XPower FC-200 User manual

Air Circulator Owner's Manual
Circulateur d'air Manuel d'emploi
Model:
FC-100, FC-200 Series, FC-300, FC-420
(115V 60HZ)
Read and save these instructions
Lisez et gadez ces instructions
www.xpower.com | 1-(855)-855-8868 | [e-mail]
Index: NA-1-A9
Edition: 4.1.Final

English - 2
Safety Instructions
!WARNING - READ AND SAVE THIS INSTRUCTIONS BEFORE USING THIS PRODUCT.
The user of electrical products may create hazards that include, but are not limited to
injury, fire, electrical shock. Failure to follow these instructions may damage and/or
impair its operation and void the warranty.
• Before operating, remove all packaging material and check for any damage that may
have occurred during shipping or any missing items.
• Check household power supply to ensure it matches the appliance’s specification.
• DO NOT operate any fan with a damaged cord or plug. Discard fan or return it to an
authorized service facility for examination and/or repair.
• Use only on GFCI protected receptacles. Please contact a qualified electrician for
verification and / or installation of a GFCI receptacle if necessary.
• DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or
similar coverings. DO NOT route cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
• To reduce the risk of fire or electric shock, DO NOT use this fan with any solid-state
speed control device.
• DO NOT touch this appliance or the plug with wet hands or while standing in water.
• DO NOT operate the appliance in any pooled water.
• DO NOT use the product in areas where gasoline, paint or other flammable goods and
objects are used or stored.
• DO NOT insert or allow objects to enter any ventilation or exhaust opening as this may
damage the appliance and void the warranty.
• DO NOT cover the air inlet or outlet on the appliance.
• DO NOT direct the air flow at human faces or bodies.
• DO NOT allow children to play with this appliance.
• AUTOMATICALLY OPERATED DEVICE – To reduce the risk of injury, disconnect from
power supply before servicing.
• Remove the power cord from the electrical receptacle by grasping and pulling on the
power cord plug-end only, DO NOT pull the cord directly.
• DO NOT attempt to repair or adjust any electrical or mechanical functions of this
appliance, as this may cause danger and void the warranty.
• If the appliance is damaged or it malfunctions, DO NOT continue to use it. Unplug the
product from the electrical outlet. Refer to troubleshooting guide or contact XPOWER.
• Store in a dry area, away from exposure to sunlight, extreme temperature and humidity,
or other extreme environments, when not in use.
• For model FC-100 / FC-200 Series, DO NOT stack more than six units of this appliance.
For model FC-300 / FC-420, DO NOT stack more than five units of this appliance.
• An electronic instruction manual can be obtained through manufacturer’s website
www.xpower.com.

English - 3
Items Included
Axial Fan Owner's Manual
XXXManual De Usuario (página 10)
XXXMode d'emploi (page 18)
Model / Modelo / Modèle:
P-80Series, P-100 Series, P-200 Series
(115V 60HZ)
Readand save these instructions before use
Leay guarde estas instrucciones antes de usar la unidad
Lireet conserver ces instructions avant utilisation
www.xpower.com| 1-(855)-8868 | [email protected]
Index:NA-1-A2
Edition:1.0.Alpha
• Owner’s Manual x 1
• Air Circulator
Body x 1**• Air Circulator x 1*
Parts Description
1
2
10
13
12
14
11
3
8
9
8
6
7
5
4
• Rack x 1**
• Rack Handle x 2**
• Rubber Washer
x 2**
* For model FC-100/FC-200 Series/FC-420 only.
The exact appearance of the products might be slightly different from the diagram.
** For model FC-300 only.

English - 4
Air Circulator Introduction
• XPOWER Air Circulators are designed to offer
efficient air circulation and ventilation with its
high and long-distance focused airflow.
• It’s perfect for air circulation and ventilation in
janitorial/sanitation jobs, air condition control
and more.
* / ** / *** / **** These functions do not apply all models mentioned in this manual.
(See Page 11: Technical Specification)
Parts Description
(1) Front Grille Cover
(2) Motor
(3) Housing
(4) Capacitor
(5) Housing Handle
(6) Switch Plate*/ Switch
and Timer Plate**
(7) Additional Electrical
Receptacle *** / Timer
Plate ****
(8) Rack Handle
(9) Rubber Washer
(10) Rack
(11) Fan
(12) Rear End Cover
(13) Rear Grille Cover
(14) Power Cord
(Continued)

English - 5
Installing the Rack*
①
①
③
②
②
③
①Fit both rubber washers onto bolts on both sides of unit.
②Align the rack onto the air circulator.
③Fasten the connection with the rack handle.
* For model FC-300 only.
Installation and Operation Guide
Switch Plate
OFF
1
2 3
4
Four Speed Control
OFF 5
1
2 3
4
Five Speed Control
OFF
MAX
LOW
Variable Speed Control
Four Speed Switch ( For model FC-100/FC-200/FC-300 only)
• Turn to “OFF” position to switch the machine OFF. Turn to any speed position to switch
the machine ON.
• Turn clockwise to set the desired speed. There are 4 speeds from: 4, 3, 2, 1. “4” is the
highest speed and “1” is the lowest speed .

English - 6
Installation and Operation Guide (Continued)
Switch Plate (Continued)
Five Speed Switch (For model FC-420 only)
• Turn to “OFF” position to switch the machine OFF. Turn to any speed position to switch
the machine ON.
• Turn clockwise to set the desired speed. There are 5 speeds from: 5, 4, 3, 2, 1. “5” is
the highest speed and “1” is the lowest speed.
Variable Speed Switch (For model FC-250D/FC-250AD only)
• Turn to “OFF” position to switch the machine OFF. Turn clock-wisely to any position
between “MAX” and “LOW” to switch the machine ON.
• You can adjust to any desired speed variably. “MAX” is the higest speed and “LOW” is
the lowest speed.
* For model FC-250AD only.
Additional Electrical Receptacle (Daisy Chain)*
CIRCUIT BREAKER 12A
TOTAL OUTPUT
12 AMPS MAX WITH THIS UNIT OFF
10 AMPS MAX WITH THIS UNIT ON
• Other appliances can be plugged in the
additional electrical receptacles and work
whether the machine is on or off. However,
the total amperage must be lower than the
amperage instructed. Different models may
have varying instructions.
• If the machine or the plugged in appliance
stops working, press the RESET BUTTON to
reset the circuit.

English - 7
Installation and Operation Guide (Continued)
Adjust Operation Position
• The Air Circulator features 360° Rotation. Tilt Air Circulator to desired angle and
screw on rack handles to secure the position.
• Turn clockwise to set timer for minutes count
down to an automatic stop.
• The timer can be set for up to 180 minutes (3
hours).
• When the timer reaches “0” position, the unit
stops working. On “ON” position, it will work
constantly.
Timer Switch*
120
60
0
ON
180
* For model FC-100/FC-200/FC-250D/FC-300/FC-420 only.

English - 8
Installation and Operation Guide (Continued)
Transportation
Lift with Handle
• Lift the Air Circulator with the
handle on the top.
Use without Rack*
• Uninstall the rack and place the
Air Circulator on a level surface.
* For model FC-420 only.
Adjust Operation Position (Continued)

English - 9
User Maintenance Instructions
Frequent maintenance is recommended on this appliance. Failure to follow the
maintenance instructions may cause failure of the appliance and void the warranty.
• When not in use, unplug and store the appliance in a dry and cool indoor place. Make
sure it’s out of reach of children.
• Before performing any maintenance or cleaning, always disconnect the Air Circulator
from its power source.
• Use a damp cloth to wipe the surface of the housing. Do not clean the unit with water
directly.
• Check if the grille covers are clean. Remove dirt or any other objects that could block
the air inlet and air outlet.
Fasten the Rack Handles
• To prevent possible injury, when
you finish using this appliance,
please position the Air Circulator
UPRIGHT.
• Fasten the rack handle to lock the
position of the Air Circulator.
Organize the Power Cord
• Wrap the power cord around the housing.
• Clip the cord to the cord clip on the plug shown above.

English - 10
User Maintenance Instructions (Continued)
Stack Multiple Units
• Stack the Air Circulators on the sides. Align the air
inlets of both Air Circulators.
WARNING
• For model FC-100 / FC-200 Series, DO NOT stack
more than six units of this appliance.
• For model FC-300 / FC-420, DO NOT stack more
than five units of this appliance.
• Stacking function is not secure during
transportation.
!
Troubleshooting Guide
PROBLEM POSSIBLE CAUSE SOLUTION
Air Circulator does
not start
No electricity. Check for power supply.
The power cord is not properly
plugged in.
Remove and reconnect the
power cord.
The circuit breaker on the
additional electrical receptacle
(Daisy chain) jumps.*
Remove all appliance on
the additional electrical
receptacle and press “Reset”.
The timer switch is set to “0”
position.*
Set the timer switch to “ON”
position.
Unit runs but the
speed is abnormal
Air inlet or air outlet is blocked. Remove blockage.
* These functions do not apply to all models mentioned in this manual.
If troubleshooting does not resolve your problem, please contact XPOWER or other
parties authorized by XPOWER for further instructions.

English - 11
Technical Specication
MODEL
NUMBER FC-100 FC-200 FC-250D FC-250AD FC-300 FC-420
Voltage/
Frequency 115 V~60 Hz
Amperage 0.6 A 1.0 A 0.9 A 1.5 A 2.8 A
Motor Power - - 1/4 HP 1/3 HP
Rated
Airflow
1100
CFM 1300 CFM 1560 CFM 2100 CFM 3600 CFM
Speed
Control
4
Speeds Variable Speeds 4 Speeds 5 Speeds
Timer 3 Hours (OFF) N/A 3 Hours (OFF)
Additional
Electrical
Receptacle
N/A Yes N/A
Cord Length 6 ft. / 1.8 m 10 ft. / 3.0 m 15 ft. /
4.5 m
Housing PP ABS
Unit
Dimension
(L) x (W) x
(H)
16.1 x 8.9
x 14.2 in.
/ 41.0 x
22.5 x
36.0 cm
17.3 x 8.9 x 15.4 in. / 44.0 x 22.5 x
39.0 cm
18.6 x
9.4 x
19.2 in.
/ 47.2 x
23.9 x
48.8 cm
21.9 x 9.8
x 22.5 in.
/ 55.6
x 24.9 x
57.1 cm
Unit Weight 9.7 lbs.
/ 4.4 kg 10.1 lbs. / 4.6 kg 10.8 lbs. / 4.9 kg 13.0 lbs. / 5.9 kg 23.4 lbs. / 10.6 kg
Safety
Certification ETL / C-ETL
If your product(s) is not listed above, please visit www.xpower.com for more information.

English - 12
XPOWER Limited Warranty (USA)
1 YEAR LIMITED WARRANTY
XPOWER-branded products purchased in the U.S. from authorized distributors include
a 1-year limited warranty. Contact XPOWER to confirm warranty information about your
product(s).
This limited warranty covers defects in materials and workmanship in your XPOWER-
branded products, purchased in the U.S. ONLY. Local warranty policy (if any) in your
country will cover products purchased outside the U.S.
Items mentioned but not limited to below are not covered by warranty:
(1) Power cord, filters or any other components considered as a “consumable parts” by
XPOWER.
(2) Normal wear and tear.
(3) Problems that result, directly or indirectly, at XPOWER’s sole discretion, from:
(3.1) External causes such as accident, abuse, misuse or problems with electrical power
supply.
(3.2) Disassembling, servicing or modification not authorized by XPOWER.
(3.3) Usage that is not accordant with product instructions stated in Owner’s Manual.
(3.4) Failure to follow the product instructions or lack of necessary maintenance stated
in Owner’s Manual.
Before contacting XPOWER, please try one or more of the following:
(1) Consult this Owner’s Manual and follow the instructions of troubleshooting guide.
(2) Access www.xpower.com for more advice and information that could be helpful to
address your problems.
If you need additional assistance from XPOWER, please:
(1) Email [e-mail].
(2) Call XPOWER U.S. Customer Service Department at 855-855-8868 or other numbers
provided on www.xpower.com.
(3) Visit XPOWER U.S. Head Office at 668 S. 6th Ave., City of Industry, CA 91746 or the
most current address provided on www.xpower.com.
Please also have your original proof of purchase and the serial number(s) of your
product(s) ready when you contact XPOWER.
IMPORTANT:
(1) Please finish the online warranty registration before usage. Visit www.xpower.com/
service-support/warranty-registration.
(2) This Limited Warranty applies with its own timeliness. Contact XPOWER or visit
www.xpower.com for more information.
!

English - 13
If you are instructed to return the unit for service or replacement, please:
(1) Request a RMA (Return-Merchandise-Authorization) number.
(2) Use the original or an equivalent packaging, prepay shipping charges at your own
expense to the address provided by XPOWER, with the RMA number on the shipping
label or the packaging.
(3) Include all the original parts and components.
XPOWER will inspect, assess and advise the repairs needed and applicable cost, if any.
For products under warranty, we will pay to ship the repaired or replaced product(s) to
you if you use an address within the Contiguous United States. Otherwise, we will ship
the product(s) to you at your own expense.
XPOWER Limited Warranty (USA)

English - 14
