OWNER’S/
OPERATOR’S
MANUAL
MODEL NO.’s
FLGR-262
SSGR-262
FLGR-277
SSGR-277
SSGR-84
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SI NO LEEINGLES, PIDA AYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
CAUTION
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator’s
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator’s manual.
8. Before operating, read the maintenance section of your
operator’s manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
Grapple Rake for
Skid Steer and
Tractor Front Loader
Safety Instructions Assembly & Mounting
Tractor Preparation Maintenance
Operating Instructions Repair Parts

1
SI NO LEEINGLES, PIDA AYUDA A
AIGUIEN QUE SI LO LEA PARA QUE
LE TRADUZCA LAS MEDIDAS DE
SEGURIDAD.
STATEMENT
OF POLICY
It is the policy of Worksaver,
Inc. to improve its products where
it is possible and practical to do
so. Worksaver, Inc. reserves the
right to make changes or
improvements in design and con-
struction at any time, without
incurring the obligation to make
these changes on previously
manufactured units.
TABLE OF CONTENTS
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
SAFETY SIGNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PREPARATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . 12-14
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . 15-16
OWNER MAINTENANCE & LUBRICATION . . . . . . . . . . . . 17
TROUBLE-SHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . 18-19
PARTS LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-26
TO THE OWNER:
Read this manual before using your Grapple Rake. This manual is provided to give you the necessary operat-
ing and maintenance instructions for keeping your Grapple Rake in top operating condition. Please read this
manual thoroughly. Understand what each control is for and how to use it. Observe all safety signs on the machine
and noted throughout the manual for safe operation of implement. Keep this manual handy for ready reference.
Like all mechanical products, it will require cleaning and upkeep.
Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet
standards required for safe and satisfactory operation. Record the model and serial number of your Grapple Rake
here:
Model:________________________________________ Serial Number:_______________________________
RETAIL CUSTOMER’S RESPONSIBILITY
It is the Retail Customer and/or Operator’s responsibility to read the Operator’s Manual, to operate, lubri-
cate, maintain, and store the product in accordance with all instructions and safety procedures. Failure
of the operator to read the Operator’s Manual is a misuse of this equipment.
It is the Retail Customer and/or Operator’s responsibility to inspect the product and to have any part(s)
repaired or replaced when continued operation would cause damage or excessive wear to other parts or
cause a safety hazard.
It is the Retail Customer’s responsibility to deliver the product to the authorized Worksaver Dealer, from
whom he purchased it, for service or replacement of defective parts which are covered by warranty.
Repairs to be submitted for warranty consideration must be made within forty-five (45) days of failure.
It is the Retail Customer’s responsibility for any cost incurred by the Dealer for traveling to or hauling
of the product for the purpose of performing a warranty obligation or inspection.

2
LIMITED WARRANTY
Worksaver warrants to the original purchaser of any new Grapple Rake (Models FLGR-262, FLGR-277,
SSGR-262, SSGR-277, and SSGR-84), that the equipment be free from defects in material and workmanship
for a period of one (1) year for non-commercial, state, and municipalities. Use sixty (60) days for commercial
use from date of retail sale.
Replacement or repair parts installed in the equipment covered by this warranty are warranted for sixty (60)
days from the date of purchase of such part or to the expiration of the applicable new equipment warranty
period, whichever occurs later.
Such parts shall be provided at no cost to the user during regular working hours. Worksaver reserves the right
to inspect any equipment or parts which are claimed to have been defective in material or workmanship.
DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES
Worksaver’s obligation under this warranty, to the extent allowed by law, is in lieu of all warranties, implied or
expressed, including implied warranties of merchantability and fitness for a particular purpose and any liabili-
ty for incidental and consequential damages with respect to the sale or use of the items warranted. Such
incidental and consequential damages shall include but not be limited to: transportation charges other than
normal freight charges; cost of installation other than cost approved by Worksaver; duty; taxes; charges for
normal service or adjustments; loss of crops or any other loss of income; rental of substitute equipment,
expenses due to loss, damage, detention or delay in the delivery of equipment or parts resulting from acts
beyond the control of Worksaver.
THIS WARRANTY SHALL NOT APPLY:
1. To vendor items which carry their own warranties, such as hydraulic cylinders, tires, and tubes.
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident.
3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge-
ment of Worksaver such use affects its performance, stability, or reliability.
4. If the unit has been altered or repaired outside of an authorized Worksaver dealership in a manner which,
in the sole judgement of Worksaver affects its performance, stability or reliability.
5. To normal maintenance service and normal replacement items such as gearbox lubricant, hydraulic fluid,
worn teeth, or to normal deterioration of such things as belts and exterior finish, due to use or exposure.
6. To expendable or wear items such as teeth, chains, sprockets, belts, springs and other items that in the
company’s sole judgement is a wear item.
NO EMPLOYEE OR REPRESENTATIVE OF WORKSAVER IS AUTHORIZED TO CHANGE THIS WARRANTY IN
ANY WAY OR GRANT ANY OTHER WARRANTY UNLESS SUCH CHANGE IS MADE IN WRITING AND SIGNED
BY WORKSAVER’S SERVICE MANAGER, POST OFFICE BOX 100, LITCHFIELD, ILLINOIS 62056-0100.

3
To the Owner/Operator/Dealer
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera-
tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this
implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!!
Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
THIS SAFETY ALERT SYMBOL IDENTIFIES IMPORTANT
SAFETY WARNING MESSAGES. CAREFULLY READ EACH
WARNING MESSAGE THAT FOLLOWS. FAILURE TO
UNDERSTAND AND OBEY A SAFETY WARNING, OR
RECOGNIZE A SAFETY HAZARD, COULD RESULT IN AN
INJURY OR DEATH TO YOU OR OTHERS AROUND YOU.
THE OPERATOR IS ULTIMATELY RESPONSIBLE FOR THE
SAFETY OF HIMSELF, AS WELL AS OTHERS, IN THE
OPERATING AREA OF THE TRACTOR AND ATTACHED
EQUIPMENT.
IMPORTANT SAFETY INFORMATION!
Working with equipment can lead to injuries. Read this manual, and the manual for your tractor, before assembly or
operating, to acquaint yourself with the machines. It is the implement owner’s responsibility, if this machine is used by
any person other than yourself, is loaned or rented, to make certain that the operator, prior to operating:
1. Reads and understands the operator’s manuals.
2. Is instructed in safe and proper use.
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design. All operators of this equipment must read and understand this entire manual, pay-
ing particular attention to safety and operating instructions, prior to using. If there is something in this manu-
al you do not understand, ask your supervisor, or your dealer, to explain it to you.
THIS SYMBOL MEANS
– ATTENTION!
– BECOME ALERT!
– YOUR SAFETY IS INVOLVED!
UNDERSTAND SIGNAL WORDS
Indicates an imminently hazardous situation that, if not avoided, WILL result in
DEATH OR VERY SERIOUS INJURY.
Indicates a imminently hazardous situation that, if not avoided, COULD result in
DEATH OR SERIOUS INJURY.
Indicates a imminently hazardous situation that, if not avoided, MAY result in
MINOR INJURY.
Identifies special instructions or procedures that, if not strictly observed, could
result in damage to, or destruction of the machine, attachments or the environment.
NOTE: Identifies points of particular interest for more efficient and convenient operation or repair.
If you have questions not answered in this manual or require additional copies or the manual is damaged, please
contact your dealer or the manufacturer directly.
WARNING
DANGER
CAUTION
IMPORTANT

4
SAFETY INSTRUCTIONS (continued)
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment.
Designers and manufacturers build in as many safety features as possible. However, every year many
accidents occur which could have been avoided by a few seconds of thought and a more careful approach to
handling equipment.You, the operator, can avoid many accidents by observing the following precautions in this
section. To avoid personal injury, study the following precautions and insist those working with you, or for you,
follow them.
In order to provide a better view, certain photographs or illustrations in this manual may show an assembly with
a safety shield removed. However, equipment should never be operated in this condition. Keep all shields in
place. If shield removal becomes necessary for repairs, replace the shield prior to use.
To prevent injury or death, use a tractor equipped with a Roll-Over Protective System (ROPS). Do not paint
over, remove or deface any safety signs or warning signs on your equipment. Observe all safety signs and
practice the instruction on them.
Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question - DON’T
TRY IT.
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety and
could affect the life of the equipment.
In addition to the design and configuration of this implement, including Safety Signs and Safety Equipment,
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also
to Safety Messages and Operation Instructions in each of the appropriate sections of the Tractor, Skid Steer,
and Implement Manuals. Pay close attention to the Safety Signs affixed to the Tractor, Skid Steer, and the
Implement.
Replace any CAUTION, WARNING, DANGER or instruction safety sign that is not readable or is missing.
Location of such safety signs is indicated in this booklet.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this
equipment. Consult your doctor about operating this machine while taking prescription medications.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator should be a
responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not allow per-
sons to operate or assemble this unit until they have read this manual and have developed a thorough
understanding of the safety precautions and of how it works.
EQUIPMENT SAFETY GUIDELINES

5
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY
Be sure power unit is in good condition. Read all the safety precautions and make sure all operators are famil-
iar with the safety rules of operation.
Never leave the power unit and implement unattended while the implement is in the lifted position. Accidental
operation of lifting lever or a hydraulic failure may cause sudden drop of unit with injury or death by crushing.
Keep all helpers and bystanders fifty feet (50’) from an operating power unit and attached equipment. Only
properly trained people should operate this machine. It is recommended the tractor be equipped with a
Rollover Protection System (ROPS) and a seat belt that is used. Always stop the tractor, or skid steer, set
brake, shut off the engine, remove the ignition key, and lower loader and attachment to the ground before dis-
mounting. Relieve all hydraulic pressure. Never leave equipment unattended with the engine running.
Please remember it is important that you read and heed the safety signs on the front loader attachment and
loader, and the safety rules set forth. Clean or replace all safety signs if they cannot be clearly read and under-
stood. They are there for your safety as well as the safety of others. The safe use of this machine is strictly
up to you, the operator.
The use of any loader attachment is NOT recommended on tractor with a tricycle wheel arrangement. Tricycle
type tractors are unstable for front loader use.
A heavy load can cause instability in driving a power unit. Make sure the front or rear of the power unit is
properly counter-balanced with weights. Always drive slowly – especially around turns. An unstable power unit
could steer badly and possibly tip over, causing injury or death.
Never allow children to play on or around power unit or implement. Children can slip or fall off the equipment
and be injured or killed. Inadvertent contact with controls can cause the implement to shift or fall crushing them-
selves or others.
Never place any part of your body where it would be in danger if movement should occur during assembly,
installation, operation, maintaining, repairing, removal, or moving the implement.
Start power unit only when properly seated in the operator’s seat. Starting a power unit in gear can result in
injury or death. Do not mount or dismount while the power unit is moving. Mount or dismount only when the
power unit and all moving parts are completely stopped.
Operate the power unit and/or implement controls only while properly seated in the operator’s seat with the
seat belt securely fastened around you. Inadvertent movement of the power unit or implement may cause seri-
ous injury or death.
Do not allow others to ride on the power unit with an operator. Riders are subject to injury such as being struck
by foreign objects or being thrown off. Riders obstruct the operator’s view resulting in unsafe operation. Never
allow anyone to ride on the implement!
Know your controls and how to stop the power unit and engine quickly in an emergency. READ THIS MANU-
AL AND THE ONE PROVIDED WITH YOUR TRACTOR AND LOADER, OR SKID STEER.

6
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY (continued)
For operator safety, always keep load in front of power unit. NEVER position load back over operator. ALWAYS
BE CAREFUL!
Keep alert and watch the rear as well as the front when working with the loader. Beware of lift clearance when
raising loader to maximum height.
Beware of low electrical wires when loader is raised. Serious injury or death can result if contact is made.
Before you operate any equipment, check over all pins, bolts and connections to be sure all are securely in
place. Replace any damaged or worn parts immediately.
Check that this attachment is securely mounted to the loader. Failure to install lock pins or have the latching
mechanism engaged could result in injury or death.
Do not work under a raised loader unless it is securely blocked or held in position. Do not depend on the power
unit hydraulic system to hold the implement in place.
Operate the loader controls smoothly, avoiding jerky operation. Stop loader gradually when lowering or lifting
loads.
When handling material on a slope, always approach the material with the power unit facing uphill.
Only use a power unit equipped with a ROPS cab or rollover protective structure. Keep foldable ROPS sys-
tems in “locked up” position at all times. Keep seat belt fastened.
When stacking logs or stumps, ALWAYS MAKE SURE MATERIAL IS PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER FALLING LOGS OR STUMPS CAN ROLL OR TUMBLE.
Do not handle loads that exceed the weight limitations of the loader.
Carry the loads slowly and as low as possible to the ground. Avoid excessive speed during operation.

7
SAFETY INSTRUCTIONS (continued)
When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance
for the power unit, loader, and load. Drive slowly.
Operate loader from operator’s seat only. Remain at controls until operating cycle is complete.
Use extreme care when working on inclines and hillsides.
Do not operate close to ditches, creeks or holes. Slow down when operating over rough ground.
Allow for additional length of loader and load on power unit while turning.
Keep load centered on Grapple Rake and loader. Unbalanced loads increase possibility of tipping or roll-over.
When handling brush or branches, be aware of branches that might contact power unit or operator.
When cleaning up old building sites, check for live utility lines. Always be sure electric, gas, and water lines
have been properly disconnected.
Check material to be handled, especially at old building sites or dumps. Be alert for any hazardous material
that could be released by Grapple Rake contact. If in doubt, check with professional waste haulers.
Do not lift or carry anyone on loader or in bucket or on attachment.
ALWAYS lower loader to the ground or block securely before performing any maintenance work.
Always keep power unit on solid footing when operating loader.
Observe Safety Recommendations in loader instruction manual.
Inspect the entire machine periodically as indicated in the Maintenance Section of this manual. Look for loose
fasteners, worn or broken parts, pinched hydraulic hoses, and leaky or loose fittings. Make sure all pins have
cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
OPERATIONAL SAFETY (continued)

8
SAFETY INSTRUCTIONS (continued)
Comply with state and local laws governing highway safety and movement of farm machinery on public roads.
The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use.
Local laws should be checked for all highway lighting and marking requirements.
When driving the power unit and equipment on the road or highway under 20 mph (32 kph) at night or during
the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Always be sure the implement is in the proper raised position for transport.
Reduce speed when transporting mounted implements to avoid bouncing and momentary loss of steering
control.
Plan your route to avoid heavy traffic.
Always install transport locks, pins or brackets before transporting.
Do not drink and drive!
Watch for traffic when operating near or crossing roadways.
Turn curves or go up or down hills only at a low speed and at a gradual steering angle. Make certain that at
least 20% of the tractor’s weight is on the front wheels to maintain safe steerage. Slow down on rough or
uneven surfaces, and loose gravel.
Use extreme care and maintain minimum ground speed when transporting on hillside, over rough ground and
when operating close to ditches or fences. Be careful when turning sharp corners.
Never allow riders on either power unit or implement. Falling off can kill.
Be a safe and courteous driver. Always yield to oncoming traffic in all situations, including narrow bridges, inter-
sections, etc.
Do not exceed 20 mph (32 kph). Reduce speed on rough roads and surfaces.
TRANSPORT SAFETY

9
SAFETY INSTRUCTIONS (continued)
Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if
working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the
brakes, and remove the ignition keys.
Be certain all moving parts on attachments have come to a complete stop before attempting to perform
maintenance.
Never work under equipment unless it is blocked securely. Never depend on hydraulic system to keep imple-
ment in raised position.
Always use personal protection devices such as eye, hand and hearing protectors, when performing any
service or maintenance.
Keep all persons away from operator control area while performing adjustments, service, or maintenance.
Periodically tighten all bolts, nuts and screws and check that all cotter pins are properly installed to ensure unit
is in a safe condition.
When completing a maintenance or service function, make sure all safety shields and devices are installed
before placing unit in service.
Openings in the skin and minor cuts are susceptible to infection from hydraulic fluid. If injured by escaping
hydraulic fluid, see a doctor at once. Gangrene and death can result. Without immediate medical treatment,
serious infection and reactions can occur.
MAINTENANCE SAFETY
Check to ensure all safety signs are installed and in good condition.
Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement
parts must be used to restore your equipment to original specifications.The manufacturer will not claim respon-
sibility for use of unapproved parts and/or accessories and other damages as a result of their use.
If equipment has been altered in any way from original design, the manufacturer does not accept any liability
for injury or warranty.

10
SAFETY INSTRUCTIONS (continued)
Following operation, or when unhooking, stop the tractor, set the brakes, disengage the PTO, relieve all
hydraulic pressure, shut off the engine and remove the ignition keys.
Hoses for the attachment must be disconnected before the quick attach is disengaged. Pulling the attachment
with the hoses could result in damage to the prime mover or the attachment.
STORAGE SAFETY
Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock
injury could result.
Store the unit in an area away from human activity. Do not permit children to play on or around the stored unit.
Make sure all parked machines are on a hard, level surface and engage all safety devices. Storage location
should be level and solid to make connecting and unconnecting to power unit easy.
Use extreme care to keep feet and hands from under the unit and clear of any pinch points. Never stand or
allow another person to stand between a running power unit and the unit when disconnecting the implement.
Keep safety signs clean and legible at all times.
Replace safety signs that are missing or have become illegible.
Replaced parts that displayed a safety sign should also display the current sign.
Safety signs are available from your Distributor or Dealer Parts Department or the factory.
Be sure that the installation area is clean and dry. Be sure temperature is above 50°F (10°C).
Decide on the exact position before you remove the backing paper.
Remove the smallest portion of the split backing paper. Align the sign over the specified area and carefully
press the small portion with the exposed sticky backing in place.
Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign in place. Small
air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper.
How to Install Safety Signs:
SAFETY SIGNS

11
SAFETY SIGNS
REMEMBER:
If Safety Signs have been
damaged, removed, become
illegible or parts replaced with-
out Signs, new Safety Signs
must be applied. New Safety
Signs are available from your
authorized distributor or factory.
BE CAREFUL! Use a clean, damp cloth to clean safety decals. Avoid spraying to close to decals when
using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals caus-
ing them to peel or come off.

12
TRACTOR AND SKID STEER
REQUIREMENTS AND
PREPARATION
The Grapple Rake is designed to handle logs, brush,
loose stumps, limbs, medium size rocks, and other hard
to handle materials.
Two 2” bore x 10” stroke hydraulic cylinders operate the
grapple clamps to grip and hold the material.
The Grapple Rake is available in five models.
The models FLGR-262 and FLGR-277 are designed to
mount on farm tractor front-end loaders. Optional
brackets are available to fit most popular quick coupler
front-end loaders or pin on type loaders.
One pair of remote hydraulic coupler outlets are
required to operate the grapple clamp cylinders.
The model FLGR-262 Grapple Rake is recommended
for tractors with a PTO horsepower rating of 45-110 hp.
The model FLGR-277 Grapple Rake is recommended for
tractors with a PTO horsepower rating of 60-150 hp.
The models SSGR-262 and SSGR-277 Grapple Rakes
are designed to mount on skid steer units equipped with
the universal quick-attach attachment connection.
The model SSGR-84 is designed for skid steer units
with a door on the cab. Lower height of this grapple
allows the door to open without interference with the
grapple.
Skid steer units need to have sufficient lift capacity to
handle the expected load and the weight of the Grapple
Rake.
INSTRUCTIONS
ASSEMBLY
This unit is shipped almost completely assembled.
Refer to the “exploded views” on pages 20-26 of this
manual.
Carefully follow instructions for final assembly.
Before attempting assembly check the following items.
Having all the needed parts and equipment readily at
hand will speed up your assembly task and will make the
job as safe as possible.
• Check for fasteners and pins that were shipped with
the Grapple Rake.
• Have a fork lift or loader along with chains and safety
stands that are sized for the job ready for the assem-
bly task.
• Have a minimum of 2 people at hand during assembly.
• Check to see that all hardware is tightened.
ASSEMBLY – TRACTOR LOADERS
PIN ON ATTACHMENT
Assemble the two (2) lift brackets on the main frame
(Ref. #1) with the 5/8” x 3” I.D. U-bolts. Leave the U-bolts
loose.
Be sure your tractor and loader, or skid steer is in
good condition. Read all the safety precautions and
make sure all equipment operators are familiar with
the safety rules of operation.
A heavy load can cause instability in driving a
power unit. Make sure the rear of the tractor is
properly counterbalanced with weights. Always drive
slowly – especially around turns. An unstable power
unit could steer badly and possibly tip over, causing
injury or death.
The operator is responsible for the safe operation of this
equipment. The operator must be properly trained.
Operators should be familiar with the tractor, loader and
loader attachment, and all safety practices before start-
ing operation. Read the safety rules and safety signs on
pages 3-11.
Remove the bucket from your front end loader or skid
steer. Check your loader to make sure it is in good work-
ing order. Check all frame mounting bolts to make sure
they are tight.
Loaders that attach to the tractor frame rails should
have a cross-tie installed for stability.
Check the power unit’s hydraulic system. Be sure the
hydraulic oil and filter have been serviced according to
manufacturer’s recommendations. Refer to your tractor or
loader operator’s manual or dealer for any adjustments
necessary to put the hydraulic system in good working
order.
■Power unit must be equipped with ROPS or ROPS
cab and seat belt. Keep seat belt securely fastened.
Falling off power unit can result in death from being
run over or crushed. Keep foldable ROPS systems in
“locked up” position at all times.
An optional parking stand kit (#811395) is available.
(See page 20.)
WARNING
WARNING
CAUTION

13
INSTRUCTIONS (continued)
NOTE: The lift channel brackets are supplied with 1”
diameter pins to fit your loader. If your loader requires
11/8” pins, it will be necessary for the hole diameter in the
channel brackets to be drilled out to 15/32” (1.156”) and
ask your dealer to order 11/8” diameter pins. The 11/8” pins
are part #830318. Be sure to indicate if two or four 11/8”
pins are required.
If your loader requires 11/4” diameter pins, please ask
your dealer to order adapter bushings (part #830319). Be
sure to indicate how many adapter bushings are
required.
NOTE: The Ford (New Holland) models 7109, 7209,
7210, 7309, 7310 and 7410 Pin Type Loaders require
special brackets. Also, Rhino (Alamo) models 2410 and
2491. Order #830330 bracket kit.
NOTE: For loaders that require brackets that provide
additional roll back, order #830335 (1” pins).
Connect the assembly to the loader arms using the bot-
tom hole in the channel and attach the upper control
cylinder to the top hole in the lift channels. Center the
main frame (side to side) with your loader arms and
tighten the four (4) 5/8” x 3” U-Bolts.
The lower hole positions in the lift channels can be used
to obtain more angle movement. However, if the frame
becomes too parallel with the loader lift arms, the loader
may not have enough power (mechanical advantage) to
bring the frame back.
NOTE: Generally, it is not recommended to have the tilt
cylinders located any closer than 10-12 inches to the
main loader lift arms. Check the spacing of mounting
pins on your loader bucket and use this as a guide.
If tilt cylinders are located too close to the loader arms,
they may go “over center” when fully extended. If this
happens, damage may occur to the cylinders and/or
mounting brackets.
Remove the bucket from your skid steer unit and
connect the main frame of the Grapple Rake to the
universal quick-attach coupler.
The model SSGR-262, SSGR-277, and SSGR-84 have
a universal quick-attach bracket welded on the frame. No
special brackets are required. Make sure latch pins
engage slots to lock the frame in place.
Route the hoses (not supplied) back to your
tractor/loader remote hydraulic couplers. Be sure to allow
a loop of hose just behind the attachment to allow for the
tilt angles that will be encountered. Make sure that the
hoses are routed so they will not be pinched or snagged
by attachment pivot arms, loader, or tractor parts. Fasten
the hoses securely so they will remain in the correct
position and not drop down where they could be pinched
or sheared.
Use a good thread sealant. (DO NOT USE TEFLON
TAPE as this could cause hydraulic system problems in
your tractor or power unit.)
After making the hose connection between the
tractor/skid remote outlets and the grapple cylinders,
operate the grapple several times to work the air out of
the system.
ASSEMBLY – TRACTOR LOADERS
PIN ON ATTACHMENT
(continued)
To help prevent personal injury, stand clear of frame
and loader. Keep feet away from underside of main
frame.
Escaping hydraulic fluid under pressure can pene-
trate the skin, causing serious injury.
DO NOT use your hand to check for leaks. Use a
piece of cardboard or paper to search for leaks.
Stop engine and relieve pressure before connecting
or disconnecting lines.
Tighten all connections before starting engine or
pressurizing lines.
If any fluid is injected into the skin, obtain medical
attention immediately, or gangrene may result.
ASSEMBLY – SKID STEER AND
TRACTOR LOADERS
ASSEMBLY – QUICK ATTACH
SKID STEER MOUNTING
If your tractor loader has a bucket Quick Attach feature,
check with your dealer on the availability of adapter
brackets for your brand and model loader.
Measure the width of the front adapter on your loader
and locate the Quick Attach brackets on the main frame.
Locate these brackets so the main frame will be centered
on your loader.
Tighten the U-bolts that connect the brackets to the
main frame.
CAUTION
DANGER

14
INSTRUCTIONS (continued)
MODELS SSGR-262, SSGR-277,
AND SSGR-84
ATTACHMENT TO
PRIME MOVER
——————————————————
3. Enter the prime mover. Fasten seatbelt, start engine.
Disengage the parking brake.
4. Follow the attaching procedure in the prime mover
owner's manual. Align the attachment mechanism
with the mounting on the grapple rake, attach to the
prime mover on loader.
5. Engage the parking brake and shut down the prime
mover. Be sure to relieve pressure to the auxiliary
hydraulic lines.
6. Unfasten safety restraints and exit the prime mover.
7. Make sure the hydraulic couplers are clean. Connect
the hydraulic lines to the prime mover. Twist the collar
of the quick couplers one-quarter turn to secure
connections.
8. Engage the latching mechanism to secure attachment
to loader. The lockpins must be completely extended
and secured into the retaining slots.
9. Re-enter the prime mover. Fasten seatbelt and re-
start engine.
1. Position the attachment on a level surface.
2. The quick attach coupler handles should be in the
unlocked position with lock pins retracted, Figure 2.
Improper attachment of the Grapple Rake could
result in injury or death. Do not operate this product
until you have positive indication that the attachment
is securely mounted.
Attachment coupler handles must always be
rotated to LOCK POSITION to prevent coupler latch
from disengaging and attachment from falling off.
Figure 2. Quick Attach Coupler Handles - Unlocked
Figure 3. Attachment Coupler Handles - Locked
10. Carefully raise the loader and cycle the rollback/tilt
cylinders to check clearances and to ensure that the
attachment is securely mounted.
REMOVING THE GRAPPLE RAKE
1. If possible, find a level solid location to place the
attachment. This makes it easier to disconnect and
re-connect later on.
2. Lower the attachment to the ground.
3. Engage the parking brake and shut down the prime
mover. Be sure to relieve pressure to the auxiliary
hydraulic lines.
4. Unfasten safety restraints and exit prime mover.
5. Disconnect the hydraulic lines from the prime mover.
Connect quick couplers together to keep clean.
6. Disengage attachment-locking mechanism (mechan-
ical type).
7. Enter prime mover, fasten safety restraints and start
the prime mover.
8. Disengage attachment-locking mechanism (hydraulic
type).
9. Disengage the parking brake, and back away from
the attachment.
WARNING
WARNING

15
OPERATING INSTRUCTIONS
PRE-OPERATION CHECKLIST
(OWNER/OPERATOR RESPONSIBILITY)
____ Review and follow safety rules and safety signs on
pages 3 through 11.
____ Check that Grapple Rake is properly and securely
attached to tractor loader or skid steer.
____ Lubricate all grease fitting locations.
____ Check that all hardware is properly installed.
____ Check that no one enters the area of machine
operation. Always work at a safe distance from
roads, built-up areas, or populated places.
____ Know your controls and how to stop tractor, engine
and PTO quickly in an emergency. READ THIS
MANUAL AND THE ONE PROVIDED WITH YOUR
POWER UNIT.
____ To avoid accident or injury, do not allow anyone to
operate this equipment without proper instructions.
Any person who operates this equipment must be
instructed in and be capable of the safe operation
of the tractor, skid steer, attachment and all
controls.
OPERATION
Be sure tractor is properly counter-balanced with
weights before attempting to lift any load with the
Grapple Rake Attachment. It is recommended to attach a
heavy implement or weight box on the 3 pt. hitch of the
tractor for counter weight.
Make sure all operators have read the Owner’s Manual
and are familiar with the instructions and the safety rules
of operation.
When working on side hills, DO NOT RAISE
LOADER TOO HIGH. Keep an eye on terrain
changes. Keep load low.
• Become familiar with controls.
• Be sure anyone operating the loader is aware of safe
operation and potential hazards. Read and observe
safety recommendations in loader manual.
• Operate loader from operator’s seat only. Remain at
controls until operating cycle is complete.
• Stop loader gradually when lowering or lifting loads.
• Use particular care when working on inclines and
hillsides.
• Avoid holes, ditches, and obstructions which may
cause tractor/loader to tip.
• Allow for additional length of loader on tractor while
turning.
• Never allow anyone to walk or work under a raised
loader.
• Be sure that people, livestock, or pets are not stand-
ing near the machine while operating.
• Do not handle loads that exceed the weight limitations
of the loader.
• Carry the loads slowly and as low as possible to the
ground.
• Operate the loader hydraulic controls smoothly, avoid-
ing jerky operation.
• When handling material on a slope, always approach
the material with the tractor facing uphill.
• Only use a tractor or power unit equipped with a
ROPS cab or roll-over protective structure.
• Travel slowly over rough ground or when making
turns.
• Lower bucket or attachment to ground when loader is
unattended.
OPERATE LOADER SAFELY
Do not operate this product until you have positive
indication that this attachment is securely mounted
to the loader. Failure to install lock pins or have the
latching mechanism engaged could result in injury
or death.
WARNING

16
OPERATING INSTRUCTIONS (continued)
Beware of lift clearance when raising loader to
maximum height.
Keep load centered on Grapple Rake and loader.
Unbalanced loads increase possibility of tipping or
roll-over.
When handling brush or branches, be aware of
branches that might contact power unit or operator.
When cleaning up old building sites, check for live
utility lines. Always be sure electric, gas, and water
lines have been properly disconnected.
Check material to be handled, especially at old
building sites or dumps. Be alert for any hazardous
material that could be released by grapple rake con-
tact. If in doubt, check with professional waste
haulers.
When stacking logs, trees, or stumps, always make
sure the load will not roll back toward the power unit
when released from Grapple Rake.
Failure to observe the above warnings could result
in serious injury or death.
When stacking or loading vehicles, make sure you are
operating in an area AWAY FROM OVERHEAD WIRES.
Beware of low electrical wires when loader is
raised. Serious injury or death can result if contact is
made.
Do not leave the operator’s seat if any part of the
tractor or implement contacts electric lines.
HANDLING MATERIAL
Approach the material to be handled with the grapple
clamp open, when the rake frame contacts the material,
close the grapple clamp. As the load is lifted, tilt the frame
back and then apply hydraulic pressure to the grapple
clamp a second time. Sometimes, as the load is being lift-
ed or pulled from a pile, it will shift.
It is recommended that the Grapple Rake be tilted back
when transporting. Always carry a load in a low position
so that you have good visibility and a low center of
gravity.
When lifting a heavy log or tree, always lift slowly and
while the load is low to the ground, make the decision if
the grapple rake is properly positioned or if the load is too
big or heavy to safely handle.
If necessary, the operator must release the Grapple
Rake from the load and back away. Then use a chain saw
to cut it into lighter or more manageable pieces.
When handling a pile of posts, trees, boards, limbs,
etc., it may be necessary to release the load and pick up
smaller amounts.
The Grapple Rake used properly, will make difficult
handling and clean up jobs easier, but it requires a good
safe operator.
When picking up logs or fallen trees, make sure that
you pick up in the center of the load weight. Remember
that the stump end of a tree that has been bulldozed out
of the ground has a lot of soil attached to the roots and
can be very heavy.
If you are handling stumps that have soil attached to
the roots, it is strongly suggested that you use the rake
points to loosen and knock the soil off. Picking the
stumps up and dropping them a few times will also
remove soil. Removing soil from the roots will result in a
cleaner burn pile and less cleanup work later.
When approaching a pile of brush or trees, watch out
for branches sticking out of pile that may contact opera-
tor or power unit.
If operator is handling large branches or trees that are
considerably wider than the width of the power unit,
always be alert for branches of standing trees that could
snap back toward the operator.
Grapple Rake Limitations (continued)
more complete burning and final land clearing. The rake
frame is not designed to bulldoze out stumps or buried
rocks.
NOTE: To prevent damage to the grapple clamp arm, DO
NOT use the grapple clamp to push or lift trees, logs, or
stumps. DO NOT use the grapple clamp arm to rake or
pull material back.
The grapple clamp is designed for holding material
against the rake main frame for handling only. It is NOT
built for pushing, pulling, raking, or lifting heavy objects.
NOTE: Grapple Rake Limitations
The Grapple Rake is designed for handling loose logs,
trees, stumps, brush, or other loose material. It is not
designed for heavy bulldozing.
The rake frame will dig into dozer piles of bulldozed
trees and stumps to consolidate them into few piles for
WARNING
CAUTION
DANGER

17
When traveling on public roads, whether at night or
during the day, use accessory light and devices for
adequate warnings to operators of other vehicles.
Comply with all federal, state and local laws.
Check visibility. If visibility is impaired, reduce speed or
consider other means of transport.
Allow for additional length of loader on tractor while
turning. Carry load low.
Select a safe ground travel speed when transporting
from one area to another. When traveling on roadways,
transport in such a way that faster moving vehicles may
pass you safely.
When traveling over rough or hilly terrain or when
making turns, slow down and use extra care.
Read all the safety warnings in the front of this manu-
al and in the manual of tractor or skid steer unit.
TRANSPORTING
OWNER SERVICE
Check the pins at the ends of the loader arms. Make
sure they are locked in place with the linchpins.
Periodically check all bolts to make sure they are tight.
Check hydraulic hoses. Make sure they are not chafed
or pinched. Replace any damaged hose.
Check hydraulic hoses and fittings for leaks. Repair any
leaks immediately. Never use your hand to check for a
hydraulic leak when system is under pressure.
Periodically lubricate the clamp arm pivot bushings.
Thoroughly clean the grease zerks before servicing.
Dirt mixed with lubricant will rapidly wear parts and
destroy bearings. Keep it clean.
At the end of the working season or when the Grapple
Rake will not be used for a long period, it is good practice
to clean off any dirt or grease that may have accumulated.
Replace any worn or damaged parts immediately. Do
not use attachment with any damaged parts.
It is recommended to store the grapple rake with the
clamps fully opened and then face down. This leaves the
grapple in a stable position with the rods of the hydraulic
cylinders retracted into the cylinders. See figure below.
STORAGE
POSITION
MAINTENANCE
Always stop the power unit, set brake, shut off
engine, remove key, and lower loader to ground
before attempting to service. Never leave equipment
unattended with engine running.
Do not work under a raised loader unless it is
securely blocked or held in position. Do not depend
on the hydraulic system to hold loader and attach-
ment in place.
STORAGE
If the above method is not satisfactory, you may
purchase the optional parking stand kit #811395. The
stands bolt on the back of the main frame. Be sure to
raise the stand legs and pin in the raised position before
using the grapple. (See page 20.) Always store the
grapple on a solid surface when using the parking
stands.
Always store in a safe place away from children or
livestock.
REPLACE
SAFETY SIGNS
IF DAMAGED
OR MISSING.
WARNING
WARNING
CAUTION

18
TROUBLE-SHOOTING GUIDE
PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY
Grapple Rake
clamp will not
operate.
1. No or insufficient oil flow. Remote hydraulic connection fittings not
compatible. Check for proper fitting.
Hydraulic system may not be supplying
rated pressure. Consult your dealer.
Hydraulic system may not be delivering its
rated volume of oil due to wear. Hydraulic
pump may need to be repaired.
Hydraulic valve on tractor or skid steer not
engaged.
Grapple Rake is
loose on loader.
1. Attachment not correct. U-bolts that connect quick-attach brackets
to main frame may be loose or worn.
Tighten or replace U-bolts
NOTE: If bolts are loose or damaged, it
could be that they were never properly
tightened. It also could be that the opera-
tor is impacting the Grapple Rake into
stumps or ground during operation.
Grapple Rake mount may not be properly
latched on tractor or skid steer loader.
Check lock pins.
Hydraulic hose
failure.
1. Hydraulic relief pressure setting is
very high and may cause
hydraulic hose failure.
2. Hoses are worn or frayed.
3. Hose rating may be too low for
hydraulic system pressure.
4. Hose is being pinched by move-
ment of loader mount or loader
linkage.
Check hydraulic system and adjust relief
valve.
Replace hose.
Replace with higher rated hoses.
Reroute hose and refasten.
Hydraulic oil over-
heats.
1. Hydraulic oil level in power unit
may be low.
2. Hydraulic oil or oil filter in power
unit may be dirty.
3. Hydraulic oil reservoir of power
unit may be small.
Check and add oil.
Change oil and filter according to power
unit manufacturer’s recommendations.
Allow time for oil to cool down.

19
TROUBLE-SHOOTING GUIDE (continued)
PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY
Tractor loader tilt
cylinders won’t pull
back after tilting
forward.
1. Loader tilt cylinders are too close
to loader arm pins in standard
pin-on lift channels.
2. Loader too small for weight of
material being handled.
3. Hydraulic system not operating at
correct pressure.
Move further apart.
Use larger tractor with larger size loader.
Check pressure and adjust or repair.
Grapple Rake is off
to one side of trac-
tor loader.
1. Lift brackets on frame not set
correctly.
Loosen brackets and measure from cen-
ter of frame to position correctly.
Bent lower main
frame tines.
1. Improper operation. Operator ramming into in-ground stumps
or rocks – retrain operator.
Operating in frozen ground – trying to
loosen material too large to be handled.
Excessive rear
tractor tire slip-
page.
1. Tractor too small.
2. Insufficient traction.
Use larger, heavier tractor or reduce
amount handled.
Add rear tire weights or add ballast in
tire. Use tractor with FWDA.
Attach heavy implement on rear of trac-
tor for counter weight.
Material slips from
Grapple Rake
grasp.
1. Clamp arms not positioned cor-
rectly on material.
2. Not firmly clamped by hydraulic
cylinder.
3. Hydraulic system has leak – allow-
ing clamping pressure to back off.
Reposition clamp arms.
Operate hydraulic cylinder to clamp
tighter.
Find leak and repair (could be O-Ring in
valve).
