Wyrestorm EXP-SP-0104-H2 User manual

IMPORTANT! Installation Requirements
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Read through the Wiring and Connections section for important guidelines
before creating or choosing premade cables.
In The Box
1x WyreStorm EXP-SP-0104-H2 HDMI Splitter
2x Mounting Brackets
1x 5v DC Power Supply
Basic Wiring Diagram
Copyright © 2019 WyreStorm Technologies | wyrestorm.com
EXP-SP-0104-H2 Quickstart Guide | 190930
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 2
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation
process.
4K HDR HDMI Splitter with 4 Scaling Outputs
EXP-SP-0104-H2 Quickstart Guide
KEY
HDMI
EX-SP-0104-H2
DC 5V
4K HDR Source
HDMI HDMI
HDMI
HDMI HDMI
HDR Display 1080p Display 1080p Display HDR Display
Power

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in its
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
IMPORTANT! HDMI Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and electrical or environmental interference will have an adverse effect on HDMI
transmission limiting performance. Steps should be taken to minimize or remove these factors completely during installation for best results.
• WyreStorm recommends using high quality HDMI cables such as WyreStorm Essentials to ensure the highest content performance available.
Installation and Operation
1. Connect an HDMI source to the HDMI IN port using a good quality HDMI cable.
2. Connect HDMI display devices to the HDMI OUT ports of the splitter.
Note: The switcher is powered via mains power supply to the unit. WyreStorm recommend using only power adapter supplied.
3. Turn the power on ensuring LED power indicators are fully lit on the front of the splitter. If not, check power cable is rmly connected.
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to all devices in the system and that they are powered on.
• Verify that all HDMI connections are not loose and are functioning properly.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K rated.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to other devices to verify functionality.
Copyright © 2019 WyreStorm Technologies | wyrestorm.com
EXP-SP-0104-H2 Quickstart Guide | 190930
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
2 of 2
Specications
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Audio and Video
Inputs 1x HDMI In: 19-pin type A
Outputs 4x HDMI Out: 19-pin type A
Audio Formats 2ch PCM | Multichannel: LPCM and up to DTS-X and Dolby Atmos
Video Resolutions (Max)
Resolution HDMI
1920x1080p @60Hz 12bit
1920x1080p @60Hz 16bit
3840x2160p @24Hz 10bit 4:2:0 HDR
3840x2160p @30Hz 8bit 4:4:4
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:2:0
4096x2160p @60Hz 8bit 4:4:4
15m/49ft
7m/23ft
5m/16ft
7m/23ft
5m/16ft
7m/23ft
5m/16ft
Supported Standards DCI | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock 600MHz
Communication and Control
HDMI HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
Power
Power Supply 5V DC 1A
Max Power Consumption 1.8W
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU 6.14 BTU/hr
Dimensions and Weight
Rack Units/Wall Box <1U
Height 20mm/0.79in
Width 140mm/5.5in
Depth 65.2mm/2.57in
Weight 0.24kg/0.53lbs
Regulatory
Safety and Emission CE | FCC | RoHS | RCM
