough forward so the log does not hit it. Failure to do so may result in

Safety & General Information
Sawmill Maintenance
Safety & General Information 15doc120709 1-3
1
machine damage.
CAUTION! Do not try to force the saw head beyond its upper and lower
travel limits. Damage to the up/down system may result.
CAUTION! Be sure to stop the blade when returning the carriage. This will
not only prevent the blade from being pulled off and ruined by a wood sliver,
but also will increase the life of the blade.
CAUTION! The saw head will hit the spring-loaded ramp stops when
adjusted for low cuts. Remove the loading ramps before sawing to prevent
damage to the saw head and/or blade guide arm.
CAUTION! The sawmill’s work-stand should be equipped with a 4 kg or
bigger dry powder extinguisher.
1.5 Sawmill Maintenance
CAUTION! The up/down screw bellows should completely cover the
screw. If either of the bellows is damaged, replace it immediately. Before
installing the new bellows, clean the up/down screw and nut thoroughly with
extraction naphtha and then grease them.
CAUTION! Reinstall the track wiper so that it lightly touches the track bar.
If the wiper presses too firmly against the bar, it can cause the power feed
to bind.
CAUTION! Never use grease on the mast rails as it will collect sawdust.
See Table 1-1. Pictogram decals used to warn and inform the user about danger in the LT15.
TABLE 1-1
Decal View W-M No. Description
096317 CAUTION! Read thoroughly the manual
before operating the machine. Observe all
safety instructions and rules when
operating the sawmill.

Safety & General Information
Sawmill Maintenance
1
1-4 15doc120709 Safety & General Information
099220 CAUTION! Close all guards and covers
before starting the machine.
099219 Blade tension. Turning the bolt clockwise
will increase the blade tension and turning
the bolt counterclockwise will decrease the
tension.
099221 CAUTION! Keep all persons a safe
distance away from work area when
operating the machine.
098176 CAUTION! Keep away from debarker
blade!
TABLE 1-1
099220
099219
+
099221
098176

Safety & General Information
Sawmill Maintenance
Safety & General Information 15doc120709 1-5
1
096316 CAUTION! Do not open or close the
electric box when the switch is not in the
“0” position.
096319 CAUTION! Disconnect power supply
before opening the box.
096321 Blade movement direction
S12004G CAUTION! Always wear safety goggles
when operating the sawmill!
TABLE 1-1

Safety & General Information
Sawmill Maintenance
1
1-6 15doc120709 Safety & General Information
S12005G CAUTION! Always wear protective ear
muffs when operating the sawmill!
501465 CAUTION! Always wear safety boots when
operating the sawmill
501467 Lubrication Point
P11789 Aligning the blade on the wheels
092597 Setting the blade tension indicator
P85070 CE safety certification
TABLE 1-1
092597

Safety & General Information
Belt Sizes
Safety & General Information 15doc120709 1-7
1
1.6 Belt Sizes
See Table 1-2. Belt sizes for the LT15 are shown.
099401 Russian safety certification
S20097F 2925 RPM - Motor rotation direction
100582 a. Debarker On/Off (option)
b. Starting motor
c. Debarker In/Out (option)
P85066 Blade positioning
Description Belt Size Wood-Mizer
Part #
Motor Drive Belt (E11) B81 014819
Up/Down Drive Belt AVX13x1030 094253
Blade Pulley Belts B57 1
1 To insure proper blade tracking, use Goodyear, Dayco Super II, or
Browning belts only.
P04185
TABLE 1-2
TABLE 1-1
099401
S20097F
2925 RPM
10058
2
I0 I0
abc
P85066
3-4 mm

Safety & General Information
Blade Sizes
1
1-8 15doc120709 Safety & General Information
1.7 Blade Sizes
See Table 1-3. Wood-Mizer TRU•SHARP™ offers three types of blades to provide efficient sawing for all
models of sawmills. The engine/motor size of your sawmill and the type of wood you saw should determine
which blade you choose for optimum performance.
See The Blade Handbook for blade hook angle, tooth height, and tooth set specifications.
1.8 Cutting Capacity
See Table 1-4. The log size capacities of the LT15 sawmills are listed below.
See Table 1-5. The performance capacity of the LT15 sawmill is listed below. Peak cutting rates are
measured in 12” (30 cm) wide red oak and represent the capability of the sawmill only. Rates based on using
Tru-Sharp 1 1/4” x .042 blades.
Engine/Motor Size Recommended Blade For Sawing:
Softwood Hardwood Frozen or Hard-to-Cut
Wood
5 hp - 15hp B275IH1030
B275IH741030
B375IH929 B375IH929 1
1 TRU•SHARP™ “F” blades use a 9/29 profile (9° hook angle and 29° back angle) and are de-
signed to cut frozen and/or extremely dense, hard-to-cut wood. Standard TRU•SHARP™
blades use a 10/30 profile.
16hp or more B376IH1030
B376IH741030
B275IH1030
B275IH741030
B376IH1030
B376IH741030 2
2 Customer may choose preferred blade.
B375IH929 1
Electric Motor B376IH1030
B376IH741030
B275IH1030
B275IH741030
B376IH1030
B376IH741030 2
B375IH929 1
TABLE 1-3
Max.
Diameter Max.
Length 1
1 Each additional bed frame segment adds approximately 195
cm ( 6’ 5” ) to length capacity.
LT15 S3 71 cm 5,4 m
LT15 S2 71 cm 3,5 m
LT15 M2 71 cm 5,2 m
LT15 M3 71 cm 7,9 m
TABLE 1-4
Model Cutting Rate
LT15 E11, G13, D10 16 ft. (3.3 m)/min.
TABLE 1-5

Safety & General Information
Engine/Motor Specifications
Safety & General Information 15doc120709 1-9
1
1.9 Engine/Motor Specifications
See Table 1-6. The power options available for the LT15 sawmills are listed below.
See Table 1-7. See the table below for power supply specifications for the LT15 sawmill.
DANGER! It is recommended to use 30mA GFI (Ground Fault Interrupter).
1.10 Noise level
See Table 1-8. The average level of noise is given in the table below12.
1.11 Dust Extractor Specifications
See Table 1-9. See the table below for dust extractor specifications.
Engine/Motor Type Manufacturer Model No. Specifications
7.5 kW Motor Siemens, Germany 1LE1002 1CA13-4AA4-Z
F01+F12
3 x 400V, 50 Hz
13HP Gasoline Kohler CH13T Spec #PA22519 398 cm3
10HP Diesel Yanmar, Japan L100 406 cm3, 3600 min-1
Up/Down Motor
0.55kW
Besel SKh71X-4C2/HPS08 3x 230/400VAC, 50Hz
Power Feed Motor
0.55kW
Dutchi Motors,
Holland
DMA 80K4 230/400V, 50 Hz
TABLE 1-6
3-Phase V Switch, Fuse Recommendedwire
section
400 VAC 16 A 2,5 mm2
to 15m length
TABLE 1-7
Sawmill Noise level
LT15E11 LEX8 = 81,9 dB (A)
TABLE 1-8
1. The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard . The noise
exposure level given above concerns an 8-hour work day.
2. The measured values refer to emission levels, not necessarily to noise levels in the workplace. Although
there is a relation between emission levels and exposure levels, it is not possible to determine with certainty
if preventives are needed or are not needed. The factors affecting a current level of noise exposure during
work are inter alia room characteristics and characteristics of other noise sources, e.g. number of machines
and machining operations nearby. Also, the permissible exposure level value may vary depending on
country. This information enables the machine’s user to better identify hazards and a risk .

Safety & General Information
Noise level
1
1-10 15doc120709 Safety & General Information
Airflow 1200 m3/h
Inlet diameter 150 mm
Motor power 1.5 kW
Number of sacks for waste 1 pcs
Total capacity of sacks 0.25 m3
Weight 110 kg
Conveying speed when 10 m
long hose is used 20 m/s
TABLE 1-9

Safety & General Information
Overall Dimensions
Safety & General Information 15doc120709 1-11
1
1.12 Overall Dimensions
See Figure 1-1. The overall dimensions of the LT15 sawmills are shown below.
FIG. 1-1

Safety & General Information
Components
1
1-12 15doc120709 Safety & General Information
1.13 Components
See Figure 1-2. The major components of the Wood-Mizer LT15 are shown below.
See Figure 1-3. The picture below shows the operator’s position.
FIG. 1-2
FIG. 1-3
Water Tank
Sawmill Mast
Saw Head
Blade Tension Handle
Blade Drive Motor
Blade Guide
Arm Handle
Blade Guide
Electric Box
Operator Box
Feed Crank Handle
Sawmill Frame
Up/Down Drive
Assembly
Log Clamp
