Worx WX255L User manual

WX255L WX255L.2

EN
F
ES
P10
P20
P32

4
2
1
3
6711
9
8
10
5

1
1
1
2
2
2
BA
C

D1
D2

F1 F2
E1 E2

7
F3
G2 H1
G1

8
H2 H3
I1 I2

9
J

10
WARNING: Some dust created by power
sanding, sawing, grinding, drilling and other
construction activities contains chemicals known to
the State of California to cause cancer, birth defects
or other reproductive harm. Some examples of these
chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement and
other masonry products and
• Arsenic and chromium from chemically-treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work.To reduce your
exposure to these chemicals:
• Work in a well ventilated area, and
• Work with approved safety equipment, such as
those dust masks that are specially designed to
filter out microscopic particles.
WARNING:This product can expose you to
chemicals including lead, phthalate or bisphenol A
which are known to the State of California to cause
cancer, birth defects or other reproductive harm.
Wash your hands after use. For more information
go to www.P65Warnings.ca.gov.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings and
instructions. Failure to follow the warnings
and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term power tool in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with grounded
power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with grounded surfaces
such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging

11
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor
use marked “W-A” or “W”. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
f ) If operating a power tool in a damp
location is unavoidable, use a Ground Fault
Circuit Interupter (GFCI) protected supply.
Use of a GFCI reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger on
the switch or energizing power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f ) Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can
be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any

12
adjustments, changing accessories, or
storing power tools. Such preventive safety
measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc., in accordance with these
instructions and in the manner intended for
the particular type of power tool, taking
into account the working conditions and
the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
h)
Use clamps or another practical way to secure
and support the workpiece to a stable platform.
i) Holding the work by hand or against your
body leaves it unstable and may lead to
loss of control.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified
by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

13
SCREWDRIVER SAFETY WARNINGS
1. Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring. Fasteners contacting a “live” wire may
make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
GENERAL SAFETY WARNINGS FOR YOUR
BATTERY CHARGER
WARNING: This product can expose you to
chemicals including lead, phthalate or bisphenol
which are known to the State of California to cause
cancer, birth defects or other reproductive harm. Wash
your hands after use. For more information go to
www.P65Warnings.ca.gov.
This device complies with Canadian ICES-001.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
SAFETY INSTRUCTIONS FOR BATTERY
1) WARNING: Risk of fire and burns. Do not
disassemble, heat above 100°C (212°F), or
incinerate. Do not expose cells or batteries to
heat or fire. Avoid storage in direct sunlight.

14
2) Dispose of used battery promptly. When
disposing of secondary cells or batteries,
keep cells or batteries of different
electrochemical systems separate from each
other.
3) Keep battery out of reach of children and in
original package until ready to use.
4) Never put batteries in mouth. If swallowed,
contact your physician or local poison control
center.
5) CAUTION – The battery used in this device
may present a risk of fire or chemical burn
if mistreated. Replace battery with (WORX)
only. Use of another battery may present a
risk of fire or explosion
6) Warning: Do not use a visibly damaged
battery pack or appliance as applicable.
7) Warning: Do not modify or attempt to
repair the appliance or the battery pack as
applicable.
8) BATTERY MUST BE RECYCLED
9) Do not short-circuit a cell or battery. Do
not store cells or batteries haphazardly in
a box or drawer where they may short-
circuit each other or be short-circuited by
conductive materials.
10) Do not subject cells or batteries to
mechanical shock.
11) Keep cells and batteries clean and dry. Wipe
the cell or battery terminals with a clean dry
cloth if they become dirty.
12) Do not maintain secondary cells and batteries
on charge when not in use.
13) Retain the original cell and battery literature
for future reference.
14) Do not use any charger other than that
specifically provided for use with the
equipment. Secondary cells and batteries
need to be charged before use. Always use
the correct charger and refer to the manufacturer’s
instructions or equipment manual for proper
charging instructions.
15) When possible, remove the battery from the
equipment when not in use.
16) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to battery
pack, picking up or carrying the appliance. Carrying
the appliance with your finger on the switch or
energizing appliance that have the switch on invites
accidents.

15
Do not stare directly into the tool
holder. When changing the tool insert,
it can be thrown out toward the front.
To reduce the risk of injury, user
must read instruction manual
Warning
Double insulation
Wear eye protection
Wear ear protection
Wear dust mask
Do not burn
Do not expose to rain or water
Wear protective gloves
Li-Ion battery. Separate collection,
and battery must be recycled
For indoor use only
T 1A Fuse
The output plug is with positive
center pole and negative outer pole
Don’t use double end bit
POSITEC Inc. has established
a partnership with the RBRC
Corporation to recycle any Positec
batteries with the RBRC-call2recycle
seal. For environmental protection,
please do not discard batteries in the
trash. After the batteries’ life cycle
is ended, then please call 1-800-
822-8837 for a free service that will
properly dispose of the battery.
SYMBOL

16
1. SLIDE COVER
2. FORWARD/REVERSE ROTATION CONTROL
3. SOFT GRIP HANDLE
4. CHARGING INDICATOR
5. CHARGING SOCKET
6. ON/OFF SWITCH
7. LED LIGHT
8. SCREW HOLDER
9. CHUCK
10. BIT CARTRIDGE
11. EXTENDABLE FLEXIBLE SHAFT (ONLY FOR WX255L.2)
Not all the accessories illustrated or described are included in standard delivery.

17
TECHNICAL DATA
Charger input 100-240V~ 50/60Hz 190mA
Charger output 4.2V 500mA
Rated voltage 4V Max*
Charger input power 3W
Battery capacity 1.5Ah
Battery type lion
Battery model no. ISR18650
No-load speed 230/min
Maximum torque 27 in.lbs
Machine weight 1.1 lbs
Charger protection class /II
Charging time 5 hours (Approx.)
* Voltage measured without workload. Initial battery voltage reaches maximum of 4 volts. Nominal voltage is 3.6 volts.
ACCESSORIES
WX255L WX255L.2
Screwdriver bit (PH1, PH2, SL4, SL6, SQ1, SQ2) 66
Cartridge 11
Charger 11
Extendable Flexible Shaft /1
We recommend that you purchase your accessories from the same store that sold you the tool. Choose the type
according to the work you intend to undertake. Refer to the accessory packaging for further details. Store personnel
can assist you and offer advice.

18
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
ACTION FIGURE
BEFORE OPERATION
Charging the Battery
NOTE: 1. Maximize Battery Performance
Prior to initial use, the battery must be charged 5 hours to fully utilize the battery capacity.
2. When the battery is full charged, the light turns green.
See Fig. A
ASSEMBLY AND ADJUSTMENT
Inserting and Removing the Bit Cartridge See Fig. B,C
Assembling and Removing the Screw Holder See Fig. D1,D2
INSTALLING AND REMOVING EXTENDABLE FLEXIBLE SHAFT (ONLY FOR
WX255L.2 ) See Fig. E1,E2
Forward/Reverse/Lock
WARNING: Never change the direction of rotation when the chuck is rotating, wait until
it is stopped! See Fig. F1,F2,F3
OPERATION
Selecting a Bit See Fig. G1, G2
Assembling screw See Fig. H1,
H2, H3
Tightening and Loosening Screw See Fig. I1, I2
Operating the On/Off Switch
WARNING: Do not operate for long periods at low speed because excess heat will be
produced internally. See Fig. J
LED Light Indicator See Fig. J

19
Automatic Spindle Locking
NOTE: When the SD Driver is out of power, this function enables the customer tightening or
loosening screws manually.
MAINTENANCE
Your power tool requires no additional lubrication or maintenance.There are no user serviceable parts in your
power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of dust.
If you see some sparks flashing in the ventilation slots, this is normal and will not damage your power tool.
TROUBLE SHOOTING
Problem Possible cause Solution
Battery will not charge. 1. Charger not plugged into
a working outlet.
2. Surrounding air
temperature is too hot or
too cold.
1. Plug charger into a working outlet. Check
current by plugging in a lamp.
2. Move charger to an appropriate place which
temperature is suitable for the charger.
Switch cannot be pressed. Forward/Reverse switch at
middle position.
Make sure switch is on Forward or Reverse
rotation according to project need.
Driver stops during
driving screws.
Driver battery is out of
power.
Make sure the driver is fully charged before
using it.
Bit Cartridge will not
rotate when Cover slides.
The cover is not fully open. Make sure the Cover is fully open and past the
red line on the tool.

20
AVERTISSEMENT! Certaines des poussières
produites en utilisant des outils électriques
sont considérées par l’État de Californie comme
susceptibles de provoquer le cancer, des anomalies
congénitales et d’autres problèmes de reproduction.
Voici des exemples de ces produits chimiques :
• Plomb issu de peinture à base de plomb
• Silice crystalline issue de briques et du ciment
et autres produits de maçonnerie
• Arsenic et chrome issus de bois traité
chimiquement
Votre risque de ces expositions varie en fonction de
la fréquence à laquelle vous effectuez ce travail. Pour
réduire votre exposition à ces produits chimiques :
• Travaillez dans une zone bien ventilée;
• Portez un équipement de sécurité approuvé, tel
que des masques antipoussières spécialement
conçus pour éliminer les particules
microscopiques par filtrage.
AVERTISSEMENT: Ce produit peut vous
exposer à des produits chimiques, incluant au
plomb, au phtalate ou au bisphénol A, qui sont
reconnus dans l’État de Californie comme pouvant
causer un cancer, des anomalies congénitales ou
d’autres dommages à l’appareil reproducteur.
Assurez-vous de bien vous laver les mains
après usage. Pour en savoir plus, veuillez consulter
le site www.P65Warnings.ca.gov.
AVERTISSEMENTS GENERAUX CONCERNANT
LA SECURITE DES OUTILS ELECTRIQUES
AVERTISSEMENT! Lisez et assimilez
toutes les instructions. Le non-respect des
instructions ci-après peut entraîner un risque de
choc électrique, d’incendie et/ou de blessures
graves.
Conservez tous les avertissements et
instructions pour pouvoir les consulter
ultérieurement.
L’expression « outil électrique » dans tous les
avertissements énumérés ci-dessous se réfère
à votre outil électrique fonctionnant sur secteur
(branché) ou à batterie (sans-fil).
1. AIRE DE TRAVAIL
a) Veillez à ce que l’aire de travail soit
propre et bien éclairée. Le désordre et le
manque de lumière favorisent les accidents.
b) N’utilisez pas d’outils électriques dans un
milieu présentant un risque d’explosion,
par exemple en présence de liquides,
de gaz ou de poussières inflammables.
Les outils électriques créent des étincelles qui
pourraient enflammer les poussières ou les
vapeurs.
c) Gardez à distance les curieux, les enfants
et les visiteurs lorsque vous travaillez
avec un outil électrique. Ils pourraient
vous distraire et vous faire faire une fausse
manoeuvre.
2. SÉCURITÉ ÉLECTRIQUE
a) Les fiches des outils électriques doivent
