Xtreme XR-101 User manual

Page
1
(Photos may vary)
PLEASE BE SAFE WHEN RIDIN
X-Treme TM Electric Scooters
Model: XR-101
Product Handbook

Page
2
PLEASE BE SAFE WHEN RIDING
!ALWAYS WEAR A HELMET AND OBEY ALL LAWS!
BATTERY MAINTENANCE and
CHARGING INSTRUCTIONS
1. You MUST charge completely prior to initial use. (Follow
charging instructions in your Product Handbook)
2. Charge immediately after each use.
3. Charge before storage. You must charge every 30 days if not
in use.
4. Charge the unit for 6-8 hours after the light on the charger turns
green.
5. DO NOT allow this unit to deep discharge the battery.
6. For safety purposes, DO NOT charge for over 12 hours.
7. Turn the unit OFF when not in use.
This PRODUCT IS NOT INTENDED FOR EXTREME or
OFF-ROAD Use! Please take care of your XR-101!
DO NOT JUMP or ABUSE THIS PRODUCT!
DO NOT RIDE IN WET/ICY CONDITIONS!
Failure to follow these instructions will
VOID YOUR WARRANTY!
IMPORTANT
Failure to follow these INSTRUCTIONS will
VOID YOUR WARRANTY!

Page
3
WARNING
This product does not conform to Federal Motor Vehicle Standards and is not
intended for operation on public streets, roads or highways. Serious injury can
result from the unsafe operations of this product. Operator can minimize these
risks by using certain safety equipment such as: safety helmet, goggles, gloves,
elbow and kneepads and appropriate footwear.
DO NOT operate this product in traffic, on wet, frozen, oily or unpaved surfaces.
Avoid uneven surfaces, potholes, surface cracks and obstacles.
DO NOT use a water hose to clean this product.
This product is recommended for riders 3-8 years of age and under 80lbs.
SAFETY GUIDE
An adult should preform charging of the scooter. TO AVOID ELECTRIC
SHOCK, NEVER ALLOW CHILDREN TO HANDLE THE CHARGER OR
ATTEMPT TO PLUG THE BATTERY CHARGER INTO AWALL OUTLET!
Keep children away from the scooter during the charging process.
Do not place the battery near fire or heat.
To avoid damage to the battery, do not use the charger if it has been damaged
in any way.
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Adult supervision during operation is required at all times.
The scooter is designed for flat terrains only. For safety purposes, never
allow children to operate the scooter in hilly areas.
When not in use, ensure the scooter is turned off and stored in an enclosed dry
area away from moisture or rain.
This product is ELECTRIC! DO NOT ride this product in wet conditions,
puddles or rainy weather.
The user of this product assumes ALL risks associated with its use. To
minimize these RISKS, the user must wear safety helmet, goggles, gloves,
elbow and kneepads and appropriate footwear.
IMPORTANT
PLEASE READ THIS BEFORE USING THIS PRODUCT
READ THIS FIRST!

Page
4
SAFETY GUIDE
The recommended age for riding this scooter is 3-8 years old and under 80lbs.
To avoid damage to the motor and footplate, do not overload the scooter.
Never ride with more than one person.
Inspect your scooter thoroughly before each use for loose or missing parts.
Avoid unintentional starts by turning the scooter off while not in use.
To avoid the risk of a short circuit in the electrical parts, do not use your
X-Treme Electric scooter in the rain and never spray or wash off your scooter
with water.
Do not place the battery near fire or heat.
To avoid damage to the battery, do not use the charger if it has been damaged
in any way.
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Brakes are designed to control speed as well as stop the scooter. Practice
braking for proper slowing down and smooth stops.
Maintain your X-Treme XR-101 as recommended in this Product Handbook.
Use only quality replacement parts as recommended by the manufacturer.
Inspect the entire scooter prior to each use. Replace any part that is cracked,
chipped or damaged before use.
*NEVER ALLOW CHILDREN TO OPERATE THE SCOOTER WITHOUT ADULT
SUPERVISION.
Contact your dealer or X-Treme (www.x-tremescooters.com/support/)
if you need further assistance
QUICK
REFERENCE
SAFETY GUIDE

Page
5
TABLE OF CONTENTS
IMPORTANT
INFORMATION…………………………………….………………………...……2-3
QUICK REFERENCE……………………………………………………………….4
TABLE OF CONTENTS……………………………….…………….………………5
GETTING TO KNOW YOUR X-TREME XR-101………………..………...……..6
PACKAGE CONTENTS…………………………………………………………….7
GETTING STARTED………………..……………………………..………………..7
ASSEMBLY………………………………………………………………….…..…7-9
CHARGING……………………………………………………………..………….10
OPERATING INSTRUCTIONS…………………………………………………….9
IMPORTANT SAFETY GUILDINES..…………………………….………………10
MAINTENANCE…………………………………………………………………….11
OTHER QUESTIONS….…………………………………………………………..11
GENERAL INFORMATION/TECH SUPPORT………………………………….12

Page
6
GETTING TO KNOW YOUR X-TREME XR-101
(Photo’s may vary)
Recommended Age 3-8yrs Speed 1.5mph – 3mph
Maximum Weight 80lbs Battery 6V 10AH
Assembled Size 44 x 26.5 x 23 Charge Time 6-8 hours
Acceleration Foot Pedal Charge AC110V
Fuse 20A Glass Speed Dual speed switch
Direction Forward/Reverse Sounds Yes
Remote Control Yes

Page
7
PACKAGE CONTENTS
Your X-Treme XR-101 comes with the following items in the box. Please locate
all of the following:
1. Car Body, 1pc
2. Front Windshield, 1pc
3. Steering Wheel, 1pc
4. Seat, 1pc
5. Wheels, 4pcs
6. Battery Charger, 1pc
7. Wheel Cover, 4pcs
8. Remote Control, 1 pc
9. Gearbox with motor, 1pc
10. Gearbox Hub, 1pc
11. User Manual, 1pc
12. AABatteries, 2pcs
13. Screws/Washer
GETTING STARTED
Please read and understand these instructions and the OPERATING
PROCEDURES section, prior to starting or riding your XR-101
KEEP CHILDREN AWAY DURING ASSEMBLY. SOME SMALL
PARTS POSE A CHOKING HAZARD. DISCARD ALL PLASTIC
COVERINGS AND BAGS.
Assembly
1. Carefully remove the XR-101 from the box.
2. Locate the enclosed front windshield and
align it with the corresponding holes on the
front of the car. Insert into place and
secure using the two enclosed screws.
Tighten into place from the underside of the
car.
3. Install the rear spoiler to the rear of the car
by first removing the two bolts from the car
and then using them to secure the spoiler in
place.
4. First ensuring that the battery bracket is
secure to prevent the battery from falling
out under the seat area, turn the car on its
side to assemble the rear axle, gearbox
and wheels.
a) Attach one washer to the rear axle
and insert the axle into the main car
body position left to right.
b) Attach three more washers to the
axle.
c) Assemble gearbox/motor and all
appropriate connections to the axle
being sure the gearbox is mounted in
the correct position to move the
wheels when completed.

Page
8
d) Attach wheels and appropriate
washers finishing with the
decorative wheel covers. Secure
each end of the axle with the
enclosed washers and nuts.
Continue with the Installation of Front Wheels
by attaching one washer to the fr
ont axle.
Install the wheel in the correct position ending
with the decorative ring. Repeat for opposite
side and secure the wheels with the enclosed
washers and nuts.
Attach the steering wheel as shown below.
1. First remove the set bolt in the steering
wheel.
2. Attach the steering wheel to the shaft and
re-insert the set bolt.

Page
9
Your XR-101 is now complete and ready for use.
Operation Instructions
*Be sure all assembly is complete before riding.
*Disconnect charger from scooter and store properly.
Your scooter is operated using a foot push button. To ride the scooter, simply
set on the scooter, select the desired direction and turn the speed switch to the
desired speed. Use your right foot; push the foot button located on the right
footplate. To stop the scooter, simply release the foot button.
1. Locate the Power On/Power Off switch located on the dash. Select
Power On.
2. Locate the Pedal/Remote switch located on the dash. Select the
desired mode.
a. When in the remote mode, using the enclosed remote control
operates the car.
3. Locate the forward/reverse gearshift located to the right of the dash.
Select the desired direction, forward or reverse.
4. To accelerate forward, use your right foot to press the foot button on
the right footplate.
5. To move in reverse, stop the scooter; shift into neutral (middle
position on gearshift) then pull the gearshift into the reverse position.
Not following this step correctly can damage the gear box/motor.
Finally, attach the motor/gearbox connection
and install the seat.
1. Locate the motor/gearbox connector
that was inserted into the under-seat
compartment during motor/gearbox
installation.
2. Connect the motor/gearbox to the white
connector coming from the battery.
Next, remove the two gray seat bolts from the
seat area, install seat to the desired leg position
and re-install the seat bolts, tightening securely.

Page
10
6. To stop, simply release the foot button.
7. To park the car, keep the slow/fast switch in the middle (neutral)
position.
Charging Instructions
***WARNING*** An adult should perform charging of the scooter. TO AVOID
ELECTRIC SHOCK, NEVER ALLOW CHILDREN TO HANDLE THE
CHARGER OR ATTEMPT TO PLUG THE BATTERY CHARGER INTO A
WALL OUTLET!
1. Locate the enclosed battery charger. Plug the charger into a wall
outlet.
2. Locate the charger socket on the scooter.
3. Plug the battery charger into the socket on the scooter. Depending on
the charge remaining in the battery, charging time will vary. Normal
charging time will be 6-8 hours.
Do not allow the charger to charge the batteries for more than 20 hours as
this may damage the batteries.
IMPORTANT SAFETY GUIDELINES
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Adult supervision during operation is required at all times.
The scooter is designed for flat terrains only. For safety purposes,
never allow children to operate the scooter in hilly areas.
When not in use, ensure the scooter is turned off and stored in an
enclosed dry area away from moisture or rain.
This product is ELECTRIC! DO NOT ride this product in wet
conditions, puddles or rainy weather.
You MUST charge completely prior to initial use.
Charge immediately after each use, before prolonged storage and at
least every 30 days if not used for at least 6-8 hours. DO NOT allow
this unit to deep discharge the battery
DO NOT charge the scooter for more than 20 hours as this may
damage the batteries.
Keep children away from the scooter during the charging process.
Do not place batteries near fire or heat.
The user of this product assumes ALL risks associated with its use. To
minimize these RISKS, the user must wear safety helmet, goggles,
gloves, elbow and kneepads and appropriate footwear.

Page
11
MAINTENANCE SCHEDULE
Proper care of your X-Treme XR-101 will insure optimal performance and
longer life span. The following are a few maintenance suggestions that will
keep your X-Treme XR-101 running in top condition:
Daily Maintenance
Perform each time you ride your XR-101
Clean the exterior of the unit with a soft, damp rag.
Check that all nuts and bolts are securely tightened.
Check battery charger for any frayed/cut wires.
OTHER QUESTIONS
For additional questions, service instructions, further information and important
phone numbers, please go to the X-Treme website at www.x-tremescooters.com
Thank you for purchasing an X-Treme XR-101 and please tell your friends how
much fun you’re having on the X-Treme XR-101

Page
12
For General Information or Parts Visit
www.x-tremescooters.com
For Technical Support or Assistance Visit
www.x-tremescooters.com/support/
