Xantrex RV2012GS User manual

This Inverter/Charger has been factory
Battery Type = L IQUID LEAD ACID
programmed to thefollowing settings:
Bat Capacity= AUTO Auto LBCO = ON Search sense= DEFEAT
PN3341
Shore Power= 30A VAC Dropout= 40VAC Charge Rate = 80%
PN270-0697-01-01
30
RV GS Series
Inverter/Charger
Owner’s Manual
RV2012GS
RV2012GS-15/20B
RV2012GS-20B
RV2512GS
RV3012GS

975-0209-01-01 i
About This Manual
Purpose
The purpose of this Owner’s Manual is to provide explanations and procedures for
installing, operating, and troubleshooting the RV Series Inverter/Charger.
Scope
The Manual provides safety guidelines, detailed planning and setup information,
procedures for installing the inverter, as well as information about operating and
troubleshooting RV Series Inverter/Charger models RV2012GS, RV2012GS-15/
20B, RV2012GS-20B, RV2512GS, RV3012GS. It does not provide details about
particular brands of batteries. You need to consult individual battery
manufacturers for this information.
Audience
The Manual is intended for anyone who needs to install and operate the RV Series
Inverter/Charger. Installers should be certified technicians or electricians.
Organization
This Manual is organized into four chapters and one appendix.
Chapter 1 introduces you to the RV Series Inverter/Charger and describes its
features and performance characteristics.
Chapter 2 contains information and procedures to install the RV Series Inverter/
Charger.
Chapter 3 contains information about operating the RV Series Inverter/Charger.
Chapter 4 contains information and procedures to troubleshoot the RV Series
Inverter/Charger.
Appendix A contains contains the electrical and physical specifications for the RV
Series Inverter/Charger.

About This Manual
ii 975-0209-01-01
Conventions Used
The following conventions are used in this guide.
Symbols Used
Related Information
You can find more information about Xantrex Technology Inc. as well as its
products and services at www.xantrex.com
WARNING
Warnings identify conditions or practices that could result in personal injury or loss of life
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or other
equipment.
Important: These notes describe things that are important for you to know, but not as
serious as a caution or warning.
!AC ground
"Chassis ground
#Alternating current (AC)

RV Series Inverter/Charger
Owner’s Manual

About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from
50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup
power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery
chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute
electrical power.
Trademarks
RV Series Inverter/Charger is a trademark of Xantrex International. Xantrex is a registered trademark of Xantrex
International.
Other trademarks, registered trademarks, and product names are the property of their respective owners and are used
herein for identification purposes only.
Notice of Copyright
RV Series Inverter/Charger Owner’s Manual© June 2005 Xantrex International. All rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER DIRECT,
INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH
INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
Date and Revision
June 2005 Revision A
Part Number
975-0209-01-01
Contact Information
Telephone: [phone] (toll free North America)
1 360 925 5097 (direct)
Fax: [phone] (direct)
Email: [email protected]
Web: www.xantrex.com

975-0209-01-01 v
Important Safety Instructions
General Precautions
1. Before installing and using the RV Series Inverter/Charger, read all
instructions and cautionary markings on the RV Series Inverter/Charger, the
batteries, and all appropriate sections of this Manual.
2. Do not expose the RV Series Inverter/Charger to rain, snow, spray, or bilge
water. To reduce risk of fire hazard, do not cover or obstruct the ventilation
openings. Do not install the RV Series Inverter/Charger in a zero-clearance
compartment. Overheating may result.
3. Use only attachments recommended or sold by the manufacturer. Doing
otherwise may result in a risk of fire, electric shock, or injury to persons.
4. To avoid a risk of fire and electric shock, make sure that existing wiring is in
good condition and that wire is not undersized. Do not operate the RV Series
Inverter/Charger with damaged or substandard wiring.
5. Do not operate the RV Series Inverter/Charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. If the RV Series Inverter/
Charger is damaged, see the Warranty section.
6. Do not disassemble the RV Series Inverter/Charger. It contains no user-
serviceable parts. See Warranty for instructions on obtaining service.
Attempting to service the RV Series Inverter/Charger yourself may result in a
risk of electrical shock or fire. Internal capacitors remain charged after all
power is disconnected.
7. To reduce the risk of electrical shock, disconnect both AC and DC power
from the RV Series Inverter/Charger before attempting any maintenance or
cleaning. Turning off controls will not reduce this risk.
8. The RV Series Inverter/Charger must be provided with an equipment-
grounding conductor connected to the AC input ground.
WARNING
This chapter contains important safety and operating instructions. Read and keep this
Owner’s Manual for future reference.

Safety
vi 975-0209-01-01
Explosive gas precautions
1. This equipment contains components that tend to produce arcs or sparks. To
prevent fire or explosion, do not install the RV Series Inverter/Charger in
compartments containing batteries or flammable materials, or in locations that
require ignition-protected equipment. This includes any space containing
gasoline-powered machinery, fuel tanks, as well as joints, fittings, or other
connections between components of the fuel system.
2. To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and the manufacturer of the equipment
in which the battery is installed.
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the
manufacturer of the equipment in which the battery is installed.
2. To reduce the risk of injury, charge only deep-cycle lead acid, lead antimony,
lead calcium gel cell, absorbed mat, or NiCad/NiFe type rechargeable
batteries. Other types of batteries may burst, causing personal injury and
damage.
3. Make sure the area around the battery is well ventilated.
4. Never smoke or allow a spark or flame near the engine or batteries.
CAUTION: Equipment damage
The output side of the inverter’s AC wiring should at no time be connected to public
power or a generator. This condition is far worse than a short circuit. If the unit survives
this condition, it will shut down until corrections are made.
Installation should ensure that the inverter’s AC output is, at no time, connected to its AC
input. Also the AC input neutral must be isolated from the AC output neutral connections.
Review the installation diagrams included before you start making connections.
WARNING: Risk of explosive gases
Working in the vicinity of lead-acid batteries is dangerous. Batteries generate explosive
gases during normal operation. Therefore, you must read this guide and follow the
instructions exactly before installing or using your RV Series Inverter/Charger.
WARNING: Explosion or fire hazard

Safety
975-0209-01-01 vii
5. Use caution to reduce the risk or dropping a metal tool on the battery. It could
spark or short circuit the battery or other electrical parts and could cause an
explosion.
6. Remove all metal items, like rings, bracelets, and watches when working with
lead-acid batteries. Lead-acid batteries produce a short circuit current high
enough to weld metal to skin, causing a severe burn.
7. Have someone within range of your voice or close enough to come to your aid
when you work near a lead-acid battery.
8. Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
9. Wear complete eye protection and clothing protection. Avoid touching your
eyes while working near batteries.
10. If battery acid contacts skin or clothing, wash immediately with soap and
water. If acid enters your eye, immediately flood it with running cold water
for at least twenty minutes and get medical attention immediately.
11. If you need to remove a battery, always remove the ground terminal from the
battery first. Make sure all accessories are off so you don’t cause a spark.
Precautions for Using Rechargeable Appliances
Most rechargeable battery-operated equipment uses a separate charger or
transformer that is plugged into an AC receptacle and produces a low voltage
charging output.
Some chargers for small rechargeable batteries can be damaged if connected to the
modified sine wave output of the RV Series Inverter/Charger. When first using a
rechargable device with the RV Series Inverter/Charger, monitor its temperature
for 10 minutes to ensure that it does not become abnormally hot. Use caution
when using the following with the RV Series Inverter/Charger:
• Small battery-operated appliances like flashlights, razors, and night lights that
can be plugged directly into an AC receptacle to recharge.
• Lightweight, “transformer-less” cordless power tool chargers. Affected
chargers may display a warning label stating that dangerous voltages are
present at the battery terminals.
CAUTION: Equipment damage
Important: If you are unsure about using your rechargeable appliance with the RV
Series Inverter/Charger, contact the equipment manufacturer to find out if the equipment
is compatible with the modified sine wave output of the RV Series Inverter/Charger.

viii

975-0209-01-01 ix
Important Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -v
1 Introduction
Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2
Inverter to Charger Transition - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–2
Transfer Switching Speed - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–3
Front Panel Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–3
Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4
Remote Controls - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–4
Battery Temperature Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–5
2 Installation
Choosing a Location - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–2
Wiring the Inverter/Charger - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–4
AC Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–5
AC Input Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–6
General Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–7
Installation with an External Transfer Relay (120/240 System) - - - - - - - - - - - - - - - - - - - - - 2–7
Tools and Materials Required - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–8
Connecting the AC Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–9
GFCI Requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–9
DC Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–10
Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–10
Battery Requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–10
DC Over-Current Protection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–10
Connection of Grounding and Battery Systems - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–11
Battery Cable Sizing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–12
Battery Cable Connection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–13
Connecting the Battery Temperature Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–16
Mounting Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–16
Option A: Mounting to the Negative Battery Terminal - - - - - - - - - - - - - - - - - - - - - - - - - - 2–16
Option B: Mounting to the Side of the Battery Case - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–17
Wiring to a Generator- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–18
Generator Requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–18
Auto Gen Start connections - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–19
Generator Wiring Diagrams - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–21
Wiring to a Thermostat- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2–22
Contents

Contents
x975-0209-01-01
3 Operation
Remote Operation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Stand-Alone Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Search Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–2
Powering Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Resistive Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–3
Inductive Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Low Battery Dropout - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Problem Loads - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–4
Typical Battery Draw of Common Appliances - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–6
Battery Charging - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Stage One: Bulk Charge (Constant Current) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Stage Two: Absorption (Constant Voltage) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Stage Three: Float Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Temperature-Compensated Charging - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–7
Dead Battery Charging - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–8
Battery Equalization - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3–8
LED Indicator - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3–10
Error Conditions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3–11
4 Troubleshooting
Troubleshooting Guide - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–2
A Specifications
Electrical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–2
Environmental Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–2
Physical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–3
Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–3
Regulatory Approvals - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–3
Warranty and Return Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - WA–1

1Introduction
Chapter 1 introduces you to the RV Series Inverter/Charger and
describes its features and performance characteristics. This chapter
also contains information about the accessories available for the RV
Series Inverter/Charger.

Introduction
1–2 975-0209-01-01
Features
The RV Series Inverter/Charger produces up to 3000 watts (depending on model)
of continuous, modified sine wave power from a 12-volt battery bank. It is ideal
for simultaneous applications including microwaves, TV entertainment systems,
fax machines, computers, and power tools.
The RV Series Inverter/Charger provides automatic, multistage battery charging,
manual battery equalization and temperature sensitive charging with an optional
battery temperature sensor. The charger is designed for use with electricity
supplied from your generator or RV campground hookup.
The RV Series Inverter/Charger also has automatic generator start (AGS)
capability. When the inverter/charger is connected to an Onan QuietDiesel,
Generac or Powertech generator, it will start the generator to charge the batteries
when battery power is low, or in response to a signal from a thermostat. An RC/
GS remote control is required to configure and use the AGS feature.
Three RV Series Inverter/Charger models are available. Each model has a
different maximum continuous output power rating and surge power rating—the
power necessary to operate motor-driven appliances, which require high current at
startup (see “Inductive Loads” on page 3–4).
Inverter to Charger Transition
The RV Series Inverter/Charger includes a built-in transfer switch that
automatically transfers between inverter power and incoming AC power. To
operate the RV Series Inverter/Charger as a charger, an external source of AC
power (such as shore power or a generator) must be supplied to the inverter AC
input. The inverter/charger automatically stops inverting and begins charging
batteries whenever AC power is connected to its AC inputs. When AC power is
connected, the RV Series Inverter/Charger will begin charging even when the
inverter itself is turned off (with the on/off switch).
There is a minimum 5-second delay from the time the inverter senses that AC is
present at the input terminals to when the transfer is made. This delay is built in to
provide time for a generator to spin-up to a stable voltage and avoid relay
chattering. The inverter will not transfer to generator until it has locked onto the
generator’s output. The inverter’s AC input is internally connected to the
inverter’s AC output while in the battery charger mode.
Table 1-1 RV Series Inverter/Charger model specifications
Model Output power AC (max. continuous) Surge rating (AC amps)
RV2012GS 2000 W 44 A
RV2012GS-15/20B 2000 W 44 A
RV2012GS-20B 2000 W 44 A
RV2512GS 2500 W 48 A
RV3012GS 3000 W 52 A

Features
975-0209-01-01 1–3
Transfer Switching Speed
While this inverter is not designed as an uninterruptible power supply (UPS)
system, its transfer time is normally fast enough to hold up most computers. The
transfer time is typically 16 milliseconds.
Front Panel Features
Before installing and operating the RV Series Inverter/Charger, review the front
panel features shown in Figure 1-1 and described in Table 1-2.
Figure 1-1 RV Series Inverter/Charger Front Panel Features
Table 1-2 Front Panel Features
Feature Description
1 AC wiring knockout
2 Negative DC terminal (black)
3 RV ground terminal (green)
4 Positive DC terminal (red)
5 Remote control jack
6 Battery Temp. Sensor jack
7 LED indicator light
8 Inverter ON/OFF switch
9 Charger circuit breaker
10 AC wiring compartment cover (with wiring diagram)
PN 270-0697 -01- 01
30



60A
30A
2
4
3
1
56 897
10

Introduction
1–4 975-0209-01-01
Accessories
Remote Controls
Three remote control panels are available for the RV Series Inverter/Charger—
RC/GS, RC6 and RC7.
For inverter/charger on/off control and basic system monitoring, use the RC6
remote.
For complete inverter/charger configuration capability, use the RC7 or RC/GS
remotes. (The RV Series Inverter/Charger has an internal memory to retain its
configuration settings even with a loss of power.)
All RV Series inverter/chargers have a built-in shunt, which when paired with the
optional RC/GS remote control enables advanced battery monitoring and inverter/
charger control. To use the shunt, the inverter/charger must be wired correctly,
using the green RV ground terminal.
The RV Series Inverter/Charger also has the necessary built-in hardware to be
connected to your generator, enabling automatic generator starting when paired
with the optional RC/GS remote control.
The RC6, RC7, and RC/GS use a telephone-style cord to connect to the RV Series
Inverter/Charger (models RV2012GS, RV2012GS-15/20B, RV2012GS-20B,
RV2512GS, and RV3012GS).
Figure 1-2 Remote Control Panels
RC/GS Remote Control/Gen Starting
RC6 RC/GS
RC7

Accessories
975-0209-01-01 1–5
Use only Xantrex-recommended accessories. Remote cables are available in three
lengths:
Battery Temperature Sensor
The battery temperature sensor (BTS) allows the inverter/charger to monitor the
battery temperature and adjust charging voltage according to the temperature. The
BTS can extend the life of a battery by preventing overcharging in warm
temperatures and undercharging in cold temperatures.
The BTS attaches to a battery terminal post or to the side of the battery using a
self-adhesive backing.
Part number Cable Length
31-6257-00 25 feet
31-6262-00 50 feet
31-6275-00 70 feet
Table 1-3
Part number Details
130-0004-01-01 15 foot cord, surface mount only
130-0004-02-01 25 foot cord, surface mount only
130-0004-03-01 35-foot cord, surface mount only
808-0231 25-foot cord, surface or terminal mount (shown in Figure 1-3)
Figure 1-3 Battery Temperature Sensor (808-0231)
Connector
25 foot (7.6 m) cord
Sensor

1–6

2Installation
Chapter 2 contains information and procedures to install the RV
Series Inverter/Charger.
The topics in this chapter are organized as follows:
• “Choosing a Location”
• “Wiring the Inverter/Charger”
• “Wiring to a Generator”

Installation
2–2 975-0209-01-01
Choosing a Location
Inverters are sophisticated electronic devices and should be treated accordingly.
When selecting the operating environment for the inverter, don’t think of it in the
same terms as other equipment that works with it, such as batteries, diesel
generators, motor generators, washing machines, and so on. It is a highly complex
microprocessor-controlled device, similar in nature to stereo equipment,
television sets, or computers. The use of conformal-coated circuit boards, plated
copper bus bars, powder-coated metal components, and stainless steel fasteners
improves tolerance to hostile environments. However, in a condensing
environment (one in which humidity and/or temperature change causes water to
form on components) all the ingredients for electrolysis are present: water,
electricity and metals. In a condensing environment the life expectancy of the
inverter is indeterminate and the warranty is voided.
The inverter/charger should only be installed in a location that meets the
following requirements:
CAUTION
Install the inverter in a dry, protected location away from sources of high temperature and
moisture. Exposure to salt water is particularly destructive and potentially hazardous.
Ventilated Do not operate the inverter/charger in a closed-in area or restrict
ventilation in any way. The inverter/charger requires air circulation
to maintain optimum operating temperature and provide best
performance. If the unit has inadequate ventilation, it may shut down
due to overheating.
The air vented through the openings should also have a path to
circulate away from the inverter/charger.
Dry Do not allow water or other fluids to drip or splash on the inverter.
Do not expose to rain, snow or water.
Cool Normal air temperature should be between 32 °F and 122 °F
(0 °C and 50 °C)—the cooler the better within this range.
Clearance Allow as much space around the inverter/charger as possible.
Xantrex recommends that other objects and surfaces be at least
3 inches (76 mm) away from the ventilation openings for best
performance.
Safe Locate the inverter/charger away from battery in a separate well
ventilated compartment. Do not install the inverter/charger in any
compartment containing flammable gases or liquids like gasoline.
Close to
battery
compartment
The length and size of your DC cables will affect performance. Use
the DC cables recommended in Table 2-2 on page 2–12. The unit
should not be installed in the battery compartment due to the
possible presence of explosive hydrogen gas from the batteries.
