Yaesu FT-1807M Manual

Introduction
This manual provides technical information necessary for servicing the FT-1807M FM Transceiver.
Servicing this equipment requires expertise in handling surface-mount chip components. Attempts by non-
qualified persons to service this equipment may result in permanent damage not covered by the warranty,
and may be illegal in some countries.
Two PCB layout diagrams are provided for each double-sided circuit board in the Transceiver. Each side of is
referred to by the type of the majority of components installed on that side (“leaded” or “chip-only”). In most
cases one side has only chip components, and the other has either a mixture of both chip and leaded compo-
nents (trimmers, coils, electrolytic capacitors, ICs, etc.), or leaded components only.
While we believe the technical information in this manual to be correct, VERTEX STANDARD assumes no
liability for damage that may occur as a result of typographical or other errors that may be present. Your
cooperation in pointing out any inconsistencies in the technical information would be appreciated.
©2006 VERTEX STANDARD CO., LTD. EH023U90A
Technical Supplement
Specifications ......................................................2
Exploded View & Miscellaneous Parts............3
Block Diagram....................................................5
Connection Diagram..........................................6
Circuit Description.............................................7
Alignment............................................................9
Contents
Board Unit ( Schematics, Layouts & Parts )
MAIN Unit Circuit Diagram .................................13
MAIN Unit Parts Layout .......................................15
MAIN Unit Parts List ............................................17
CNTL Unit Circuit Diagram..................................27
CNTL Parts Layout ...............................................28
CNTL Parts List ....................................................29
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
FM TRANSCEIVER
FT-1807M
Important Note
This transceiver was assembled using Pb (lead) free solder, based on the RoHS specification.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-0.5Cu) should be used for repairs performed on
this apparatus. The solder stated above utilizes the alloy composition required for compliance with the
lead-free specification, and any solder with the above alloy composition may be used.

2
Specifications
General
Frequency Range: Tx 400 - 470 MHz
Rx 400 - 470 MHz
Channel Step: 5/10/12.5/15/20/25/50/100 kHz
Standard Repeater Shift: ±600 kHz
Frequency Stability: Better than ±5 ppm (–20 °C to +60 °C)
Modes of Emission: F2D/F2A/F3E
Antenna Impedance: 50 Ohms, unbalanced
Supply voltage: 13.8 V DC ±15%, negative ground
Current Consumption (typical): Rx: less than 0.7 A, less than 0.3 A (squelched)
Tx: 10 A (50 W) /7 A (25 W) /5 A (10 W) /4 A (5 W)
Operating Temperature Range: –20° C to +60° C
Case Size (WxHxD): 140 x 40 x 146 mm (w/o knobs)
Weight (Approx.): 1.2 kg
Transmitter
Output Power: 50 W/25 W/10 W/5 W
Modulation Type: Variable Reactance
Maximum Deviation: ±5 kHz (Wide)/±2.5 kHz (Narrow)
Spurious Radiation: Better than –60 dB
Microphone Impedance: 2 k-Ohms
Receiver
Circuit Type: Double Conversion Superheterodyne
Ifs: 47.25 MHz & 450 kHz
Sensitivity (for 12dB SINAD): Better than 0.2 µV
Selectivity (–6/–60dB): 12 kHz/28 kHz (Wide)
9 kHz/22 kHz (Narrow)
IF Rejection: Better than 70 dB
Image Rejection: Better than 70 dB
Maximum AF Output: 3 W into 4 Ohms @10 % THD
Specifications subject to change without notice or obligation. Specifications guaranteed only within Amateur band.
Frequency ranges and functions will vary according to transceiver version; check with your dealer.

3
Exploded View & Miscellaneous Parts
g
c
d
e
f
g
g
d
d
d
c
c
c
f
f
f
f
f
f
f
f
e
e
e
e
e
e
e
e
e
e
M4090178
SPEAKER
Non-designated parts are available only as
part of a designated assembly.
S8002063
CAP-SP
RA0753600
FRONT PANEL
RA0753800
RUBBER KNOB
G6090169
LCD
RA0754500
INTER CONNECTOR
RA0754600
DIFFUSER
CNTL UNIT
MAIN UNIT
RA0754400
GROUND PLATE
RA0753400
CHASSIS
RA0754200
ENCODER KNOB
RA0754100
KNOB (VOL/CQL)
RA0754300
REFLECTOR
P1091172
CONNECTOR
G1094344
RA55H4047M
T9206876 (FT-1807M)
T9206955 (FT-1807E)
WIRE ASSY
CP8579001
CASE ASSY
w/SP NET: S8002087
DESCRIPTION
MICROPHONE (MH-48A6J)
DC CABLE (FT-1807M)
DC CABLE (FT-1807E)
SPARE FUSE (15 A: FT-1807M)
SPARE FUSE (15 A: FT-1807E)
BRACKET (MMB-36)
SCREW SET
VXSTD P/N
AAA43X001
T9021715
T9022815
Q0000081
Q0000075
D6000055
CB0297000
ACCESSORIES
REF.
c
d
e
f
g
QTY.
4
4
11
9
3
DESCRIPTION
SEMS SCREW ASM3X10NI
TAPTITE SCREW M2X12NI
TAPTITE SCREW M3X8NI
TAPTITE SCREW M2.6X6B
HEXA SOCKET BOLT M3X20B
VXSTD P/N
U03310002
U24112002
U24308002
U36206007
U51320007
T9207248
WIRE ASSY
S8002118 (2 pcs)
CUSHION
T9206438A
WIRE ASSY

4
Note

5
Block Diagram

6
Connection Diagram

7
Circuit Description
Receive Signal Path
Incoming RF signal is from the antenna jack is deliv-
ered to the Main Unit and passed through the low-
pass filter network consisting capacitors C1213,
C1236, C1239, & C1238 and coils L1017, L1018, &
L1019, antenna switching diode D1020 and D1028
(both RLS135), delivery to the RF amplifier Q1045
(3SK296ZQ). The amplified RF signal is passed
through the another varactor-tuned band-pass filter
consisting of capacitors C1198, C1199, C1200, C1290,
C1218, C1249, C1251, C1219, C1248, C1221 & C1268,
coils L1012, L1015, & L1026, and diodes D1017,
D1021 and D1025 (both HVC350B). The amplified
RF signal is passed through the another varactor-
tuned band-pass filter consisting of capacitors C1198,
1199, 1200, & 1218, coils L1012 and L1015, and di-
odes D1017 and D1021 (both HVC350B), then ap-
plied to the 1st mixer Q1037 (3SK296ZQ) along with
the first local signal from the PLL circuit.
The first local signal is generated between 352.75
MHz and 422.75 MHz by the VCO, which consists
of Q1009 (2SC5374) and varactor diode D1002
(HVC355B) according to the receiving frequency.
IF and Audio Circuits
The 47.25 MHz first IF signal is applied to the mono-
lithic crystal filters XF1001 and XF1002 which strip
away unwanted mixer products, and the IF signal is
applied to the first IF amplifier Q1032 (2SC4400).
The amplified first IF signal is then delivered to the
FM IF subsystem IC Q1028 (NJM2591V), which con-
tains the second mixer, limiter amplifier, noise am-
plifier, and FM detector.
The 46.8 MHz second local signal which is made from
quadrupled 11.7 MHz crystal X1001 produces the 450
kHz second IF signal when mixed with first IF sig-
nal within Q1028 (NJM2591V).
The 450 kHz second IF signal is applied to the ce-
ramic filter CF1001 (for Narrow FM) or CF1002 (for
Wide FM) which strip away unwanted mixer prod-
ucts to the ceramic discriminator CD1001 which re-
moves any amplitude variations in the 450 kHz IF
signal before detection of speech.
The detected audio from the Q1028 (NJM2591V)
passes through the de-emphasis circuit consisting of
resistors R1082 & R1113, and capacitors C1120 &
C1122, to the audio mute gate Q1034 (2SJ364).
The audio signal passes through a band-pass filter
consisting of Q1046 and Q1047 (both 2SC4154), and
the audio mute gate Q1039 (2SJ347), to the audio
VR which adjusts the audio sensitivity to compen-
sate for audio level variations. The adjusted audio
signal is delivered to the audio amplifier Q1035
(LA4425A) which provides up to 3 Watts, to the ex-
ternal speaker jack or a 4-Ohm loudspeaker.
Squelch Control
When no carrier received, the noise signal from
Q1028 (NJM2591V) is amplified by Q1051
(2SC4617), and is detected by D1011 and D1013
(both DA221). The resulting DC voltage passes
through the SQL knob to main CPU Q2002
(HD64F2266TF13). While no carrier is received,
main CPU Q2002 (HD64F2266TF13) control Q1048
(CD4094BPWR), thus, audio mute gate Q1034
(2SJ364) and Q1039 (2SJ347) turns “OFF” to dis-
able the audio output from the speaker.
Transmit Signal Path
The speech signal from the microphone is amplified
by Q1049 (LA2902PWR). The amplified speech sig-
nal is subjected to the low-pass filter network Q1049
(LA2902PWR) to deviation controlled by Q1043
(M62364FP).
The adjusted speech signal from Q1043 (M62364FP)
is delivered to VCO Q1009 (2SC5374) which fre-
quency modulates the transmitting VCO made up
of D1004 (HSC277).
The modulated transmit signal passes through buff-
er amplifier Q1010 and Q1023 (both 2SC5374).
The transmit signal applied to the drive amplifier
Q1026 (2SC5226), then finally amplified by power
amplifier module Q1030 (RA55H4047M) up to 50
Watts. The APC circuit controls the Q1030
(RA55H4047M) power amplifier’s gain.
The 50 Watts RF signal passes through low-pass fil-
ter network consisting of Capacitors C1210 and
C1211 and coil L1013, antenna switch D1018 and
D1019 (both XB15A709), and another low-pass fil-
ter network consisting capacitors C1213, C1236, &
C1239, C2038 and coils L1017, L1018, & L1019, and
then deliver to the ANT jack.

8
Circuit Description
TX APC Circuit
A portion of the power amplifier module output is
rectified by D1022 (1SS321), then delivered to APC
Q1038 (LM2904PWR), as a DC voltage which is pro-
portional to the output level of the power amplifier
module.
The APC Q1038 (LM2904PWR) is compared the rec-
tified DC voltage from the power amplifier module
and the reference voltage from the main CPU Q2002
(HD64F2266TF13), to produce a control voltage,
which regulates supply voltage to the power ampli-
fier module Q1030 (RA55H4047M), so as to main-
tain stable output power under varying antenna
loading condition.
PLL
A portion of the output from the VCO Q1009
(2SC5374) passes through the buffer amplifier
Q1010 and Q1017 (both 2SC5374), then delivered
to the programmable divider section of the PLL IC
Q1011 (MB15A01PFV1), which divided according
to the frequency dividing data that is associated with
the setting frequency input from the main CPU
Q2002 (HD64F2266TF13). It is then sent to the phase
comparator section of the PLL IC Q1011
(MB15A01PFV1).
The 11.7 MHz frequency of the reference oscillator
circuit made up of X1001 is divided by the reference
frequency divider section of Q1011 (MB15A01PFV1)
into 2340 or 1872 parts to become 5 kHz or 6.25 kHz
comparative reference frequencies, which are utilized
by the phase comparator section of Q1011
(MB15A01PFV1).
The phase comparator section of Q1011
(MB15A01PFV1) compares the phase between the
frequency-divided oscillation frequency of the VCO
circuit and comparative frequency and its output is
a pulse corresponding to the phase difference. This
pulse is integrated by the charge pump and loop fil-
ter into a control voltage (VCV) to control the oscil-
lation frequency of the VCO Q1009 (2SC5374).

9
Alignment
Introduction
The FT-1807M is carefully aligned at the factory for
the specified performance across the amateur band.
Realignment should therefore not be necessary ex-
cept in the event of a component failure. Only an
authorized Vertex Standard representative should
perform all component replacement and service, or
the warranty policy may be void.
The following procedures cover the adjustments that
are not normally required once the transceiver has
left the factory. However, if damage occurs and some
parts subsequently are replaced, realignment may
be required. If a sudden problem occurs during nor-
mal operation, it is likely due to component failure;
realignment should not be done until after the faulty
component has been replaced.
We recommend that servicing be performed only by
authorized Vertex Standard service technicians who
are experienced with the circuitry and fully equipped
for repair and alignment. If a fault is suspected, con-
tact the dealer from whom the transceiver was pur-
chased for instructions regarding repair. Authorized
Vertex Standard service technicians realign all cir-
cuits and make complete performance checks to en-
sure compliance with factory specifications after re-
placing any faulty components.
Those who do undertake any of the following align-
ments are cautioned to proceed at their own risk.
Problems caused by unauthorized attempts at re-
alignment are not covered by the warranty policy.
Also, Vertex Standard reserves the right to change
circuits and alignment procedures in the interest of
improved performance, without notifying owners.
Under no circumstances should any alignment be
attempted unless the normal function and operation
of the transceiver are clearly understood, the cause
of the malfunction has been clearly pinpointed and
any faulty components replaced, and realignment
determined to be absolutely necessary.
Required Test Equipment
The following test equipment (and familiarity with
its use) is necessary for complete realignment. Cor-
rection of problems caused by misalignment result-
ing from use of improper test equipment is not cov-
ered under the warranty policy. While most steps
do not require all of the equipment listed, the inter-
actions of some adjustments may require that more
complex adjustments be performed afterwards.
Do not attempt to perform only a single step unless
it is clearly isolated electrically from all other steps.
Have all test equipment ready before beginning and,
follow all of the steps in a section in the order pre-
sented.
RF Signal Generator with calibrated output level
at 500 MHz
Deviation Meter (linear detector)
In-line Wattmeter with 5% accuracy at 500 MHz
50-Ohm 100-W RF Dummy Load
8-Ohm AF Dummy Load
Regulated DC Power Supply adjustable from 9 to
16.5 VDC, 15A
Frequency Counter: 0.2-ppm accuracy at 500 MHz
AF Signal Generator
AC Voltmeter
DC Voltmeter: high impedance
UHF Sampling Coupler
SINAD Meter

10
Alignment Preparation & Precautions
A 50-Ohm RF load and in-line wattmeter must be
connected to the antenna jack in all procedures that
call for transmission; alignment is not possible with
an antenna. After completing one step, read the next
step to see if the same test equipment is required. If
not, remove the test equipment (except dummy load
and wattmeter, if connected) before proceeding.
Correct alignment requires that the ambient tempera-
ture be the same as that of the transceiver and test
equipment, and that this temperature be held con-
stant between 20 °C ~ 30 °C. When the transceiver is
brought into the shop from hot or cold air, it should
be allowed some time to come to room temperature
before alignment. Whenever possible, alignments
should be made with oscillator shields and circuit
boards firmly affixed in place. Also, the test equip-
ment must be thoroughly warmed up before begin-
ning.
Note: Signal levels in dB referred to in the alignment
procedure are based on 0dBµ = 0.5µV.
Test Setup
Set up the test equipment as shown below for trans-
ceiver alignment.
Entering the Alignment Mode
Alignment of the FT-1807M is performed using a
front panel software-based procedure. To perform
alignment of the transceiver, it must first be placed
in the “Alignment Mode,” in which the adjustments
will be made and then stored into memory.
To enter the Alignment mode, press and hold in the
[REV(DW)] and [D/MR(MW)] keys while turning the
radio on. Once the radio is on, release these two key.
The transceiver is now in the “Alignment Mode.”
PLL Reference Frequency
Rotate the DIAL knob to set the alignment param-
eter to “435.000 rF435.000 rF
435.000 rF435.000 rF
435.000 rF.”
Press the [D/MR(MW)] key to enable adjustment
of the “PLL Reference Frequency.”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the counter frequency
reading is 435.100 MHz (±200 Hz).
Press the [D/MR(MW)] key.
RF Front-end Tuning
Inject a 435.100 MHz signal at a level of –10 dBµ
(with 1 kHz modulation @±3.5 kHz deviation)
from the RF signal generator.
Rotate the DIAL knob to set the alignment param-
eter to “435.100 tn435.100 tn
435.100 tn435.100 tn
435.100 tn.”
Press the [D/MR(MW)] key to enable adjustment
of the “RF Front-end Tuning.”
Adjust the DIAL knob so that the maximum
SINAD.
Press the [D/MR(MW)] key.
Alignment
TEST EQUIPMENT SETUP
MIC SW2
MIC SW1
GND +8V
MIC INPUT
PTT/CLONE
FT-1807M
Inline
Wattmeter
SINAD MeterDeviation Meter
Frequency
Counter
RF
Signal Generator
AF
Signal Generator
RF
Signal Generator
50-Ohm
Dummy Load
MIC
ANT
EXT SP
RF Sampling
Coupler
DC INPUT

11
Squelch Threshold Level
Inject a 435.100 MHz signal at a level of –14 dBµ
(with 1 kHz modulation @±3.5 kHz deviation)
from the RF signal generator.
Rotate the SQL knob to the 10-o’clock position.
Rotate the DIAL knob to set the alignment param-
eter to “435.100 tL435.100 tL
435.100 tL435.100 tL
435.100 tL.”
Press the [D/MR(MW)] key to enable adjustment
of the “Squelch Threshold Level.”
Press the [D/MR(MW)] key three times.
Press the [D/MR(MW)] key.
S-meter Level (S-1)
Inject a 435.100 MHz signal at a level of –5 dBµ
(with 1 kHz modulation @±3.5 kHz deviation)
from the RF signal generator.
Rotate the DIAL knob to set the alignment param-
eter to “435.100 S1435.100 S1
435.100 S1435.100 S1
435.100 S1.”
Press the [D/MR(MW)] key to enable adjustment
of the “S-meter Level (S-1).”
Press the [D/MR(MW)] key three times.
Press the [D/MR(MW)] key.
S-meter Level (S-9)
Inject a 435.100 MHz signal at a level of +23 dBµ
(with 1 kHz modulation @±3.5 kHz deviation)
from the RF signal generator.
Rotate the DIAL knob to set the alignment param-
eter to “435.100 S9435.100 S9
435.100 S9435.100 S9
435.100 S9.”
Press the [D/MR(MW)] key to enable adjustment
of the “S-meter Level (S-9).”
Press the [D/MR(MW)] key three times.
Press the [D/MR(MW)] key.
TX Power (High)
Rotate the DIAL knob to set the alignment param-
eter to “435.000 HP435.000 HP
435.000 HP435.000 HP
435.000 HP.”
Press the [D/MR(MW)] key to enable adjustment
of the “TX Power (High).”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the RF Power Meter
reading is 50 W (±1.0W).
Press the [D/MR(MW)] key.
TX Power (Low 3)
Rotate the DIAL knob to set the alignment param-
eter to “435.000 L3435.000 L3
435.000 L3435.000 L3
435.000 L3.”
Press the [D/MR(MW)] key to enable adjustment
of the “TX Power (Low 3).”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the RF Power Meter
reading is 25 W (±1.0 W).
Press the [D/MR(MW)] key.
TX Power (Low 2)
Rotate the DIAL knob to set the alignment param-
eter to “435.000 L2435.000 L2
435.000 L2435.000 L2
435.000 L2.”
Press the [D/MR(MW)] key to enable adjustment
of the “TX Power (Low 2).”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the RF Power Meter
reading is 10 W (±0.5 W).
Press the [D/MR(MW)] key.
TX Power (Low 1)
Rotate the DIAL knob to set the alignment param-
eter to “435.000 L1435.000 L1
435.000 L1435.000 L1
435.000 L1.”
Press the [D/MR(MW)] key to enable adjustment
of the “TX Power (Low 1).”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the RF Power Meter
reading is 5 W (±0.5 W).
Press the [D/MR(MW)] key.
TX Deviation
Inject a 1 kHz, 50 mV signal from the Audio Gen-
erator.
Rotate the DIAL knob to set the alignment param-
eter to “435.000 dU435.000 dU
435.000 dU435.000 dU
435.000 dU.”
Press the [D/MR(MW)] key to enable adjustment
of the “TX Deviation.”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the Deviation Meter
reading is 4.2 kHz (±0.1 kHz).
Press the [D/MR(MW)] key.
Alignment

12
CTCSS TX Deviation
Rotate the DIAL knob to set the alignment param-
eter to “435.000 103435.000 103
435.000 103435.000 103
435.000 103.”
Press the [D/MR(MW)] key to enable adjustment
of the “CTCSS TX Deviation.”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the Deviation Meter
reading is 0.6 kHz (±0.05 kHz).
Press the [D/MR(MW)] key.
Alignment
DCS TX Deviation
Rotate the DIAL knob to set the alignment param-
eter to “43.000 dC43.000 dC
43.000 dC43.000 dC
43.000 dC.”
Press the [D/MR(MW)] key to enable adjustment
of the “DCS TX Deviation.”
Press the PTT switch to activate the transmitter,
adjust the DIAL knob so that the Deviation Meter
reading is 0.8 kHz (±0.05 kHz).
Press the [D/MR(MW)] key.
Closing the Alignment mode
Press the [DW(REV)] key to save the new setting and
exit to normal operation.

13
MAIN Unit
Circuit Diagram
1.5 V
(1.5 V)
Ú1
Ú2 Q1043 Pin 2
TX (LOW 1): 0.7 V (2.0 V)
TX (LOW 2): 0.7 V (2.4 V)
TX (LOW 3): 0.7 V (3.1 V)
TX (HIGH): 0.7 V (3.8 V)
Ú1 Q1028
Pin RX TX
1 5.0 V 5.0 V
2 --- ---
3 3.0 V 0 V
4 5.0 V 0.6 V
5 5.0 V 0.5 V
6 5.0 V 0.5 V
7 --- ---
8 0.7 V 0 V
9 1.1 V 0 V
10 5.0 V 0.6 V
11 4.2 V 0.1 V
12 0.6 V 0 V
13 --- ---
14 --- ---
15 0 V 0 V
16 1.0 V 0 V
0 V
(0 V)
1.7 V
(1.7 V)
3.5 V
(3.5 V)
1.0 V
(1.0 V)
0 V
(0.8 V) 2.9 V
(2.9 V)
3.4 V
(3.4 V)
0.6 V
(0.6 V)
0.7 V
(0.7 V)
5.5 V
(5.5 V)
0 V
(6.4 V)
6.3 V
(0.4 V)
0 V
(0.7 V) 0 V
(6.4 V)
0 V
(4.0 V)
0 V
(4.2 V) 0 V
(2.6 V)
0 V
(2.6 V)
0 V
(2.7 V)
0 V
(1.6 V)
0 V
(0.9 V)
0 V
(0 V)
0 V
(0 V)
0 V
(6.7 V)
5.5 V
(0.2 V)
2.2 V
(0.1 V)
5.2 V (0.3 V)
1.0 V (0 V)
2.3 V
(0.7 V)
2.2 V
(0.7 V)
2.1 V
(0.6 V)
1.6 V
(0 V)
2.9 V
(0.1 V)
0.9 V
(0 V)
7.3 V
(0.3 V)
0.7 V
(0.3 V)
6.5 V
(0.3 V)
5.2 V
(0.6 V)
5.0 V
(4.5 V)
2.3 V
(0.1 V)
4.5 V
(0 V)
2.9 V
(0.4 V)
0.1 V (0 V)
4.9 V
(4.9 V)
0 V
(0 V)
0 V
(0 V)
0.6 V
(0.6 V)
0 V
(0 V)
0 V
(0 V)
0 V
(5.0 V)
0 V
(0 V)
2.5 V
(0.8 V)
2.5 V
(0.3 V)
0 V
(0 V)
0 V
(0 V)
7.2 V
(4.5 V) 0 V
(4.6 V)
3.2 V
(0 V)
7.7 V
(0.5 V)
3.2 V
(0.2 V)
0 V
(0 V)
1.4 V
(0.5 V)
0.9 V
(0 V)
3.1 V
(0.5 V)
5.5 V (0.5 V)
2.6 V
(0.4 V) 2.5 V
(0 V)
2.3 V
(2.3 V)
0.6 V (0.5 V)
4.2 V (0.5 V)
4.8 V
(0.2 V)
5.4 V
(0 V)
1.4 V
(0.5 V)
4.8 V
(4.9 V)
0.6 V
(0.6 V)
1.8 V
(1.8 V) 1.9 V
(1.9 V)
1.9 V
(1.9 V)
5.0 V
(5.0 V)
4.8 V
(4.8 V)
3.8 V
(3.8 V)
4.8 V
(4.8 V)
4.6 V
(4.6 V)
0 V
(0 V)
1.5 V
(1.5 V)
0 V
(0 V)
7.9 V
(0.4 V)
2.1 V (0 V)
2.1 V
(0 V)
1.9 V
(0 V)
0 V (0 V) 5.0 V
(5.0 V) 0 V (0 V)
1.9 V
(0 V) 2.2 V
(0 V)
3.4 V
(0 V)
0 V
(8.0 V)
7.8 V
(7.2 V)
7.2 V (8.0 V)
7.9 V
(0.5 V)
0.1 V
(8.0 V)
0.7 V
(0.1 V)
7.8 V
(0.1 V)
5.0 V
(5.0 V)
8.0 V
(8.0 V)
0 V
(0 V)
4.1 V
(4.1 V)
13.8 V
(12.4 V)
0 V (0 V) 5.0 V
(5.0 V) 0 V (0 V)
5.0 V
(5.0 V)
Ú2
2.4 V
(0.7 V)
2.8 V
(2.8 V)
0 V
(0 V)
0 V
(0 V)
0 V
(0 V)
0 V (4.4 V)
1.3 V
(1.3 V)
6.5 V
(6.0 V)
0 V
(0 V)
1.9 V
(1.9 V)
0 V
(0 V)
1.9 V
(1.8 V)
1.9 V
(1.9 V)
2.4 V
(2.4 V)
0.7 V
(0.7 V)
0 V
(4.9 V)
0 V
(5.0 V)
RX : XX
TX : (XX)
Frequency : 430.000 MHz

14
MAIN Unit
Note

15
MAIN Unit
Parts Layout (Side A)
BADCEF
1
2
3
4
5
2SA1774 (FR)
(Q1007) 2SC4154 (E) (Q1033)
2SC4400 (RT4)
(Q1032)
2SC4617 (BR)
(Q1051, 1053)
2SC5226 (R22)
(Q1026)
2SC4915O (Q0)
(Q1054)
2SC5374 (NA)
(Q1009, 1010, 1017,
1023)
DAN235E (M)
(D1010)
CD4094BPWR
(Q1048)
MB15A01PFV1
(Q1011)
NJM2591V
(Q1028)
2SJ562
(Q1008)
3SK296ZQ (ZQ)
(Q1037, 1045)
KIA7808API
(Q1015) LA4425A (Q1035)
RA55H4047M
(Q1030)
DTC144EE (26)
(Q1003, 1004, 1014)
DA221 (26)
(D1011, 1013, 1016)
2SJ364 (4M)
(Q1055)

16
MAIN Unit
Parts Layout (Side B)
badcef
1
2
3
4
5
2SA1774 (FR)
(Q1024, 2027, 1029)
2SC4154 (E)
(Q1001, 1021, 1046,
1047)
FMMTL718TA
(Q1025)
2SJ364 (4M)
(Q1034, 1036,
1041, 1042)
LM2904PWR
(Q1038, 1044,
1050)
LM2902PWR
(Q1005, 1049)
DTC144EE (26)
(Q1013, 1020, 1022,
1031, 1040)
M62364FP
(Q1043)
S-812C50AUA
(Q1016)
1SS321 (F9)
(D1022)
DAN222 (N)
(D1012, 1014, 1029,
1031)
DA221 (26)
(D1009)
2SJ347 (KS)
(Q1039)

17
PCB with Components CB3539001 FT-1807M
CB3539002 FT-1807E
Printed Circuit Board AH023U000 FR014760C 1-
C 1001 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B e4
C 1002 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B e4
C 1003 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B e3
C 1005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A1
C 1006 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A A1
C 1007 AL.ELECTRO.CAP. 3300uF 16V RE3-16V332MI6# K40129065 1- A B2
C 1008 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50BZ01D K22174265 1- A B5
C 1009 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A B5
C 1010 CHIP CAP. 330pF 50V B GRM188B11H331KD01D K22174803 1- A B5
C 1011 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C5
C 1012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B5
C 1013 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B5
C 1014 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C5
C 1015 CHIP TA.CAP. 0.1uF 20V SKF-1D104M-RP K78130049 1- A C5
C 1016 CHIP TA.CAP. 0.1uF 20V SKF-1D104M-RP K78130049 1- A C5
C 1017 CHIP TA.CAP. 3.3uF 6.3V TESVSP0J335M-8R K78080052 1- A C5
C 1018 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C5
C 1019 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A C4
C 1020 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C5
C 1024 CHIP TA.CAP. 4.7uF 16V TAJA475M016Y K78120079 1- B c4
C 1025 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c4
C 1026 CHIP CAP. 0.0027uF 50V B GRM188B11H272KA01D K22174814 1- B c4
C 1027 CHIP TA.CAP. 22uF 6.3V TAJA226M006Y K78080086 1- B c4
C 1029 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B f2
C 1030 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B2
C 1031 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 1032 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 1033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B4
C 1034 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B4
C 1035 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B5
C 1036 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1- A B4
C 1037 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1- A B4
C 1038 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 1039 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- A C4
C 1040 CHIP CAP. 1.5pF 50V CK GRM1884C1H1R5CZ01D K22174258 1- A B4
C 1041 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 1042 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- A C4
C 1043 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C5
C 1044 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 1045 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 1046 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- A C4
C 1047 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C5
C 1048 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C5
C 1049 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C5
C 1050 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C5
C 1052 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B d4
C 1053 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- B d4
C 1054 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B c4
C 1055 CHIP CAP. 560pF 50V B GRM188B11H561KA01D K22174806 1- B c4
C 1056 AL.ELECTRO.CAP. 100uF 16V RE3-16V101ME3# K40129063 1- A B4
C 1057 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3
C 1059 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e4
C 1060 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e4
C 1061 AL.ELECTRO.CAP. 10uF 16V RE2-16V100ME3# K40129004 1- A B4
C 1062 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e4
C 1063 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C4
C 1064 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3
C 1065 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B4
C 1067 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B3
C 1068 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A D5
C 1069 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A D5
C 1070 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A D5
C 1071 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D5
C 1072 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D5
C 1073 CHIP CAP. 4.7uF 6.3V B JMK107BJ475MA-T K22084803 1- A D5
C 1074 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D5
C 1076 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D5
C 1077 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B d5
C 1078 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- B d5
C 1079 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B d5
C 1080 CHIP CAP. 560pF 25V CH GRM39CH561J25PT K22144201 1- B d5
C 1081 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e3
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR

18
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
C 1082 AL.ELECTRO.CAP. 100uF 16V RC2-16V101MF1# K40129038 1- A B3
C 1083 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d4
C 1084 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 1086 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a5
C 1087 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D5
C 1089 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A F4
C 1090 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a4
C 1091 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 1- A E4
C 1092 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a4
C 1093 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 1- A E4
C 1094 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A E4
C 1096 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A E4
C 1098 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 1- A E4
C 1099 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B d4
C 1101 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e3
C 1102 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e3
C 1103 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e4
C 1104 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e3
C 1105 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B3
C 1106 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 1107 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3
C 1109 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3
C 1110 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 1111 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A F5
C 1112 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a4
C 1113 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F5
C 1114 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A F5
C 1115 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- A F5
C 1116 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A F5
C 1117 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E4
C 1118 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E5
C 1119 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B b4
C 1120 CHIP CAP. 0.033uF 16V R GRM188R11C333KA01D K22124801 1- B a3
C 1121 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B b4
C 1122 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B a3
C 1123 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a3
C 1124 AL.ELECTRO.CAP. 10uF 16V RE2-16V100ME3# K40129004 1- A A2
C 1125 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D5
C 1126 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1127 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1128 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1129 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1130 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A B5
C 1131 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C3
C 1132 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1- A C3
C 1133 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- A C2
C 1134 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D2
C 1135 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C2
C 1136 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E4
C 1138 CHIP CAP. 18pF 50V CH K22174217 1- A E4
C 1139 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B b4
C 1140 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B f1
C 1141 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B f1
C 1142 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f3
C 1143 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B f5
C 1144 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A A3
C 1145 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e5
C 1146 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B f5
C 1147 AL.ELECTRO.CAP. 220uF 16V RE3-16V221MF3# K40129095 1- A A5
C 1148 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- A E5
C 1149 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1150 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1151 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1152 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b5
C 1153 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1154 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1155 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1156 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1157 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A D2
C 1158 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D2
C 1161 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B c3
C 1162 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B c3
C 1163 AL.ELECTRO.CAP. 10uF 16V RE2-16V100ME3# K40129004 1- A D2
C 1164 CHIP TA.CAP. 4.7uF 16V TAJA475M016Y K78120079 1- B b3
C 1165 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3

19
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
C 1166 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A E4
C 1167 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D3
C 1168 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A D4
C 1170 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E4
C 1171 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A D4
C 1173 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b4
C 1174 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A D4
C 1175 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A E4
C 1176 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f5
C 1177 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b5
C 1178 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B b5
C 1179 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1180 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1181 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1182 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1183 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1184 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b5
C 1185 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1186 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1187 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 1188 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A E3
C 1189 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A E3
C 1190 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- A E3
C 1191 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E3
C 1192 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E3
C 1193 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b3
C 1194 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3
C 1196 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A E3
C 1198 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A E4
C 1199 CHIP CAP. 0.75pF 50V CK GRM1884C1HR75BZ01D K22174266 1- A E3
C 1200 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E4
C 1201 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b4
C 1202 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b3
C 1203 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B c4
C 1204 CHIP TA.CAP. 22uF 6.3V TAJA226M006Y K78080086 1- B c4
C 1205 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B b5
C 1206 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B b5
C 1207 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 1- B a5
C 1208 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B b5
C 1209 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B f5
C 1210 CHIP CAP. 3.9pF 500V CH 1206N3R9C501LT K22278204 1- A E2
C 1211 CHIP CAP. 2.2pF 500V CH 1206N2R2C501LT K22278201 1- A E2
C 1212 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A F3
C 1213 CHIP CAP. 2.7pF 500V CH 1206N2R7C501LT K22278202 1- A F2
C 1214 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a3
C 1215 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3
C 1216 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a3
C 1217 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B a3
C 1218 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A E4
C 1219 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50BZ01D K22174265 1- A E4
C 1220 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E4
C 1221 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A E4
C 1223 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F4
C 1224 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A F3
C 1225 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c4
C 1226 CHIP CAP. 0.0056uF 50V B GRM188B11H562KA01D K22174818 1- B b3
C 1227 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b4
C 1228 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c4
C 1230 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- B a5
C 1231 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B a5
C 1232 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a5
C 1233 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B a5
C 1235 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1- A F2
C 1236 CHIP CAP. 3.9pF 500V CH 1206N3R9C501LT K22278204 1- A F2
C 1237 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50BZ01D K22174265 1- A F2
C 1238 CHIP CAP. 1.5pF 500V CH GRM31M5C2H1R5CY21L K22271287 1- A F2
C 1239 CHIP CAP. 3.3pF 500V CH 1206N3R3C501LT K22278203 1- A F2
C 1243 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- B a2
C 1244 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E3
C 1245 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F3
C 1246 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A F4
C 1247 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1- A F3
C 1248 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A E4
C 1249 CHIP CAP. 1pF 50V CK GRM1884C1H1R0BZ01D K22174267 1- A E3
C 1250 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50BZ01D K22174265 1- A F4

20
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
C 1251 CHIP CAP. 1pF 50V CK GRM1884C1H1R0BZ01D K22174267 1- A E3
C 1252 CHIP CAP. 1pF 50V CK GRM1884C1H1R0BZ01D K22174267 1- A F4
C 1253 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3
C 1254 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3
C 1255 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c4
C 1256 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b3
C 1257 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c4
C 1258 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1- B c4
C 1259 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c4
C 1260 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B b5
C 1261 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B a5
C 1262 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- B a5
C 1263 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B b5
C 1265 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A F1
C 1267 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- B a2
C 1268 CHIP CAP. 0.75pF 50V CK GRM1884C1HR75BZ01D K22174266 1- A E4
C 1270 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B b3
C 1273 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B a5
C 1274 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B a5
C 1275 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A D5
C 1276 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B e5
C 1277 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174813 1- A F4
C 1278 CHIP CAP. 0.0056uF 50V B GRM188B11H562KA01D K22174818 1- A F4
C 1279 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A F4
C 1280 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A F4
C 1281 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1282 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 1284 CHIP CAP. 18pF 50V CH K22174217 1- A D5
C 1285 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A D5
C 1290 CHIP CAP. 0.75pF 50V CK GRM1884C1HR75BZ01D K22174266 1- A E3
C 1292 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D5
C 1293 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B d4
C 1294 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1- A F4
C 1295 CHIP CAP. 4.7uF 6.3V B JMK107BJ475MA-T K22084803 1- A D5
CD1001 CERAMIC DISC JTBC450C7 H7901500 1- A F5
CF1001 CERAMIC FILTER LTM450GW H3900573 1- A F5
CF1002 CERAMIC FILTER LTM450FW H3900572 1- A F4
D 1001 DIODE 1SS400 TE61 G2070634 1- B e4
D 1002 DIODE HVC355B TRF-E G2070588 1- A B5
D 1003 SURGE ABSORBER P6KA18 Q9000721 1- A B2
D 1004 DIODE HSC277TRF-E G2070584 1- A B5
D 1005 DIODE HSC277TRF-E G2070584 1- A C5
D 1006 DIODE 1SV325(TPH3) G2070848 1- A D5
D 1007 DIODE HVC350B-TRF-E G2070596 1- A D5
D 1009 DIODE DA221 TL G2070178 1- B d4
D 1010 DIODE DAN235E TL G2070612 1- A B3
D 1011 DIODE DA221 TL G2070178 1- A F4
D 1012 DIODE DAN222 TL G2070174 1- B a4
D 1013 DIODE DA221 TL G2070178 1- A F4
D 1014 DIODE DAN222 TL G2070174 1- B a4
D 1015 DIODE EDZ TE-61 5.1B G2070998 1- B b4
D 1016 DIODE DA221 TL G2070178 1- A E4
D 1017 DIODE HVC350B-TRF-E G2070596 1- A E4
D 1018 DIODE XB15A709A0HR G2070826 1- A F3
D 1019 DIODE XB15A709A0HR G2070826 1- A F3
D 1020 DIODE RLS135 TE-11 G2070128 1- A F3
D 1021 DIODE HVC350B-TRF-E G2070596 1- A E4
D 1022 DIODE 1SS321 TE85R G2070076 1- B a2
D 1025 DIODE HVC350B-TRF-E G2070596 1- A E4
D 1026 DIODE 1SS400 TE61 G2070634 1- A D5
D 1028 DIODE RLS135 TE-11 G2070128 1- A F3
D 1029 DIODE DAN222 TL G2070174 1- B b4
D 1031 DIODE DAN222 TL G2070174 1- B b4
D 1032 DIODE EDZ TE-61 5.1B G2070998 1- A C2
FB1001 FERRITE BEADS SMB304729 L9190094 1- A A1
FB1002 FERRITE BEADS SMB304729 L9190094 1- A B1
FB1003 FERRITE BEADS SMB304729 L9190094 1- A A1
FB1004 FERRITE BEADS SMB304729 L9190094 1- A B1
FB1005 FERRITE BEADS SMB304729 L9190094 1- A B2
FB1006 FERRITE BEADS BK1608HS121-T L9190081 1- B f1
FB1007 FERRITE BEADS BK1608HS121-T L9190081 1- B f1
J 1001 CONNECTOR SC25-02WS P0090621 1- A A3
J 1002 CONNECTOR HSJ0836-0105009 P1091085 1- A A1
J 1003 CONNECTOR 32FLT-SM2-TB(LF)(SN) P1091258 1- A E5
L 1002 CHIP COIL 0.01uH LQW2BHN10NJ03L L1690609 1- A B5
