Yaesu FTM-400DE User manual

TOP SIDE
Switch to the operating band by touching the frequency
display on the screen, or
pressing the [DIAL] knob
on the right side of the
operating band.
Tune in the frequency to be saved in the memory and press
the key for one second or longer on the frequency
display screen.
Touch on the screen for one second or longer to
display the memory list.
Press the [DIAL] knob or touch the frequency display on
the screen on the operating side and the MHz digits will
blink. The frequency can then be adjusted in 1 MHz steps
for a few seconds.
Press the [DIAL] knob for one second or longer to display
only the MHz digits. The frequency can then be adjusted in
5 MHz steps for a few seconds.
An empty memory channel will
be selected and displayed
automatically.
To write the desired frequency to
the selected memory channel
number, press the [DIAL] knob
at the top right of the screen or
touch the screen directly to
select the memory channel.
When the key is pressed,
memory writing will end and the
memory channel and frequency
will appear in the display.
Press the key on the frequency display screen. The
function keys will be displayed under the operating band.
Touch or on the screen to switch the display and
select the desired function.
The band scope switches on or off each time is
touched on the screen.
The display bandwidth of the band scope is either ±25
frequency steps (for wideband) or ±12 frequency steps (for
narrowband).
Touch the screen, or turn the [DIAL] knob at the top right
of the screen to select the memory channel.
After entering the name on the character input screen, press
the key for one second or longer, and touch to return
to the memory list. Press the key again to return to the
previous screen.
These keys can be substituted by the four operation keys normally
displayed at the lower part of the frequency display screen (refer
to the operating manual for details).
*is displayed on when the optional voice unit FVS-2 is installed.
The function key will disappear and the display returns to the
previous screen when key is pressed again.
Normally use the auto mode (AMS).
Switch the Band A mode manually by pressing the key.
Press the key for one
second or longer and then
touch in the SETUP
MENU screen.
Touch on the screen and
follow the same process as the input
procedure to change the call sign or
name (moving the cursor to the left
end using and and touching
will return the display to the
previous screen without the change
being reflected). Press the key
to return to the frequency screen.
After entering the call sign or name,
by touching the characters on the
screen, or turning and pressing the
[DIAL] knob at the top right of
the screen, touch on the screen
to confirm and enter the call sign.
Using the AMS (Automatic Mode Select) function, the transceiver
can switch its communication mode automatically to match the
received signal. This is very convenient because there is no need to
pay attention to the communication mode of the partner. Turn on the
AMS function during normal operation. When the AMS function is
active, a bar will be displayed on top of the mode (Example: ).
In the AMS mode, transmission and reception is carried out using
the normal DN mode. However, when transmitting after receiving in
other modes, the mode last received will be used. To transmit using
the normal DN mode, touch the key and set the AMS function
again. When operating using the digital fixed mode ( / ), try to be
aware of the FM signal status and do not transmit when there is a
possibility of interfering with the FM signals on the channel.
FTM-400DR/DE C4FM
Quick Guide
VFO
mode
Memory
mode
Using the band scope
Saving to a memory channel
Assign a name to the memory
Switching the operating band
108 to 137MHz (air band)
137 to 174MHz (144MHz band)
174 to 400MHz
400 to 480MHz (430MHz band)
480 to 999.99MHz
SKIP/SEL
OF F
D W
Tx PWR
H I
SCAN REV
F W DBACK
FW D
BACK
BEACON
BACK F W D
S.LIST
MSG
LO G
HO ME
BEACON
TX
BACK F W D
REC
PLAY T RACK
AL L
PLAY STOP
CLR VOICE
DWN UP
1
2
3
4
56789
10 11
Microphone
aperture
PTT
Volume knobs
Band A (digital/analog)
Transmit band; white characters
Band B (analog)
Sub-band; gray characters
Dial knobs for frequency,
memory channel and squelch setting
5 Band A communication mode
switch / WIRES-X key
1 Power switch / Lock key
4 GM operation key
2 DISP switch / SET mode key
6
VFO / memory mode switch-over key
Memory edit key
7 SQL key (touch the key then adjust using
the DIAL knob)
8 Mute key
3
Function key / MW key
9 Band scope key
10 DATA terminal
11 microSD memory card slot
ENT
Reception frequency bands
of Bands A & B
NORMAL WIDE
RX COVERAGE settings
(Default)
O
O
O
O
O
O
O
-
-
-

MW
F
MW
F
MW
F
MW
F
MW
F
Displaying the function keys
SCOPE
5MHz
steps





Input / change call sign or name
ENT
CALLSIGN
SETUP
DISP
BACK












MW
F
MW
F
M/V



MW
F
MW
F



Press for one
second or longer
Selecting the communication mode
Analog
Digital
High-quality voice
Auto

Automatic mode operation using the AMS function
SETUP
DISP
CHANGE
C4FM FDMA Digital basic mode.
High-quality voice communication mode using the full
12.5 kHz bandwidth.
High-speed data communication mode that uses the full
12.5 kHz bandwidth for data communication. The mode
automatically switches to this mode for picture
communication.
Conventional FM mode that uses the 25 kHz FM mode.
:
:
:
:
Enter a call sign or name when
using the FTM-400DR/DE for
the first time after purchase, or
after a factory reset is carried
out.
The call sign or name entered
can be changed any time.
Digital communication between fellow C4FM digital
amateur transceivers and also communication with FM
amateur transceivers are possible.
Frequency operations
EH034M551

communication (digital)
Panel key Touch key
BACK F W D
M/V MUTE
SCOPE
SQL
NOISE
SQL DTMF
Touch the blinking [CALLSIGN] on
the screen to begin inputting the call
sign (the display will switch to the
character input screen automatically
if there are no operations for about 3
seconds).

DOWN SIDE
Press the [DIAL] knob of the
sub-band.
Press the key and touch on the screen to display
the message and picture list (the micro-SD card must be
inserted).
Touch to switch between the lists. The contents can be
checked and new messages can be created, sent, replied
to and forwarded.
*Show whether there is any
ACK (acknowledgement) from
the destination station in the
transmission results when the
address is specified.
Press the key and will appear temporarily
on the display, indicating the keys and dial are locked.
Press the key again and will appear
temporarily on the display indicating the keys and dial
are unlocked.
To return to the frequency display during setting, press
the key for one second or longer, or press the
microphone [PTT] while in the set-up menu.
*Touch [RESET/CLONE] in the set-up menu, and then
run [1 FACTORY RESET] in the next screen to return
to the default factory settings. The settings registered
at a certain point in time under [2 PRESET] can be
recalled using [3 RECALL PRESET].
Touch the function key to change the transmit power
The GM function will be temporarily
stopped and operation will be on
Band B. Upon pressing the
[DIAL] knob of Band A after the sub-band operation, the GM function
will resume operation.
Group members within and outside the sphere of
communication can be shown in different colors.
Information such as the distance and position can be
displayed.
Messages and pictures can also be sent and received.
The member from which new messages are received
is also displayed in “ ”.
Tune Band A to the GM operating frequency and
press the key to display “ALL” and commence GM
operation. The frequency cannot be changed when
GM is active. To change the frequency, press the
key to cancel GM operation.
The GM function can also be used among friends only
(refer to the GM operating manual for details).
The call sign and position information of a partner
station can be displayed when receiving a C4FM
digital signal.
Press the key to display the compass screen.
When the received signal contains position
information, the “station name and time of receipt”,
and the “direction” and “distance” to the transmitter
location will be displayed.
Press the key to return to the frequency display
screen.
During transmissions, movements of the partner
station or your own station will be updated in real time
in the display.
Message sending position, picture taking position,
APRS beacon position information
*The display can be switched between “Heading Up” and
“North Up” by touching the screen close to the compass
center.
Displaying the direction and distance of a
partner station on the compass screen
Returning to the frequency display screen
Registering the departure point
Returning to the departure point
Sending pictures
Creating and sending
new messages
Checking messages received
Forwarding messages received
Replying to messages received
Taking snapshots with the optional camera attached to
the speaker mike MH-85A11U
Receiving pictures
SETUP
DISP
SETUP
DISP
YR
Station outside the communication range
(gray)
Finding the call sign and position of a partner station Registering the departure point and returning to that position Using the GM (Group Monitor) function When operating the sub-band with the GM function active Taking pictures with the microphone camera and
sending and receiving pictures
SETUP
DISP
Press the key to display the compass screen.
Touch on the screen to display your current
location.
Upon arrival at the registered point, the triangular
arrow will turn into a green aiming mark.
Press the [D-TX] key on the microphone with the built-in
camera to send the latest picture taken.
Press [PTT] to stop the transmission (it may take a while for
the transmission to stop).
After appearing for 10 seconds, the picture taken will be
saved on the micro-SD card in JPEG format.
You can check and retake the picture as many times as you
want.
Point the lens at the object to
be captured and press the
shutter button.
(Maintain a focal distance of at least
50 cm from the object to be captured
in order to take clear pictures)
Touch the partner station and
press the key to display the
compass screen and position
information of the partner
station. Press the key again
to return to the screen in the
figure on the right.
Station within the
communication range
(green)
* Remains even when the station moves
outside the communication range
When picture reception starts with the AMS function active,
“DATA RX” will appear and then “>>>” representing the
progress status will appear.
The received picture will be shown for 10 seconds on the
screen, after which the display returns to the previous screen.
To view a received picture, press the key followed by
on the screen. Touch to display the picture list and
then select the desired picture from the list.
Touch on the screen.
Touch one of the blinking keys , or that you
want to register.
The current location will be registered in the touched
key.
SETUP
DISP
Press the key to display the compass screen.
Touch , or where the return point was
registered.
The distance and a triangular arrow showing the
direction from the current location to the registration
point will be displayed.
SETUP
DISP
MY
L
L
L 
L 
MEMORY
forwarding button
Lens
PTT
Shutter
button
MW
F
Sending and receiving messages
LO G
Displaying the “LOG” (MSG / PICT list)
With
ACK
w/o
ACK
When in doubt during operation set-up
SETUP
DISP
Other positions may be viewed using
* Default setting
320 *
240 px
NORMAL picture
quality (transmission
time about 30 seconds)
Changing the transmit power
Tx PWR
H I
Tx PW R
H I
Tx PWR
M D
Tx PWR
L O
50W20W5WFTM-400DR/DE
 
Locking the dial and keys
LOCK
LOCK
SETUP
DISP
SETUP
DISP
MW
F
LO G
