Worx WX317 User manual

WX317 WX318
Impact drill EN
Schlagbohrmaschine D
Perceuse à percussion F
Trapano a percussione I
Taladro de percusión ES
Klopboormachine NL
Wiertarka udarowa PL
Ütvefúró HU
Ciocan perforator RO
Vrtací kladivo CZ
Príklepová vŕtačka SK
Berbequim com percussão PT
Slagborr SV
Vibracijski vrtalnik SL
P06
P11
P16
P21
P26
P31
P36
P41
P46
P51
P56
P61
P66
P71

6
7
5
4
8
1 3
2

1
2
E
G
2
3
1
B
A1
4
5
C2
H
D
1
2
3
C1
F
A2

1
2
E
G
2
3
1
B
A1
4
5
C2
H
D
1
2
3
C1
F
A2

Impact drill EN
76
1. KEYLESS CHUCK
2. DEPTH GAUGE
3. DRILL/ HAMMER DRILL FUNCTION SELECTOR
4. SWITCH LOCK ON BUTTON
5. ON/OFF SWITCH
6. VARIABLE SPEED CONTROL
7. FORWARD AND REVERSE ROTATION CONTROL LEVER
8. AUXILIARY HANDLE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX317 WX318 (300-329-designation of machinery, representative of Impact Drill)
WX317 WX318
Voltage 230-240V~50Hz
Power input 600W 810W
No load speed 0-3000/min
Impact rate 0-48000/min
Chuck capacity 13mm
Drilling capacity
Masonry 13mm 16 mm
Wood 25mm 32 mm
Steel 13mm 13 mm
Protection class /II
Machine weight 2.1kg 2.42kg
NOISE/VIBRATION INFORMATION
WX317 WX318
A weighted sound pressure LpA: 99dB(A) LpA: 93,5dB(A)
A weighted sound power LwA: 110dB(A) LwA: 104,5dB(A)
KpA & KwA 3.0dB(A)
Wear ear protection when sound pressure is over 80dB(A)

Impact drill EN
76
VIBRATION INFORMATION
WX317 WX318
Vibration total values (triax vector sum) determined according to EN 60745:
Impact drilling into
concrete
Vibration emission value ah ID= 6.435m/s2ah ID= 9,217m/s2
Uncertainty K= 1.5m/s²
Drilling into metal Vibration emission value ah D = 4,046m/s2ah D = 7,288m/s2
Uncertainty K= 1.5m/s²
The declared vibration total value may be used for comparing one tool with another, and may
also be used in a preliminary assessment of exposure.
WARNING:The vibration emission value during actual use of the power tool can differ
from the declared value depending on the ways in which the tool is used dependant on
the following examples and other variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration accessories are used.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
WARNING:To be accurate, an estimation of exposure level in the actual conditions of
use should also take account of all parts of the operating cycle such as the times when
the tool is switched off and when it is running idle but not actually doing the job.This may
significantly reduce the exposure level over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate)
If the tool is to be used regularly then invest in anti vibration accessories.
Avoid using tools in temperatures of 100C or less
Plan your work schedule to spread any high vibration tool use across a number of days.
ACCESSORIES
WX317 WX318
Auxiliary handle 1 1
Depth gauge 1 1
HSS drill bit /3 (5mm, 6mm, 8mm)
Masonry drill bit /3 (6mm, 8mm, 10mm)
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type
according to the work you intend to undertake. Refer to the accessory packaging for further
details. Store personnel can assist you and offer advice.

Impact drill EN
98
HAND DRILL SAFETY
INSTRUCTIONS
1. Wear ear protectors when impact
drilling. Exposure to noise can cause
hearing loss.
2. Use auxiliary handle(s), if supplied
with the tool. Loss of control can cause
personal injury.
3. Hold power tool by insulated gripping
surfaces, when performing an
operation where the cutting accessory
may contact hidden wiring or its own
cord. Cutting accessory contacting a “live”
wire may make exposed metal parts of
the power tool “live” and could give the
operator an electric shock.
SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Double insulation
Wear ear protection
Wear eye protection
Wear dust mask
Waste electrical products must not
be disposed of with household
waste. Please recycle where
facilities exist. Check with your local
authorities or retailer for recycling
advice
Before any work on the machine
itself, pull the mains plug from the
socket outlet.
Wear protective gloves
Hammer drilling
Drilling
Wood
Metal
Plastic
Concrete
Masonry
High speed
Low speed

Impact drill EN
98
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for impact drilling in
brick, concrete and stone as well as for drilling
in wood, metal and plastic.
ASSEMBLY AND OPERATION
ACTION FIGURE
Clamping and loosening the
Auxiliary Handle
WARNING! Always
check and rotate the
handle tightly before using to
avoid any accident.
See Fig. A1,
A2
Installing the Depth Gauge See Fig. B
Inserting Bits into Chuck See Fig. C1, C2
Plugging in the power See Fig. D
On/Off Switch and Lock-on
Button
See Fig. E
Variable Speed Control See Fig. F
Forward and Reverse
Rotation Control
NOTE: Never move
the forward/reverse
switch whilst the drill in
operation or the on/off
switch is locked as this
will damage the drill.
See Fig. G
Hammer or Drilling Control See Fig. H
WORKING HINTS FOR YOUR
DRILL
1. Drilling masonry and concrete
Select the drill/impact action selector switch
to the “hammer symbol” position. Tungsten
carbide drill bits should always be used for drilling
masonry, concrete etc with a high speed.
2. Drilling steel
Select the drill/impact action selector switch to
the “drill symbol” position. HSS drill bits should
always be used for drilling steel with a lower
speed.
3. Pilot holes
When drilling a large hole in tough material (i.e.
steel), we recommend drilling a small pilot hole
first before using a large drill bit.
4. Drilling tiles
Select the drill/impact action selector switch to
the “drill symbol” position to drill the tile. When
tile has been penetrated, switch over to “hammer
symbol” position.
5. Cool the motor
If your power tool becomes too hot, set the speed
to maximum and run no load for 2-3 minutes to
cool the motor.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional
lubrication or maintenance.
There are no user serviceable parts in your
power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean
with a dry cloth. Always store your power tool
in a dry place. Keep the motor ventilation slots
clean. Keep all working controls free of dust.
Occasionally you may see sparks through the
ventilation slots. This is normal and will not
damage your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
If the replacement of the supply cord is necessary,
this has to be done by the manufacturer or his
agent in order to avoid a safety hazard.
TROUBLESHOOTING
1. If your power tool does not start, check the
plug on the power supply first.
2. If the drill doesn’t work properly, check the
drill bit for sharpness, replace drill bit if
worn. Check that the drill is set to forward
rotation for normal use.
3. If a fault can not be rectified, return the tool
to an authorized dealer for repair

1110
Impact drill EN
1110
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or retailer for
recycling advice.
PLUG REPLACEMENT
(UK & IRELAND ONLY)
If you need to replace the fitted plug then
follow the instructions below.
IMPORTANT
The wires in the mains lead are colored in
accordance with the following code:
Blue = Neutral
Brown = Live
As the colors of the wires in the mains lead of
this appliance may not correspond with the
colored markings identifying the terminals
in your plug, proceed as follows.The wire
which is colored blue must be connected to
the terminal which is marked with N.The wire
which is colored brown must be connected to
the terminal which is marked with L.
WARNING: Never connect live or
neutral wires to the earth terminal of the
plug. Only fit an approved 13ABS1363/A plug
and the correct rated fuse.
NOTE: If a moulded plug is fitted and has to
be removed take great care in disposing of the
plug and severed cable, it must be destroyed
to prevent engaging into a socket.
Connect
Blue to N
(neutral)
Outer sleeve
firmly clamped
Cable grip
Brown L (live)
13 Amp fuse approved
to BS1362
DECLARATION OF
CONFORMITY
We,
POSITEC Germany GmbH
Konrad-Adenauer-Ufer 37
50668 Köln
Declare that the product,
Description WORX Impact Drill
Type WX317 WX318 (300-329-desig-
nation of machinery, representative of
Impact Drill)
Function Boring holes in various materi-
als
Complies with the following Directives,
2006/42/EC
2004/108/EC
2011/65/EU
Standards conform to
EN 60745-1
EN 60745-2-1
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
The person authorized to compile the techni-
cal file,
Name Russell Nicholson
Address Positec Power Tools (Europe)
Ltd, PO Box 152, Leeds, LS10 9DS, UK
Suzhou 2015/07/01
Allen Ding
Deputy Chief Engineer,Testing & Certification

Copyright © 2015, Positec. All Rights Reserved.
AR01001800
