Wyrestorm SP-0108-H2 User manual

Copyright © 2017 WyreStorm Technologies | wyrestorm.com
SP-0108-H2 Quickstart Guide | 171026
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation
process.
1x8 4K HDMI2.0 (18Gbps) Splitter with HDCP 2.2
SP-0108-H2 Quickstart Guide
IMPORTANT! Installation Requirements
• This product was released in multiple versions which contain different
congurationprocedures.Thedifferencesareidentiedintheappropriate
sectionsofthisdocumentandversionscanbeidentiedbytheproduct
model number sticker. See Identifying Product Versions.
• Visittheproductpagetodownloadthelatestrmware,documentversion,
additionaldocumentation,andcongurationtools.
• Installthelatestrmwaretoensurethatallfeaturesdescribedinthis
document are available during and after installation.
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
• WhilethisproductsupportsCEC,WyreStormcannotguarantee
compatibility with all forms of CEC communication.
In The Box
1x SP-0108-H2 Splitter
1x 12V DC 1A Power Supply
1x 3-pin Screw Down Phoenix Connector
2x Mounting Brackets
1x Quickstart Guide (This Document)
Identifying Product Versions
This product was released in multiple versions which contain different
congurationprocedures.Thedifferencesareidentiedintheappropriate
sections of this document.
Versionscanbeidentiedbyav#afterthemodelnumberontheproduct
chassis. Note that version 1 of this product may not contain a v1 after the
productwhileallversionsaboveversion1areidentiedwiththeversion
number.
Basic Wiring Diagram
KEY
HDMI
Power
12V DC 1A
Power Supply UHD Source
UHD Display
UHD Display
UHD Display
UHD Display UHD Display
UHD Display
UHD Display UHD Display

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in this
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
HDMI Wiring
IMPORTANT! HDMI Wiring Guidelines
• Theuseofpatchpanels,wallplates,cableextenders,kinksincables,andelectricalorenvironmentalinterferencecanhaveanadverseeffectonHDMI
transmission limiting performance. Steps should be taken to minimize or remove these factors completely during installation for best results.
• WyreStorm recommends using high quality HDMI cables such as WyreStorm Express to ensure the highest content performance available.
• The length of HDMI cable used can restrict the available video resolution. See Video Resolutions in the Specications table before determining cable length.
EDID Settings
EDIDscanbeconguredtoresolveissueswithvideooutputondisplaysthatmaynotacceptthemaximumresolutionavailablefromthesource.
• EnsurethatadisplayisconnectedandpoweredOntotheselectedoutputbeforecopyingEDIDsorthecopywillfail.Whenthisoccurs,EDIDwillbesetto
1080p @60Hz 2ch.
• Power to the splitter must be cycled (Off/On) after changing dip switches in order for the setting to take effect.
Copying EDIDs from Output 1
1. Set the EDID dial to 0 (Default)
2. Connect a source to the input.
3. Connect the lowest resolution display to output 1.
4. Poweronthesource,display,andsplitter.
5. AfterafewmomentstheEDIDfromthedisplaywillbecongured.
Note:IftheEDIDcopyfails,theEDIDwillbesetto1080p@60Hz2ch.
Operation Rotary Position
Copy EDID from HDMI output1 (default setting) 0
1920x1080i @60Hz 2ch 1
1920x1080i @60Hz 5.1ch 2
1920x1080i @60Hz 7.1ch 3
1920x1080p @60Hz 2ch 4
1920x1080p @60Hz 5.1ch 5
1920x1080p @60Hz 7.1ch 6
1920x1080p @60Hz 3D 2ch 7
1920x1080p @60Hz 3D 5.1ch 8
1920x1080p @60Hz 3D 7.1ch 9
1280x1024 DVI A
1920x1080 DVI B
1920x1200 DVI C
3840x2160p @30Hz 2ch D
4096x2160p @60Hz 2ch E
Copy EDID from HDMI output2 F
Rotary Dial Settings
Copyright © 2017 WyreStorm Technologies | wyrestorm.com
SP-0108-H2 Quickstart Guide | 171026
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4

Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to all devices in the system and that they
are powered on.
• Verify that all source connections are not loose and are functioning properly.
• Verify that the splitter and display support the output resolution of the
source.
• Refer to Video Resolutions in the Specications table before determining
cable type and length.
• Iftransmitting3Dor4K,verifythattheHDMIcablesusedare3Dor4Krated.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
• UseaashlighttolocatetheIRreceiverbehindanytintedpanelsonthe
device being control.
Copyright © 2017 WyreStorm Technologies | wyrestorm.com
SP-0108-H2 Quickstart Guide | 171026
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4

Warranty Information
Thisproductiscoveredbya2yearlimitedpartsandlaborwarranty.Duringthisperiodtherewillbenochargeforunitrepair,
component replacement or complete product replacement in the event of malfunction. The decision to repair or replace will
be made by the manufacturer. This limited warranty only covers defects in materials or workmanship and excludes normal
wear and tear or cosmetic damage. Visit the product page located at wyrestorm.com for additional information on this
product including important technical information not provided in this document and warranty terms & conditions.
Specications
Note:WyreStormreservestherighttochangeproductspecication,appearanceordimensionsofthisproductatanytimewithoutpriornotice.
Audio and Video
Inputs 1x HDMI 19-pin type A
Outputs 8x HDMI 19-pin type A
Audio Formats 2ch PCM | Up to DTS-X and Dolby Atmos
Version 1 Version 2
Video Resolutions (Max)
1920x1080p @60Hz 12bit (15m/49.2ft) | 16bit (15m/49.2ft)
3840x2160p @30Hz 4:4:4 8bit (15m/49.2ft)
4096x2160p @60Hz 8bit 4:2:0 (15m/49.2ft)
1920x1080p @60Hz 12bit (15m/49.2ft) | 16bit (15m/49.2ft)
3840x2160p @30Hz 4:4:4 8bit (15m/49.2ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (15m/49.2ft)
4096x2160p @60Hz 8bit 4:2:0 (15m/49.2ft)
4096x2160p @60Hz 8bit 4:4:4 (3m/9.8ft)
Color Depth 1080p: 48bit | 4K UHD: 24bit 1080p: 48bit | 4K UHD: 24bit | HDR @24p: 10bit BT.2020
Maximum Pixel Clock 340mHz 600MHz
Communication and Control
HDMI HDMI1.4|HDCP1.4|CongurableEDID
DVI/D supported with adapter (not included)
HDMI|HDCP2.2|CongurableEDID
DVI/D supported with adapter (not included)
RS-232 1x RS-232 3-pin Phoenix Connector (Firmware Updates)
Power
Power Supply Input: 100~240V AC 50/60Hz | Output: 12V DC 1A
Max Power Consumption 6W
Environmental
Operating Temperature 32°F~113°F(0°C~45°C)|10%~90%,non-condensing
Storage Temperature -4°Fto~158°F(-20°C~+70°C)|10%~90%,non-condensing
Maximum BTU 20.47 BTU/hr
Dimensions and Weight
Rack Units/Wall Box <1U
Height 18mm/0.71in
Width 257.2mm/10.13in
Depth 89.7mm/3.54in
Weight 0.58kg/1.28lbs
Regulatory
Safety and Emission CE | FCC | RoHS
