Xantrex PROsine 2.0 User manual

PROsine 2.0
Inverter/Charger
User’s Manual

PROsine 2.0 Inverter/Charger
User’s Manual

About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from
50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup
power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery
chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute
electrical power.
Trademarks
PROsine 2.0 Inverter/Charger is a trademark of Xantrex International. Xantrex is a registered trademark of Xantrex
International.
Other trademarks, registered trademarks, and product names are the property of their respective owners and are used
herein for identification purposes only.
Notice of Copyright
PROsine 2.0 Inverter/Charger User’s Manual © November 2006 Xantrex International. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES,
WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE
OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE
ENTIRELY AT THE USER’S RISK; AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE
ACCURACY CANNOT BE GUARANTEED. APPROVED XANTRES CONTENT IS CONTAINED WITH THE
ENGLISH LANGUAGE VERSION WHICH IS POSTED AT WWW.XANTREX.COM.
Date and Revision
November 2006 Revision C
Part Number
445-0089-01-01
Product Number
805-2000, 805-2020
Contact Information
Telephone: [phone] (toll free North America)
1 360 925 5097 (direct)
Fax: [phone] (toll free North America)
1 360 925 5143 (direct)
Email: [email protected]
Web: www.xantrex.com

445-0089-01-01 iii
About This Manual
Purpose
The purpose of this User’s Manual is to provide explanations and procedures for
installing, operating, maintaining, and troubleshooting the PROsine 2.0 Inverter/
Charger.
Scope
The Manual provides safety guidelines, detailed planning and setup information,
procedures for installing the inverter, as well as information about operating and
troubleshooting the unit. It does not provide details about particular brands of
batteries. You need to consult individual battery manufacturers for this
information.
Audience
The Manual is intended for anyone who needs to install and operate the PROsine
2.0 Inverter/Charger. Installers should be certified technicians or electricians.
Organization
This Manual is organized into seven chapters and three appendixes:
Introduction: Chapter 1 introduces you to the PROsine, explains the inverting,
changing and power system management functions
Product Orientation: Chapter 2 will familiarize you with the following
components of a PROsine system:
Installation: Chapter 3 This section gives complete information for installing a
PROsine system.
Configuration: Chapter 4 explains how to configure the PROsine to best meet
your electrical system requirements. It is divided into three parts:
Operation: Chapter 5 begins with a system startup check that you carry out after
installation and configuration to verify that the PROsine is operating correctly.
The chapter also provides information that will guide you during routine, ongoing
operations.
Troubleshooting: Chapter 6 describes how to troubleshoot the PROsine
Series Operation: Chapter 7 provides information about installing and operating
two PROsines in series:

About This Manual
iv 445-0089-01-01
Specifications: Appendix A contains specifications and performance graphs for
the PROsine and the display panel.
System Diagrams: Appendix B illustrates typical designs for PROsine custom-
designed systems.
Charging Algorithms: Appendix C provides information about the charging
algorithms for PROsine 2.0.

About This Manual
445-0089-01-01 v
Conventions Used
The following conventions are used in this guide.
Abbreviations and Acronyms
<just the common ones--don’t make the list too long. If there are lots, then create
an appendix to contain them>
Related Documents
PROsine 2.0 Inverter/Charger Quick Installation Guide
Part Number: 445-0099-01-01: This document is included with your PROsine. It
is a job aid that provides instructions for installing the PROsine and its display
panel. It also provides a mounting template for the PROsine.
PROsine 2.0 Inverter/Charger Display Panel Mounting Template
Part Number: 445-0101-01-01: This is provided with your PROsine.
PROsine 2.0 Inverter/Charger Quick Reference Guide
Part Number: 445-0100-01-01: This document is included with your PROsine. It
provides frequently used information about configuring and operating the unit as
well as system default values.
Related Information
You can find more information about Xantrex Technology Inc. as well as its
products and services at www.xantrex.com
WARNING
Warnings identify conditions or practices that could result in personal injury or loss of life
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or other
equipment.
Important: These notes describe things which are important for you to know, but not as
serious as a caution or warning.

vi

445-0089-01-01 vii
Important Safety Instructions
1. Before installing and using the PROsine 2.0 Inverter/Charger (PROsine), read
all instructions and cautionary markings on the PROsine, the batteries, and all
appropriate sections of this Manual.
2. Do not expose the PROsine to rain, snow, spray, or bilge water. To reduce risk
of fire hazard, do not cover or obstruct the ventilation openings. Do not install
the PROsine in a zero-clearance compartment. Overheating may result.
3. Use only attachments recommended or sold by the manufacturer. Doing
otherwise may result in a risk of fire, electric shock, or injury to persons.
4. The PROsine is designed to be permanently connected to you AC and DC
electrical systems. Xantrex recommends that all wiring be done by a certified
technician or electrician to ensure adherence to proper electrical wiring
regulations.
5. To avoid a risk of fire and electric shock, make sure that existing wiring is in
good condition and that wire is not undersized. Do not operate the PROsine
with damaged or substandard wiring.
6. Do not operate the PROsine if it has received a sharp blow, been dropped, or
otherwise damaged in any way. If the PROsine is damaged, see the Warranty
section.
7. Do not disassemble the PROsine. It contains no user-serviceable parts. See the
Warranty section for instructions on obtaining service. Attempting to service
the PROsine yourself may result in a risk of electrical shock or fire. Internal
capacitors remain charged after all power is disconnected.
8. To reduce the risk of electrical shock, disconnect both AC and DC power
from the PROsine before attempting any maintenance or cleaning or working
on any circuits connected to the PROsine. Turning off controls will not reduce
this risk.
9. The PROsine must be provided with an equipment-grounding conductor
connected to the AC input ground terminal. Grounding and all other wiring
must comply with local codes and ordinances.
WARNING
This chapter contains important safety and operating instructions. Read and keep this
User’s Manual for future reference.
WARNING:Limitations on use
The PROsine 2.0 Inverter/Charger is not intended for use in connection with life support
systems or other medical equipment or devices.

Safety
viii 445-0089-01-01
Explosive gas precautions
1. Working in the vicinity of lead-acid batteries is dangerous. Batteries generate
explosive gases during normal operation. Therefore, you must read this guide
and follow the instructions exactly before installing or using your PROsine.
2. This equipment contains components which tend to produce arcs or sparks. To
prevent fire or explosion, do not install the PROsine in compartments
containing batteries or flammable materials, or in locations that require
ignition-protected equipment. This includes any space containing gasoline-
powered machinery, fuel tanks, as well as joints, fittings, or other connections
between components of the fuel system.
3. To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and the manufacturer of the equipment
in which the battery is installed.
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the
manufacturer of the equipment in which the battery is installed.
2. Make sure the area around the battery is well ventilated.
3. Never smoke or allow a spark or flame near the engine or batteries.
4. Use caution to reduce the risk or dropping a metal tool on the battery. It could
spark or short circuit the battery or other electrical parts and could cause an
explosion.
5. Remove all metal items, like rings, bracelets, and watches when working with
lead-acid batteries. Lead-acid batteries produce a short circuit current high
enough to weld metal to skin, causing a severe burn.
6. Have someone within range of your voice or close enough to come to your aid
when you work near a lead-acid battery.
7. Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
8. Wear complete eye protection and clothing protection. Avoid touching your
eyes while working near batteries.
WARNING: Explosion hazard
WARNING: Explosion or fire hazard
