Yakima FoldClick 2 User manual

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 1/16
FoldClick 2
16.3 kg
=
FoldClick 3
19.0 kg
=
50 kg 33.7 kg 31.0 kg
60 kg 43.7 kg 41.0 kg
70 kg 53.7 kg 51.0 kg
80 kg 63.7 kg 61.0 kg
Max
kg
FoldClick
2
FoldClick
3
MAX 2100 mm
MAX 100 mm (4”)
MAX 30 kg MAX 58 kg
FoldClick 2
FoldClick 3
< 1.8 m
50 mm
®

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 2/16
ITEM COMPONENT FOLDCLICK 2FOLDCLICK 3
1. FoldClick Bike Assembly x1 x1
2. Bike Frame Grabs x2 x3
3. Tow Ball 50 mm x1 x1
4. Number Plate Fasteners x16 x16
5. Number Plate Spacer x4 x4
6. Bike Carrier Key Set x1 x1
KIT CONTENTS
2
1
5
4
6
3
NOTE - FoldClick 3 pictured for illustrative purposes

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 3/16
COMPATIBLE TOW BALLS
INCOMPATIBLE TOW BALLS
Ensure you have
removed the tow
ball cover
Ensure you
have removed
any Shin
Guards
OR
+50 MM ≥
Height from base to center of ball to be 50 mm+
+
75 MM >
AND
75 MM ≤
Tongue width less than 75 mm
65 MM ≥
Height from base to center of ball to be 65 mm+
Distance from center of ball to end of lat
base to be 70 mm+
70 MM ≥
TROUBLESHOOTING
Duo and Multi Ball
tow balls
Quick change style tow balls Tow balls with welded supports
or tabs often interfere with the
plastic covers on the carrier.
Tongue width greater than 75 mm

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 4/16
2
RED
GREEN
Click!
1. 2.
VERTICAL
3
INSTALLATION
1INSTALL SUPPLIED TOW BALL
Install supplied Tow Ball
to your hitch receiver.
Tighten to 200 Nm.
PLACE FOLDER CARRIER
ONTO TOW BALL
Ensure the carrier remains folded
when placing on tow ball.
UNFOLD
CARRIER
Once the carrier
is vertically
positioned on
the tow ball as
pictured, unfold
the carrier
until a “click”
is heard.
NOTE - Ensure
the lock is in
the unlock
position and
the indicator
window is
completely
green.

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 5/16
1.
2. 3.
Click!
Click!
Click!
Click!
Click!
Click!
4
5
Number Plate Spacers must be used
to comply with local regulations.
UNFOLD LIGHTS AND WHEEL TRAYS
Unfold lights and wheel trays until a “click” is heard.
ATTACH NUMBER PLATE
Using the supplied Number Plate Spacers and Fasteners,
secure your number plate to the carrier.
NOTE - Press levers to unfold lights

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 6/16
7 Pin Plug
!
!
6
7
12 V 24 V
TILT CARRIER
Using one foot on the carrier pedal while holding onto the carrier
hoop, press to tilt carrier to gain access to the light plug.
CONNECT LIGHT PLUG
Connect carrier light plug to
your hitch power supply.

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 7/16
Click!
8
9
REPOSITION CARRIER
Holding onto the carrier hoop, return the carrier to its
horizontal position until a “click” is heard.
LOCK CARRIER
Lock the carrier to tow ball using the keys provided.
Use caution when opening
and closing tailgate.

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 8/16
10
1.
2.
MIN 22 mm
MAX 80 mm
3.
ATTACH FRAME GRABS
Press knob of Frame Grabs to expand frame holders (1) and attach to
carrier hoop (2).
Attach frame clamp to your bike frame and rotate knob clockwise to secure (3).

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 9/16
1. 2. 3.
FoldClick 2
FoldClick 3
1.
2.
3.
11
12
MULTI BIKE CONFIGURATION
Load heaviest bikes irst and lock bikes to carrier.
SECURE BIKE WITH WHEEL STRAPS
Secure bikes to carrier using the wheel straps and buckles.

6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 10/16
Recommended maintenance to be performed at least every 12 months.
MAINTENANCE
