1x4 4K HDMI2.0 (18Gbps) Splitter with HDCP 2.2
SP-0104-H2 Quickstart Guide
IMPORTANT! Installation Requirements
• This product was released in multiple versions which contain different
conguration procedures. The differences are identied in the appropriate
sections of this document and versions can be identied by the product
model number sticker. See Identifying Product Versions.
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Install the latest rmware to ensure that all features described in this
document are available during and after installation.
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
In The Box
1x SP-0104-H2 Splitter
1x 12V DC 1A Power Supply
1x 3-pin Screw Down Phoenix Connector
2x Mounting Brackets
1x Quickstart Guide (This Document)
Identifying Product Versions
This product was released in multiple versions which contain different
conguration procedures. The differences are identied in the appropriate
sections of this document.
Versions can be identied by a v# after the model number on the product
chassis. Note that version 1 of this product may not contain a v1 after the
product while all versions above version 1 are identied with the version
number.
Basic Wiring Diagram
UHD Display
12V DC 1A
Power Supply
HDMI HDMI HDMI
UHD Display
UHD Source
HDMI
KEY
Power
UHD Display UHD Display

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in this
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
HDMI Wiring
IMPORTANT! HDMI Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and electrical or environmental interference can have an adverse effect on HDMI
transmission limiting performance. Steps should be taken to minimize or remove these factors completely during installation for best results.
• WyreStorm recommends using high quality HDMI cables such as WyreStorm Express to ensure the highest content performance available.
• The length of HDMI cable used can restrict the available video resolution. See Video Resolutions in the Specications table before determining cable length.
EDID Settings
EDIDs can be congured to resolve issues with video output on displays that may not accept the maximum resolution available from the source.
Note: This product was released in multiple versions which have different EDID settings for the rotary switch. See Identifying Product Versions to ensure that
the proper settings are used based on the product version.
• Ensure that a display is connected and powered On to the selected output before copying EDIDs or the copy will fail. When this occurs, EDID will be set to
1080p @60Hz 2ch.
• Power to the splitter must be cycled (Off/On) after changing dip switches in order for the setting to take effect.
EDID Dial Setting Location
Copying EDIDs from Output 1
1. Set the EDID dial to 0 (Default)
2. Connect a source to the input.
3. Connect the lowest resolution display to output 1.
4. Power on the source, display, and splitter.
5. After a few moments the EDID from the display will be congured.
Note: If the EDID copy fails, the EDID will be set to 1080p @60Hz 2ch.
Copyright © 2017 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 Quickstart Guide | 171115
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
Operation Rotary Position
Copy EDID from HDMI output1 (default setting) 0
1920x1080i @60Hz 2ch 1
1920x1080i @60Hz 5.1ch 2
1920x1080i @60Hz 7.1ch 3
1920x1080p @60Hz 2ch 4
1920x1080p @60Hz 5.1ch 5
1920x1080p @60Hz 7.1ch 6
1920x1080p @60Hz 3D 2ch 7
1920x1080p @60Hz 3D 5.1ch 8
1920x1080p @60Hz 3D 7.1ch 9
1280x1024 DVI A
1920x1080 DVI B
1920x1200 DVI C
3840x2160p @30Hz 2ch D
4096x2160p @60Hz 2ch E
Copy EDID from HDMI output2 F
Version 1 and 2 Rotary Dial Settings
Mode Operation Rotary Position
Mixed
Video: Compatibility | Audio: Compatibility (Default) 0
Video: Quality | Audio: Compatibility 1
Video: Compatibility | Audio: Quality 2
Video: Quality | Audio: Quality 3
Fixed
3840x2160p @30Hz 2ch 4
3840x2160p @30Hz 5.1ch 5
3840x2160p @30Hz 7.1ch 6
1920x1080p @60Hz 3D 2ch 7
1920x1080p @60Hz 3D 5.1ch 8
1920x 1080p @60Hz 3D 7.1ch 9
Copy Copy EDID from Output 1 A
No Function B~F
Version 3 Rotary Dial Settings

Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to all devices in the system and that they
are powered on.
• Verify that all source connections are not loose and are functioning properly.
• Verify that the splitter and display support the output resolution of the
source.
• Refer to Video Resolutions in the Specications table before determining
cable type and length.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K rated.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
• Use a flashlight to locate the IR receiver behind any tinted panels on the
device being control.
Copyright © 2017 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 Quickstart Guide | 171115
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4

Warranty Information
This product is covered by a 2 year limited parts and labor warranty. During this period there will be no charge for unit repair,
component replacement or complete product replacement in the event of malfunction. The decision to repair or replace will
be made by the manufacturer. This limited warranty only covers defects in materials or workmanship and excludes normal
wear and tear or cosmetic damage. Visit the product page located at wyrestorm.com for additional information on this
product including important technical information not provided in this document and warranty terms & conditions.
Specications
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Audio and Video
Inputs 1x HDMI 19-pin type A
Outputs 4x HDMI 19-pin type A
Audio Formats 2ch PCM | Up to DTS-X and Dolby Atmos
Version 1 Version 2/3
Video Resolutions (Max)
1920x1080p @60Hz 12bit (15m/49.2ft) | 16bit (15m/49.2ft)
3840x2160p @30Hz 4:4:4 8bit (15m/49.2ft)
4096x2160p @60Hz 8bit 4:2:0 (15m/49.2ft)
1920x1080p @60Hz 12bit (15m/49.2ft) | 16bit (15m/49.2ft)
3840x2160p @30Hz 4:4:4 8bit (15m/49.2ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (15m/49.2ft)
4096x2160p @60Hz 8bit 4:2:0 (15m/49.2ft)
4096x2160p @60Hz 8bit 4:4:4 (3m/9.8ft)
Color Depth 1080p: 48bit | 4K UHD: 24bit 1080p: 48bit | 4K UHD: 24bit | HDR @24p: 10bit BT.2020
Maximum Pixel Clock 340mHz 600MHz
Communication and Control
HDMI HDMI 1.4 | HDCP 1.4 | Congurable EDID
DVI/D supported with adapter (not included)
HDMI | HDCP 2.2 | Congurable EDID
DVI/D supported with adapter (not included)
RS-232 1x RS-232 3-pin Phoenix Connector (Firmware Updates)
Power
Power Supply Input: 100~240V AC 50/60Hz | Output: 12V DC 1A
Max Power Consumption 4W
Environmental
Operating Temperature 32°F ~ 113°F (0°C ~ 45°C) | 10% ~ 90%, non-condensing
Storage Temperature -4°F to ~ 158°F (-20°C ~ +70°C) | 10% ~ 90%, non-condensing
Maximum BTU 13.64 BTU/hr
Dimensions and Weight
Rack Units/Wall Box <1U
Height 18mm/0.71in
Width 167.2mm/6.59in
Depth 69.7mm/2.75in
Weight 0.32kg/0.7lbs
Regulatory
Safety and Emission CE | FCC | RoHS
